Fluke 5820A User manual

®
5820A
Oscilloscope Calibrator
Service Manual
PN 673142
June 1999 Rev.1, 4/03
© 1999-2003 Fluke Corporation, All rights reserved. Printed in U.S.A.
All product names are trademarks of their respective companies.

LIMITED WARRANTY & LIMITATION OF LIABILITY
Each Fluke product is warranted to be free from defects in material and workmanship under
normal use and service. The warranty period is one year and begins on the date of shipment.
Parts, product repairs and services are warranted for 90 days. This warranty extends only to the
original buyer or end-user customer of a Fluke authorized reseller, and does not apply to fuses,
disposable batteries or to any product which, in Fluke’s opinion, has been misused, altered,
neglected or damaged by accident or abnormal conditions of operation or handling.Fluke warrants
that software will operate substantially in accordance with its functional specifications for 90 days
and that it has been properly recorded on non-defective media. Fluke does not warrant that
software will be error free or operate without interruption.
Fluke authorized resellers shall extend this warranty on new and unused products to end-user
customers only but have no authority to extend a greater or different warranty on behalf of Fluke.
Warranty support is available if product is purchased through a Fluke authorized sales outlet or
Buyer has paid the applicable international price. Fluke reserves the right to invoice Buyer for
importation costs of repair/replacement parts when product purchased in one country is submitted
for repair in another country.
Fluke’s warranty obligation is limited, at Fluke’s option, to refund of the purchase price, free of
charge repair, or replacement of a defective product which is returned to a Fluke authorized
service center within the warranty period.
To obtain warranty service, contact your nearest Fluke authorized service center or send the
product, with a description of the difficulty, postage and insurance prepaid (FOB Destination), to
the nearest Fluke authorized service center. Fluke assumes no risk for damage in transit.
Following warranty repair, the product will be returned to Buyer, transportation prepaid (FOB
Destination). If Fluke determines that the failure was caused by misuse, alteration, accident or
abnormal condition of operation or handling, Fluke will provide an estimate of repair costs and
obtain authorization before commencing the work. Following repair, the product will be returned to
the Buyer transportation prepaid and the Buyer will be billed for the repair and return
transportation charges (FOB Shipping Point).
THIS WARRANTY IS BUYER’S SOLE AND EXCLUSIVE REMEDY AND IS IN LIEU OF ALL
OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
FLUKE SHALL NOT BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR
CONSEQUENTIAL DAMAGES OR LOSSES, INCLUDING LOSS OF DATA, WHETHER
ARISING FROM BREACH OF WARRANTY OR BASED ON CONTRACT, TORT, RELIANCE OR
ANY OTHER THEORY.
Since some countries or states do not allow limitation of the term of an implied warranty, or
exclusion or limitation of incidental or consequential damages, the limitations and exclusions of
this warranty may not apply to every buyer. If any provision of this Warranty is held invalid or
unenforceable by a court of competent jurisdiction, such holding will not affect the validity or
enforceability of any other provision.
Fluke Corporation Fluke Europe B.V.
P.O. Box 9090 P.O. Box 1186
Everett, WA 98206-9090 5602 BD Eindhoven
U.S.A. The Netherlands
5/94

SafetyInformation
This Calibrator complies with IEC publication 1010-1 (1992-1), Safety Requirements for
Electrical Measuring, Control and Laboratory Equipment, and ANSI/ISA-S82.01-1994,
and CAN/CSA-C22.2 No. 1010.1-92. This manual contains information, warnings, and
cautions that must be followed to ensure safe operation and to maintain the Calibrator in
a safe condition. Use of this Calibrator in a manner not specified herein may impair the
protection provided by the Calibrator.
This Calibrator is designed for IEC 1010-1 Installation Category II use. It is not designed
for connection to circuits rated over 4800 VA.
Warning statements identify conditions or practices that could result in personal injury
or loss of life.
Caution statements identify conditions or practices that could result in damage to
equipment.
SYMBOLS MARKED ON THE CALIBRATOR
WARNING Risk of electric shock. Refer to the manual (see the Index for
references).
GROUND Ground terminal to chassis (earth).
Attention Refer to the manual (see the Index for references). This
symbol indicates that information about usage of a feature is contained in
the manual.
AC POWER SOURCE
The Calibrator is intended to operate from an ac power source that will not apply more
than 264V ac rms between the supply conductors or between either supply conductor
and ground. A protective ground connection by way of the grounding conductor in the
power cord is required for safe operation.
USE THE PROPER FUSE
To avoid fire hazard, use only the specified replacement fuse:
•For 100 V or 120 V operation, use a 5A/250V time delay fuse (Fluke PN 109215).
•For 220 V or 240 V operation, use a 2.5A/250V time delay fuse (Fluke PN 851931).
GROUNDINGTHE CALIBRATOR
The Calibrator uses controlled overvoltage techniques that require the Calibrator to be
grounded whenever normal mode or common mode ac voltages or transient voltages
may occur. The enclosure must be grounded through the grounding conductor of the
power cord, or through the rear panel CHASSIS GROUND binding post.

