Follett HCD700R Operation manual

HCD700R/N, HMD700R/N
Ice Machines
Following installation, please forward this manual
to the appropriate operations person.
Operation and Service Manual
Order parts online
www.follettice.com
801 Church Lane • Easton, PA 18040, USA
Toll free (877) 612-50861 • [phone]
www.follettice.com 01012715R00

2
2

3
Welcome to Follett Corporation ................................................................................................................4
Specications ............................................................................................................................................5
Operation.....................................................................................................................................................7
Cleaning, weekly exterior care ............................................................................................................7
Cleaning, semi-annual evaporator cleaning........................................................................................7
Service....................................................................................................................................................... 12
Ice machine operation....................................................................................................................... 12
Water system..................................................................................................................................... 13
Electrical system ............................................................................................................................... 14
Normal control board operation .................................................................................................14
Test points.................................................................................................................................. 15
Error faults ................................................................................................................................. 15
Hard errors................................................................................................................................. 15
Soft errors .................................................................................................................................. 15
Relay output indication............................................................................................................... 15
Compressor/refrigerant solenoid output..................................................................................... 15
Wiring diagram, evaporator unit................................................................................................. 16
Wiring diagram, condenser unit .................................................................................................17
Gearmotor data.......................................................................................................................... 17
Mechanical system............................................................................................................................ 18
Evaporator disassembly............................................................................................................. 18
Evaporator reassembly ..............................................................................................................20
Refrigeration system .........................................................................................................................23
Condenser unit operation ..........................................................................................................23
Refrigerant pressure data ..........................................................................................................23
Refrigerant charges ...................................................................................................................23
Refrigeration system diagram ....................................................................................................24
Refrigerant replacement requirements ......................................................................................25
Evacuation .................................................................................................................................25
Ambients (evaporator unit).........................................................................................................25
Ice capacity test .........................................................................................................................25
Bin full detection system ...................................................................................................................26
Troubleshooting .................................................................................................................................27
Replacement parts............................................................................................................................30
Table of contents

4
4
Welcome to Follett
Follett equipment enjoys a well-deserved reputation for excellent performance, long-term reliability and
outstanding after-the-sale support. To ensure that this equipment delivers the same degree of service, we ask
that you review the installation manual (provided as a separate document) before beginning to install the unit. Our
instructions are designed to help you achieve a trouble-free installation. Should you have any questions or require
technical help at any time, please call our technical service group at [phone] or
[phone].
Before you begin
After uncrating and removing all packing material, inspect the equipment for concealed shipping damage. If
damage is found, notify the shipper immediately and contact Follett Corporation so that we can help in the ling
of a claim, if necessary.
Check your paperwork to determine which model you have. Follett model numbers are designed to provide information
about the type and capacity of Follett equipment. Following is an explanation of the different model numbers in the 700
series.
A V SC 700HC
ConfigurationApplication
S RIDE™
(RIDE remote ice
delivery equipment)
T Top-mount
400 up to
454 lbs
(206kg)
700 up to
675 lbs
(306kg)
1000 up to
1036 lbs
(471kg)
1400 up to
1450 lbs
(658kg)
1650 up to
1580 lbs
(717kg)
V Vision™
H Harmony™
B Ice storage
bin
J Drop-in
M Ice Manager™
diverter valve
system
CondenserSeriesVoltageMachine
C 208-230/60/1 (icemaking head)
Self-contained only.
D 115/60/1 (icemaking head)
Self-contained and remote.
If remote unit, high side is
208-230/60/1.
E 230/50/1 (icemaking head)
Self-contained only.
F115/60/1 (icemaking head)
Self-contained and remote.
If remote unit, outdoor
condensing unit is
208-230/60/3
MC Maestro™
Chewblet
(400 Series)
HC Horizon
Chewblet
(1000, 1400,
1650 Series)
HM Horizon
Micro
Chewblet
A Air-cooled, self-contained
W Water-cooled,
self-contained
R Air-cooled, remote
condensing unit
N Air-cooled, no condensing
unit for
connection to parallel rack
system
Chewblet®Ice Machine Model Number Configurations
CAUTION
§Outdoor installation of low side is not recommended and will void warranty.
§Moving parts. Do not operate with front cover removed.
§Hot parts. Do not operate with cover removed.
§To reduce risk of shock, disconnect power before servicing.
§Most ice machine cleaners contain citric or phosphoric acid, which can cause skin irritation. Read caution
label on product and follow instructions carefully.
§Ice is slippery. Maintain counters and oors around dispenser in a clean and ice-free condition.
§Ice is food. Follow recommended cleaning instructions to maintain cleanliness of delivered ice.

