PRODUCT MANUAL
200–400–100 |200–400 –102
NOMADNOMAD®NOW

2
TABLE OF CONTENTS
INTRODUCTION
Reference Guide 3
Overview 4
Physical Characteristics 4
BATTERY PACK
Charging the Battery Pack 5
Charging from a 12VDC Vehicle Adaptor 5
Charge Indicator 5
OPERATIONAL MODES
AC-DC Adaptor and International Use 6
Operational Modes 6
Battery Life 7
Battery Life Indicator 7
Using the Nomad®NOW While Plugged in 7
FEATURES
Swiveling Light Head 8
Sliding Diffuser Lens 8
Remote Key Fob Use 9
MOUNTING THE NOMAD®
Magnetic Mount 10
Stacking 10
OPTIONAL ACCESSORIES (NOT INCLUDED)
Horizontal Right Angle Mount 10
Utility Mount 11
Wall Mount Kit 11
Tripo-Scope®M1/ Tripod and FoxFury Puck Adaptor 11
MAINTENANCE 12–14
WARRANTY 15–16
CONTACT FOXFURY 16

3
NOMAD®NOW REFERENCE GUIDE
COLLAPSIBLE
HANDLE
SLIDING DIFFUSER LENS
(AREA-SPOT)
REMOTE SWITCH
SWIVELING
LIGHT HEAD
¼"-20 MOUNT
(ON TOP & BOTTOM)
BATTERY LIFE/
CHARGE INDICATOR
MAGNETIC/WALL
MOUNT HOLES (4)
CHARGING PORT
POWER/MODE SWITCH
REMOTE SWITCH
INDICATOR
ALSO INCLUDED
12VDC Vehicle Adaptor
Accessories Bag
All Thread ¼"-20 Screw
Remote Key Fob
Magnetic Mount
AC-DC Adaptor
AC Cable

4
OVERVIEW
The Nomad®NOW is FoxFury's most compact and versatile Area-Spot light.
It can provide up to 3,300 lumens on HIGH Power. Portable enough to go
anywhere, it is completely waterproof and adapts to many specific needs. As
a handheld lantern, it lights an immediate path. Rest it on a flat surface, hang it
or mount it and have a well-lit work area and two free hands. Three (3) Nomad®
NOWs can be stacked to provide additional or multi-directional light.
PHYSICAL CHARACTERISTICS
Please read below before using the Nomad®NOW as it relays beneficial
operating and safety information.
NOMAD®NOW
DIMENSIONS 8.7 x 5.3 x 4.3 in (221 x 135 x 109 mm)
WEIGHT 4.5 lbs (2 kg)
WARNINGS
Please fully charge the Battery Pack before using the Nomad®NOW for
the first time.
Do not stare into LEDs for long periods of time or from a close range
(less than 2 ft or 0.6 m).
When used for extended periods of time the Nomad®NOW Light Head
will become HOT to the touch. Please use care when operating.
Be sure to rinse the Nomad®NOW with fresh water immediately after use
in the ocean or a pool.
!
!
!

5
CHARGING THE BATTERY PACK
1. Start with the AC Cable. Connect it to the AC-DC Adaptor.
The AC Cable is Universal to NEMA 5-15P, 3 prong for USA and will
work with a power range of 100VAC–240VAC 50/60 Hz.
2. Then, plug the Barrel Connector (part of the AC-DC Adaptor) into the
Charging Port of the Nomad® NOW.
Input voltage: 11–17VDC. Do NOT exceed!
The Nomad®NOW is shipped with a 30% charge. It is important to
charge it before using it for the first time.
When the Charge Indicator FLASHES green it indicates that the
Battery Pack is being charged. When the Nomad®is completely
charged, the Charge Indicator will turn solid green.
Charging time will be approximately 4 hours.
CHARGING FROM A 12VDC VEHICLE ADAPTOR
1. Insert the 12VDC Vehicle Adaptor into a 12V socket (located within the
vehicle).
2. Then, insert the opposite end (Barrel Connector) into the Charging Port of
the Nomad®NOW.
NOTE: Do NOT start vehicle while the Nomad® is plugged in.
CHARGE INDICATOR (FOR LOCATION, PLEASE REFERENCE PAGE 3)
COLOR DESCRIPTION
GREEN (SOLID) FULLY CHARGED
GREEN (FLASHING) CHARGING
RED (SOLID) CHARGING ERROR*
*If a charging error occurs, please contact FoxFury Customer Service (see p. 16).
WARNINGS:
• Please DO NOT leave AC-DC Adaptor plugged in to Nomad charged for
more than eight (8) continuous hours.
• Continuously charging (leaving the unit plugged in) could damage the
Battery Pack and lead to a decreased battery life.
• Extended periods of charge could also result in the batteries being placed
in thermal runaway mode.
• Use of any non FoxFury supplied AC-DC charger will VOID Product
Warranty.