USE THE PROPER POWER CORD
Use only the power cord and connector appropriate for the voltage and plug
configuration in your country.
Use only a power cord that is in good condition.
Refer power cord and connector changes to qualified service personnel.
DONOT OPERATE IN EXPLOSIVE ATMOSPHERES
To avoid explosion, do not operate the Calibrator in an atmosphere of explosive gas.
CHECK INSULATIONRATINGS
Verify that the voltage applied to the unit under test does not exceed the insulation
rating of the UUT and the interconnecting cables.
DONOT REMOVE COVER DURINGOPERATION
To avoid personal injury or death, do not remove the Calibrator cover without first
removing the power source connected to the rear panel. Do not operate the Calibrator
without the cover properly installed. Normal calibration is accomplished with the cover
closed. Access procedures and the warnings for such procedures are contained in the
Service Manual. Service procedures are for qualified service personnel only.
DO NOTATTEMPTTO OPERATEIFPROTECTIONMAYBEIMPAIRED
If the Calibrator appears damaged or operates abnormally, protection may be impaired. Do
not attempt to operate the Calibrator under these conditions. Refer all questions of proper
Calibrator operation to qualified service personnel.

i
Table of Contents
Chapter Title Page
1 Introduction and Specifications........................................................ 1-1
1-1. Introduction........................................................................................... 1-3
1-2. How to Contact Fluke........................................................................... 1-4
1-3. Instruction Manuals.............................................................................. 1-4
1-4. 5820A Operators Manual................................................................. 1-4
1-5. 5820A Service Manual..................................................................... 1-5
1-6. Specifications........................................................................................ 1-5
1-7. General Specifications.......................................................................... 1-6
1-8. Volt Specifications........................................................................... 1-8
1-9. DC Volt Measure Specifications...................................................... 1-8
1-10. Edge Specifications.......................................................................... 1-9
1-11. Leveled Sine Wave Specifications................................................... 1-10
1-12. Time Marker Specifications............................................................. 1-11
1-13. Wave Generator Specifications........................................................ 1-12
1-14. 1 ns Pulse Generator Specifications................................................. 1-13
1-15. Trigger Signal Specifications (Pulse Function) ............................... 1-13
1-16. Trigger Signal Specifications (Time Marker Function)................... 1-13
1-17. Trigger Signal Specifications (Edge Function)................................ 1-14
1-18. Trigger Signal Specifications (Square Wave Voltage Function)..... 1-14
1-19. Trigger Signal Specifications (TV).................................................. 1-14
1-20. Tunnel Diode Drive Capability........................................................ 1-14
1-21. Oscilloscope Input Resistance Measurement Specifications........... 1-14
1-22. Oscilloscope Input Capacitance Measurement Specifications......... 1-14
1-23. Overload Measurement Specifications............................................. 1-15
1-24. External Reference Input Specifications.......................................... 1-15
1-25. Auxiliary Input Specifications.......................................................... 1-15
1-26. Current Output Specifications.......................................................... 1-15
2 Theory of Operation........................................................................... 2-1
2-1. Introduction........................................................................................... 2-3
2-2. Voltage Mode................................................................................... 2-7
2-3. Edge Mode........................................................................................ 2-7
2-4. Leveled Sine Wave Mode ................................................................ 2-7
2-5. Time Marker Mode .......................................................................... 2-7

