Fluke T+ Use and care manual

July 2007 Rev. 1, 9/17
© 2007-2017 Fluke Corporation, All rights reserved. Printed in USA.
All product names are trademarks of their respective companies.
1
T+ and T+ PRO
Electrical Tester
Calibration Information
Introduction
This document provides the following information for the T+ and T+ PRO Electrical Testers
(hereafter referred to as the “Tester” or UUT):
•Safety information
•Symbols
•Contacting Fluke
•Specifications
•Maintenance
•Performance tests
•Parts and accessories list
•Product Warranty Statement
For complete operating instructions, refer to the T+ and T+ PRO Instruction Sheet.
Safety Information
A Warning identifies conditions and procedures that are dangerous to the user. A Caution
identifies conditions and procedures that can cause damage to the Product or the equipment under
test.
XWWarning
To avoid possible electric shock or personal injury, follow these
guidelines:
•Use the Tester only as specified in this document, otherwise
the protection provided by the Tester may be impaired.
•The Tester is to be used only by qualified personnel.
•Do not use the Tester if it is damaged. Inspect the case
before use. Look for cracks or missing plastic. Pay particular
attention to the insulation surrounding the connectors.
•Inspect the test leads for damaged insulation or exposed
metal. Check the test leads for continuity. Replace damaged
test leads before using the Tester.

T+ and T+ PRO
Calibration Information
2
•Do not use the Tester if it operates abnormally. Protection
provided by the Tester may be impaired. When in doubt, have
the Tester serviced.
•Do not operate the Tester around explosive gas, vapor, or
dust.
•Do not apply more than the rated voltage, as marked on the
Tester, between terminals or between any terminal and earth
ground.
•When measuring hazardous voltage, verify the Tester’s
operation by measuring a known voltage.
•Only the test probes and batteries are serviceable. When
servicing, use only specified replacement parts.
•To determine the LEDs and beeper are working correctly,
short the test leads together. The beeper sounds (if enabled)
and all LEDs and display segments (T+ PRO) switch on
briefly indicating correct operation.
•Comply with local and national safety requirements when
working in hazardous locations.
•Use proper protective equipment, as required by local or
national authorities when working in hazardous areas.
•Use caution when working above 30 V ac rms, 42 V peak, or
60 V dc. Such voltages pose a shock hazard.
•When using probes, keep fingers away from the probe tips.
•Connect the common test lead before connecting the live test
lead. When disconnecting the test leads, disconnect the live
test lead first.
•Do not operate the Tester with the battery door or portions of
the cover removed or loosened.
•When the batteries are depleted, self test will not function.
•When the beeper is disabled, it will not sound until the beeper
is reactivated.
•For voltages above 240 V, you must only connect to a voltage
source for a MAXIMUM of 30 seconds and then disconnect for
a MINIMUM of 300 seconds.
•Perform a self test before any measurements are taken for
voltage, continuity, resistance, or rotary field. See “Self Test.”
•Exercise caution when performing measurements on PLC
inputs. When measuring relay control voltages on PLCs, be
aware that this may open or close the relay/switch.
WCaution
Although the Tester may be used with depleted batteries,
replace depleted batteries immediately to avoid Tester damage
from battery acid leakage.

Electrical Tester
Symbols
3
Symbols
Table 1 describes the symbols that appear on the Tester or in this document.
Table 1. Symbols
Symbol Explanation Symbol Explanation
WWARNING - RISK OF DANGER. Consult
user documentation. XWARNING. HAZARDOUS VOLTAGE. Risk of electric shock.
TDouble insulated Earth
)Certified by CSA Group to North American
safety standards. RContinuity beeper

Measurement Category III is applicable to
test and measuring circuits connected to the
distribution part of the building’s low-voltage
MAINS installation.
Measurement Category IV is applicable to test
and measuring circuits connected at the source
of the building’s low-voltage MAINS installation.
~
This product complies with the WEEE Directive marking requirements. The affixed label indicates that you
must not discard this electrical/electronic product in domestic household waste. Product Category: With
reference to the equipment types in the WEEE Directive Annex I, this product is classed as category 9
"Monitoring and Control Instrumentation" product. Do not dispose of this product as unsorted municipal
waste.
Contacting Fluke
To contact Fluke, call one of the following telephone numbers:
•Technical Support USA: 1-800-44-FLUKE (1-800-443-5853)
•Calibration/Repair USA: 1-888-99-FLUKE (1-888-993-5853)
•Canada: 1-800-36-FLUKE (1-800-363-5853)
•Europe: [phone]
•Japan: [phone]
•Singapore: [phone]
•China: [phone]
•Anywhere in the world: [phone]
Or, visit Fluke's website at www.fluke.com.
To register your product, visit http://register.fluke.com.
To view, print, or download the latest manual supplement, visit
http://us.fluke.com/usen/support/manuals.

