Mercia Garden Products 01PTGRO1208DD-V3 Instruction manual

P 1
01PTGRO1208DD-V3
12x8 Pressure Treated Groundsman
2mm Drill bit
x2 Winter = High Moisture = Expansion
Summer = Low Moisture = Contraction
All buildings should be
erected by two adults
For ease of assembly, you
MUSTpilot drill all screw
holes and ensure all screw
heads are countersunk.
For assistance please contact customer care on: 01636 880514
Mercia Garden Products Limited,
Sutton On Trent,
Newark,
Nottinghamshire,
NG23 6QN
www.merciagardenproducts.co.uk
CAUTION
Every eort has been made during the
manufacturing process to eliminate the
prospect of splinters on rough surfaces of the
timber. You are strongly advised to wear gloves
when working with or handling rough sawn
timber.
Please retain product label and instructions for future reference
General Instructions
BEFORE YOU START PLEASE READ INSTRUCTIONS CAREFULLY
- Check the pack and make sure you have all the parts listed.
- When you are ready to start, make sure you have the right tools at hand (not supplied) including a Phillips
screwdriver, Stanley knife, Wood saw, Step ladder, Hammer and a Drill with 2mm bit.
- Ensure there is plenty of space and a clean dry area for assembly.
TIMBER
As with all natural materials, timber can be aected during various weather conditions. For the duration of heavy
or extended periods of rain, swelling of the wood panels may occur. Warping of the wood may also occur during
excessive dry spells due to an interior moisture loss. Unfortunately, these processes cannot be avoided but can
be helped. It is suggested that the outdoor building is sprayed with water during extended periods of warm
sunshine and sheltered as much as possible during rain or snow.
Once your garden building has been installed it will need to be treated as soon as possible and annually to
prevent the timber from deteriorating and to waterproof it. This is required to maintain the anti-rot guarantee.
Dip Treated buildings - Require a preservative treatment to protect against rot and decay and a waterproof
treatment to prevent water ingress
Pressure Treated buildings - Require a waterproof treatment to prevent water ingress
Log Cabins - Are supplied untreated and require a preservative and waterproong treatment.
BUILDING A BASE
When thinking about where the building and base is going to be constructed:
Ensure that there will be access to all sides for maintenance work and annual
treatment.
Ensure the base is level and is built on rm ground, to prevent distortion. Refer to diagrams for the base
dimensions, The base should be slightly smaller than the external measurement of the building, i.e. The cladding
should overlap the base, creating a run o for water. It is also recommended that the oor be at least 25mm
above the surrounding ground level to avoid ooding.
TYPES OF BASE
- Concrete 75mm laid on top of 75mm hard-core.
- Slabs laid on 50mm of sharp sand.
Whilst all products manufactured are made to the highest standards of Safety and in the case of childrens
products independently tested to EN71 level, we cannot accept responsibility for your safety whilst erecting or
using this product.
Refer to the instructions pages for you specic product code
For ease of assembly, you
will need a tape measure to
check dimensions of
components.
Pressure Treated Timber
Pressure treating is a chemical process which helps to protect wood against adverse weather which could
lead to rot or insect damage.
The most common chemicals used to pressure treat wood are Alkaline Copper Quaternary(ACQ),
Copper Azole (CA), and Micronized Copper Quaternary(MCQ).
Safety:Always wear gloves, eye protection and a dust mask when handling wood. Due to chemicals in
pressure treated wood, never burn its sawdust or scraps; instead dispose in a landll.

P 2
21
34
5
6
20
7
8
10
11
13
15 16
17
18
19
9
21
12
Door Gable QTY 1
AI-01GRO1208DD-V3DG
Plain Gable QTY 1
AI-01GRO1208DD-V3PG
Window Panel QTY 2
AI-01GRO1208DD-V3WS
Roof Panel QTY 4
AI-01GRO1208DD-V3R
Plain Panel QTY 2
AI-01GRO1208DD-V3PS
Window QTY 2
AI-01OW-V1
Floor QTY 2
AI-01GRO1208DD-V3F
Door QTY 2
AI-01-21ZB675X1720-V1
Fixing Kit
Fascias - 12 x 95 x 1480mm QTY 4
S1295-1480MM
Cover trims - 12 x 55 x 1652mm QTY 6
S1255-1652MM
Shed Diamond Finial QTY 2
Truss Support B - 27 x 44 x 140mm QTY 2
F2744-160MM
Fascia Blocks - 27 x 44 x 120mm QTY 4
F2745-120MM Tower Bolt Block -12 x 44 x 120mm QTY 4
F2745-120mm
Horizontal Door Strip - 12 x 44 x 1449mm QTY 1 S1245-1449mm
Vertical Door Strip - 12 x 44 x 1732mm QTY 2 S1245-1732MM
Window Strip - 12 x 45 x 1055mm QTY 2 S1245-1055MM
22
T-Hinge QTY 6
PI-02-1045
23
Butt Hinge QTY 4
PI-07-0066
25
Nail Bag
Casement Stay x2
PI-07-0007
138x30mm Screw
5x60mm Screw
26x40mm Screw
Felt Tacks x180
15x20mm Screw
54x50mm Screw
3x70mm Screw
15x30mm Black Screw
12x16mm Screw
Tower Bolt
PI-07-0030
Hasp & Staple Lock QTY 1
PI-07-0191
Door Cloaking Strip - 27 x 44 x 1670mm QTY 1 S1245-1055MM
24
Truss Support A - 44 x 44 x 1240mm QTY 2
F4444-1260MM
26
Truss bar A - 44 x 44 x 345mm QTY 1
F4444-385MM
14
Truss bar B - 27 x 44 x 1850mm QTY 2
F2744-1890MM
01PTGRO1208DD-V3
Overall Dimensions:
Width = 2430mm
Depth = 3638mm
Height = 2282mm
Base Dimensions:
Width = 2388mm
Depth = 3568mm
Please retain product label and instructions for future reference
Before assembly
please make sure you have a
suitable base ready to erect your
building
MADE IN GREAT BRITAIN