5820A
Service Manual
ii
2-6. Wave Generator Mode ..................................................................... 2-8
2-7. Pulse Generator ................................................................................ 2-8
2-8. Input DC Voltage Measurement Mode ............................................ 2-8
2-9. Input Impedance Mode (Resistance)................................................ 2-8
2-10. Input Impedance Mode (Capacitance).............................................. 2-8
2-11. Current Module ................................................................................ 2-9
2-12. Overload Mode................................................................................. 2-9
2-13. Trigger.............................................................................................. 2-9
2-14. High Frequency Switching............................................................... 2-9
2-15. 5 Channel Option.............................................................................. 2-9
2-16. GHz Option Module......................................................................... 2-9
3 Calibration and Verification............................................................... 3-1
3-1. Introduction........................................................................................... 3-3
3-2. Equipment Required for Calibration and Verification......................... 3-3
3-3. Calibration Setup.................................................................................. 3-6
3-4. Calibration and Verification of Square Wave Voltage Functions........ 3-6
3-5. Overview of HP3458A Operation.................................................... 3-6
3-6. Setup for Scope Calibrator Voltage Square Wave Measurements... 3-6
3-7. Setup for Scope Calibrator Edge and Wave Gen Square Wave
Measurements................................................................................... 3-8
3-8. DC Voltage Calibration........................................................................ 3-9
3-9. AC Voltage Calibration........................................................................ 3-10
3-10. DC Measurement Calibration............................................................... 3-11
3-11. Current Calibration............................................................................... 3-11
3-12. DC Current Calibration.................................................................... 3-11
3-13. AC Current Calibration.................................................................... 3-11
3-14. Wave Generator Calibration................................................................. 3-12
3-15. Edge Amplitude Calibration................................................................. 3-12
3-16. Leveled Sine Wave Amplitude Calibration.......................................... 3-13
3-17. Leveled Sine Wave Flatness Calibration.............................................. 3-14
3-18. Low Frequency Calibration.............................................................. 3-14
3-19. High Frequency Calibration............................................................. 3-15
3-20. Pulse Width Calibration........................................................................ 3-15
3-21. MeasZ Calibration................................................................................ 3-16
3-22. Leveled Sine Wave Flatness Calibration (GHz Option)....................... 3-18
3-23. 5820A-5 Option.................................................................................... 3-18
3-24. Verification........................................................................................... 3-18
3-25. DC Voltage Verification .................................................................. 3-20
3-26. Verification at 1 MΩ.................................................................... 3-20
3-27. Verification at 50 Ω..................................................................... 3-20
3-28. AC Voltage Amplitude Verification ................................................ 3-23
3-29. Verification at 1 MΩ.................................................................... 3-23
3-30. Verification at 50 Ω..................................................................... 3-24
3-31. AC Voltage Frequency Verification ................................................ 3-25
3-32. DC Measurement Verification ......................................................... 3-26
3-33. Current Verification ......................................................................... 3-27
3-34. DC Current Verification .............................................................. 3-27
3-35. AC Current Verification .............................................................. 3-28
3-36. Edge Amplitude Verification ........................................................... 3-30
3-37. Edge Frequency Verification............................................................ 3-30
3-38. Edge Duty Cycle Verification.......................................................... 3-31
3-39. Edge Rise Time Verification............................................................ 3-31
3-40. Edge Aberrations.............................................................................. 3-33

Contents (continued)
iii
3-41. Tunnel Diode Pulser Drive Amplitude Verification........................ 3-34
3-42. Leveled Sine Wave Amplitude Verification.................................... 3-34
3-43. MHz Leveled Sine Wave Flatness Verification............................... 3-35
3-44. Equipment Setup for Low Frequency Flatness............................ 3-35
3-45. Equipment Setup for High Frequency Flatness ........................... 3-36
3-46. Low Frequency Verification........................................................ 3-36
3-47. High Frequency Verification ....................................................... 3-37
3-48. < 600 MHz Leveled Sine Harmonic Verification........................ 3-47
3-49. Time Marker Verification ................................................................ 3-48
3-50. Wave Generator Verification........................................................... 3-50
3-51. Verification at 1 MΩ.................................................................... 3-50
3-52. Verification at 50 Ω..................................................................... 3-52
3-53. Pulse Width Verification.................................................................. 3-53
3-54. Pulse Skew Calibration and Verification......................................... 3-54
3-55. Calibration.................................................................................... 3-55
3-56. Verification .................................................................................. 3-55
3-57. Pulse Period Verification ................................................................. 3-56
3-58. MeasZ Resistance Verification ........................................................ 3-56
3-59. MeasZ Capacitance Verification...................................................... 3-57
3-60. Overload Function Verification ....................................................... 3-58
3-61. Hardware Adjustments ......................................................................... 3-59
3-62. Equipment Required......................................................................... 3-59
3-63. Adjusting the Leveled Sine Wave Function..................................... 3-59
3-64. Equipment Setup.......................................................................... 3-59
3-65. Adjusting the Leveled Sine Wave VCO Balance........................ 3-60
3-66. Adjusting the Leveled Sine Wave Harmonics............................. 3-60
3-67. Adjusting the Aberrations for the Edge Function ............................ 3-61
3-68. Equipment Setup.......................................................................... 3-61
3-69. Adjusting the Edge Aberrations................................................... 3-62
4 Maintenance........................................................................................ 4-1
4-1. Introduction........................................................................................... 4-3
4-2. Replacing the Line Fuse ....................................................................... 4-3
4-3. Cleaning the Air Filter.......................................................................... 4-4
4-4. General Cleaning.................................................................................. 4-6
4-5. Service Information .............................................................................. 4-6
5 Options................................................................................................ 5-1
5-1. Introduction........................................................................................... 5-3
5-2. 5820A-5 Option.................................................................................... 5-3
5-3. GHz Module ......................................................................................... 5-3
5-4. GHz Option Specifications............................................................... 5-3
5-5. Fast Edge Specifications .................................................................. 5-3
5-6. Leveled Sine Wave (> 600 MHz ) Specifications............................ 5-4
5-7. Time Marker Specifications............................................................. 5-5
5-8. Theory of Operation......................................................................... 5-5
5-9. Fast Edge Adjustment for the GHz Module..................................... 5-6
5-10. GHz Leveled Sine Wave Frequency Verification............................ 5-9
5-11. GHz Leveled Sine Wave Harmonics Verification ........................... 5-10
5-12. Verification Tables ............................................................................... 5-11
5-13. Verification Tables for Channels 2-5 ................................................... 5-21
5-14. Leveled Sine Flatness (< 600 MHz)................................................. 5-21
5-15. Pulse Width ...................................................................................... 5-23
5-16. Edge Rise Time Verification (Channels 2-5)................................... 5-24

