FONESTAR TMRI-844 User manual

TMRI-844, TPRI-845, TSRI-841
WIRELESS PERSONAL MONITOR SYSTEM
40 PLL UHF 863-865 MHz CHANNELS
INSTRUCTION MANUAL
RI-840 MSHT-45P
MSHT-40M
TSI-40
TMRI-844 TPRI-845, TSRI-841 MANUAL (EN) 20180315 Maquetación 1 15/3/18 12:30 Página 1

EN
- 2-
We take this opportunity to thank you for buying this product.
We recommend you read the instruction manual before switching on the machine and follow the instructions
that are given. Keep the manual for future reference.
SECU ITY AND THE ENVI ONMENT
ELECTRICAL SECURITY
Check that the current in the mains connection where the machine is to be installed corresponds to the
power supply of the machine.
To avoid damaging the equipment, electrical shocks, fire or physical injury when you connect or disconnect
the equipment from the power supply, pull the plug firmly out of the mains socket holding the plug, never the
cable.
Always do this with dry hands.
Keep the power supply cable far from sources of heat. Do not put heavy objects on top of it or change it.
Clean dust and dirt off the power supply cable regularly.
Do not open the machine; you could get an electric shock.
CAUTION
While installing the machine, make sure it is switched off and unplugged.
Do not open the machine. Touching the internal parts is dangerous and you could receive an electric shock.
The machine must not be splashed or dripped on. Never place recipients with liquid inside on the machine.
Do not place anything inside the machine.
LOCATION
Place the equipment on a horizontal surface with enough space around it to allow ventilation.
Avoid direct sunlight, heat sources and excessive dust.
Do not place the machine near magnetic fields or static electricity.
Do not use surfaces which vibrate or receive impact.
Do not pile machines on top of one another.
VENTILATION
Never block or cover the ventilation slits on the machine.
Do not expose it to direct sunlight or place it near sources of heat.
PERIODS OF INACTIVITY
When the machine is not going to be used for a long period of time, disconnect it from the mains.
If you are using an adapter, take into account that it will continue using electricity even if the machine is
switched off. If it is not going to be used for a long period of time, disconnect it from the mains.
THE ENVIRONMENT
To save energy, switch the machine off when you are not going to use it for a long time. The machine could
contain substances that are harmful to the environment or human health. To minimize the effect of these
substances the machine must be correctly managed and recycled when you decide to dispose of it.
When you dispose of it remember: it cannot be thrown into a conventional rubbish bin.
If it contains or uses batteries, these must be disposed of separately.
The machine (without batteries) must be disposed of correctly. Put it in a container specially intended for the
collection of electronic and electrical appliances, at the dump or hand it over to the dealer when you purchase
similar equipment, so that the dealer can dispose of it correctly (at no added cost).
TMRI-844 TPRI-845, TSRI-841 MANUAL (EN) 20180315 Maquetación 1 15/3/18 12:30 Página 2

SIGNIFICANCE OF THE SYMBOLS ON THE MACHINE*
The symbol formed by the expression “Class 1 laser product” written in a rectangle
indicates that visible or invisible laser radiation could be produced. Avoid direct expose to
the laser.
The symbol formed by a ray of lightening inside a triangle shows that the machine has
connection terminals or a circuit with areas with a current which could cause an electric
shock, even in normal working conditions.
The symbol formed by an exclamation mark in a triangle shows that the instruction manual
must be referred to for information on how the machine works and its use.
The symbol formed by one square inside another square shows that the machine has
double electrical insulation.
The European Community symbol shows that the machine complies with the current
European Union legislation, as well as its transposition to local legislation.
The symbol of a rubbish bin crossed out and over a horizontal line shows that when the
product is disposed of it must be done properly, placing it in a special selective electronic
and electrical equipment container or through a dealer when purchasing a similar product,
at no additional cost. It also shows that the machine was put on the market after 13th
August 2005 (European Community Directive 2002/96/CE of Electrical and Electronic
recycling, and its Spanish equivalent R.D.208/2005).
In accordance with what is set out in the aforementioned decree, FONESTAR is registered
in the RAEE (Registro de Aparatos Eléctricos y Electrónicos) in a special section REI
(Registro de establecimientos Industriales), with the entry number 001851.
*It is possible that some of these symbols do not appear on the machine.
EXEMPTION OF LIABILITY
The characteristics of the equipment and the content of the manual can change without forewarning.
FONESTA , S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the
information supplied in this instruction manual, and specifically disclaims any implied liability for marketability
or fitness for any other use.
All rights reserved by FONESTA , S.A.
- 3-
EN
TMRI-844 TPRI-845, TSRI-841 MANUAL (EN) 20180315 Maquetación 1 15/3/18 12:30 Página 3