P 3
Opening Window
Fixed Window
30mm
screw
30mm
screw
16mm
screw
30mm
screw
Place the opening window strip
11mm above the window gap in the
window panel and x with 3x30mm
screws.
If you would like the windows to be
opening use the butt hinges to
attach the opening window strip
and the opening window together.
Use 30mm screws to x the butt
hinge to the Window Strip and
16mm screws to x it to the
Opening Window.
If you want to x the opening
windows, instead of xing butt
hinges to the opening window,
use 4x30mm screws to attach
the opening windows to the
window panel as shown in the
diagram.
*SCREW COUNT PER WINDOW
19
25
8
8
Fix the door strips onto the front
gable using 4x30mm screws for
each strip
Fix the T Hinges onto the doors
and door frame as shown
above. Ensure that each hinge
is 720mm apart and that there
is a 170mm gap from the top of
the door and the middle screw
of the T Hinge.
Pre Assembly
7
1
7
17
23
12X30mm screws
42x30mm screws
30mm
16mm
Please retain product label and instructions for future reference

P 4
Step 1
Remove transportation blocks
from the bottom of each panel
before beginning assembly. Each
Panel should have two blocks.
x10 50mm Screws
6
6
Step 2
Place the oor on a rm and
level base, ensure base has
suitable drainage free from
areas where standing water can
collect. (See front page on
base requirements). Ensure
oors are ush to each other
and x using 10x50mm screws.
Alternate xing positions along
the length of the oors.
Step 3
Do not secure the building to
the oor until the roof is tted.
Fix the panels onto the oor
using 50mm screws in align-
ment with the oor joists
Fix the corners with 50mm
screws as shown in diagram.
Position the panels so there is equal spacing
between the oor and cladding on all 4 sides
x6 50mm Screws
2Window panel can be tted on
either left or right side
6
6
3
3
Step 4
Fix door gable and plain side
panels using same method
shown in step 3.
x12 50mm Screws
3
2
5
1
Please retain product label and instructions for future reference
For assistance please contact customer care on: 01636 880514
Mercia Garden Products Limited,
Sutton On Trent,
Newark,
Nottinghamshire,
NG23 6QN
www.merciagardenproducts.co.uk

P 5
Step 8
Once the roof is xed,
secure the building to the
oor with 24x50mm screws.
* Ensure to screw in alignment
with the oor bearers.
30x50mm Screws
Pre drill
hole
50mm
screw
Step 6
Fix the roof panels on either
side as shown in diagram.
Ensure roof framing ts into slot
at top between the gable top
rafters and the roof truss.
Fix panels into position using
30x 30mm screws from the top
of panel, straight into the rafter
and roof truss. Pre drill holes
before hand.
Ensure the larger over hang on
both panels are facing each
other at the top point.
40x 30mm Screws
5
1
4
4
4
4
12
*Secure the truss support 51mm from the top edge.
14
Fix the last two truss supports
to the assembly with 2x40mm
screws per side.
4x40mm Screws
11 11
Attach the truss blocks to each side
of the support with 1x60mm
screw per block.
2x50mm Screws
Pre drill
hole
50mm
screw
12
11
*
Secure the rst 2 truss
supports together with
4x40mm screws as shown
in the illustration.
4x40mm Screws
40mm
screw
Step 5
Pre drill
hole
50mm
screw
Fix the assembled truss inbetween
the panels, approximately half
way between the gables, and secure
using 4x50mm screws.
4x50mm screws
Step 7
Please retain product label and instructions for future reference

P 6
10mm Felt Tags
100mm
intervals
50mm
Overhang
Cut felt into 4 sheets and lay
onto roof as shown in
diagram ensuring there is a
50mm overhang around the
sides.
Fix using felt tacks at 100mm
intervals
Step 9
5
1
14
4
4
Step 10
Use 30mm screws to x
each cover trim.
18x 30mm Screws
1
4
5
10
10
10
Step 11
Use 40mm screws to x
each fascia block, fascia and
Shed Diamond.
44
1
25
9
18x 40mm Screws
15
15
Step 12
To x the lock in place. Screw the Staple
to the Door Gable or Slave door.
Making sure the Hasp is in line with
the staple and screw into the Door or
Master door.
To lock the Door, place the Hasp over the
Staple and twist into the lock position as
shown.
8x30mm screws.
Pre drill
hole
30mm
screw
Please retain product label and instructions for future reference

22
6x20mm screws per casement stay
It is ESSENTIAL that you apply wood treat-
ment immediately after the building has
been assembled.
Step 14
Fix the casment stay to the
opening window then align
the xings onto the the
window panel frame. ensure
thecasement stay ts into
xings when closed before
screwing them down using
x12 20mm screws.
AFTER TREATMENT:
score around protective
cover on glazing and
carefuly peel
covering back
30mm
screw
Pre drill
hole
19
Place the Cloaking Strip to the
rear of one of the doors. Fixing in
position screwing through the door
into the cloaking strip with 3x30mm
screws.
Align the tower bolts onto the
vertical framing of the slave
door, secure the bolts to the
top and bottom using 6x30mm
black screws per tower bolt.
Mark the position of the bolt
& drill a hole above and below
for the bolt to catch in to.
15x30mm Black Screws
21
20
Step 13
P 7
Please retain product label and instructions for future reference