5820A
Service Manual
iv
5-17. Pulse Skew........................................................................................ 5-25
5-18. Channel 2 DMM Input..................................................................... 5-25
5-19. Channel 3 DMM Input..................................................................... 5-27
5-20. Channel 4 DMM Input..................................................................... 5-28
5-21. Channel 5 DMM Input..................................................................... 5-29
5-22. Capacitance ...................................................................................... 5-30
6 Replaceable Parts............................................................................... 6-1
6-1. Introduction........................................................................................... 6-3
6-2. How to Obtain Parts.............................................................................. 6-3
6-3. List of Replacement Parts..................................................................... 6-3
Index

v
List of Tables
Table Title Page
1-1. General Specifications ........................................................................................... 1-6
1-2. Volt Specifications................................................................................................. 1-8
1-3. DC Volt Measure Specifications ........................................................................... 1-8
1-4. Edge Specifications................................................................................................ 1-9
1-5. Leveled Sine Wave Specifications (≤600 MHz ).................................................. 1-10
1-6. Time Marker Specifications................................................................................... 1-11
1-7. Wave Generator Specifications.............................................................................. 1-12
1-8. Pulse Generator Specifications .............................................................................. 1-13
1-9. Trigger Signal Specifications (Pulse Function)..................................................... 1-13
1-10. Trigger Signal Specifications (Time Marker Function)......................................... 1-13
1-11. Trigger Signal Specifications (Edge Function)...................................................... 1-14
1-12. Trigger Signal Specifications (Square Wave Voltage Function)........................... 1-14
1-13. TV Trigger Signal Specifications .......................................................................... 1-14
1-14. Tunnel Diode Drive Capability.............................................................................. 1-14
1-15. Oscilloscope Input Resistance Measurement Specifications................................. 1-14
1-16. Oscilloscope Input Capacitance Measurement Specifications .............................. 1-14
1-17. Overload Measurement Specifications .................................................................. 1-15
1-18. Auxiliary Input Performance.................................................................................. 1-15
1-19. Current Output Specifications................................................................................ 1-15
3-1. Scope Calibrator Calibration and Verification Equipment.................................... 3-3
3-2. Voltage HP3458A Settings.................................................................................... 3-7
3-3. Edge and Wave Generator HP3458A Settings....................................................... 3-8
3-4. Verification Methods for Scope Calibrator Functions........................................... 3-19
3-5. DC Voltage Verification........................................................................................ 3-21
3-6. DC Voltage Verification at 50 Ω........................................................................... 3-22
3-7. AC Voltage Amplitude Verification...................................................................... 3-24
3-8. AC Voltage Verification at 50Ω............................................................................ 3-25
3-9. AC Voltage Frequency Verification...................................................................... 3-26
3-10. DC Voltage Measurement Verification ................................................................. 3-27
3-11. DC Voltage Verification at 1 MΩ......................................................................... 3-28
3-12. Edge and Wave Generator HP3458A Settings....................................................... 3-28
3-13. AC Current Verification......................................................................................... 3-29
3-14. Edge Amplification Verification............................................................................ 3-30
3-15. Edge Frequency Verification ................................................................................. 3-31
3-16. Edge Rise Time Verification.................................................................................. 3-33