DESC IPTION
Wireless personal monitor system for audio signal transmission in the band UHF 863-865 MHz. The system is
composed of a wireless in ear belt-pack monitor receiver (mod. I-840) with silicone rubber earphones and
a wireless hand-held microphone transmitter (mod. MSHT-40M) or a tie-clip microphone (mod. MSHT-45P)
with wireless belt-pack transmitter, depending on the model chosen.
The system has 40 transmission channels in the band UHF 863-865 MHz, with PLL frequency control which
allows a transmission channel free of interference to be easily selected.
It is possible to use multiple receivers ( I-840) in the same channel with one transmitter.
CONT OLS AND FUNCTIONS
I-840 Wireless in ear belt-pack monitor receiver with headphones.
1.- Information display: displays information on tuned frequency, channel number, battery level, RF signal
level and audio signal level. If the level of the batteries is low, the display will light up red.
2.- w/s: allow menu options to be selected in order to configure the wireless belt-pack receiver.
3.- SET: allows selection among the different configuration options: channel number and frequency, RF
transmission level (high/low), battery type selection (1.2 V - rechargeable/1.5 V - alkaline) to display the
battery level correctly and lock the receiver. In order to do so, press the SET button repeatedly and use
the w/sbuttons to select the options.
4.- Battery compartment: uses two 1.5 V LR6-AA batteries, alkaline or rechargeable.When inserting the
batteries, make sure the polarity is correct.
5.- HEADPHONES OUTPUT: select the type of headphone output signal, single (L+R channels in left earphone)
or double (L+R channels in both earphones).
6.- Contacts to recharge the rechargeable batteries of the wireless receiver in the recharge docking station mod.
MSC-2.
7.- Antenna.
8.- VOL: wireless belt-pack receiver volume control.
9.- 3.5 mm stereo jack connector for connecting headphones/recording. If you wish to record a signal
received by the receiver I-840, connect the recording equipment to the headphone output or use an
adapter to be able to use the headphone signal and the recorder simultaneously.
10.- POWE : receiver on/off switch.
Note: when the SET button is pressed to configure the different parameters of the receiver, a MUTE indicator
appears in the display and the receiver will not receive audio while the parameters are being
configured.
- 4-
EN
TMRI-844 TPRI-845, TSRI-841 MANUAL (EN) 20180315 Maquetación 1 15/3/18 12:30 Página 4

MSHT-40M Wireless hand-held microphone transmitter
1.- Grille: protects the microphone capsule and helps to reduce noises from breathing or the wind blowing.
2.- Display: displays information on the tuned frequency, channel number, battery level, RF signal level
and audio signal level. If the battery level is low, the screen will light up red.
3.- Battery compartment: unscrew this cover to access the battery compartment.
4.- GAIN: adjust the sensibility of the audio input.
5.- q: hand-held microphone on/off switch.
6.- Battery compartment: use two 1.5 V LR6-AA type batteries, alkaline or rechargeable. When inserting
the batteries, make sure that the polarity is correct.
7.- SET: allows selection among the following configuration options: channel number and frequency, RF
transmission level (high/low), battery type selection (1.2 V - rechargeable/1.5 V - alkaline) to display the
battery level correctly and lock the microphone transmitter. In order to do so, press the SET button
repeatedly and use the w/sbuttons to select the options.
8.- w/s: allow selection of the menu options to configure the hand-held wireless microphone.
9.- Contacts to recharge the wireless microphone’s rechargeable batteries in the recharge docking station
mod. MSC-2.
Note: when the SET button is pressed to configure the different microphone parameters, a MUTE indicator
appears in the display and the microphone does not transmit audio while the parameters are being
configured.
- 5-
EN
TMRI-844 TPRI-845, TSRI-841 MANUAL (EN) 20180315 Maquetación 1 15/3/18 12:31 Página 5

