Fortis FSFITNSBNHA User manual

HOME GYM FITNESS WEIGHT BENCH
FSFITNSBNHA
ASSEMBLY INSTRUCTIONS
EXPLODED DIAGRAM

PARTS LIST
Part No Description QTY
01 RT. Barbell Crutch 1
02 LT. Barbell Crutch 1
03 Support Bar 1
0 Main Base 1
05 Central Brace 1
06 Front Leg 1
07 Quick Pin 1
08 Leg Lift 1
09 RT. Butterfly Arm 1
10 LT. Butterfly Arm 1
11 Backrest HT. Bar 1
12 Backrest Support 2
13 Leg Lift Pad Bar 3
1 Butterfly Pad Tube 2
15 Seat 1
16 Backrest 1
17 Pad 8
19 38mm Square Cap 10
20 Buffer Bushing 2
21 25mm Square Cap
22 Φ 25 Round Bumper 1
23 Φ25 Round Cap 5
2 Φ19 Round Cap 10
25 Round Bushing
27 M10*60 Bolt 6
28 M10*55 Bolt
30 M6*15 Bolt
31 M6* 0 Bolt
32 M10 Washer 20
33 Secure Ball 2
3 M6 Washer 8
35 M10*20 Bolt 1
36 M10 Nylon Nut 10

ASSEMBLY
Step One
1. Place 38mm Square Cap (19) onto both ends of Main Base (0 )
2. Attach RT. & LT. Barbell Crutch (01, 02) to Main Base (0 ). Secure with
Bolts (27), Washers (32) and Nuts (36) as shown.
3. Attach Support Bar (03) to RT. & LT. Barbell Crutch (01, 02). Secure with
Bolts (28), Washers (32) and Nuts (36) as shown.
. Place Buffer Bushing (20) onto RT. & LT. Barbell Crutch (01, 02)

Step Two
1. Place 38mm Square Cap (19) onto both ends of front leg (06).
2. Attach the Central Brace (05) to Front Leg (06), then attach the other end
of the Central Brace (05) to the Support Bar (03). Secure with Quick Pin
(7), Bolts (27), Washers (32) and Nuts (36), as shown.

Step Three
1. Place 38mm Square Cap (19) and Φ25 Round Cap (23) onto both ends of
the Butterfly Arm (09, 10).
2. Insert Round Bushing (25) into the welded tubes on the RT. & LT. Barbell
Crutches (01, 02).
3. Insert Butterfly Pad Tube (1 ) into the Butterfly Arms (09, 10)
. Slide on Butterfly Pad (17) and Φ19 Round Cap (2 ) into the Butterfly Pad
Tube (1 ).

Step Four
1. Place 38mm Square Cap (19) onto Leg Lift (08).
2. Place Φ25 Round Bumper (22) and Φ25 Round Cap (2 ) onto Leg Lift
(08).
3. Attach Leg Lift (08) to Central Brace (05). Secure with Bolts (27), Washers
(32) and Nuts (36), as shown.
. Slide Leg Lift Pad Bar (13) through the Leg Lift (08) and Central Brace
(05), as shown.
5. Slide the Leg Lift Pad (17) and Φ19 Round Cap (2 ) onto Leg Lift Pad Bar
(13), as shown.

Step Five
1. Place 25mm Square Cap (21) onto Backrest Support (12).
2. Attach Backrest Support (12) over the welded rod of the Central Brace
(05). Attach the Backrest (16) and Backrest Support (12) to the Central
Brace (05). Secure with Bolts (31) and Washers (3 ) as shown.
3. Attach the Seat (15) to the Central Brace (05). Secure with Bolts (30) and
Washers (3 ), as shown.
. Place Φ19 Round Cap (2 ) onto the Backrest HT. Bar (11).
5. Lift the Backrest (16) onto the Backrest HT Bar (11) through the RT. & LT.
Barbell Crutch (01, 02) to your desired height.
