GB
Contents
Introduction .................................4
Intended purpose.........................4
General description......................5
Scope of delivery ...........................5
Overview ......................................5
Functional description .....................5
Technical data..............................5
Safety precautions .......................6
Symbols on the implement ...............6
Symbols used in the manual.............7
General notes on safety ..................7
Assembling instructions..............10
Assembling the handle bar.................. 10
Mounting and emptying the
collection bag................................ 10
Operation ..................................10
Setting the working positions ........... 11
Switching on and off ...................... 11
Working with the implement............ 12
Exchanging the cylinder.................. 12
Cleaning, maintenance, storage . 13
General cleaning and maintenance
work............................................. 13
Storage......................................... 13
Disposal and protection of the
environment ..............................13
Spare parts................................13
Trouble shooting ........................ 14
Guarantee .................................15
Repair Service............................16
Service-Center............................16
Importer ....................................16
Translation of the original
EC declaration of conformity ....101
Exploded Drawing ...................105
This device can be used by child-
ren aged 8 and over and by peo-
ple with reduced physical, sensory
or mental capacities or with a lack
of experience or knowledge, if
they are supervised or have been
instructed regarding safe use of the
device and understand the resul-
ting risks. Children are not
permitted to play with the device.
Cleaning and user maintenance
are not to be undertaken by
children without supervision.
Introduction
Congratulations on the purchase of your
new device. With it, you have chosen a
high quality product.
The operating instructions constitute part of
this product. They contain important infor-
mation on safety, use and disposal.
Before using the product, familiarise your-
self with all of the operating and safety
instructions. Use the product only as de-
scribed and for the applications specied.
Keep this manual safely and in the event
that the product is passed on, hand over
all documents to the third party.
Intended purpose
This implement is used:
- As a lawn aerator and to rake leaves,
moss and weeds out of the lawn and
to collect these leaves and plant resi-
dues.
- As a verticuttor to cultivate the grass
sward and thereby regenerate the
lawn.
Any other use that is not specically ap-
proved in these Instructions can result in
damage to the implement and could be a
serious danger to the user.
The implement must only be operated by
adults. Children and people who are not
familiar with these Instructions must not be
allowed to use this implement. Never oper-
ate this implement while it is raining and in
a wet environment.
The owner or operator is responsible for
accidents or harm to people and their
property.

5
GB
The manufacturer cannot be held liable for
damage caused by incorrect operation of
the implement or if it is not used in con-
formity with its intended purpose.
General description
Scope of delivery
Carefully unpack the implement and check
that all the subsequently listed parts are
complete:
•Implement case with verticuttor cylinder
and impact protector
•Aerating cylinder
•Upper handle bar complete with start-
ing lever, power plug, unlocking button
and rmly mounted power cable
•Lower bar
•2 centre bars
•Collection bag
•Cable strain relief
•2 cable clamps
•Mounting accessories:
- 2 Philips screws, 4 screws and 4
wing nuts to fasten the bar
- Spanner to change the cylinders
•Instruction Manual
Ensure during assembly that the
power cable is not squeezed and
that it has sufcient play.
Overview
The most important functional
parts are illustrated on the
cover page.
A
1 Unlocking button
2 Starting lever
3 Upper handle bar
4a+b 4 screws and 4 wing nuts to se-
cure the bar
5 Collection bag
6 Impact protector
7 Lower bar
8 Implement case
9 Setting button
10 2 rear wheels
11 2 wheels
12 Machine cable terminal
13 Spanner
14 Tool holder
15 2 centre bars
16 Machine cable terminal
17 Electric cable
18 Cable strain relief
19 Machine cable
20 Aerator cylinder with sprung
tines
21 Verticutor cylinder with knives
B
22 Fastening screw
C
23 Collection bag rods
E
24 Square receptacle
Functional description
The verticuttor and lawn aerator has two
easily exchangeable work cylinders:
An aerator cylinder made of hard plastic
with vertically rotating sprung tines, and a
verticutor cylinder with vertically mounted
high-grade steel knives.
The implement features a high-quality plas-
tic case with collection bag and a handle
bar with a folding function. Please refer to
the subsequent descriptions for the actual
functions of the individual control elements.
Technical data
Electric Scarier /
Aerator...................... FLV 1200 A1
Motor input .............................. 1200 W
Rated voltage ........... 230-240 V~, 50 Hz
Protection Class ............................... II
Degree of protection.........................IPX4
Rotating speed of the tool (no)
......................................3500 min-1 (r.p.m)
Cylinder width..............................31 cm
Readjustment range for wear...........9 mm