5820A
Service Manual
vi
3-17. Edge Aberrations.................................................................................................... 3-33
3-18. Tunnel Diode Pulser Verification.......................................................................... 3-34
3-19. Leveled Sine Wave Amplitude Verification.......................................................... 3-35
3-20. Low Frequency Flatness Verification at 5.5 V...................................................... 3-37
3-21. High Frequency Flatness Verification ................................................................... 3-38
3-22. Leveled Sine Wave Harmonics Verification ......................................................... 3-48
3-23. Marker Generator Verification .............................................................................. 3-49
3-24. Wave Generator Verification at 1 MΩ.................................................................. 3-51
3-25. Wave Generator Verification at 50 Ω.................................................................... 3-52
3-25. Pulse Generator Verification: Pulse Width............................................................ 3-54
3-25. Pulse Skew............................................................................................................. 3-55
3-25. Pulse Generator Verification: Period..................................................................... 3-56
3-26. MeasZ Resistance Verification.............................................................................. 3-57
3-27. MeasZ Capacitance Verification............................................................................ 3-58
4-1. Replacement Fuses................................................................................................. 4-3
5-1. Fast Edge Specifications........................................................................................ 5-3
5-2. Leveled Sine Wave Specifications (> 600 MHz)................................................... 5-4
5-3. Time Marker Specifications................................................................................... 5-5
5-4. Leveled Sine Wave Frequency Verification (Channels 1, 2, and 5)..................... 5-11
5-5. Fast Edge Rise Time for Channels 1, 2, and 5....................................................... 5-11
5-6. Leveled Sine Wave Harmonics Verification (Channels 1, 2, and 5)..................... 5-12
5-7. GHz Leveled Sinewave Verification: Flatness (Channels 1, 2, and 5).................. 5-14
5-8. Leveled Sine Flatness (5.5 V) (Channel 2)............................................................ 5-21
5-9. Leveled Sine Flatness (5.5 V) (Channel 3)............................................................ 5-22
5-10. Leveled Sine Flatness (5.5 V) (Channel 4)............................................................ 5-22
5-11. Leveled Sine Flatness (5.5 V) (Channel 5)............................................................ 5-23
5-12. Pulse Width............................................................................................................ 5-23
5-13. Edge Rise Time (Channel 2).................................................................................. 5-24
5-14. Edge Rise Time (Channel 3).................................................................................. 5-24
5-15. Edge Rise Time (Channel 4).................................................................................. 5-24
5-16. Edge Rise Time (Channel 5).................................................................................. 5-24
5-17. Pulse Skew............................................................................................................. 5-25
5-18. Levsine Amplitude................................................................................................. 5-25
5-19. DC Voltage 1 MΩ.................................................................................................. 5-25
5-20. AC Voltage 1 MΩ.................................................................................................. 5-26
5-21. Edge Amplitude...................................................................................................... 5-26
5-22. Levsine Amplitude................................................................................................. 5-27
5-23. DC Voltage 1 MΩ.................................................................................................. 5-27
5-24. AC Voltage 1 MΩ.................................................................................................. 5-27
5-25. Edge Amplitude...................................................................................................... 5-27
5-26. Levsine Amplitude................................................................................................. 5-28
5-27. DC Voltage 50 Ω................................................................................................... 5-28
5-28. AC Voltage 50 Ω................................................................................................... 5-28
5-29. Edge Amplitude...................................................................................................... 5-29
5-30. Levsine Amplitude................................................................................................. 5-29
5-31. DC Voltage 1 MΩ.................................................................................................. 5-29
5-32. AC Voltage 1 MΩ.................................................................................................. 5-29
5-33. Edge Amplitude...................................................................................................... 5-30
5-34. Capacitance (Channels 2-5) ................................................................................... 5-30
6-1. 5820A Manuals...................................................................................................... 6-4
6-2. Front Panel Module List of User Replaceable Parts.............................................. 6-4
6-3. Rear Panel Module List of Replaceable Parts........................................................ 6-7
6-4. Chassis Module List of Replaceable Parts............................................................. 6-9
6-5. Single Channel Without GHz Option List of Replaceable Parts........................... 6-12
6-6. Single Channel With GHZ Option List of Replaceable Parts................................ 6-15