6
AC-DC ADAPTOR AND INTERNATIONAL USE
The Nomad®Series has a AC-DC Adaptor which uses AC Cables like those
used in desktop computers or monitors. With every Nomad®, FoxFury supplies
a cable that terminates in the USA standard 110 VAC plug.
The plug of the AC Cable should be country specific. Example: IEC Types A-N.
The Female Connector side of the AC Cable must be IEC Type C13 to mate
with the Male Inlet of the AC-DC Adaptor.
ON/LOW mode: Press the Power/Mode Switch once.
MEDIUM mode: From LOW mode, press the Power/Mode Switch once.
HIGH mode: From MEDIUM mode, press the Power/Mode Switch once.
OFF: From HIGH mode, press the Power/Mode Switch once.
NOTE: The light does not retain the mode in memory. Once the light is ON,
re-select the mode desired.
OPERATIONAL MODES
AC CABLE
TYPE B
10A (250V)
INLET (MALE) (C14 IEC)
(LOCATED AT END OF
ADAPTOR)
CONNECTOR
(FEMALE) (C13 IEC)
(VIEW OF CABLE END)
AC-DC ADAPTOR
BARREL CONNECTOR
CONNECTOR (FEMALE) AC PLUG
MUST BE IEC C13
CONNECTOR CAN BE ANY PLUG IEC TYPES A-N
AC CABLE
10A (250V)

7
BATTERY LIFE
MODE BATTERY LIFE* LUMENS
HIGH POWER 3 hours 3,300
MEDIUM POWER 9 hours 1,320
LOW POWER 24 hours 550
*Battery Pack life may vary according to age and ambient conditions.
BATTERY LIFE INDICATOR
COLOR DESCRIPTION
GREEN FULL BATTERY
ORANGE CAUTION —BATTERY IS GETTING LOW
RED (FLASHING) CHARGE IMMEDIATELY
USING THE NOMAD®NOW WHILE PLUGGED IN
The Nomad®can run for longer periods by plugging it into a power source.
1. Start with the AC Cable. Connect it to the AC-DC Adaptor.
2. Then, plug the Barrel Connector (part of the AC-DC Adaptor) into the
Charging Port of the Nomad®.
3. Press the Power/Mode Switch. The light will then turn ON.
The Nomad®must be turned OFF in order to charge the Battery Pack.
If it is plugged in and the Nomad®is ON, the battery is NOT being
charged.
Continuously charging (leaving the Nomad®plugged in) could damage
the Battery Pack and also lead to decreased battery life.
Input voltage: 11–17VDC. Do NOT exceed!
NOTE: The Nomad®NOW will NOT accept a 24VDC input.

