Foxfury Lighting Solutions EXOLANDER 700-XLS-IIE User manual

PRODUCT MANUAL
700-XLS-IIE | 700-XSS-IIE
EXOLANDEREXOLANDER©©SYSTEMSSYSTEMS
AUTEL EVO II ENTERPRISEAUTEL EVO II ENTERPRISE

2
TABLE OF CONTENTS
EXOLANDER©SYSTEMS 3
EXOLANDER©Landing System
Reference Guide 4
Physical Characteristics 5
Installation 5 - 7
D100 DRONE SPOTLIGHT©
Reference Guide 8
Physical Characteristics 9
Battery 10
Operational Modes 10
Installation 11-12
CARE/CLEANING 13
WARNINGS/WARRANTY 13-14
CONTACT FOXFURY 14

3
EVO II
Enterprise
Saddle Mount©
EXOLANDER©Landing Skids,
set of 2
D100 Drone
Spotlight©
EXOLANDER©
Landing System
for EVO II
Enterprise
P/N 700-XLS-IIE
- - -
EXOLANDER©
Spotlight System
for EVO II
Enterprise
P/N 700-XSS-IIE
EXOLANDER©SYSTEMS

4
EXOLANDER©LANDING SYSTEM
REFERENCE GUIDE
EVO II ENTERPRISE
SADDLE MOUNT©
EXOLANDER©HALF
ALIGNMENT
SLOT
SNAP LOCK
(7 EA) LOCKING KNOB
& SCREW
ALIGNMENT
PIN (2 EA)
THREADED LOCKING
NUT INSERT
EXOLANDER©ASSEMBLED
EXOLANDER©MOUNT
CONNECTOR TO
SADDLE MOUNT (4 EA)
PAYLOAD DELIVERY
MOUNT SLOT (4 EA)
EXTERNAL
ACCESSORY SNAP
LOCK MOUNT (4 EA)
D100©MOUNTING
HOLE (4 EA)
LOCKING KNOB
& SCREW (2 EA)
EXOLANDER©LANDING
FOOT WITH SLOT (2 EA)
LANDING SKIDS
TA B (2 EA)
PER SKID

5
WARNINGS
It is the responsibility of drone/UAV users to follow the FAA and global
laws and regulations and/or the laws and regulations applicable to the
flight location.
While using any FoxFury product, please operate at safe speeds.
PHYSICAL CHARACTERISTICS
INCLUDED
EVO II Enterprise Saddle Mount©
EXOLANDER©
Landing Skid, set of 2
DIMENSIONS WEIGHT*
EVO II Enterprise
Saddle Mount©
3.29 x 2.63 x 3.5 in
(83.5 x 66.8 x 88.9 mm) 1.29 oz (36.5 g)
EXOLANDER©,
assembled
6.8 x 6.5 x 4.8 in
(173.2 x 163.8 x 123 mm) 4.05 oz (114.7 g)
Landing Skid 8.67 x 0.97 x 0.6 in
(220 x 24.7 x 15.2 mm)
0.45 oz (12.8 g)
per skid
*Total weight of 700-XLS-IIE system is 6.24 oz (176.8 g).
EXOLANDER©LANDING SYSTEM
INSTALLATION
Install Saddle Mount©on EVO II Enterprise.
1. Slide the Saddle Mount©on EVO II Enterprise and make sure that the
two extensions fit behind the front arms of the EVO II Enterprise and
press down.
1

6
Install EXOLANDER©on Saddle Mount©.
1. Place EVO II Enterprise with Saddle Mount©upside down on a flat
surface.
2. Align the EXOLANDER©Half with Snap Lock locations on Saddle
Mount©and slide in the EXOLANDER©Half at an angle as shown
below. Make sure the foot is facing away from the center of the
drone. Tilt the EXOLANDER©Half as shown.
3. Install the other EXOLANDER©Half in the open Saddle Snap Lock
locations. Bring the units together and align the Pin into the Hole on
each side.
4. Align Locking Knob & Screw and Thread Locking Nut Insert on each
side.
2

7
5. Tighten each screw until the units are mated.
6. The EXOLANDER©installation is now complete.
7. To install the Landing Skid, align each Tab on Landing Skid with each
Slot on the EXOLANDER© Landing Foot. Press and snap Landing Skid
on.
WARNING:
Manually test the EXOLANDER©Landing System by wiggling it and making
sure nothing is loose. Note that a small amount of movement between the
structure and the UAV has been created, at the request of Autel, to eliminate
adding unnecessary forces to the vehicle’s structure.
NOTE:
Do not pull/spread the Saddle during installation. The Saddle is intended to be
pushed into place.
NOTE:
Before our accessories are made available, they are tested internally
and verified externally by a minimum of 2 professional users. We have
experienced multiple cases of UAS (drone) mechanical modifications from
manufacturers within the same P/N and revision, and without providing
warnings or product updates. If there is a fit problem, please contact our
customer service department at https://www.foxfury.com/contact/

8
D100 DRONE SPOTLIGHT©
REFERENCE GUIDE
D100 DRONE SPOTLIGHT©
BACK VIEW
POWER/MODE
SWITCH
¼-20 THREADED
HOLE (2 EA)
BATTERY COVER
MOUNTING KNOB (2 EA)

9
WARNINGS
Please fully charge the provided 18650 batteries before using the D100©
for the first time.
Do not stare into the LEDs for long periods of time or from close range
(less than 2 ft / 0.6 m)
While using any FoxFury product, please operate at safe speeds.
It is the responsibility of drone/UAV users to follow the FAA and global
laws and regulations and/or the laws and regulations applicable to the
flight location.
The D100©will become hot to touch after 20 min of continuous use.
Please handle carefully by avoiding contact with the metal heatsink.
PHYSICAL CHARACTERISTICS
INCLUDED
D100 Drone Spotlight©
Mounting Knob (2 ea)
18650 Lithium-Ion Battery (2 ea)
XTAR Battery Charger
DIMENSIONS 3.46 x 2.01 x 2.44 in (88 x 51 x 62 mm)
WEIGHT 8.92 oz (253 g)
12.23 oz (346.6 g) with provided 18650 batteries
*Total weight of 700-XSS-IIE system is 18.47 oz (523.4 g).