6
GB
Weight ....................................... 9.9 kg
Acoustic pressure level (LpA)
....................... 84 dB (A); KpA= 3 dB (A)
Measured sound power level (LwA)
.......................99 dB (A); KwA= 4 dB (A)
Guaranteed sound power level
............................................ 103 dB (A)
Vibration (an) ..............4 m/s2; K= 2 m/s2
The noise and vibration values were estab-
lished by the standards and stipulations
listed in the Conformity Declaration.
Technical and visual changes can be com-
pleted in the course of further development
without notication. Consequently, all
dimensions, references and details in these
Operating Instructions are without guar-
antee. Consequently legal claims based
on these Operating Instructions cannot be
asserted.
The stated vibration emission value was
measured in accordance with a standard
testing procedure and may be used to com-
pare one power tool to another.
The stated vibration emission value may
also be used for a preliminary exposure
assessment.
Warning: The vibration emission
value may differ during actual use
of the power tool from the stated
value depending on the manner in
which the power tool is used.
Safety precautions aimed at protect-
ing the user should be based on esti-
mated exposure under actual usage
conditions (all parts of the operating
cycle are to be considered, includ-
ing, for example, times during which
the power tool is turned off and
times when the tool is turned on but
is running idle).
Safety precautions
This section covers the basic safety instruc-
tions when working with this implement.
Symbols on the implement
WARNING!
These Instructions must be read!
Danger of injury due to ung-out
material! Keep bystanders well
away from the implement.
Danger of electric shock
if the power cable is dam-
aged! Always ensure that
the power cable is kept well
away from the implement
and its cutting tools!
Wear eye and ear protection.
CAUTION – Sharp tools: Ensure
that the hands and feet are kept
well away from the cutting tools.
The cutting cylinder continues to
rotate briey after the motor has
been switched off!
Always disconnect the plug from
the mains prior to maintenance
work or if the power cable is
damaged!
Caution with steps! Turn off
the power when the implement
is to be carried across steps!
Noise level ratings LWA in dB(A).
Protection Class II

7
GB
Electrically powered implements
must not be disposed of with the
domestic waste
Remove any soil residue from the springs
of the impact protection cover and/or the
housing to ensure that the cover closes
correctly. When operating without the coll-
ection basket, the impact protection cover
must be completely closed.
Symbols used in the manual
Warning symbols with in-
formation on damage and
injury prevention.
Instruction symbols (the instruction is
explained at the place of the excla-
mation mark) with information on
preventing damage.
Help symbols with information on
improving tool handling.
General notes on safety
This implement can cause serious
injuries if it is not properly used.
Please read these Operating In-
structions carefully and familiarize
yourself with all the control elements
before operating this implement.
Keep these Operating Instructions
in a readily accessible place so that
this information is always at your
disposal.
Operating the implement:
WARNING! The implement can
cause serious injuries.
How to a avoid accidents and inju-
ries:
Preparations:
•Never allow children and people who
are not familiar with these Operating
Instructions to use the implement. Local
regulations may stipulate a minimum
age for operators.
•Never start up the implement while
other people, but especially children
and domestic pets, are in the vicinity.
•Check the area on which the imple-
ment is to be used. Remove all stones,
sticks, wire and other foreign bodies
that could be caught up and ung out.
Never use the implement to level out
uneven patches.
•Always wear appropriate protective
work clothes and rm shoes with non-
slip soles, strong long trousers, ear
defenders and goggles. Never operate
the implement while bare footed or
when wearing open sandals.
•Never operate the implement if it is
damaged, incomplete or has been
modied without the consent of the
manufacturer. Never work with dam-
aged or missing protective devices
(e.g. starting lever, unlocking knob,
impact protector).
•Never disengage protective devices
(e.g. by tying the starting lever).
• Children should be supervised to en-
sure that they do not play with the ap-
pliance.
• Before starting the equipment, ensure
that no objects or branches are pushed
into the blade opening, that the equip-
ment is standing stably and that the
workspace is tidy and not blocked.
Check the condition of your extension
cable and the connecting cable of your
equipment. Use the necessary protec-
tive equipment.

8
GB
• If your equipment vibrates or emits
unusual noises when switched on,
disconnect the plug from the socket
and check the cutting cylinder. Ensure
that no remains of chopped matter
are blocking the cutting cylinder or
jammed between the blades. If you
nd no problems, return the equipment
to a customer service centre.
• If the blades no longer cut correctly
or if the motor is overloaded, check
all the parts of your equipment and
replace the worn parts. If a more ex-
tensive repair is required, contact a
customer service centre.
Use:
•CAUTION – A very sharp tool. Avoid
cutting your ngers or toes. While
working always keep your feet and
ngers well away from the cutting cyl-
inder and the ejector opening. There is
the danger of serious injury!
•Do not operate the implement while it
is raining, in poor weather conditions
and when the surrounding area and
lawn are wet. Operate the implement
only during daylight hours or with
bright lighting.
•Do not operate the implement if you
are tired or are lacking in concentra-
tion and after having drunk alcohol or
taken medicine. Always take a work
break in due time. Approach the work
with common sense.
•Familiarize yourself with the terrain
and remain focused on the potential
hazards that you could miss on ac-
count of the motor noise.
•Always maintain a secure footing
while working, especially on a sloping
terrain. Always work across slopes -
never up and down! Be particularly
careful when changing the travelling
direction. Do not work on very steep
slopes.
•Always guide the implement at a
walking pace with both hands on the
handle. Be especially careful when you
turn the implement around or draw it
towards you. Danger of stumbling!
•Start or actuate the starting lever with
care and in conformity with the direc-
tions in these Instructions.
•Do not tilt the implement when start-
ing, other than it has to be lifted. In
this case tilt the implement only to the
extent that is absolutely necessary and
always lift the implement on the side
that is opposite to the operator.
•Never operate the implement without
the attached collection bag or impact
protector. Danger of injury! Always
keep well away from the ejector open-
ing.
•Do not operate the implement in the vicin-
ity of inammable liquids or gases as this
could give rise to the danger of a re or
explosion.
Work intervals:
•After the implement has been turned
off, the cutting cylinder will continue to
rotate for a few seconds. Keep hands
and feet well away.
•Only remove plant parts when the
implement is standing completely still.
Ensure that the grass ejector opening is
clean and free.
•Switch off the power when the imple-
ment is to be transported, lifted or tilt-
ed and when traversing other surfaces
than grass.
•Never leave the implement unattended
at the place of work.
•Always switch off the implement and
disconnect the power plug:-
- Whenever you leave the implement
- Before you clean the ejector open-
ing or unblock or unclog the imple-
ment
- When the implement is not being
used