8
FEATURES
SWIVELING LIGHT HEAD
The Nomad® NOW Light Head is able to swivel 45° to the left or right. This
allows the light beam to be manually directed.
SLIDING DIFFUSER LENS
Lighting needs can change in an instant or on a case-by-case basis. As an
Area-Spot light, the Nomad®NOW provides two types of lights in one. To
change from Area to Spot lighting, simply slide the Diffuser Lens down (Area)
or up (Spot).
NOTE: The Sliding Diffuser Lens can be removed and cleaned. Please
reference p. 13 for instructions.
NORMALLEFT RIGHT
SPOT
AREA

9
REMOTE KEY FOB USE
TO ACTIVATE THE REMOTE KEY FOB
Press the Remote Switch on the light once and make sure the green
indicator light is ON.
TO DEACTIVATE THE KEY FOB
Press the Remote Switch on the light once and make sure the green
indicator light is OFF.
REMOTE KEY FOB FEATURES
The Remote Key Fob functions at a maximum distance of 70 ft (21 m)
(This is the maximum distance that multiple stacked units will operate in
sync).*This distance was recorded without obstructions or interference, in ideal
conditions.
Runs on one (1) 27A battery.
The Remote Key Fob has the ability to cycle through the standard modes.
NOTE: While the Remote Key Fob is active, the Power/Mode Switch also
functions. You may use the Power/Mode Switch on the Light Head and the
Remote Key Fob simultaneously.
IMPORTANT!
Make sure to turn OFF the Remote Switch when not in use to prevent battery
drain OR accidental activation.
FOR P/N 200-400-100:
Multiple Nomad®NOWs share the same code, meaning that the included
Remote Key Fob can be used for multiple Nomad® NOWs.
FOR P/N 200-400-102:
The single unit is coded to only match the Light Head with remote control,
meaning that the included Remote Key Fob can be used for only the Nomad®
NOW that it is paired to.
LOST REMOTE KEY FOBS
If the Remote Key Fob becomes lost, please contact FoxFury Customer
Service (see p. 16).

10
MOUNTING THE NOMAD®NOW
OPTIONAL ACCESSORIES
(NOT INCLUDED)
HORIZONTAL RIGHT ANGLE MOUNT (P/N 85-046)
The Horizontal Right Angle Mount can be mounted to the NOW using two (2)
bolts. This allows the NOW to be mounted horizontally to a tripod or any mount
with a ¼"-20 screw providing the ability to direct light 45° up or down.
MAGNETIC MOUNT
The Nomad®NOW can also be mounted via the Magnetic Mount (included).
This allows the NOW to be held vertically on a magnetic surface. The Nomad®
NOW and Magnetic Mount can be pulled and placed from one surface to
another to fit your workspace and needs.
STACKING
The Nomad®NOW can stack to other units via the ¼"-20 Threaded Screw
(included). Thread the Screw into either end of the Nomad®NOW, then, twist
and screw another Nomad®onto the opposite end of that same Screw.
NOTE: Do not exceed 3 Nomad®NOWs.

11
WALL MOUNT KIT (P/N 85-044)
The Nomad®NOW Wall Mount can be permanently mounted to a wall or
surface by using the provided hardware.
TRIPO-SCOPE ® M1 (P/N 650-100), FOXFURY PUCK
ADAPTOR (P/N 85-045)
The NOW can be mounted to the FoxFury Tripo-Scope® M or other tripods.
Puck Adaptor is required when mounting Nomad NOW on tripods with a 3/8
-16 screw.
Thread the hole of the Nomad® NOW onto the ¼"-20 Threaded Screw of the
tripod or Puck Adaptor. Then, twist the Nomad® NOW onto the tripod or Puck
Adaptor until it is securely fastened.
UTILITY MOUNT (P/N 85-048)
The Nomad®NOW Utility Mount allows the NOW to be mounted on utility
vehicles with buckets or on trucks with tailgates. To prevent possible
scratching of paint, it is recommended that a cloth be placed between the
painted surface and the Utility Mount.

