Technical Data
New! Fluke 233
Remote Display Multimeter
The NEW Fluke 233 True-rms Remote
Display Digital Multimeter allows you to
be in two places at once.
• Removabledisplaygivestheuserultimateflexibility
inunusualmeasurementscenarios
• Placethedisplaywhereyoucanseeitandthenput
themeterwhereitisconvenientforyou—nomore
jugglingofleadsandthemeterwhilestretchinginto
atightspot
• Removesthedilemmaoftryingtotakemea-
surementsinhard-to-reachplaces,ormaking
measurementsinmachinesorpanelsthatare
physicallyseparatedfromalimitorisolatorswitch
• Canbeusedinareaswheretheoperatorcan’tbe
closetotheactivemeasurementpoint,likeclean
roomsorhazardousareas
•True-rms ac voltage and current
for accurate measurements on
non-linear signals
•Measure up to 1000 V ac and dc
•Measure up to 10 A (20 A for 30
seconds)
•10,000 µF capacitance range
•Frequency to 50 kHz
•Built in thermometer conveniently
allows you to take temperature readings
without having to carry a separate
instrument
•Resistance, continuity and diode test
Features
•Low power wireless technology allows
the display to be carried up to 10
meters (33 ft) away from the point of
measurement for added flexibility.
No interference with measurements
•The removable magnetic display can be
conveniently mounted where it is easily
seen
•Make measurements without holding
the meter to improve visual focus on
probes and augment safe electrical
measurements
•Use as a conventional multimeter when
the display is connected
•Radio transmitter automatically turns off
when the display is connected to the
meter
•Auto power off maximizes battery life
•Min/Max and Average recording to
capture variations automatically
•Test continuity and diodes
•Easy to read display with large digits
and bright backlight
•Battery life approximately 400 hours

2 Fluke Corporation Fluke 233 Remote Display MultimeterOptimum
Optimum Energy Products Ltd
Toll Free 1-877-766-5412
www.MyFlukeStore.com
©2009 Fluke Corporation.
Specifications subject to change without notice.
Printed in U.S.A. 9/2009 3476728B D-EN-N
Modification of this document is not permitted
without written permission from Fluke Corporation.
Fluke. Keeping your world
up and running.®
General specifications
Basic features
AC true-rms Yes
Ranging Auto/Manual
Display
Backlight Yes
Data storage
Min/Max/Avg Yes
Other features
Battery type AA alkaline
Removable display Yes
Warranty and protection
Safety rating CAT IV 600 V/CAT III 1000 V
External protection Rubber overmold
Warranty Three-years
Size (H x W x L) 5.3 cm x 5.3 cm x 19.3 cm (2.08 in x 2.08 in x 7.6 in)
Weight 604 g (1.3 Ib)
Accuracy specifications
DC voltage Range 0.1 mV to 1000 V
Accuracy 0.25 % + 2
AC voltage Range 0.1 mV to 1000 V
Accuracy 1.0 % + 3
DC current Range 0.1 mA to 10 A
Accuracy 1.0 % + 3
AC current Range 0.1 mA to 10 A
Accuracy 1.5 % + 3
Resistance Range 0.1 Wto 40 MW
Counts 6000
Capacitance 1000 nF to 9999 µF
Frequency 0.1 Hz to 50.00 kHz
Temperature -40 °C to +400 °C
Power AA batteries: Three for main body; two for display
Battery life 400 hours
Wireless frequency 2.4 GHz ISM Band 10 meter range
Safety rating CAT IV 600 V , CAT III 1000 V
Ordering information:
233 Remote Display Multimeter
Includes: Test leads, alligator clips,
80BK-A temperature probe, manual,
CD-ROM, and AA batteries
Optional accessories
TPak Magnetic Hanging Kit
i410 AC/DC Current Clamp
80PK-9 General Purpose Probe
(Type K)
80AK-A Thermocouple Adapter
C35 Soft Carry Case