T+ and T+ PRO
Calibration Information
4
Specifications
Temperature Performance
Operating ...........................................................−10 °C to 55 °C (14 °F to 131 °F)
Storage ...............................................................−30 °C to 60 °C (−22 °F to 140 °F)
Relative Humidity
90 %.................................................................... 0 °C to 30 °C (32 °F to 86 °F)
75 %.................................................................... 30 °C to 40 °C (86 °F to 104 °F)
45 %.................................................................... 40 °C to 50 °C (104 °F to 122 °F)
Altitude
Operating ............................................................ 2,000 m
Storage ............................................................... 10,000 m
Battery Type/Life................................................... AAA (2); 40 hours
Shock, Vibration.................................................... Sinusoidal vibration per MIL-PRF-28800F for a Class 2 instrument
Safety ..................................................................... ANSI/ISA S82.02.01, CSA C22.2-1010.1, IEC 61010-1 to 1000 V CAT
III/600 V CAT IV
AC Bandwidth ....................................................... 45 Hz to 66 Hz
Earth Ground......................................................... MAXIMUM working voltage 1000 V ac or dc
MAXIMUM measurable voltage 600 V ac or dc
This will be displayed on the LED and LCD (T+ PRO)
Duty Cycle..............................................................Indefinitely for voltages up to 240 V.
For voltages between 240 V to 600 V, the duty cycle is 30 s on / 300 s
off. For voltages above 240 V, the Tester must connect to a voltage
source only for a MAXIMUM of 30 s and then disconnect for a
MINIMUM of 300 s.
Voltage Hazard LED.............................................. LEDs turn on @ voltages > 30 V ac/dc ±35 %
LEDs....................................................................... LEDs turn on @ between 70 % and 100 % of the indicated voltage on
the LED, except for the 12 V LED that turns on @ between 50 % and
100 %.
Accuracy
AC voltage ..........................................................±(3 % rdg + 2 digits)
DC voltage .......................................................... ±(2 % rdg + 2 digits)
Resistance..........................................................±(5 % rdg + 3 digits)
LCD Resolution...................................................0.1 V for voltages < 50 V, 1 V for voltages ≥50 V, 0.01 kΩat
resistance measurement
GFCI Test Current .............................................. 100 V to 150 V @ 6 mA to 9 mA ac
150 V to 240 V < 12 mA
Standard Input Test Current ................................ < 5 mA
Size (HxWxL) ......................................................... 1.3 x 2.15 x 7.6 in.
Weight.................................................................... 9.9 oz

Electrical Tester
Maintenance
5
Maintenance
Basic maintenance for the Tester includes cleaning, checking the battery charge, and replacing
depleted batteries.
Cleaning the Tester
XWWarning
To avoid electrical shock or damage to the Tester, never allow
water inside the case. To avoid damaging the Tester case,
never use solvents on the Tester.
If the Tester requires cleaning, wipe it down with a cloth that is lightly dampened with water or a
mild detergent. Do not use aromatic hydrocarbons, chlorinated solvents, or methanol-based fluids
when wiping down the tester. These cleaning agents will damage the Tester case.
Testing the Batteries
Perform a self test, described later in this document, to determine the charge state of the batteries
on the Tester. The self test will not work with depleted batteries. On T+ PRO Testers, the low
battery icon ( B) on the LCD indicates that the batteries need to be replaced.
Replacing the Batteries
XWWarning
To avoid possible electric shock or personal injury:
•Disconnect test leads from any electrical source before opening
the battery compartment.
•Do not operate the Tester with the battery door or portions of the
cover removed or loosened.
To replace the batteries, do the following:
1. Remove the battery door by using a flat blade screwdriver to turn the battery door
fastener one-quarter turn counterclockwise.
2. Observing proper polarity, replace the batteries with two new AAA alkaline batteries.
3. Replace the battery door and secure it by turning the battery door fastener one-
quarter turn clockwise.
Calibration Adjustment
The T+ and T+ Pro have no field calibration. If the UUT fails any performance test, contact Fluke
Service for repair. See “Contacting Fluke.”
Performance Tests
XWWarning
To avoid possible electric shock, do not perform the
performance test procedures unless the Tester is fully
assembled and you are qualified to do so.
The following performance tests verify the complete operation of the Tester and check the
accuracy of each Tester function against its specifications. The recommended calibration interval
is 12 months. In the performance tests, the Tester is referred to as the unit under test (UUT). If the
UUT fails any performance test, contact Fluke Service for repair. See “Contacting Fluke.”
Required Equipment
Table 2 lists equipment that is required to complete the performance tests:

T+ and T+ PRO
Calibration Information
6
Table 2. Equipment Requirements
Equipment Minimum Required Characteristics Recommended Model
Calibrator ac / dc voltage range: 10 V to 600 V
Accuracy: ±5 %
Frequency 50/60 Hz
Resistance range: 100 Ωto 9 kΩ
Accuracy: ± 1.25 %)
Fluke 5520A High Performance
Multi-Product Calibrator
or
5500A Multi-Product Calibrator
3-phase power supply 120 V, 3-phase output Elgar 5250A or equivalent
Digital multimeter ac current range: 0 to 20 mA ±7 Fluke 189 Digital Multimeter
Self Test
XWWarning
To avoid possible electric shock or personal injury:
•Perform a self test before any measurements are taken for
voltage, continuity, resistance, or rotary field.
•When the batteries are depleted, self test will not function.
Replace the batteries.
WCaution
Although the Tester may be used with depleted batteries,
replace depleted batteries immediately to avoid Tester damage
from battery acid leakage.
To perform the self test, short the two probes. The self test lights all LEDs, and all LCD segments
(T+ PRO). The beeper sounds (unless disabled) and the Tester switches to continuity mode. To
complete the self test, measure a known voltage before use. If the Tester fails self test, it must not
be used and requires service. See “Contacting Fluke.”
Testing the LCD Display (T+ PRO)
Use the following procedure to test the LCD display:
Note
The Tester must remain inactive for approximately 30 seconds before
performing the following test. This will force a processor reset that will
display all LCD segments for approximately 1 second at power up.
1. Observe the LCD and short the test probes together. All LCD segments shown in
Figure 1 should light.
eqc001f.eps
Figure 1. LCD Display

Electrical Tester
Performance Tests
7
Testing the LEDs
Use the following procedure to test the LEDs:
Note
The Tester must remain inactive for approximately 30 seconds before
performing the following test. This will force a processor reset that will
display all LCD segments for approximately 1 second at power up.
1. Short the test probes together.
2. Observe that all LEDs light (voltage range, hazard, volts ac and dc, and continuity).
Testing the Backlight (T+ PRO)
Use the following procedure to test the backlight:
1. Insert the test probes into a voltage source of > 10 V ac or dc.
2. Observe that the backlight lights.
Testing the Audible Signal
Use the following procedure to test the audible signal:
1. Short the UUT test probes together. The beeper should sound.
2. If inactivated, press and hold until you hear three beeps.
Testing the Flashlight
Use the following procedure to test the flashlight:
1. Press the UUT headlight button.
2. Observe that the flashlight turns on for approximately five seconds.

T+ and T+ PRO
Calibration Information
8
Accuracy Tests
Perform the accuracy and verification tests in Table 3.
Table 3. T+ and T+ PRO Accuracy Tests
Step Function Range Input
Value
UUT Response
(LED)
LCD Display (T+ PRO)
Measurement Limits
1 Pos Off 12 V +20 V 12 V LED On - - -
2 Neg Off 12 V −20 V 12 V LED On - - -
3 Pos On 24 V +40 V
+ LED On
12 V, 24 V LED On
Hazard On
- - -
4 Neg On 24 V −40 V
−LED On
12 V, 24 V LED On
Hazard On
- - -
5
Digital Display
Voltage
Measurement
dc V
0 – 50 V
+10.5 V 12 V LED On 10.1 to 10.9
6 −10.5 V 12 V LED On −10.1 to −10.9
7 +48 V
+ LED On
12 – 48 V LED On
Hazard On
Beeper & Vibration On
46.8 to 49.2
8 −48 V
−LED On
12 – 48 V LED On
Hazard On
Beeper & Vibration On
−46.8 to −49.2
9
dc V
0 – 600 V
+55 V
+ LED On
12 – 48 V LED On
Hazard On
Beeper & Vibration On
52 to 58
10 −55 V
−LED On
12 – 48 V LED On
Hazard On
Beeper & Vibration On
−52 to −58
11 +590 V
+ LED On
12 – 600 V LED On
Hazard On
Beeper & Vibration On
576 to 604
12 −590 V
−LED On
12 – 600 V LED On
Hazard On
Beeper & Vibration On
−576 to −604
13 ac V
0 – 600 V 55 V, 60 Hz
ac LED On
12 – 48 V LED On
Hazard On
Beeper & Vibration On
51 to 59