9
GB
- During all maintenance and clean-
ing work
- When the power cable is damaged
or has become tangled
- When the implement hits an obstruc-
tion during work or when unusual
vibrations arise. Establish the cause
and see if the implement has been
damaged. Do not repair it yourself!
Have the implement repaired by an
authorised workshop!
•Store the implement in a dry place
well out of reach of children.
CAUTION! The following states
how to avoid damage to the imple-
ment and any resulting harm to
people:
Take care of your implement
•Switch off the power when the imple-
ment is to be carried across steps.
•Inspect the implement each time before
it is to be used. Never operate the im-
plement if safety devices (e.g. impact
protector, parts of the cutting facility
or bolts are missing, worn out or dam-
aged. Check especially the power
cable and starting lever for damage.
To avoid imbalance, all tools and bolts
must be exchanged as complete sets.
•Only use spare parts and accessories
that have been supplied or recom-
mended by the manufacturer. The use
of alien parts results in the immediate
loss of all guarantee claims.
•Ensure that all nuts, bolts and screws
are rmly tightened and that the imple-
ment is in a safe working state.
•Never try to repair the implement your-
self, other than you have been trained
accordingly. All work that has not
been listed in these Instructions must
only be carried out by authorised serv-
icing agencies.
•Treat the implement with the greatest
care. Always keep the tool clean for
better and safer work. Follow the main-
tenance instructions.
•Never overload the implement. Always
work within the specied capacity
range. Do not use low-power machines
for heavy-duty work. Do not operate the
implement for purposes for which it is not
intended.
Electrical safety:
CAUTION! The following states how
to avoid accidents and injuries due to
electric shock:
• Before each use, carry out a visual
inspection of the power and extension
cables for signs of damage or ageing.
• If the power cable for this equipment is
damaged, it must be replaced by the
manufacturer, a customer service agent
of the same or a similarly qualied per-
son in order to prevent hazards.
•Keep the power cable well away from
the cutting tools. Should the power
cable become damaged during work,
then instantly disconnect the power
cable from the mains.
DO NOT touch the power cable
before it has been disconnected
from the mains.
•Keep the extension cables away from
the teeth. The teeth may damage the
cables and result in contact with live
parts.
•Check that the mains voltage is the
same as indicated on the rating plate.
•Connect the implement to a power
socket with a residual-current circuit
breaker that has a rated current of not
more than 30 mA.
•Avoid body contact with earthed parts
(e.g. metal fences, metal posts).
•Only use approved extension cables
of the type H05RN-F with a maximum
length of 75 m and which have been
approved for open-air use. The strand-

10
GB
ed cord diameter of the extension ca-
ble must be at least 2.5 mm2. Always
unreel a cable drum to its full length so
that the entire cable can be checked
for damage.
•Use the envisaged cable suspension
when attaching an extension cable.
•Never pull the cable to disconnect the
plug from the socket. Protect the cable
from heat, oil and sharp edges.
•If the connecting cable is damaged,
rst disconnect the extension cable
from the socket. You can then discon-
nect the connecting cable of the equip-
ment.
• If the power cable for this equipment is
damaged, it must be replaced by the
manufacturer, a customer service agent
of the same or a similarly qualied per-
son in order to prevent hazards.
Assembling
instructions
Prior to any work on the implement
always disconnect the plug from the
power socket!
Assembling the handle bar
B
1. Insert the lower bar (8) into the
implement case (10) and screw
it on with the two Philips screws
(28).
2. Screw both central bars (15)
with the screws and the wing
nuts (4b) to the lower bar (7).
3. Hang the cable strain relief
(19a) on the upper handle bar
(4).
Attach the clip ring to the tension
adjuster bracket (19b) beneath
the cable tension adjuster (19a)
on the upper handle (4).
4. Screw the upper bar (3) with the
screws and the wing nuts (4a) to
both central bars (15).
5. Fasten the machine cable (19)
with the machine cable terminals
(12/16) to the bar.
Mounting and emptying the
collection bag
WARNING: Never operate
the implement without the
impact protector. Danger of
Injury!
Assembling the collection bag:
The collection bag is delivered in a folded
state and must therefore be assembled be-
fore it is mounted on the implement.
C
1. Assemble the collection bag rods
(22).
2. Pull the collection bag over the
rods.
3. Put the plastic straps of the col-
lection bag over the collection
bag rods and clip into the plastic
straps.
Mounting the collection
bag on the implement:
4. Lift the impact protector (9).
5. Push the pins (23) on the collec-
tion bag rods into the socket in
the implement case (10).
6. Release the impact protector so
that it holds the collection bag
(6) in its position.
Removing and emptying
the collection bag:
7. Lift the impact protector (9) and
take out the collection bag (6).
Operation
Please observe local regulations
concerning noise protection. It is
quite possible that local rules and
regulations may limit the time of
implement operation or even pro-
hibited its use on certain days (e.g.