EN
- 6-
MSHT-45P Tie-clip microphone with wireless belt-pack transmitter
1.- Display: displays information on the tuned frequency, channel number, battery level, RF signal level
and audio signal level. If the battery level is low, the screen will light up red.
2.- w/s: allows selection of required optionsin order to configure the wireless belt-pack microphone.
3.- SET: allows selection among the different configuration options: channel number and frequency, RF
transmission level (high/low), battery type selection (1.2 V - rechargeable/1.5 V - alkaline) to display the
battery level correctly and lock the receiver. In order to do so, press the SET button repeatedly and use
the w/sbuttons to select the options.
4.- Battery compartment: use two 1.5 V LR6-AA batteries, alkaline or rechargeable. When inserting the
batteries, make sure the polarity is correct.
5.- Antenna.
6.- VOL: wireless belt-pack transmitter volume control.
7.- 3.5 mm mono jack connector for connection of microphone or required audio source.
8.- POWE : transmitter on/off switch.
9.- LINE/MIC: input signal sensitivity selector.
10.- Contacts to recharge the wireless microphone’s rechargeable batteries in the recharge docking station
mod. MSC-2.
Note: when the SET button is pressed to configure the different parameters of the microphone, a MUTE
indicator appears in the display and the microphone will not receive audio while the parameters are
being configured
TMRI-844 TPRI-845, TSRI-841 MANUAL (EN) 20180315 Maquetación 1 15/3/18 12:31 Página 6

TSI-40 UHF transmitter for desktop or installing in 1 U 19" rack
FONT PANEL
1.- Headphone output volume control.
2.- Headphone output for monitoring the signal to be transmitted.
3.- Information display: displays information about input and output signals, frequency, etc.
A. F: radio frequency signal level indicator.
B. AF: audio signal level indicator.
C. F EQ: indicates that the information shown on the display is the transmission frequency.
D. CHAN.: indicates that the information shown on the display is the transmission channel number.
E. Configuration information.
F. MUTE: indicates that the signal is cut off during the configuration of new parameters.
4.- SET: allows selection among the following configuration options: channel number and its associated
frequency (from CH1 to CH40), RF emission level (low, mid or high) and configuration locking
(LOCK/UNLOCK).
5.- w/s: allows selection of required options for the configuration of the transmitter.
6.- L: wireless transmitter left channel volume control.
7.- : wireless transmitter right channel volume control.
8.- POWE : transmitter on/off switch.
EA PANEL
1.- Power supply
2.- AF-IN (STE EO): line level signal input, 3.5 mm stereo jack connector.
3.- AF IN ( ): microphone/line level signal input, 6.3 mm mono jack connector.
4.- AF IN (L): microphone/line level signal input, 6.3 mm mono jack connector.
5.- Gain selector of inputs AF IN (L) and AF IN (R).
6.- TX-ANT: antenna connector.
EN
- 7-
TMRI-844 TPRI-845, TSRI-841 MANUAL (EN) 20180315 Maquetación 1 15/3/18 12:31 Página 7

