FLOS SUPERLOON User manual

REV. 1
DATE 04/08/2021
1
SUPERLOON
Designed by Jasper Morrison, 2015
F6630030
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.

EN
2
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
01. F6632030
–Black diffuser
02. RF25185
–Black mobile legs
03. RF6630130
–Black electrified fuxed leg
04. RF3320400
–48V Power supply unit with plug kit
REV. 1
DATE 04/08/2021
SUPERLOON
F6630030

EN
3
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
F6632030
BLACK DIFFUSER
SUPERLOON F6630030
REV. 1
DATE 04/08/2021

4
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
Mount the diffuser head (E) inserting the pin (F) in the
hole of the base element (C).
EN
Fig.1
REV. 1
DATE 04/08/2021
E
C
F
F6632030
BLACK DIFFUSER
SUPERLOON F6630030

5
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
The light beam’s direction can be adjusted by
rotating the head (E) into the desired position.
EN
Fig.2
REV. 1
DATE 04/08/2021
E
F6632030
BLACK DIFFUSER
SUPERLOON F6630030

EN
6
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
RF25185
MOBILE LEGS
REV. 1
DATE 04/08/2021
SUPERLOON F6630030

7
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
Insert the two legs (A) in the pins (B) of the base
element (C) paying attention to the correct
orientation of the feet (D) as indicated in Pic. 1A
EN
Fig.1
REV. 1
DATE 04/08/2021
B
A
C
Fig.1A
D
SUPERLOON F6630030
RF25185
MOBILE LEGS

EN
8
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
REV. 1
DATE 04/08/2021
RF6630130
BLACK ELECTRIFIED FIXED LEG
SUPERLOON F6630030

9
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
Insert the two legs (A) in the pins (B) of the base
element (C) paying attention to the correct
orientation of the feet (D).
EN
Fig.1
REV. 1
DATE 04/08/2021
B
A
C
D
RF6630130
BLACK ELECTRIFIED FIXED LEG
SUPERLOON F6630030

10
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
Mount the diffuser head (E) inserting the pin (F) in the
hole of the base element (C).
EN
Fig.2
REV. 1
DATE 04/08/2021
E
C
E
RF6630130
BLACK ELECTRIFIED FIXED LEG
SUPERLOON F6630030

11
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
Connect the plug (I) to the feeder unit locking in by
rotating it 90°clockwise.
EN
Fig.3
REV. 1
DATE 04/08/2021
H
I
G
RF6630130
BLACK ELECTRIFIED FIXED LEG
SUPERLOON F6630030

12
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
To switch on/off the device lightly touch the sensor (L); prolonged contact with the
sensor causes the progressive increase of the light intensity from 10% up to 100%
and at the same time an increase of the colour temperature from 2200K to 2800K;
when the desired intensity is reached, remove finger from the button. A successive
prolonged contact with the sensor will cause the progressive decrease.
NOTE
:
Thanks to the card’s
memory, when the device is turned on from a wall switch, it comes on again at the
same brightness level it was at when it was turned off. The brightness level (and
corresponding colour temperature) is automatically
activated by the LED card after at least 15 seconds’ fixed operation (without making
adjustments).
EN
Fig.4
REV. 1
DATE 04/08/2021
L
RF6630130
BLACK ELECTRIFIED FIXED LEG
SUPERLOON F6630030

EN
13
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
RF3320400
POWER SUPPLY UNIT WITH PLUG KIT
REV. 1
DATE 04/08/2021
SUPERLOON F6630030
Noctambule
All Floor
Versions
p.15
Captain
Flint
p.05
Sawaru
p.03
Superloon
p.13
Taccia
Led
p.13
Arco Led
p.03
Bellhop
F
p.11
Coordinates F
p.14

14
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
EN
Insert the plug into the power unit. By using the guides, snap the plug
inside its apposite slot (use the correct type of plug for the country in
which the device must be installed).
Fig.1
RF3320400
POWER SUPPLY UNIT WITH PLUG KIT
REV. 1
DATE 04/08/2021
SUPERLOON F6630030