11
GB
Sundays and holidays), and dur-
ing certain times of the day (noon,
night hours) and in certain areas
(e.g. spars, clinics, etc.).
Setting the working positions
The implement has 4 principal position set-
tings:
Setting 0 : Transport position
This position sets the maximum safety spac-
ing between the tool and the oor.
Setting 1 : Working position
Set this position when working with a new
implement.
Settings 2 - 3 : Readjustment posi-
tions
The working position can be lowered with
increased knife and sprung tine wear.
Wear can be identied from an increas-
ingly poor result.
The readjusting depth amounts to approx.
3 mm per setting.
When the implement is delivered it
is in the Transport Position 0 setting.
The implement must be switched off to set
the working position. Pull the adjusting
knob for adjustment (see 9) and turn it
to the desired position until it clicks into
place.
Both wheels (right and left) must be indi-
vidually set to the same position.
The setting button is not intended
for height adjustment but rather to
compensate for wear. Selection of
a readjustment position without the
corresponding wear can overload
the motor and damage the cylinder.
Switching on and off
Before switching on the imple-
ment ensure that it is not in
contact with any objects. Keep
your feet and hands well
away from the cylinder and
the ejector opening. Danger of
injury!
D
1. Place the implement on a level
lawn surface.
2. Form a loop in the end of the
power cable and hang it into the
strain relief (19a).
3. Connect the implement to the
mains voltage.
4. To switch on press the unlocking
button on the handle (1) and
simultaneously press the starting
lever (3). Release the unlocking
button (1).
5. To switch off release the starting
lever (3).
Overload protection: The motor
is automatically switched off when the
implement is overloaded. Release the
starting lever and reset the implement
after a cooling down period of ap-
prox. 1 minute.
WARNING! The cylinder con-
tinues to run for a brief pe-
riod after the implement has
been switched off. Do not tilt
or carry the implement while
the motor is still running and
do not touch the cylinder
while it is still rotating.Danger
of injury!

12
GB
Working with the implement
To maintain a well cared-for lawn it should
be aerated every 4 to 6 weeks.
Verticuting is a more intensive intervention
than aerating and should only be carried
out once a year, the best time being in
spring after the lawn has been mown for
the rst time.
When working on slopes
always proceed across the
slope. Be particularly careful
when walking backwards
and pulling the implement.
Danger of stumbling!
The shorter the grass, the better the
lawn can be treated. Furthermore,
the implement is less stressed and
the service life of the cylinder is pro-
longed.
•The implement can be operated with or
without the collection bag.
Recommendation: Work with the col-
lection bag for aerating and without
the collection bag for verticuting.
•Mow the lawn to the required grass
height.
• Do not use the scarier in long grass. It
may otherwise wind around the scari-
er blade and result in damage to the
equipment.
•Select the appropriate working or
readjustment position (in the event of
cylinder wear) so that the implement is
not overloaded.
•Commence work in the vicinity of the
power socket and proceed away from
the socket.
•Always ensure that the extension cable
is behind you, and after turning move
it to the side that has already been
treated.
•Guide the implement at a walking
pace down lanes that are as straight
as possible. To ensure uninterrupted
aerating or verticuting the individual
lanes should always overlap by a few
centimetres. Dwelling too long at the
same place while the implement is run-
ning can damage the grass sward.
•To ensure that the extension cable is
not an impediment, turn the implement
in such a manner that the cable strain
release on the bar always faces the
side that has been treated.
After work and to transport the im-
plement disconnect the power plug
and wait until the cylinder is stand-
ing still.
•Adjust the transport position 0 setting
(see “Setting the Working Position”)
when transporting the implement.
•Lift the implement to transport it over
steps and sensitive surfaces (e.g. tiles).
•Always clean the implement after each
use (see “Cleaning, Maintenance, Stor-
age”).
•After having treated lawns with dense
moss growth, it is advisable to reseed
the lawn so that it can regenerate itself
quicker.
Exchanging the cylinder
Switch off the implement, disconnect
the mains plug and wait until the cyl-
inder is standing still.
Wear gloves when handling the cyl-
inder.
E
1. Turn the implement over.
2. Take the spanner (17) out of the
holder (see
A
No. 18).
3. Loosen the fastening screws and
pull the bearing support upwards.
F
4. Tilt the cylinder upwards and pull
the shaft (27) out of its seat.
5. Insert the new cylinder by revers-
ing the sequence.