10
D100©requires two (2) 18650 batteries.
Mixing of new and used, or different brand batteries, is not recommended
as this could lead to leakage or explosion.
BATTERY INSTALLATION AND REPLACEMENT
Slide the battery cover open and insert the battery according to the plus
(+) and minus (-) symbol located inside of the battery compartment.
Once batteries are installed, test the light’s performance by activating the
Power/Mode Switch. Slide the battery cover back on.
BATTERY
1
2
CHARGING BATTERY
Refer to the instruction manual provided with the XTAR Battery Charger.
POWER/MODE
SWITCH
OPERATIONAL MODES
Press and hold Power/Mode Button to turn the light ON.
Press Power/Mode Button again to change the mode to STROBE.
Press Power/Mode Button again to turn the light OFF.
MODE LUMENS BATTERY LIFE
ON 2,300 70 minutes
TURBO-STROBE 2,300 140 minutes

11
ITEMS REQUIRED
EXOLANDER©Landing System
Install EXOLANDER©Landing System on the drone. Reference p.5 - 7.
Install D100©on EXOLANDER©Landing System.
1. Insert each Mounting Knob in the D100©Mounting Hole of the forward-
facing section of EXOLANDER©.
2. Align the Mounting Knobs with the ¼-20 threaded screw holes on
D100©to install D100©on EXOLANDER©. Make sure the switch cover
faces the right side (facing the unit). Note that the curved rear edge
should be on the top.
D100©INSTALLATION
1
2

12
3. Tilt D100©to access the Switch and turn it on to desired mode.
4. Adjust the tilt of D100©to desired angle and tighten the Mounting
Knobs.

13
PRODUCT DURABILITY
CARE/CLEANING
Your FoxFury product is a professional
tool. Regular maintenance and care of
your light will maximize performance for
you. As needed, clean your FoxFury
product using a damp soft washcloth.
Do not immerse.
ACCESSORIES
Rechargeable 18650 Li-Ion
Battery, P/N 70-18650T
Battery Charger, 600-155
WARNINGS
FoxFury, LLC is not responsible for the
incorrect use of any FoxFury Lighting
product.
When used for extended periods
of time the D100©will become
HOT to the touch. Please use care
when operating.
Lights are strong enough to cause
damage to the human eye.
Do not stare into LEDs for long
periods of time or from a close
range (less than 2 ft / 0.6 m).
FoxFury, LLC is not responsible
for any injury or damage caused
during the use of this product.
Usage of this product must be
supervised by an adult when it is
being used by a minor.
Any FoxFury product should
be operated at speeds safe
enough to maneuver around
surrounding obstacles.
Do not use under the influence
of drugs or alcohol.
ONE YEAR WARRANTY
FoxFury, LLC (“FoxFury”) warrants
this product to be free from defects
in material for one year after
purchase. Li-Ion batteries have a one
year pro-rated or 500 re-charge cycle
pro-rated warranty, whichever the
user reaches first.
This warranty is given only to the
original end user of the accompanying
product. If you purchased a product
from someone other than an
authorized FoxFury reseller/distributor
or if the product was used, (including
but not limited to demo models, show
models or refurbished product by
someone other than FoxFury) prior
to your purchase, you are not the
Original Purchaser and the product
that you purchased is not covered by
this warranty. This warranty is VOID
if this Product has been altered or
modified in any way (including but not
limited to attempted warranty repair
without authorization from FoxFury
and/or alteration/removal of the
serial number). To expedite warranty
concerns, we encourage the end user
to register their FoxFury Product at
www.foxfury.com/pages/warranty-
registration.
WARRANTY AND OTHER
INFORMATION
3 M

14
THIS IS THE ONLY WARRANTY,
EXPRESSED OR IMPLIED,
INCLUDING ANY WARRANTY OF
MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE.
INCIDENTAL, CONSEQUENTIAL
OR SPECIAL DAMAGES ARE
EXPRESSLY DISCLAIMED EXCEPT
WHERE SUCH LIMITATION IS
PROHIBITED BY LAW.
You may have other specific legal
rights which vary by jurisdiction. Go to
www.foxfury.com/pages/warranty for a
complete copy of the warranty. Retain
your receipt for proof of purchase.
CONTACT FOXFURY
FoxFury, LLC
Oceanside, CA 92056 USA
Tel : [phone]
Email: [e-mail]
Web: FoxFury.com
All FoxFury products are designed in
Oceanside, CA. All FoxFury products
are manufactured with the highest
quality USA and foreign parts.
Products are assembled in either
FoxFury’s controlled plant in Asia or the
USA, under strict quality control.
CALIFORNIA
PROPOSITION 65
This product can expose you to
chemicals including Lead and DEHP,
which are known to the State of
California to cause cancer and birth
defects or other reproductive harm.
For more information go to
www.P65Warnings.ca.gov.

15
FOXFURY.COM 04/2023