vii
List of Figures
Figure Title Page
1-1. 5820A Multi-Product Calibrator............................................................................ 1-3
1-2. 5820A Calibrator Dimensional Outline................................................................. 1-6
2-1. Signal Diagram of Chassis..................................................................................... 2-4
2-2. Block Diagram of Scope Module........................................................................... 2-5
2-3. Signal Diagram of Scope Module.......................................................................... 2-6
3-1. Setup for Scope Calibrator Voltage Square Wave Measurements ........................ 3-8
3-2. Setup for Scope Calibrator Edge and Wave Gen Square Wave Measurements.... 3-9
3-3. Connecting the Calibrator Mainframe to the 5790A AC Measurement Standard. 3-14
3-4. Setup for MeasZ Calibration.................................................................................. 3-17
3-5. Setup for AC Voltage Frequency Verification ...................................................... 3-26
3-6. Setup for Edge Rise Time Verification.................................................................. 3-32
3-7. Setup for Leveled Sine Wave Harmonics Verification.......................................... 3-47
3-8. Setup for Wave Generator Function ...................................................................... 3-50
3-9. Setup for Overload Function Verification ............................................................. 3-58
3-10. Adjusting the Leveled Sine Wave Balance............................................................ 3-60
3-11. Adjusting the Leveled Sine Wave Harmonics....................................................... 3-61
3-12. Adjusting Short-Term Edge................................................................................... 3-63
4-1. Accessing the Fuse................................................................................................. 4-4
4-2. Accessing the Air Filter ......................................................................................... 4-5
5-1. GHz Block Diagram............................................................................................... 5-6
5-2. Fast Edge Full Wave Form..................................................................................... 5-7
5-3. Porch ...................................................................................................................... 5-8
5-4. Bullet on the Porch................................................................................................. 5-8
5-5. Critically Triggered Edge at Porch Height Level I................................................ 5-9
5-6. Critically Distorted Edge at Porch Height Level II................................................ 5-9
5-7. Setup for Leveled Sine Wave Harmonics Verification.......................................... 5-10
6-1. Final Assembly....................................................................................................... 6-5

5820A
Service Manual
viii

1-1
Chapter 1
Introduction and Specifications
Title Page
1-1. Introduction........................................................................................... 1-3
1-2. How to Contact Fluke........................................................................... 1-4
1-3. Instruction Manuals.............................................................................. 1-4
1-4. 5820A Operators Manual................................................................. 1-4
1-5. 5820A Service Manual..................................................................... 1-5
1-6. Specifications........................................................................................ 1-5
1-7. General Specifications.......................................................................... 1-6
1-8. Volt Specifications........................................................................... 1-8
1-9. DC Volt Measure Specifications...................................................... 1-8
1-10. Edge Specifications.......................................................................... 1-9
1-11. Leveled Sine Wave Specifications................................................... 1-10
1-12. Time Marker Specifications............................................................. 1-11
1-13. Wave Generator Specifications........................................................ 1-12
1-14. 1 ns Pulse Generator Specifications................................................. 1-13
1-15. Trigger Signal Specifications (Pulse Function) ............................... 1-13
1-16. Trigger Signal Specifications (Time Marker Function)................... 1-13
1-17. Trigger Signal Specifications (Edge Function)................................ 1-14
1-18. Trigger Signal Specifications (Square Wave Voltage Function)..... 1-14
1-19. Trigger Signal Specifications (TV).................................................. 1-14
1-20. Tunnel Diode Drive Capability........................................................ 1-14
1-21. Oscilloscope Input Resistance Measurement Specifications........... 1-14
1-22. Oscilloscope Input Capacitance Measurement Specifications......... 1-14
1-23. Overload Measurement Specifications............................................. 1-15
1-24. External Reference Input Specifications.......................................... 1-15
1-25. Auxiliary Input Specifications.......................................................... 1-15
1-26. Current Output Specifications.......................................................... 1-15

5820A
Service Manual
1-2

Introduction and Specifications
Introduction
1
1-3
1-1. Introduction
The Fluke Model 5820A Oscilloscope Calibrator (Figure 1-1) is a precise instrument that
calibrates analog and digital oscilloscopes. Specifications are provided in this chapter.
Warning
To prevent electric shock or other possible injuries, the 5820A
Calibrator must be operated in the way specified by this manual
or other documentation provided by Fluke.
WCaution
Input voltages exceeding 30 V dc may cause damage to the
instrument. Do not apply voltages except in voltage
measurement mode.
Features of the 5820A Calibrator include the following:
•Automatic meter error calculation.
•%and keys that change the output value to pre-determined cardinal values
for various functions.
•Programmable entry limits that prevent invalid amounts from being entered.
•Edge, Leveled Sine, Pulse, Marker, and Wave Generation modes.
•Accurate oscilloscopic input impedance measurement.
•Tunnel Diode Pulse compatibility.
•DC Volt Measure Mode.
•Current Mode generates both DC and low frequency ac current.
•1 ns to 500 ns pulse width capability with skew controlled trigger.
0•
123
456
789
ENTER
FIELD
EDIT
/
+
MENU
PREV
RESETCE
MULT
x
DIV
÷
sec
VNEW
REF
Hz
M
SETUP
MODES
MORE
CHAN
dBm
n
INPUT
AUX
OPR
STBY
k
m
µ
MARKER
LEVSINE
EDGE
VOLT
20V PK MAX
100 mA MAX
POWER
I
O
5820A
OSCILLOSCOPE
CALIBRATOR • 2GHz
EXT TRIG
EXT TRIG
SOURCE/MEASURE
CHAN 1 CHAN 2
CHAN 3 CHAN 4
CHAN 5
20V PK
MAX
CHAN 1-5
AUX
INPUT
20V PK
MAX 20V PK
MAX
CAT
130V
PK
MAX
SOURCE
30V DC
MAX
MEASURE
yh001f.eps
Figure 1-1. 5820A Oscilloscope Calibrator