EN
- 8-
INSTALLATION AND CONNECTION
I-840 Wireless in ear UHF belt-pack monitor receiver with earphones
1.- Insert the batteries in the battery compartment respecting the polarity indicated on it. If rechargeable
batteries have been used, they can be recharged following the instructions in the Rechargeable battery
section.
2.- Connect the earphones to the headphone output. If you wish to record a signal received by the receiver
I-840, connect a recording device to the headphone output or use an adapter to be able to use the
headphone signal and the recorder simultaneously.
3.- Select the type of headphone output signal required with the HEADPHONES OUTPUT selector, single
(mono) or double (stereo).
MSHT-40M Wireless hand-held transmitter microphone
1.- Insert the batteries in the battery compartment respecting the polarity indicated on it. If rechargeable
batteries have been used, they can be recharged following the instructions in the Rechargeable battery
section .
2.- Adjust the sensitivity of the audio input using the GAIN control.
MSHT-45P Tie-clip microphone with wireless belt-pack transmitter
1.- Insert the batteries in the battery compartment respecting the polarity indicated on it. If rechargeable
batteries have been used, they can be recharged following the instructions in the Rechargeable battery
section .
2.- Connect the tie-clip microphone or the required audio source.
3.- Place the selector on the rear part of the tie-clip microphone in the LINE or MIC position depending
on the type of signal you have connected to the input. Select LINE if connected to an audio source
with line level or MIC if connected to a microphone.
TSI-40 UHF transmitter for desktop or installing in 1 U 19" rack
1.- Connect the audio sources on the rear of the transmitter and the mains adapter provided. Place the
selector on the rear part of the device in the 0 dB or -20 dB position depending on the type of signal
that you have connected to the AF IN (L) and AF IN (R) inputs. Position the selector in 0 dB for a
source with line level and in -20 dB if a microphone was connected.
2- Place the device on a flat surface or in a 19" rack using the mounts supplied with the device.
TMRI-844 TPRI-845, TSRI-841 MANUAL (EN) 20180315 Maquetación 1 15/3/18 12:31 Página 8

EN
-9-
INST UCTIONS FO USE
RF CHANNEL SELECTION FOR TRANSMISSION/RECEPTION
The transmitter (hand-held microphone or belt-pack microphone) and the receiver (belt-pack in ear monitor)
must be tuned to the same channel. Select a channel that is free of interference in the receiver and select
the same channel in the transmitter. If you wish to use 2 or more transmitter/receiver monitor systems
simultaneously observe the following indications to avoid interference:
- Use radio frequency channels with the maximum separation between them. Bear in mind the carrier
frequencies of each channel, as is shown in the table below:
- It is possible to use multiple receivers ( I-840) in the same channel with one transmitter.
RECHARGEABLE BATTERIES
Insert the batteries in the battery compartment respecting the polarity in it. In order to recharge the batteries
use the recharge docking station mod. MSC-2.
I-840 Wireless in ear belt-pack monitor receiver with earphones
Place the receiver in the corresponding compartment in the recharge docking station MSC-2. Remove the
plastic adapter beforehand in order to insert the wireless belt-pack transmitter. During the charging process,
the LED CHARGE indicator of the recharge docking station will light up permanently in red. When the charging
process has finished, the LED FULL indicator will light up green.
MSHT-40M Wireless hand-held transmitter microphone
Place the microphone in the compartment designed for it in the recharge docking station MSC-2. During the
charging process, the LED CHARGE indicator of the recharge docking station will light up permanently in red.
When the charging process has finished, the LED FULL indicator will light up in green.
MSHT-45P Tie-clip microphone with wireless belt-pack transmitter
Place the microphone in the corresponding compartment in the recharge docking station MSC-2. Remove
the plastic adapter beforehand in order to insert the wireless belt-pack transmitter. During the charging
process, the LED CHARGE indicator of the recharge docking station will light up permanently in red. When
the charging process has finished, the LED FULL indicator will light up green.
TMRI-844 TPRI-845, TSRI-841 MANUAL (EN) 20180315 Maquetación 1 15/3/18 12:31 Página 9

T OUBLE-SHOOTING
TECHNICAL SPECIFICATIONS
P OBLEM SOLUTION
There is no sound - Check the transmitter’s and receiver’s power supply.
- Check that the transmitter and the receiver are tuned to the same
frequency/channel.
- Check if the transmitter is very far away from the receiver.
- Check if the receiver is situated near metal objects or if there are obstacles
between the receiver and the transmitter.
Interference - When using 2 or more transmitters simultaneously check that the selected
channels do not interfere.
- Check if the interference is coming from another wireless microphone system, TV,
radio, etc.
Distortion - Check if the receiver volume is selected very low or very high.
- Check if the interference is coming from another wireless microphone system,
TV, radio, etc.
I-840
CHA ACTE ISTICS Wireless in ear belt-pack monitor receiver with 40 selectable PLL UHF
863-865 MHz channels.
Reception with mono FM modulation.
For use with the FONESTAR wireless in ear monitor system.
Several receivers (RI-840) can be used in the same channel with one
transmitter.
For use with models MSHT-40M-863, MSHT-41P-863, MSHT-42S-863,
MSHT-43C-863, MSHT-44X-863 and MSHT-45P-863.
OUTPUTS Headphone, 3.5 mm stereo jack
ESPONSE 50-15,000 Hz
CONT OLS On/off
Volume control
Single (L) or double (L+R) output selector
Configuration buttons and RF channel selection
POWE SUPPLY 2 x LR6-AA batteries. Accepts rechargeable batteries; integrated recharge
function
DIMENSIONS 64 x 108 x 24 mm depth
ACCESSO IES Silicone earphones
Belt clip
Rechargeable batteries
OPTIONAL MSC-2, MSC-12 and MSC-24: wireless microphone recharge docking
stations
- 10 -
EN
TMRI-844 TPRI-845, TSRI-841 MANUAL (EN) 20180315 Maquetación 1 15/3/18 12:31 Página 10

