Fluke 729 Pro User manual

729 Pro
Automatic Pressure Calibrator
Users Manual
October 2020
© 2020 Fluke Corporation. All rights reserved.
Specifications are subject to change without notice.
All product names are trademarks of their respective companies.

LIMITED WARRANTY AND LIMITATION OF LIABILITY
Each Fluke product is warranted to be free from defects in material and workmanship under normal use and
service. The warranty period is three years and begins on the date of shipment. Parts, product repairs, and
services are warranted for 90 days. This warranty extends only to the original buyer or end-user customer of a
Fluke authorized reseller, and does not apply to fuses, disposable batteries, or to any product which, in Fluke's
opinion, has been misused, altered, neglected, contaminated, or damaged by accident or abnormal conditions of
operation or handling. Fluke warrants that software will operate substantially in accordance with its functional
specifications for 90 days and that it has been properly recorded on non-defective media. Fluke does not warrant
that software will be error free or operate without interruption.
Fluke authorized resellers shall extend this warranty on new and unused products to end-user customers only but
have no authority to extend a greater or different warranty on behalf of Fluke. Warranty support is available only if
product is purchased through a Fluke authorized sales outlet or Buyer has paid the applicable international price.
Fluke reserves the right to invoice Buyer for importation costs of repair/replacement parts when product purchased
in one country is submitted for repair in another country.
Fluke's warranty obligation is limited, at Fluke's option, to refund of the purchase price, free of charge repair, or
replacement of a defective product which is returned to a Fluke authorized service center within the warranty
period.
To obtain warranty service, contact your nearest Fluke authorized service center to obtain return authorization
information, then send the product to that service center, with a description of the difficulty, postage and insurance
prepaid (FOB Destination). Fluke assumes no risk for damage in transit. Following warranty repair, the product will
be returned to Buyer, transportation prepaid (FOB Destination). If Fluke determines that failure was caused by
neglect, misuse, contamination, alteration, accident, or abnormal condition of operation or handling, including
overvoltage failures caused by use outside the product’s specified rating, or normal wear and tear of mechanical
components, Fluke will provide an estimate of repair costs and obtain authorization before commencing the work.
Following repair, the product will be returned to the Buyer transportation prepaid and the Buyer will be billed for the
repair and return transportation charges (FOB Shipping Point).
THIS WARRANTY IS BUYER'S SOLE AND EXCLUSIVE REMEDY AND IS IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. FLUKE SHALL NOT BE LIABLE FOR ANY
SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LOSSES, INCLUDING LOSS OF
DATA, ARISING FROM ANY CAUSE OR THEORY.
Since some countries or states do not allow limitation of the term of an implied warranty, or exclusion or limitation
of incidental or consequential damages, the limitations and exclusions of this warranty may not apply to every
buyer. If any provision of this Warranty is held invalid or unenforceable by a court or other decision-maker of
competent jurisdiction, such holding will not affect the validity or enforceability of any other provision.
11/99
Fluke Corporation
P.O. Box 9090
Everett, WA 98206-9090
U.S.A.
Fluke Europe B.V.
P.O. Box 1186
5602 BD Eindhoven
The Netherlands

i
Table of Contents
Title Page
Introduction ............................................................................................... 1
Contact Fluke ............................................................................................ 2
Safety ........................................................................................................ 2
Standard Equipment ................................................................................. 2
Buttons ...................................................................................................... 4
Display ...................................................................................................... 6
Triple-Function Display....................................................................... 9
RTD Connection ................................................................................. 9
Pressure Module Connection ............................................................. 10
Ports.......................................................................................................... 11
Setup Menu............................................................................................... 12
729 Pro Information ............................................................................ 13
729 Pro Setup..................................................................................... 14
Manage Users .................................................................................... 15
Manage Test Results.......................................................................... 15
Manage Screen Shots ........................................................................ 16
Manage Custom Tasks....................................................................... 16
Maintenance Menu ............................................................................. 16
Drain Water (Condensation) ........................................................ 16
Keypad Test ................................................................................. 17
Exhaust ........................................................................................ 17
Tasks Menu............................................................................................... 18
Pressure Transmitter (P/I) .................................................................. 18
Pressure Switch (SW)......................................................................... 19
Current to Pressure Test (I/P)............................................................. 21
Pressure Leak Test............................................................................. 22
Pressure Transmitter (P/V) ................................................................. 23
Pressure Transmitter (P/P) ................................................................. 24
HART Functionality ................................................................................... 25
Loop Power +24V ON......................................................................... 26
Enable HART 250W ........................................................................... 26