5820A
Service Manual
1-4
•External reference.
•Auxiliary input.
•5-channel output (5-Channel Option). The 5-Channel Option allows you to calibrate
up to five oscilloscope channels simultaneously without changing cables.
•Simultaneous output of a signal and a trigger signal.
•600 MHz, Leveled Sine wave output.
•Optional 600 MHz - 2.1 GHz, Leveled Sine wave output with 150 ps fast edge.
•Standard IEEE-488 (GPIB) interface, complying with ANSI/IEEE Standards
488.1-1987 and 488.2-1987.
•EIA Standard RS-232-C serial data interface for printing, displaying, or transferring
internally stored calibration constants, and for remote control of the 5820A.
•Pass-through RS-232-C serial data interface for communicating with the Unit Under
Test (UUT).
•Extensive automatic internal self testing and diagnostics of analog and digital
functions.
1-2. How to Contact Fluke
USA and Canada: 1-888-99-FLUKE (1-888-993-5853)
Europe: [phone]
Japan: [phone]
Singapore: [phone]
Anywhere in the world: [phone]
For additional information about Fluke, its products, and services, visit Fluke’s web site
at: www.fluke.com
1-3. Instruction Manuals
The 5820A Manual Set provides complete information for operators and service or
maintenance technicians. The set includes:
•5820A Operators Manual (PN 802154)
•5820A Service Manual (PN 673142)
The 5820A Operators Manual ships with the instrument. The 5820A Service Manual is
optional. Order additional copies of the manuals separately using the part number
provided. For ordering instructions, refer to the Fluke Catalog, or ask a Fluke sales
representative. These manuals are also available on Fluke's web sitewww.fluke.com.
1-4. 5820A Operators Manual
The 5820A Operators Manual provides complete information for installing the 5820A
Oscilloscope Calibrator and operating it from the front panel keys and in remote
configurations. The manual also provides a glossary of calibration, specifications, and
error code information. The 5820A Operators Manual includes the following topics:
•Installation
•Operating controls and features, including front panel operation
•Remote operation (IEEE-488 bus or serial port remote control)

Introduction and Specifications
Specifications
1
1-5
•Serial port operation (printing, displaying, or transferring data, and setting up for
serial port remote control)
•Operator maintenance, including verification procedures and calibration approach
for the 5820A
•Accessories
•Error Messages
1-5. 5820A Service Manual
This 5820A Service Manual includes: product specifications, appropriate theory of
operation, calibration and verification procedures, maintenance information, and options.
1-6. Specifications
The following paragraphs describe the details for the 5820A specifications. All
specifications are valid after allowing a warm-up period of 30 minutes, or twice the time
the 5820A has been turned off. (For example, if the 5820A has been turned off for 5
minutes, the warm-up period is 10 minutes.)
All specifications apply for the temperature and time period indicated. For temperatures
outside of tcal + 5 °C (tcal is the ambient temperature when the 5820A was calibrated),
the temperature coefficient is less than 0.1 times the 1-year specification per °C (limited
to 0 °C - 50 °C).
If you ordered the GHz Option, the following specification tables are supplemented by
the tables with similar headings in Chapter 5:
•Edge Specifications
•Leveled Sine Wave Specifications
Refer to Figure 1-2 for the dimensional outline of the 5820A Calibrator.

