Forever Redwood BENCH SWINS User manual

ASSEMBLY INSTRUCTIONS FOR THE
BENCH SWINS (SEATS ONLY)
866.332.2403 (TOLL FREE); 7am –7pm Pacific Time, Monday-Saturday

P| 1
Bench Swings (Seats Only)
www.ForeverRedwood.com
CONTENT OF BOXES
No.
1
2
3
Drawing
Description
Armrest
Seat
Backrest
Qty.
2
1
1
Note: Part numbers in the Content of Boxes Table are for reference only. These do not match to the numbers marked on the parts sent.

P| 2
Bench Swings (Seats Only)
www.ForeverRedwood.com
HARDWARE LIST
No.
A
B
C
D
E
Drawing
Description
5/16´´ x 3 ½´´ Bolts
(To attach the seat and the backrest to the
armrest).
4´´ x 3/8´´ Eyebolts
(To attach the backrest to the armrest).
Quick Links
Springs
Chains
Note: Dimensions of your hardware will vary depending on size.

P| 3
Bench Swings (Seats Only)
www.ForeverRedwood.com
No
1
2
3
DESCRIPTION
Armrest
Seat
Backrest
Note: Part numbers in the Drawing are for reference only. These do not match to the numbers marked on the parts sent.
1
1
2
3

P| 4
Bench Swings (Seats Only)
www.ForeverRedwood.com
Step 1: Attach the seat (2) to the armrests (1) with 5/16´´ x 3 ½´´ bolts (A). Each part has a series of numbers that indicate where
to attach the part with the corresponding number.
Step 2: Attach the backrest (3) to the armrests with 5/16´´ x 3 ½´´ bolts (A) and 4´´ x 3/8´´ eyebolts (B). Each part has a series of
numbers that indicate where to attach the part with the corresponding number.
3
5/16´´ x 4´´ Bolts
2
1
1
5/16´´ x 3 ½´´ Bolts
5/16´´ x 3 ½´´ Bolts
4´´ x 3/8´´ Eye Bolts

P| 5
Bench Swings (Seats Only)
www.ForeverRedwood.com
Step 3: Finally, put the quick links (C) and the springs (D) in the hanger support. After that put the chains (E). Take a few minutes
to adjust the chain height to your preference.
This completes the Bench Swing assembly. Hope you enjoy your set for many decades. If you ever have a problem or a
question, don't hesitate to call us (866 332 2403) or email us. We are here to support you.