729 PRO
Users Manual
729 PRO
Users Manual
ii
HART Menu............................................................................................... 27
HART Data.......................................................................................... 27
HART Service ..................................................................................... 27
PV Zero Trim ................................................................................ 28
mA Output Trim ............................................................................ 28
Trim to Applied Values ................................................................. 28
Set Fixed mA Output .................................................................... 28
Re-range Transmitter ................................................................... 28
Device Diagnostics ....................................................................... 29
Calibrate (Ad hoc) ............................................................................... 29
Adjust............................................................................................ 30
PV Zero Trim ................................................................................ 30
mA Output Trim ............................................................................ 30
Trim to Applied Values ................................................................. 30
As Left .......................................................................................... 31
Find Task by Tag ................................................................................ 31
Bus Polling .......................................................................................... 31
Measure Mode........................................................................................... 31
Current Measurement ......................................................................... 31
Volts Measurement ............................................................................. 32
Pressure Measurement....................................................................... 32
Autostep and Auto Ramp the Output Value ........................................ 34
Autostep.............................................................................................. 34
Auto Ramp the Output............................................................................... 35
Temperature Measurement................................................................. 36
Source mA Mode ................................................................................ 36
4 to 20 mA Simulation ......................................................................... 37
Log............................................................................................................. 38
Communication with a PC ......................................................................... 39
Battery ....................................................................................................... 39
Charge the Battery.............................................................................. 39
Battery Life.......................................................................................... 40
Maintenance .............................................................................................. 40
In Case of Difficulty ............................................................................. 40
Battery Replacement........................................................................... 41
PMM Replacement.............................................................................. 42
Update Product Firmware ................................................................... 42
Calibration Data .................................................................................. 43
Service Center Calibration or Repair .................................................. 43
Error Messages................................................................................... 43
HART Commands............................................................................... 47
Documenting Functionality.................................................................. 47
Strap .......................................................................................................... 48

Automatic Pressure Calibrator
Table of Contents
iii
User-Replaceable Parts and Accessories................................................. 48
Specifications ............................................................................................ 49
Pressure Specification........................................................................ 49
Electrical Specification........................................................................ 49
Pressure Measurement Module Specification ................................... 50
Mechanical Specification .................................................................... 50
Environmental Specification ............................................................... 50
Safety ................................................................................................. 50
Electromagnetic Compatibility (EMC) ................................................. 51

729 PRO
Users Manual
729 PRO
Users Manual
iv

1
Introduction
The Fluke 729 Pro Automatic Pressure Calibrators (the Product) are portable field
pressure calibration tools for lab or field use. This battery-operated product performs
automatic pressure calibration of transmitters, pressure switches, and gauges. The
automatic functions are done by the Product or by downloaded tasks from calibration-
management software (CMS). The Product also supplies basic HART®communicator
functions when used with HART-capable transmitters.
Product key features and benefits include:
• Automatic pressure calibration of transmitters, pressure switches, and pressure
gauges.
• Source and measure pressure to test and calibrate pressure sensors, transmitters,
and other pressure instruments.
• Source and simulate milliamp signals while measuring pressure for testing current to
pressure converters (I/P).
• HART (Highway Addressable Remote Transducer) communication to configure and
perform trim on HART smart-pressure transmitters.
• Provides Loop Power and simultaneously measures mA output from a connected
device.
• Measures pressure with all Fluke-750P Series pressure modules.
• Document automated as-found/as-left procedures to satisfy quality regulations or
audits with DPCTrack2 software.
• Advanced features like auto step and auto ramp allow tests of devices automatically.
• The pressure switch test automatically ramps pressure up and down across expected
switch trip setting to calibrate pressure switches.
• Interchangeable Pressure Measurement Modules

729 Pro
Users Manual
2
Contact Fluke
Fluke Corporation operates worldwide. For local contact information, go to our website:
www.fluke.com.
To register your product, view, print, or download the latest manual or manual
supplement, go to our website.
Fluke Corporation
P.O. Box 9090
Everett, WA 98206-9090
[phone]
[email protected]
Safety
General Safety Information is in the printed Safety Information document that ships with
the Product and at www.fluke.com. More specific safety information is listed where
applicable.
A Warning identifies conditions and procedures that are dangerous to the user. A
Caution identifies conditions and procedures that can cause damage to the Product or
the equipment under test.
Standard Equipment
Table 1is a list of the standard equipment.