5820A
Service Manual
1-6
I
O
0•
123
456
789
ENTER
k sec
m
µVNEW
REF
Hz
FIELD
EDIT
/
+
VOLT EDGE LEVSINE MARKER MENU
PREV
M
RESET
SETUP
CE
MODES
MORE
CHAN
dBm
n
MULT
xDIV ÷
INPUT
AUX
OPR
STBY
43.2 cm (17 in)
47.0 cm (18.5 in) 6.4 cm
(2.5 in)
For Cable
Access
17.8 cm
(7 in)
CHAN 2
CHAN 4
EXT TRIG
EXT TRIG
SOURCE/MEASURE
CHAN 1 CHAN 2
CHAN 3 CHAN 4
CHAN 5
20V PK
MAX
CHAN 1-5
AUX
INPUT
20V PK
MAX 20V PK MAX
CAT
130V
PK
MAX
SOURCE
30V DC
MAX
MEASURE
5820A
OSCILLOSCOPE
CALIBRATOR • 2GHz
yh003f.eps
Figure 1-2. 5820A Calibrator Dimensional Outline
1-7. General Specifications
Table 1-1. General Specifications
Warmup Time Twice the time since last warmed up, to a maximum of 30 minutes
Settling Time 5 seconds or faster for all functions and ranges
Standard Interfaces IEEE-488 (GPIB), RS-232
Temperature Performance Operating: 0 °C to 50 °C
Calibration (tcal): 15 °C to 35 °C
Storage: -20 °C to 70 °C
Electromagnetic
Compatibility Designed to operate in Standard Laboratory environments where the
Electromagnetic environment is highly controlled. If used in areas with
Electromagnetic fields > 1 V/m, there could be errors in output values.
From 80 -252 MHz, the current output is susceptible to a field strength of
> 0.165 V/M.

Introduction and Specifications
General Specifications
1
1-7
Temperature Coefficient Temperature Coefficient for temperatures outside tcal ±5 °C is 0.1X/°C of
1-year specification.
Relative Humidity Operating: < 80 % to 30 °C, < 70 % to 40 °C,< 40 % to 50 °C
Storage: < 95 %, noncondensing
Altitude Operating: 3,050 m (10,000 ft) maximum
Nonoperating: 12,200 m (40,000 ft) maximum
Safety Designed to comply with IEC 1010-1 (1992-1); ANSI/ISA-S82.01-1994;
CAN/CSA-C22.2 No. 1010.1-92
Interface Impedance The 5820A is designed to drive both 50 Ωand 1MΩloads.
Analog Low Isolation 20 V
EMC Complies with EN 61326-1
Line Power Line Voltage (selectable): 100 V, 120 V, 220 V, 240 V
Line Frequency: 47 to 63 Hz
Line Voltage Variation: ±10 % about line voltage setting
Power Consumption 250 VA
Dimensions Height: 17.8 cm (7 inches), standard rack increment, plus 1.5 cm
(0.6 inch) for feet on bottom of unit;
Width: 43.2 cm (17 inches), standard rack width
Depth: 47.3 cm (18.6 inches) overall.
Weight 20 kg (44 pounds)

5820A
Service Manual
1-8
1-8. Volt Specifications
Table 1-2. Volt Specifications
Volt Function DC Signal Square Wave Signal [1]
Load into 50 Ωinto 1 MΩinto 50 Ωinto 1 M Ω
Amplitude Characteristics
Range 0 V to ±6.6 V 0 V to ±130 V ±1 mV to
±6.6 V p-p ±1 mV to ±130 V p-p
range resolution
Resolution 1mV to 24.999 mV
25 mV to 109.99 mV
110 mV to 2.1999 V
2.2 V to 10.999 V
11 V to 130 V
1µV
10 µV
100 µV
1 mV
10 mV
Adjustment Range Continuous
1-Year Absolute Uncertainty, tcal ±5 °C±(0.25% of
output
+ 40 µV)
±(0.025%
of output +
25 µV)
±(0.25%
of output
+ 40 µV)
±(0.05%
of output
+ 5 µV) [2]
Sequence 1-2-5 (e.g., 10 mV, 20 mV, 50 mV)
Square Wave Frequency Characteristics
Range 10 Hz to 10 kHz
1-Year Absolute Uncertainty, tcal ±5 °C±(0.33 ppm of setting)
Typical Aberration (from 50% of
leading/trailing edge)
25 mV to 130 V: within 4 µs
10 mV to 25 mV: within 8 µs
1 mV to 10 mV: within 14 µs
< (0.5% of output + 100 µV)
[1] Positive or negative, zero referenced square wave.
[2] Above 1 kHz, ±(0.25% of output + 40 µV). Assumes connectors and cables are in good condition.
WCaution
Input voltages exceeding 30 V dc may cause damage to the
instrument.
1-9. DC Volt Measure Specifications
Table 1-3. DC Volt Measure Specifications
Voltage Range Voltage Accuracy
DCV ±10 V maximum with 1 mV resolution 0 to ±5.99 V - 0.05% ±1 mV
6 to ±10 V – 0.25% ±10 mV
> 1 MΩinput impedance (measure voltage across
1 MΩinput resistor)