12
REMOVING THE BATTERY PACK
4 MINS ESTIMATED
At the end of the Battery Packs's life (which is about 500+ full charges), the
Battery Pack will stop holding a charge and will need replacing.
Make sure the Nomad®NOW is turned OFF before starting.
1. Begin with the back of the Nomad®NOW facing you. Locate the eight (8)
screws on the rear panel.
2. Use a Phillips Head(+) #1 screwdriver to unscrew and remove the eight (8)
screws. Then, remove the rear panel.
3. Once the rear panel is removed, notice a black strap, which holds the
Battery Pack in place. There is one (1) screw on each side of the strap.
Remove both using the same Phillips Head screwdriver. This will then
release the Battery Pack strap.
4. Pull the Battery Pack out of the Nomad® Body. Then, detach it from the
light by unclipping the Connector.
1
3
2
4
MAINTENANCE
CONNECTOR
1
2
3
4

13
REPLACING THE BATTERY PACK
4 MINS ESTIMATED
1. Attach the new Battery Pack to the light by re-clipping it the Connector.
Then, place the new Battery Pack back inside the Nomad®NOW.
2. Place the black strap over the Battery Pack. Then, re-insert and tighten
the two (2) screws.
3. Place the rear panel back onto the Nomad®NOW. Align as needed (it will
only properly fit in one direction). Re-insert and tighten the eight (8) screws
using a Phillips screwdriver.
NOTE: Remember to test the light’s performance by activating the Power/
Mode Switch.
REMOVING THE SLIDING DIFFUSER LENS
3 MINS ESTIMATED
1. Slide the Sliding Diffuser Lens back into the 'Area' setting. Locate
and remove the four (4) screws located on each side of it.
2. Then, tilt the Sliding Diffuser Lens forward.
3. Pull the Sliding Diffuser Lens out and free from the Light Head.
FOR RE-INSTALLATION: Repeat the steps above in reverse order.
2
13
1
2
3

14
MAINTENANCE (CONT'D)
GENERAL TIPS
The Nomad®NOW reaches a full charge in approximately 4 hours.
(Charge time may depend on ambient conditions and battery health).
Please DO NOT leave AC-DC Adaptor plugged into Nomad charged for
more than eight (8) continuous hours.
Maintain the light fully charged at all times, so that it is ready for use in
the event of an emergency.
If used outdoors in cold weather for an extended period of time allow
the Nomad®to warm up to above 10°C/50°F before charging.
Lithium-Ion batteries have a 500 full charge cycle life (CC followed by a
CV cycle)*. When the light gets near this number of cycles, there will be a
decrease in usage time. *CC=Constant Current charge (fast rate)
The Lithium-Ion batteries have a top-off or micro-charge life of around
1,200 cycles or more (CV only)*. If the Nomad®is un-used for 60 to 90
days, plug in the AC-DC Adaptor for 1 to 2 hours to bring the batteries
back up to peak charge. *CV=Constant Voltage charge (slow rate)
As needed, wash the Nomad®NOW using a soft washcloth, clean
water and a mild soap. When done, pat dry with a soft cloth.
STORING THE NOMAD®NOW
Make sure the light is powered OFF by pressing the Power/Mode Switch
until the light is no longer ON.
Press the Remote Switch to turn OFF the remote. If it is not turned OFF,
the battery will drain over time.
If the AC-DC Adaptor or 12VDC Vehicle Adaptor Cable is being used,
disconnect it from the Nomad®NOW and store.
WARNINGS WHEN STORING
The Nomad® depends on “ambient air” for cooling of its Light Head.
After being ON for a while, the Nomad®NOWs Heatsink Fins (which
help disperse heat) behind the Light Head will become warm to the
touch (possibly hot). This depends on the run time, setting, and/or air
temperature. The warmer the ambient air temperature is, the faster the
Light Head’s temperature will increase.
When it is time to put the Nomad®NOW away, either wait for the unit to
cool off (usually 10 - 20 min) or protect hands (with work gloves
or a cloth) while adjusting the Light Head.