TM I-844 (transmitter: MSHT-40M + receiver: I-840)
Personal in ear monitor system for audio signal transmission in the UHF 863-865 MHz band.
Composed of a wireless hand-held microphone transmitter (MSHT-40M) and a wireless in ear monitor belt-
pack receiver ( I-840) with silicone rubber earphones. 40 selectable PLL UHF 863-865 MHz channels.
Possibility of using multiple receivers ( I-840) in the same channel with one transmitter.
TP I-845 (transmitter: MSHT-45P + receiver: I-840)
Personal in ear monitor system or audio signal transmission in the UHF 863-865 MHz band.
Composed of a tie-clip microphone with belt-pack transmitter (MSHT-45P) and a wireless in ear belt-pack
monitor receiver ( I-840) with silicone earphones. 40 selectable PLL UHF 863-865 MHz channels.
Mono FM modulation. Possibility of using multiple receivers ( I-840) in the same channel with one transmitter.
MSHT-40M
CHA ACTE ISTICS Wireless hand-held microphone with unidirectional electret condenser
capsule and UHF transmitter for replacement or extension.
863-865 MHz 40 channels
823-832 MHz 32 channels
512-525 MHz 32 channels
For models MSH-887, MSH-895 and MSH-898.
POWE SUPPLY 2 LR6-AA batteries. Accepts rechargeable batteries; integrated recharge
function
DIMENSIONS 257 x 52 mm Ø
ACCESSO IES Rechargeable batteries
OPTIONAL MSC-2, MSC-12 and MSC-24: wireless microphone docking stations
MSHT-45P
CHA ACTE ISTICS Tie-clip microphone with unidirectional electret condenser capsule and
UHF wireless belt-pack transmitter for replacement or extension.
Hand-held microphone with unidirectional electret condenser capsule
and UHF transmitter for replacement or extension.
863-865 MHz 40 channels
823-832 MHz 32 channels
512-525 MHz 32 channels
For models MSH-883, MSH-892 and MSH-898.
POWE SUPPY 2 x LR6-AA batteries. Accepts rechargeable batteries; integrated
recharge function
DIMENSIONS 64 x 108 x 24 mm depth
ACCESSO IES Windshield
Tie-clip
Rechargeble batteries
OPTIONAL MSC-2, MSC-112 and MSC-24: wireless microphone recharge docking
stations
- 11 -
EN
TMRI-844 TPRI-845, TSRI-841 MANUAL (EN) 20180315 Maquetación 1 15/3/18 12:31 Página 11