13
GB
Cleaning,
maintenance, storage
Work that has not been de-
scribed in these Instructions
must be carried out by a ser-
vicing agency authorised by
us. Only use original parts.
Wear gloves when handling the cyl-
inder.
Prior to all maintenance and clean-
ing work always switch off the
implement, disconnect the plug from
the power socket and wait until the
cylinder is standing still.
General cleaning and mainte-
nance work
Do not jet water onto the
implement and do not clean
it under owing water. This
would result in the danger of
an electric shock and the im-
plement could be damaged.
• When work has nished remove plant
residues adhering to the wheels, inside
the ventilation opening, the grass ejec-
tor opening and the cylinder. Do not
use hard or pointed objects for this
purpose as they could damage the im-
plement.
•Completely empty the collection bag.
•Always keep the implement clean. Do
not use cleaning agents or solvents.
We cannot be held liable for damage caused
by our implements if they were improperly
repaired, if non-original parts have been used
or if they were used not in keeping with their
intended purpose.
Storage
•Store the implement in a dry place well
out of reach of children.
•Allow the motor to cool down before
placing the implement in a closed
room.
•Do not wrap nylon sacks around the
implement as this could result in the for-
mation of moisture.
G
Loosen the wing nuts so that the bar
can be folded up for space-saving
storage.
Ensure that the cables are not
squeezed.
Disposal and protection
of the environment
Dispose of the implement, accessories and
packaging in an environment-friendly man-
ner.
Electrically-powered appliances must
not be disposed of with the domestic
waste.
Hand in the spent implement to a recycling
centre. The plastic and metal parts can
then be sorted out and graded for recy-
cling. Our Service Center will be happy to
answer any questions in this respect.
Spare parts
Refer to the specied Service Address, Fax
No. to purchase spare parts. Orders must
specify the Order number.
Verticuttor cylinder Order No. 91102646
Aerator cylinder.... Order No. 91102647
Collection bag ..... Order No. 91102651
When ordering spare parts list the position
number indicated in the exploded view.

14
GB
Trouble shooting
Problem Possible cause Remedy
Abnormal noises,
clatter or
vibrations
Foreign body on cylinder Remove foreign body
Damaged sprung tines or
cylinder knives Exchange cylinder
Cylinder incorrectly mounted Install cylinder correctly (see chapter
on exchanging the cylinder)
Toothed-belt slip Switch device off and pull power plug. Remove the soil and grass
residues available.
Implement does
not start
No power Check power socket, cable, line;
repair only by qualied electrician
ON / OFF switch defective
Repair by After-Sales ServiceCarbon brushes worn out
Motor defective
Motor fails
Blocked by foreign body Remove foreign body
Grass is too long Mow beforehand; see chapter
“Operation”
Clogged discharge Clean discharge
Overload protection tripped Allow implement to cool down for
about 1 minute
Work result not
satisfactory
Sprung tines of aerator
cylinder worn out Exchange cylinder
Knives of verticutor cylinder
blunt or damaged Exchange cylinder
Toothed belt defective Repair by After-Sales Service
Transport Position or
incorrect Working Position
selected
Select Working Position 1 or
Readjust Position 2-4 (see chapter
“Setting the Working Positions)
Grass is too long Mow beforehand; see chapter
“Operation”