15
WARNINGS
FoxFury, LLC is not responsible for the
incorrect use of any FoxFury Lighting
product.
When used for extended periods of
time the light will become HOT to
the touch. Please use care when
operating.
Lights are strong enough to cause
damage to the human eye.
Do not stare into LEDs for long
periods of time or from a close
range (less than 2 ft).
FoxFury, LLC is not responsible
for any injury or damage caused
during the use of this product.
Usage of this product must be
supervised by an adult when it is
being used by a minor.
Any FoxFury product should be
operated at speeds safe enough
to maneuver around surrounding
obstacles.
Do not use under the influence
of drugs or alcohol.
LIMITED LIFETIME
WARRANTY
FoxFury, LLC (“FoxFury”) warrants
this product to be free from defects
in material for a lifetime of use except
for batteries, LEDs, abuse, and
normal wear. Mechanical components
subjected to constant deformation
or action, like springs and switches,
and electronic components including
chargers and LEDs are warranted
for a period of two years from the
time of purchase. FoxFury will repair
or replace a product should it be
determined defective.
WARRANTY AND OTHER
INFORMATION
IPX7
1 M
PRODUCT DURABILITY
CARE/CLEANING
Your FoxFury product is a professional
tool. Regular maintenance and care of
your light will maximize performance for
you. As needed, wash your FoxFury
product using a soft washcloth, clean
water and a mild soap. Be sure that
Battery Pack is reassembled securely
before washing. When done, pat dry with
a damp cloth.
AVAILABLE ACCESSORIES
Nomad®NOW AC Adaptor-DC
Cord Set, P/N 600-120
Nomad®NOW Battery Kit
Replacement, P/N 600-200-400
Nomad®NOW Wall Mount Kit,
P/N 85-044
Nomad®NOW Horizontal Right
Angle Mount, P/N 85-046
Nomad®NOW Magnetic Mount,
P/N 85-040
Puck Adaptor, P/N 85-045
Nomad®NOW Utility Mount,
P/N 85-048
Small FoxFury Duffel Bag,
P/N 850-200-400
Accessories Bag, P/N 600-250
Remote Key Fob: Multi Activation,
P/N 51-123
Remote Key Fob: Single
Activation, P/N 51-125
(requires the unit's serial number)
Tripo-Scope®M1, P/N 650-100
Sliding Diffuser Lens, P/N 51-011
1 M

16
Rechargeable batteries are
consumable items, and carry a pro-
rated 2 year warranty. Example: If a
problem arises after one year of use,
only 50% of the replacement cost will
be charged, as long as the batteries
are verified to have been charged,
stored, and used in accordance with
required practices.
This limited lifetime warranty is
given only to the original end user of
the accompanying product. If you
purchased a product from someone
other than an authorized FoxFury
reseller/distributor or if the product
was used, (including but not limited
to demo models, show models or
refurbished product by someone
other than FoxFury) prior to your
purchase, you are not the Original
Purchaser and the product that you
purchased is not covered by this
warranty. This limited warranty is
VOID if this Product has been altered
or modified in any way (including but
not limited to attempted warranty
repair without authorization from
Foxfury and/or alteration/removal
of the serial number). To expedite
warranty concerns, we encourage
the end user to register their FoxFury
Product at www.foxfury.com/pages/
warranty-registration.
THIS IS THE ONLY WARRANTY,
EXPRESSED OR IMPLIED,
INCLUDING ANY WARRANTY OF
MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE.
INCIDENTAL, CONSEQUENTIAL
OR SPECIAL DAMAGES ARE
EXPRESSLY DISCLAIMED EXCEPT
WHERE SUCH LIMITATION IS
PROHIBITED BY LAW.
You may have other specific legal
rights which vary by jurisdiction. Go
to www.foxfury.com/pages/warranty
for a complete copy of the warranty.
Retain your receipt for proof of
purchase.
CONTACT FOXFURY
FoxFury, LLC
Oceanside, CA 92056 USA
Toll-Free: 844-FOXFURY
Tel : [phone]
Fax: [phone]
Email: [e-mail]
Web: FoxFury.com
All FoxFury products are designed in
Oceanside, CA. All FoxFury products
are manufactured with the highest
quality USA and foreign parts.
Products are assembled in either
FoxFury’s controlled plant in Asia or
the USA, under strict quality control.
CALIFORNIA PROPOSITION
65
This product can expose you to
chemicals including Lead and DEHP,
which are known to the State of
California to cause cancer and birth
defects or other reproductive harm.
For more information go to www.
P65Warnings.ca.gov.

FOXFURY.COM 6/2021
