ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
INTENDED FOR RESIDENTIAL USE ONLY.
PARTS LIST
RTS016Z-WM
PART
NO. MATERIAL CODE PART Q’TY PART
NO. MATERIAL CODE PART Q’TY
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
2
4
32
10
12
6
1
1
1
1
2
1
1
1
4
4
PAGE 1 OF 3 COURTYARD CREATIONS INC.
STOP DON’T RETURN TO STORE!
ATTENTION:
Make sure that each bolt needed for all steps match
the corresponding figure to ensure proper assembly.
STEP 1:
Insert the right and left arms (#1 and #2) into the cross
braces (#3) on both sides. Fasten them together by
using bolts (#7), washers (#11), and plastic nuts (#12).
Keep the bolts loose. See Figure 1.
62RTS016LH101
18000337001
18000337004
17C01A0719071Y4
17C01A0710001Y4
BOLT CAP M6
BOLT CAP
HEX.KEY WRENCH 4MM
17KAA0101----Y4
17KAB1101----Y4 NUT WRENCH 10&13MM
PLASTIC NUT M6*P1.0
WASHER d6.5*D13*1.0
BOTTOM FRAME
SEATASSEMBLY
CROSS BRACE
RIGHTARM
LEFTARM
RTS016Z-CS03
BACK ASSEMBLY
BOLT M6*30
BOLT M6*55
RTS016Z-CS04
RTS016Z-CS01
RTS016Z-CS02
RTS016L-CS03
17C33A0755001Y4
17C33A0712001Y4
BOLT M6*65
BOLT M6*35
17FA05040301-Y4
18000C23001
FIGURE 1
30
#7 BOLT M6*30
Arm
assembly
1
1
2
2
3
3
3
3
7
13
13 13 13
13
11
1112
NOTE:
The labels marked “L” and “R” on the arms (#1 and #2)
should coincide with Figure 1 to ensure proper
assembly.
RL
!
!
!
!
Do not discard any of the packaging until you have checked that you have all the parts and pack of fittings.
Keep children away during assembly. This item contains small parts which can be swallowed by children.
Children should always be under direct adult supervision while using the product.
Retain the assembly instructions for future reference.
Please quote following FQC NO. when contacting service center.
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
PAGE 2 OF 3
STOP DON’T RETURN TO STORE!
STEP 2:
Place the arm assembly onto the bottom frame (#4).
Make sure that the higher tube on the bottom frame
(#4) is facing the front of the glider. See Figure 2.
STEP 3:
Fasten the swing bars of the arm assembly to the bottom
frame (#4) by using bolts (#8), washers (#11), and plastic
nuts (#12). Keep the bolts loose. See Figure 3.
STEP 4:
Fasten the back assembly (#6) to the seat assembly
(#5) by using bolts (#9), washers (#11), and plastic
nuts (#12). See Figure 4.
STEP 5:
Place the seat and back assembly onto the arm assembly.
See Figure 5.
STEP 6:
Fasten the seat assembly (#5) and the back assembly
(#6) to the right and left arms (#1 and #2) by using bolts
(#10) and washers (#11). Completely tighten all of the
bolts and cover them with bolt caps (#13 and #14).
See Figure 6.
FIGURE 2
FRONT
HIGHER TUBE
FIGURE 3
55
#8 BOLT M6*55
FIGURE 4
35
#9 BOLT M6*35
FIGURE 5
FIGURE 6
65
#10 BOLT M6*65
6
1
6
5
12 11 11 914
4
12
4
12 11 1111 11 813
11
11
11
11
12
813
511 10 14
2
6
5
FULLASSEMBLY
Cleaning and Maintenance
• Wash frame and fabric parts with mild soap and water, rinse thoroughly, and dry completely. Do not use bleach,
acid, or other solvents on the frame and fabric parts.
• We recommend the use of furniture covers when not in use.
• Please inspect and tighten all bolts or fasteners on a regular basis to ensure proper performance and safety of
your glider.
• In order to prolong the life and beauty of your glider, we recommend that it be stored in a dry and protected
area during off season periods.
STEP 7:
See Full Assembly.
Missing A Part?
No Need To Go Back To
TheStore!
The store where you made your purchase
does not stock parts for this item
if you need parts,
whether they are missing or damaged.
Call Toll Free
TEL: 1-877-539-7436
FAX: 1-877-539-7439
Call us between 9:00 AM and 4:30 PM
Eastern Time Monday through Friday
PLEASE READ THESE INSTRUCTIONS COMPLETELY BEFORE STARTING ASSEMBLY
PLEASE SEPARATE AND IDENTIFY ALL PARTS, MAKING SURE THAT YOU
HAVE ALL OF THEPARTSLISTED.
SHOULD YOU NOTLOCATE ALL OF THE ABOVE PARTS, PLEASE INSPECTALL
PACKING MATERIAL FOR ANYSMALL PARTSTHAT MAYHAVEBECOME
SEPARATED IN SHIPMENT.
SHOULDYOU EXPERIENCEANY DIFFICULTYDURING ASSEMBLYOR IF ANY
PARTIS MISSING OR DAMAGED,PLEASE CALL THE HELP LINE 1-877-539-7436
BEFORERETURNING THEITEM TO THESTORE.
PLEASE PROVIDE THEFOLLOWING INFORMATION:
1-MODEL NUMBER OF THEPRODUCT.
2-PARTNUMBER AND MATERIAL CODE OF THE PARTFROM THE PARTS LIST
SHOWN ON ASSEMBLY INSTRUCTIONS.
MOST PROBLEMSCAN BERESOLVED WITHOUT RETURNING THIS PRODUCT
TO THERETAILER.
The store where you made your purchase
does not stock parts for this item
if you need parts,
whether they are missing or damaged.
STOP!
MissingA Part?
No Need To Go Back To
The Store
Call us between 9:00 AM and 4:30 PM
Eastern Time Monday through Friday
Call Toll Free
TEL: 1-877-539-7436
FAX: 1-877-539-7439
PAGE 3 OF 3
STOP DON’T RETURN TO STORE!