15
GB
Guarantee
Dear Customer,
This equipment is provided with a 3-year
guarantee from the date of purchase.
In case of defects, you have statutory rights
against the seller of the product. These
statutory rights are not restricted by our
guarantee presented below.
Terms of Guarantee
The term of the guarantee begins on the
date of purchase. Please retain the original
receipt. This document is required as proof
of purchase.
If a material or manufacturing defect
occurs within three years of the date of
purchase of this product, we will repair or
replace – at our choice – the product for
you free of charge. This guarantee requires
the defective equipment and proof of pur-
chase to be presented within the three-year
period with a brief written description of
what constitutes the defect and when it oc-
curred.
If the defect is covered by our guarantee,
you will receive either the repaired prod-
uct or a new product. No new guarantee
period begins on repair or replacement of
the product.
Guarantee Period and Statutory
Claims for Defects
The guarantee period is not extended by
the guarantee service. This also applies for
replaced or repaired parts. Any damages
and defects already present at the time of
purchase must be reported immediately af-
ter unpacking. Repairs arising after expiry
of the guarantee period are chargeable.
Guarantee Cover
The equipment has been carefully pro-
duced in accordance with strict quality
guidelines and conscientiously checked
prior to delivery.
The guarantee applies for all material and
manufacturing defects. This guarantee
does not extend to cover product parts that
are subject to normal wear and may there-
fore be considered as wearing parts (e.g.
lters or attachments) or to cover damage
to breakable parts (e.g. switches, batteries,
or parts made of glass).
This guarantee shall be invalid if the prod-
uct has been damaged, used incorrectly or
not maintained. Precise adherence to all of
the instructions specied in the operating
manual is required for proper use of the
product. Intended uses and actions against
which the operating manual advises or
warns must be categorically avoided.
The product is designed only for private
and not commercial use. The guarantee
will be invalidated in case of misuse or
improper handling, use of force, or inter-
ventions not undertaken by our authorised
service branch.
Processing in Case of Guarantee
To ensure quick handling of you issue,
please follow the following directions:
•Please have the receipt and item num-
ber (IAN 93500) ready as proof of
purchase for all enquiries.
• Please nd the item number on the
rating plate, an engraved plate on the
front page of your manual (bottom left)
or as a sticker on the back or bottom.
•Should functional errors or other de-
fects occur, please initially contact the
service department specied below
by telephone or by e-mail. You will
then receive further information on the
processing of your complaint.
•After consultation with our customer
service, a product recorded as defec-
tive can be sent postage paid to the
service address communicated to you,
with the proof of purchase (receipt)
and specication of what constitutes

16
GB
the defect and when it occurred. In or-
der to avoid acceptance problems and
additional costs, please be sure to use
only the address communicated to you.
Ensure that the consignment is not sent
carriage forward or by bulky goods,
express or other special freight. Please
send the equipment inc. all accessories
supplied at the time of purchase and
ensure adequate, safe transport pack-
aging.
Repair Service
For a charge, repairs not covered by the
guarantee can be carried out by our ser-
vice branch, which will be happy to issue
a cost estimate for you.
We can handle only equipment that has
been sent with adequate packaging and
postage.
Attention: Please send your equipment to
our service branch in clean condition and
with an indication of the defect.
Equipment sent carriage forward or by
bulky goods, express or other special
freight will not be accepted.
We will dispose of your defective devices
free of charge when you send them to us.
Service-Center
Service Great Britain
Tel.: [phone]
(£ 0.10/Min.)
E-Mail: [email protected]
IAN 93500
Importer
Please note that the following address is
not a service address. Please initially con-
tact the service centre specied above.
Grizzly Gartengeräte
GmbH & CO KG
Am Gewerbepark 2
64823 Groß-Umstadt
Germany
www.grizzly-service.eu
GB

17
PL
Spis tresci
Wstęp........................................17
Przeznaczenie............................ 18
Opis ogólny ............................... 18
Zawartość opakowania ..................18
Przegląd .......................................18
Opis działania ..............................19
Dane techniczne......................... 19
Zasady bezpieczeństwa.............20
Symbole na urządzeniu..................20
Symbole w instrukcji.......................20
Instrukcja montażu .................... 24
Zakres dostawy ............................. 24
Montaż trzonka uchwytowego......... 24
Montaż/ opróżnianie zasobnika do
zbierania skoszonej trawy............... 24
Obsługa.....................................25
Ustawienie pozycji roboczych ......... 25
Włączenie i wyłączenie ................ 25
Praca przy użyciu urządzenia ......... 26
Wymiana walca ............................ 27
Czyszczenie, konserwacja,
przechowywanie .......................27
Ogólne czyszczenie i prace
konserwacyjne .............................. 27
Przechowywanie............................ 28
Utylizacja, ochrona środowiska . 28
Części zamienne.........................28
Szukanie usterek .......................29
Gwarancja.................................30
Serwis naprawczy .....................31
Service-Center............................ 31
Importer .................................... 31
Tłumaczenie oryginalnej deklaracji
zgodności WE............................102
Rysunek samorozwijający........105
Urządzenie to mogą obsługiwać
dzieci od 8 roku życia, a także
osoby o zmniejszonych zdolno-
ściach zycznych, zmysłowych
czy umysłowych, czy też osoby
dysponujące niedostatecznym do-
świadczeniem oraz wiedzą, pod
warunkiem, że praca odbywa się
pod nadzorem albo po instruktażu
w zakresie bezpiecznej eksploata-
cji urządzenia i ze zrozumieniem
istniejących zagrożeń. Dzieciom
nie wolno bawić się urządzeniem.
Dzieciom nie wolno bez nadzoru
wykonywać czyszczenia i konser-
wacji.
Wstęp
Gratulujemy zakupu nowego urządzenia.
Zdecydowali się Państwo na zakup warto-
ściowego produktu. Niniejsze urządzenie
sprawdzono w trakcie produkcji pod kątem
jakości, a także dokonano jego kontroli
ostatecznej. W ten sposób zapewniona jest
jego sprawność. Nie da się wykluczyć tego,
że w pojedynczych przypadkach w urzą-
dzeniu lub przy nim wzgl. w wężach mogą
się znaleźć pozostałości wody lub smaru.
Nie jest to brakiem ani uszkodzeniem, czy
powodem do troski o urządzenie.
Instrukcja obsługi jest częścią składową
produktu. Zawiera ona ważne wskazówki
dotyczące bezpieczeństwa, eksploatacji i
utylizacji. Przed rozpoczęciem użytkowania
produktu należy się zapoznać ze wszyst-
kimi wskazówkami dotyczącymi obsługi i
bezpieczeństwa. Produkt należy użytkować
tylko zgodnie z opisem i podanym przezna-
czeniem. Instrukcję należy przechowywać
starannie, a w przypadku przekazania
produktu osobom trzecim należy dostarczyć
nabywcy kompletną dokumentację.