TS I-841 (transmitter: TSI-40 + receiver: I-840)
Wireless personal monitor diversity system for audio signal transmission in the UHF 863-865 MHz band.
Composed of a transmitter for desktops or for installing in a 1 U 19" rack (TSI-40) and a wireless in ear
monitor belt-pack receiver (RI-840) with silicone earphones.
40 selectable PLL UHF 863-865 MHz channels. FM modulation.
Possibility of using as many receivers (RI-840) as required in one channel with each transmitter.
TSI-40
DESC IPTION UHF transmitter for desktop or installing in 1 U 19" rack.
40 selectable PLL UHF 863-865 MHz channels.
Transmission with mono FM modulation.
For use with the FONESTAR wireless monitor in ear system.
INPUTS 2 mic./L and R line, 6.3 mm jack
1 aux, 3.5 mm stereo jack
OUTPUTS Stereo headphone, 3.5 mm jack
CONT OLS On/off
Volume controls: L and R channel and headphone output
Configuration and RF channel selection buttons
RF output level control
POWE SUPPLY 12 V DC, 450 mA with adapter included
DIMENSIONS 210 x 46 x 215 mm depth
ACCESSO IES Antenna, 1 m cable with 6.3 mm mono jack connector and mounts for
assembly in 1 U 19" rack
- 12 -
EN
TMRI-844 TPRI-845, TSRI-841 MANUAL (EN) 20180315 Maquetación 1 15/3/18 12:31 Página 12

DECLA ATION OF CONFO MITY
FONESTA SISTEMAS S.A.
Polígono de Trascueto s/n
39600 Revilla de Camargo, Cantabria (España)
Declares, under its responsibility, that the following equipment:
Description: Wireless UHF personal in ear monitor systems
Brand: FONESTAR
Models: TMRI-844, TPRI-845
comply with that shown in theEuropean Parliament and Council directive 1999/5/EC of 9th March 1999,
transposed to Spanish legislation through the Real Decreto 1890/2000, on 20th November.
This is class 1 equipment and has no use restrictions.
List of standards applied
Standard Area Compliance with he 1999/5/EC essential
directive requirements
EN 300 422-2 RADIO Section 3.2 1999/5/EC directive
Revilla de Camargo, 5th September, 2014
uan Vallejo
Technical Engineer, Sales departmentl
- 13 -
EN
TMRI-844 TPRI-845, TSRI-841 MANUAL (EN) 20180315 Maquetación 1 15/3/18 12:31 Página 13

WA ANTY
This product has been tested and has passed the corresponding quality control prior to being put on the market.
FONESTA guarantees the suitability of the product for its specified use during a period of 2 years from the
delivery date and commits itself to repair or substitute the goods as expressed in the Spanish law ‘La Ley General
para la Defensa de los Consumidores y Usuarios, Real Decreto Legislativo 1/2007 16 Noviembre.
The lack of conformity in the first six months after purchase, due to a manufacturing defect, will be rectified with
no more than showing the proof of purchase. After six months FONESTA reserves the right to demand proof of
the product being sold with that problem.
This warranty does not include damage produced by: inappropriate use or negligence, accidents, worn out parts
due to use, breakages, burns, spilt liquids or other substances, excessive humidity, battery deterioration and
internal manipulation of the device, the software or its components by unauthorized persons, and in general any
use that is unrelated to the nature and purpose of the product.
If any service is needed during the warranty period because of lack of conformity, please contact the business or
distributor where the product was purchased in no more than 2 months after being conscious of the problem. It
is only necessary to contact FONESTA if it is impossible or imposes an undue burden for them to solve it.
To benefit from this warranty it is necessary to show the proof of purchase with the date clearly visible, with no
corrections or crossing out.
This document adds information, and never decreases the consumers’ rights, which in all cases are protected by
the Spanish law ‘La Ley General para la Defensa de los Consumidores y Usuarios, Real Decreto Legislativo 1/2007
16 Noviembre.
FONESTA is a member of ECOEMBALA ES ESPAÑA, S.A. “ECOEMBES”, with number 03497 and all our products carry the symbol,
backed by our membership and subscription to the above mentioned organization with the recycling and subsequent management of
our packaging.
FONESTAR, S.A. - NIF: A28780443 - Polígono Trascueto - 39600 Revilla de Camargo, Cantabria (Spain)
www.fonestar.com
EN
- 14 -
TMRI-844 TPRI-845, TSRI-841 MANUAL (EN) 20180315 Maquetación 1 15/3/18 12:31 Página 14

- 15 -
EN
TMRI-844 TPRI-845, TSRI-841 MANUAL (EN) 20180315 Maquetación 1 15/3/18 12:31 Página 15

www.fonestar.com
TMRI-844 TPRI-845, TSRI-841 MANUAL (EN) 20180315 Maquetación 1 15/3/18 12:31 Página 16