Automatic Pressure Calibrator
Standard Equipment
3
Table 1. Standard Equipment
Item Description Item Description
729 Pro Automatic Pressure Calibrator Fitting, 1/8 in NPT-Female x 1/4 in
NPT-Female
AC/DC converter Fitting, 1/8 in NPT-Male x G1/4-Male
Mains line cable Fitting, 1/8 in NPT-Female x
M20-Female
Rechargeable Li-ion Battery Fitting, 1/4 in BSP-Female x 1/8 in
NPT-Female
Stackable test lead set Pressure measurement module
(PMM)
AC280 Sure Grip hook set (red and black) Hose to drain condensed water
generated from the Product. 1/8 in
diameter, 1 ft length
Alligator clips (red and black)
Not
shown
Adjustable quick-release strap for
hanging the Product
One set of TP220 test probes
(red and black) Safety Information
USB communication cable: 3 ft (1 m)
Type A plug for host (PC) to Mini-B plug for
device
Traceable calibration report with data
Flex tube, 2 mm diameter, 5 ft (1.5 m)
length PTFE Tape
3
12456
7
8
9
10
11 12 13 14
16
15

729 Pro
Users Manual
4
Buttons
Table 2is a list of the Product buttons and the softkeys.
Table 2. Buttons
Item Description
Push Nto turn on or turn off the Product.
Push Fto move to the previous user interface (UI) screen. When navigating through the
screens, Fcan move out of most screens and with repeated pushes, can take you all the
way to the startup screen.
ABCD: Performs the specified function of the label above each
softkey on the display. These labels change throughout the UI.
WXYZ: Push to move the display cursor left, right, up, or down. Cursor highlights in yellow
over the selection.
Push Rto make a selection on the UI. This button cannot confirm number or character
choices (push E).
Push Ito change the display brightness from dim to bright and back again.
Numeric keypad. Used when a numeric entry is necessary.
Push Eto make a selection on the UI. Only ENTER confirms numbers and characters.
Confirm all editable items with ENTER.
Push Pto clear highlighted entry. When PI/PV/IP/SWT starts, push to zero the pressure
reading.
Push Mto select the mA measure function.
Push Vto select the measure dc voltage function.
4
13 98
12 11
10
7
6
5
3
2
1
18
16
15
14
17

Automatic Pressure Calibrator
Buttons
5
Item Description
Push Sto enter the Setup menu to change operating parameters. See Setup Menu.
Push Tto enter the Tasks menu. See Tasks Menu.
Push Uto release pressure at the internal pressure port. VENTING shows on the display
as the Product vents. VENTED shows after venting is complete.
Q: Use this function to output (source) a target pressure from the Product. Use the arrows
to select the Setpoint field and enter the values with the number buttons.
L: Use this function for pressure measurement mode.
Push Gto enter HART communication mode.
Push Hto freeze the reading on the display. Push Ha second time to release the hold on
the display. Push and hold to capture the screen and save into memory.
Table 2. Buttons (cont.)

729 Pro
Users Manual
6
Display
Table 3shows the details of the display.
Table 3. Display
Item Description Item Description
Step size indicator Pressure units indicator
Setpoint indicator 
External display shows selected device that
is connected. The device can be a pressure
module, temperature probe, process variable
(PV) of connected HART device, or Fluke
Connect secondary device reading.
Main display with measured or
sourced value Softkey indicator
HART on indicator Current, voltage, or pressure switch display
24 volt loop power active indicator Pressure Measurement Module indicator
Battery charge level Time and date display
Pressure port status
13
12
11
10
9
8
7
6542
13

Automatic Pressure Calibrator
Display
7
The display can also show different configurations:
Typically, the display does shows two functions, see Figure 1.
See Triple-Function Display for more information.
• The upper display for the internal pressure has these functions:
◦VENT
◦SOURCE
◦MEASURE
• The lower display shows these functions:
◦Measure Current
◦Source Current
◦Simulate Current
◦Measure VDC
◦Switch
Figure 1. Typical Dual-Function Display

729 Pro
Users Manual
8
The screen has two sections:
The upper display shows the internal pressure controller status and includes:
•Mode: Measure, Source, and Vent
•Pressure Value: Current measured pressure and unit
•Status: Shows nothing in measure mode, NOT READY, STABLE in source mode,
and VENTING, VENTED in vent mode.
•Setpoint: Current setpoint for source function.
•Step Size: The step size when B (Step Up) and C (Step Down) are
pushed when sourcing pressure.
The lower display shows the electrical status and includes:
•Mode: Measure Current, Source Current, Simulate Current, Measure V dc, and
Switch.
•Reading: Current reading from measure functions or setpoint for source functions.
•Switch State: Shows the pressure reading when the switch contacts open and close.
•Percent: Shows the percentage value of 4 mA to 20 mA or 1 V to 5 V in measure
functions.
•Status: Shows Open circuit detected in mA source mode.

Automatic Pressure Calibrator
Display
9
Triple-Function Display
When the third function (RTD, External Pressure Module, HART Transmitter, or FC
secondary device) is connected, the Product changes to triple-function display
automatically. In the subsequent triple-function display, the original bottom half of the
display is divided into two parts:
• The left display continues to show the electrical measurement display.
• The right display shows the model name, reading, and units from the selected third
function. See Figure 2. The figure shows a transmitter device (3051C).
When more than one third function is available, use the arrow keys to highlight the
device (in yellow) in the right display. Then use the softkeys to select the device to show.
Figure 2. Triple-Function Display
RTD Connection
The display can show RTD temperature measurements in the selected unit (C/F) as the
third-function. When the temperature unit field highlights, push the softkey to toggle the
temperature setting. The Oreading shows.
Note
The Product supports PT100-385 RTD only.