18
PL
Przeznaczenie
Niniejsze urządzenie jest przeznaczone
do użytku domowego:
- jako urządzenie do przewietrzania
trawników, czyli wyczesywania lcu (z
liści, mchu i chwastów) znajdującego
się pomiędzy źdźbłami trawy i do
zbierania liści oraz resztek roślin.
- Jako skarykator do obróbki darniny i
regeneracji powierzchni trawy i trawni-
ków.
Każde inne zastosowanie, które nie zosta-
ło dozwolone w jednoznaczny sposób,
może prowadzić do uszkodzeń urządze-
nia i stanowić poważne zagrożenie dla
użytkownika.
Urządzenie jest przeznaczone wyłącznie
do użytku przez osoby dorosłe. Dzieciom
oraz osobom, które się nie zaznajomiły z
niniejszą instrukcją, nie wolno stosować
niniejszego urządzenia. Eksploatacja urzą-
dzenia w deszczu i wilgotnym otoczeniu
jest zabroniona.
Osoba obsługująca lub użytkownik są
odpowiedzialni za wypadki i urazy innych
osób oraz ich mienia.
Producent nie ponosi odpowiedzialności
cywilnej za szkody, które są powodowane
ze względu na użycie niezgodne z prze-
znaczeniem i nieprawidłową obsługę.
Opis ogólny
Zawartość opakowania
Proszę ostrożnie wyciągnąć urządzenie z
opakowania i sprawdzić, czy dostarczone
zostały wszystkie poniższe części:
• obudowa urządzenia z walcem skary-
katora i osłoną odbojową
• walec napowietrzający
• górny trzonek uchwytowy z dźwignią
włączającą, wtyczką sieciową, przy-
ciskiem odryglowującym i na stałe
zamontowanym kablem sieciowym
• dolny pałąk
• 2 trzonki środkowe
•zasobnik do zbierania skoszonej tawy
• uchwyt kablowy odciążający
• pierścień klipsowy do zablokowania
uchwytu kablowego odciążającego
•2 zaciski do kabli
• uchwyt narzędziowy
• wyposażenie montażowe:
- 2 wkręty z rowkiem krzyżowy, 4
śruby i 4 nakrętki motylkowe do za-
mocowania trzonka
- klucz do narzędzi służący do wy-
miany walca
• Instrukcja obsługi
W trakcie montażu proszę zwrócić
na to, aby kabel sieciowy nie był
zakleszczony i posiadał dostatecz-
nie dużo luzu.
Rysunek najważniej-
szych części funkcyj-
nych znajdą Państwo
na okładce.
Przegląd
A
1 Przycisk odryglowujący
2 Dźwignia włączająca
3 Górny trzonek uchwytowy
4a/b 4 śruby i 4 nakrętki motylkowe
do zamocowania uchwytu
5 Zasobnik do zbierania skoszo-
nej tawy
6 Osłona odbojowa
7 Dolny pałąk
8 Obudowa urządzenia
9 Gałka nastawcza
10 2 koła tylne
11 2 koła
12 Zacisk kablowy urządzenia
13 Klucz do narzędzi
14 Uchwyt narzędziowy
15 2 trzonki środkowe
16 Zacisk kablowy urządzenia
17 Kabel sieciowy
18 Uchwyt kablowy odciążający