5
Specications
Electrical
Separate circuit and equipment ground required.
Evaporator unit
Standard electrical: 115/60/1
Maximum fuse: 15A
Amperage: 6A
Condensing unit
Single-Phase
Electrical 208-230V, 60Hz
Maximum Circuit HVACR breaker size 15A
Minimum Circuit Ampacity 10.7A
Evaporator plumbing
§3/8" OD push-in water inlet
§3/4" MPT
§3/4" vented drain line must slope a minimum of 1/4" per foot (6 mm per 30.4 cm run).
§Drain to be hard piped and insulated.
§Water shut-off recommended within 10 feet (3 m).
§Follett recommends installation of Follett water lter system (part# 00130286) in ice machine inlet water line.
Ambient
Evaporator unit
Air temperature 100 F/38 C max. 50 F/10 C min.
Water temperature 90 F/32 C max. 45 F/7 C min.
Water pressure 70 psi max. (483 kPa) 10 psi min. (69 kPa)
Condenser unit
Air temperature 120 F/49 C max. –20F/–29C min.
Refrigeration
§3/8" liquid line
§5/8" suction line
Note: Rack system installations require a capacity of 6,000 BTU/hr at 0 F (–18 C) evaporator temperature.
Evaporator pressure regulator (not supplied) is required.
Weight
Evaporator unit: 125 lbs (57 kg)
Condensing unit: 225 lbs (102 kg)
Ice production
F
C
50
10
60
16
70
21
80
27
90
32
60
16
747
339
714
324
671
304
649
294
600
272
70
21
678
308
673
305
643
292
609
276
583
264
80
27
644
292
618
280
589
267
561
254
535
243
90
32
586
266
559
254
528
239
506
230
499
226
100
38
565
256
529
240
512
232
478
217
441
200
lbs
kg
lbs
kg
lbs
kg
lbs
kg
lbs
kg
Inlet Water Temperature F/C
Ambient Air Temperature F/C
Air-cooled ice machine capacity/24 hrs.

6
6
Dimensions and clearances
Entire front of ice machine must be clear of obstructions/connections to allow removal.
§1" (26 mm) clearance above ice machine for service.
§1" (26 mm) minimum clearance on sides.
ICE TRANSPORT HOSE CONNECTION
3/4" MPT DRAIN
3/8" OD PUSH-IN WATER INLET
1.75"
(44.5 mm) MIN.
NEMA 5-15P
RIGHT ANGLE 5/8" SUCTION LINE
3/8" LIQUID LINE
Front View Side View Back View
Single-Phase Condensing Unit
22.44 " (57 cm)
18.23 " (46.3 cm)
22.46 " (57 cm)
2.56 " (65 mm)
9.00 " (22.9 cm)
3.29 " (84 mm)
1.81 " (46 mm)
2.88 " (73 mm)
21.25 "
(54 cm)
36.25 " (92.1 cm) 25.50
" (64.8 cm)
26.08 "
(66.3 cm)