729 Pro
Users Manual
10
Pressure Module Connection
The Product automatically detects external pressure module installation or removal.
Move the cursor to the unit type and push E to configure the pressure-unit type (it can
be different from the pressure unit of internal pressure). Change the unit type of the
internal pressure to automatically change the unit type of the pressure module.
Figure 3shows a pressure module as the third function.
• When you plug in an external pressure module, the pressure-unit type defaults to the
internal pressure unit type.
• When you remove or install an external pressure module, the zero offset resets.
Figure 3. Triple-Function Display with External Pressure Module Connected

Automatic Pressure Calibrator
Ports
11
Ports
Table 4is a list of the Product ports.
Table 4. Product Ports
Item Description
USB port – Used for communication between the Product and a PC.
Battery charger/universal power supply port. Use the battery charger for bench-top
applications that have ac line power available. Use the battery charger to charge the battery
while installed in the Product.
Rotate knob to drain water (condensation). See Maintenance Menu.
Drain port fitting connector.
External temperature port for RTD Temperature Probe
External pressure module port
Pressure connection
COM Port
Measure, source, and simulate mA; measure V dc and supply loop power.
Bottom
89
Right
7
6
5
Left
1
2
3
4
Left Right
Bottom

729 Pro
Users Manual
12
Setup Menu
Use the multi-page Setup menu to configure the Product features.
Note
For some of the submenu functions, the Product password is required. The
default password is 1234.
To access the Setup menu, push S. The Setup menu includes submenus for Product
configuration.
The submenus are:
1. 729 Pro Information
2. 729 Pro Setup
3. Manage Users
4. Manage Test Results
5. Manage Screen Shots
6. Manage Custom Tasks
7. Maintenance
Push the arrow buttons, R, or E to access these submenus. Alternatively, push the
corresponding number button for access. Push Fto go to the previous menu.
To clear all stored files, push D(Clear All Files). Enter the Product password to
use this function. This action clears all stored test results, screen shots, and custom
tasks.
The subsequent sections explain the Setup menu and submenus.

Automatic Pressure Calibrator
Setup Menu
13
729 Pro Information
The 729 Pro Information submenu is an information-only screen that shows information
about the Product. The screen shows:
• Product model
• Serial Number
• Firmware Revision: Main, PCM, EMM, and PMM
•PMMModel
• PMM Serial Number
• Last calibration date of the Product pressure components.
• Last calibration date of the Product electrical components.
The softkeys at the bottom of this screen are:
•A- Calibrate Pressure
Follow the prompts on the screen and the Product takes you through a procedure that
calibrates the pressure components of the Product. Enter the Product password to
use this function. D(Options)lets you save the calibration, go back a step, skip
a step, or move to the next section. See Calibration Manual for details.
•B- Calibrate Electrical
Follow the prompts on the screen and the Product takes you through a procedure that
calibrates the electrical components of the Product. Enter the Product password to
use this function. D(Options)lets you save the calibration, go back a step, skip
a step, or move to the next section. See Calibration Manual for details.
•C- Battery Information
An information-only screen that shows if the battery is present, the remaining battery
charge level, battery temperature, and battery voltage.

729 Pro
Users Manual
14
729 Pro Setup
The 729 Pro Setup submenu shows the information in Table 5.
Table 5. 729 Pro Setup Menu
Menu
Parameter Function
Language Push Eand use the arrows to select the UI language: English, Simplified
Chinese
Date and Time
Push Eand use the arrows to access the Date and Time menu. Once inside the
menu, use the arrows to select a parameter and use the number keys to make
changes to these settings. For am or pm, push R. Once you make changes,
push D(Done) to store the new parameters. The timestamp saves with any
stored results.
Date Format Set the format of the date. Use the softkeys to select yyyy-mm-dd, mm/dd/yyyy,
or dd/mm/yyyy.
Time Format Push the softkey to select 12-hour or 24-hour time format. The format changes in
the Date Format menu. E or R also changes the format.
Number Format Push the softkey to select a decimal point or comma for the numbering format.
Push Eor Ralso changes the format.
Temperature Unit Push the softkey to select °Cor °F. E or R also changes the units.
Auto Battery
Timeout
The Product has a programmable Auto Battery Timeout feature to save the battery
charge. Push the arrow keys to highlight this line. Push E or R to reach the
timeout menu. The choices are:
• Never
•5minutes
• 10 minutes
• 15 minutes
• 30 minutes
• 60 minutes
PCM Resolution Choices are High and Low. High resolution is the normal state, and Low reduces
the resolution one digit.
HART
Communication Enable/Disable