19
PL
19 Kabel urządzenia
20 Walec napowietrzający z ocyn-
kowanymi palcami kultywatora
21 Walec skaryaktora z nożem
B
22 śrubę mocującą
C
23 Układ dźwigni i drążków
E
24 Uchwyt czworokątny
Opis działania
Skarykator i urządzenie do na-
powietrzania trawy posiada dwa
walce robocze, których wymiana
nie sprawia trudności:
walec napowietrzający z twardego two-
rzywa sztucznego z pionowo obracający-
mi się, ocynkowanymi palcami kulturywa-
tora i walec skarykatora z umieszczonym
w pionowej pozycji nożami ze stali szla-
chetnej.
Urządzenie jest wyposażone w obudowę
z tworzywa sztucznego o wysokiej jakości
z zasobnikiem do zbierania skoszonej tra-
wy z trzonkiem uchwytowym o funkcji skła-
dania. Sposób działania części obsługi
proszę zaczerpnąć z poniższych opisów.
Dane techniczne
Skarykator i urządzenie do
przewietrzania trawników.....FLV 1200 A1
Moc pobierana przez silnik.........1200 W
Napięcie sieciowe .... 230-240 V~, 50 Hz
Klasa ochrony..................................
II
Rodzaj ochrony ...............................IPX4
Robocza prędkość obrotowa
narzędzia (n)....................... 3500 min-1
Szerokość walca........................... 31 cm
Zakres regulacji w przypadku zużycia
.................................................... 9 mm
Ciężar (bez zasobnika do zbierania sko-
szonej trawy)................................9,9 kg
Poziom ciśnienia akustycznego
(LpA)......................84 dB (A), KpA= 3 dB (A)
Poziom mocy ciśnienia akustycznego
gwarantowany ................... 103 dB (A)
zmierzony
(LWA) ................99 dB (A), KwA=4 dB (A)
Wibracje rękojeści (an)
.............................4 m/s2, K = 2 m/s2
Wartości akustyczne i prędkość wibracji
zostały określone zgodnie z wymogami
norm podanych w deklaracji producenta.
Zmiany techniczne i optyczne mogą być
dokonywane bez zapowiedzi w ramach
procedur rozwoju technicznego. Wszelkie
wymiary, wskazówki i dane tej instrukcji
obsługi są w związku z tym niewiążące.
W związku z tym wyklucza się wszelkie
roszczenia prawne zgłaszane na podsta-
wie tej instrukcji obsługi.
Podana wartość emisji drgań została
zmierzona metodą znormalizowaną i
może być wykorzystywana do porównań
urządzenia elektrycznego z innymi urzą-
dzeniami.
Podana wartość emisji drgań może też
służyć do szacunkowej oceny stopnia eks-
pozycji użytkownika na drgania.
Ostrzeżenie:
Wartość emisji drgań może się
różnić w czasie korzystania z urzą-
dzenia od podanej wartości, jest
to zależne od sposobu używania
urządzenia.
Istnieje konieczność określenia i
zastosowania środków ochrony
użytkownika, opartych na ocenie
ekspozycji w rzeczywistych warun-
kach używania urządzenia (należy
przy tym uwzględnić wszystkie części
cyklu roboczego, na przykład okresy
czasu, w których urządzenie elek-
tryczne jest wyłączone bądź jest włą-
czone, ale pracuje bez obciążenia).

20
PL
Zasady
bezpieczeństwa
W niniejszym ustępie zajęto się podstawo-
wymi przepisami bezpieczeństwa w trak-
cie pracy przy użyciu urządzenia.
Symbole na urządzeniu
Uwaga!
Przeczytaj instrukcję obsługi.
Niebezpieczeństwo urazów ze
względu na wyrzucane części.
Trzymać z daleka od urządzenia
osoby stojące w pobliżu.
Niebezpieczeństwo ze
względu na porażenie
prądem elektrycznym lub
uszkodzenia kabla siecio-
wego! Trzymać kable z da-
leka od zespołów tnących
i urządzenia!
Ostrożnie - ostre narzędzia. Trzy-
mać z daleka ręce i nogi. Rotacja
walca jest wykonywana jeszcze
po wyłączeniu silnika.
Konieczne jest noszenie ochrony
oczu i słuchu.
Przed konserwacją lub w przy-
padku, gdy kabel sieciowy zo-
stanie uszkodzony, wyciągnąć
wtyczkę z gniazda sieciowego..
Zachować ostrożność w przy-
padku schodów! W trakcie
transportu urządzenia po
schodach, należy jest wcze-
śniej wyłączyć i podnieść.
Informacje odnośnie poziomu mocy
akustycznej LWA w dB(A).
Poziom ochrony II
Urządzeń elektrycznych nie należy
wyrzucać wraz z odpadami i śmie-
ciami z gospodarstw domowych.
Usuń ew. resztki ziemi ze sprężyn klapki
przeciwwyrzutowej i/lub obudowy urzą-
dzenia, aby zapewnić prawidłowe zamy-
kanie klapki przeciwwyrzutowej. Podczas
pracy bez kosza klapka przeciwwyrzuto-
wa musi być całkowicie zamknięta.
Symbole w instrukcji
Znaki ostrzegawcze z dany-
mi odnośnie zapobiegania
szkodom osobowym i rzeczo-
wym.
Znaki nakazu (zamiast wykrzyknika
objaśniony jest nakaz) z informacjami
odnośnie zapobiegania szkodom.
Znaki informacyjne zawierające in-
formacje odnośnie lepszego sposo-
bu obchodzenia się z urządzeniem.
Ogólne wskazówki bezpie-
czeństwa
W przypadku nieprawidłowej eks-
ploatacji urządzenie może spowo-
dować poważne urazy. Przed roz-
poczęciem pracy przy użyciu urzą-
dzenia proszę starannie przeczytać
niniejszą instrukcję obsługi i dobrze
zaznajomić się ze wszystkimi czę-
ściami obsługi. Niniejszą instrukcję
obsługi należy przechowywać w
odpowiedni sposób, aby informacje
były Państwu zawsze dostępne.