77
Operation
Cleaning and preventive maintenance (all models)
Note: Do not use bleach to sanitize or clean the ice machine.
Preventive maintenance
Periodic cleaning of Follett’s ice machine system is required to ensure peak performance and delivery of clean,
sanitary ice. The recommended cleaning procedures that follow should be performed at least as frequently as
recommended, and more often if environmental conditions dictate.
Cleaning of the condenser can usually be performed by facility personnel. Cleaning of the ice machine system,
in most cases, should be performed by your facility’s maintenance staff or a Follett authorized service agent.
Regardless of who performs the cleaning, it is the operator’s responsibility to see that this cleaning is performed
according to the schedule below. Service problems resulting from lack of preventive maintenance will not be
covered under the Follett warranty.
Weekly exterior care
The exterior may be cleaned with a stainless cleaner such as 3M Stainless Steel Cleaner & Polish or equivalent.
Monthly condenser cleaning (air-cooled ice machine only)
1. Use a vacuum cleaner or stiff brush to carefully clean condenser coils of air-cooled ice machines to
ensure
optimal performance.
2. When reinstalling counter panels in front of remote ice machines, be sure that ventilation louvers line up
with condenser air duct.
Semi-annual evaporator cleaning (every 6 months)
WARNING
§Wear rubber gloves and safety goggles (and/or face shield) when handling ice machine cleaner or sanitizer.
CAUTION
§Use only Follett approved SafeCLEAN™ Cleaner (part #00132001) and NU-CALGON IMS-II SANITIZER.
§Do not mix Cleaner and Sanitizer solutions together.
§DO NOT USE BLEACH.
§It is a violation of Federal law to use these solutions in a manner inconsistent with their labeling.
§Read and understand all labels printed on packaging before use.
Note: Complete procedure for cleaning an sanitizing MUST be followed. Ice must be collected for
10minutes before putting ice machine back into service.
1. To clean – Remove cover. Press the CLEAN
button. The machine will drain. Wait for the LO
WATER light to come on (Fig. 1).
LO WATER
Fig. 1

8
8
2. Mix 1 gallon (3.8L) 120 F (49 C) water and
7 ounces (198g) (one 7 ounce packet of
Follett SafeCLEAN ice machine cleaner, part#
00132001). Locate cleaning cup. Fill until
CLEANER FULL light comes on (Fig. 2).
Note: Do not use bleach to sanitize or clean the
ice machine.
CLEANER
FULL
Fig. 2
15
Fig. 3
LO WATER
Fig. 4
3. Replace cover on cleaning cup. Wait until
machine restarts. Machine will clean, then ush
3 times in approximately 15 minutes (Fig. 3).
4. To sanitize – Press CLEAN button. The machine
will drain. Wait for LO WATER light to come on
(Fig. 4).

99
CLEANER
FULL
Fig. 5
12
Fig. 6
Fig. 7
5. Mix 1 gallon 120 F (49 C) water and 1.6 ounces
(48ml) NU-CALGON IMS-II SANITIZER. Fill until
CLEANER FULL light comes on (Fig. 5).
Place one Sani-Sponge™ in remaining
sanitizing solution and retain for Step 9.
Note: Do not use bleach to sanitize or clean the
ice machine.
6. Replace cover on cleaning cup. Wait until
machine restarts. Machine will sanitize, then ush
3 times in approximately 15 minutes (Fig. 6).
7. Disconnect coupling as shown (Fig. 7).
Note: Steps 8-11 must be completed before
machine ushes and starts producing ice.

10
10
Fig. 8
1
2
3
16"
(407mm)
Fig. 9
Fig. 10
8. Using disposable food service grade gloves,
insert dry Sani-Sponge™ (kit part# 00132068).
Next, insert Sani-Sponge soaked in Nu-Calgon
IMS-II sanitizer solution (from Step 5). Push
both Sani-Sponges down ice transport tube
with supplied pusher tube(Fig.8).
9. Remove and discard 16" (407mm) pusher tube
(Fig. 9).
10. Reconnect coupling. When sanitizing cycle
ends, machine will start producing ice. Press
power switch ON. Ice pushes Sani-Sponges
through tube (Fig. 10).