Electrical Tester
Performance Tests
9
Table 3. T+ and T+ PRO Accuracy Tests (cont.)
Step Function Range Input
Value
UUT Response
(LED)
LCD Display (T+ PRO)
Measurement Limits
14
Voltage LEDs
24 V 24 V 24 V LED On - - -
15 120 V 120 V 120 V LED On - - -
16 208 V 208 V 208 V LED On - - -
17 240 V 240 V 240 V LED On - - -
18 277 V 277 V 277 V LED On - - -
19 347 V
(Canada) 347 V 347 V LED On - - -
20 480 V 480 V 480 V LED On - - -
21 Continuity 0 – 20 kΩShort Continuity LED On Continuity Sign
22
Resistance 0.00 – 9.99 kΩ
Short None 0.00 to 0.03
23 100 ΩNone 0.06 to 0.14
24 9 kΩNone 8.52 to 9.48
Load Current Test
To test the load current, set up the UUT with equipment as shown in Figure 2 and complete the
following procedure:
1. Set the DMM to the mA dc function.
2. Apply 600 V dc from the Source. The DMM reading should be < 5 mA.
3. Apply −600 V dc from the Source. The DMM reading should be < 5 mA.

T+ and T+ PRO
Calibration Information
10
MIN MAXHOLD REL
%
ms
Hz RANGE
dB
dB
ac+dc
ac+dc
ac+dc
ac+dc
F
nS
mA
mA
A
mV
V
mV
V
OFF
C
A
A
A
AmA COM V
TEMPERATURE
A
MIN MAXHOLD REL
%
ms
Hz RANGE
dB
dB
ac+dc
ac+dc
ac+dc
ac+dc
F
nS
mA
mA
A
mV
V
mV
V
OFF
C
A
A
A
AmA COM V
TEMPERATURE
A
AutoHOLD LOGGING
SAVECANCEL
FAST MNMX
SETUP
YES
NO
1000V
400mA
FUSED
10A MAX
FUSED CAT
CLEAR MEM
VIEW
5520A
CALIBRATOR
HI
LO
TRIG
GUARD
TC
20A
NORMAL AUX SCOPE
OUT
V, , ,RTD A, -SENSE, AUX V
20VPK MAX
20VPK MAX
mA
A
mA
A
Source DMM
UUT
CONTINUITY
120
208
48
24
12
240
277
600
480
eqc90.eps
Figure 2. Load Current/GFCI Current Test
GFCI Trip Test
To test the GFCI Trip current accuracy, set up the UUT and equipment as shown in Figure 2, and
complete the following procedure:
Note
When you press the GFCI pushbutton, the resulting test will last for up to
seven seconds.
1. Set the DMM to the mA ac function.
2. Apply 100 V, 60 Hz from the Source. The DMM reading should light the 12 – 48 V
LEDs and Hazard symbol.
3. Press the UUT GFCI pushbutton for one second. The UUT DC + and DC – LEDs
should alternately switch on and off while the beeper sounds. The DMM reading
should be between 6 and 9 mA ac during the test.
Rotary Field Test (T+ PRO)
To test the rotary field direction indicator, complete the following procedure:
1. Connect the UUT to a 60 Hz, three-phase source of > 120 V, with the UUT red lead
to A-phase and the UUT COM lead to B-phase. The UUT’s rotary field direction
indicator arrow should point to the right.
2. Move the UUT COM lead to C-phase. The rotary field direction indicator arrow
should point to the left.
