Foxfury Lighting Solutions SIDESLIDE SERIES User manual

PRODUCT MANUAL
C-CLAMP 940K-010FI |BOLT 940K-010RSC |PICATINNY 940K-010PIC
SIDESLIDE SERIES

2
SIDESLIDE REFERENCE GUIDE
LANYARD
HOLE
RUBBER
SLEEVE
POWER/MODE SWITCHLOCKING GROOVE
STRIKE BEZEL
ANTI-ROLL HEAD TAILCAP
HANDLE
BOLT MOUNT PICATINNY MOUNT
C-CLAMP MOUNTHOLDER
RELEASE
LEVER
MOUNT
SCREW HOLES (3)
RELEASE
LEVER
MOUNT
THUMBSCREW (2)
RELEASE
LEVER
MOUNT
SCREWS (4)
RELEASE LEVER
FRONT

3
PHYSICAL CHARACTERISTICS
Please read below before using your SideSlide as it relays beneficial operating
and safety information.
FLASHLIGHT (940– 010FI OR 940–012)
DIMENSIONS 5.5 x 1.5 x 1.1 in
140 x 38 x 28 mm
WEIGHT
(without battery) 5.3 oz (150 g)
These application-specific SideSlide mounts allow the flashlight to be secured
to the Holder for quick and easy hands-free use.
C-CLAMP MOUNT (85-010)
DIMENSIONS 1.5 x 2.8 x 1.6 in
38 x 71 x 41 mm
WEIGHT 3.7 oz (105 g)
BOLT MOUNT (85-011)
DIMENSIONS 1.5 x 2.0 x 2.4 in
38 x 51 x 61 mm
WEIGHT 2.9 oz (82 g)
PICATINNY MOUNT (85-012)
DIMENSIONS 1.5 x 1.8 x 1.9 in
38 x 46 x 48 mm
WEIGHT 2.5 oz (71 g)

4
BATTERIES
The SideSlide Series flashlight requires one (1) 18650 battery or two (2)
CR123 batteries.
Mixing of new and used, or different brand batteries is not recommended
as this could lead to leakage or explosion.
BATTERY INSTALLATION AND REPLACEMENT
1. Twist the Tailcap in a counter-clockwise direction to remove it.
2. Insert the battery with the positive end first. (Respect appropriate polarity
when installing).
3. Re-install the Tailcap by twisting it in a clockwise direction back onto the
Handle. (Make sure the Tailcap is tightly sealed).
4. Test the light’s performance and function by activating the Power/Mode
Switch (located at the end of the Tailcap).
BATTERY LIFE (940K-010FI & 940K-010RSC)
MODE BATTERY LIFE LUMENS
HIGH POWER 3.5 hours 200
LOW POWER 8 hours 70
FLASHING 5 hours 200
+BATTERY –
1
2
TAILCAP

5
OPERATIONAL MODES
FOR THE C-CLAMP AND BOLT MOUNTS:
For HIGH mode: Press the Power/Mode Switch once.
For LOW mode: Press and hold the Power/Mode Switch for 2.0–2.5 sec.
For FLASHING mode: While in LOW mode, press and hold the Power/
Mode Switch for an additional 2.0–2.5 sec.
FOR THE PICATINNY MOUNT:
For MOMENTARY mode: Press and hold the Power/Mode Switch. While
the Switch is depressed, the flashlight will operate in HIGH mode. When
the user removes pressure from the Switch, the light will turn OFF.
For CONTINUOUS HIGH mode: Press the Power/Mode Switch two (2)
times in rapid succession. The light will remain in HIGH mode.
For CONTINUOUS LOW mode: While in HIGH mode, press and hold the
Power/Mode Switch for two (2) seconds. The mode will change to a LOW
setting.
For TURBO-STROBE™: Press the Power/Mode Switch three (3) times in
rapid succession.
For OFF or EXIT a mode: Press the Power/Mode Switch once. Then,
continue following the directions above to progress to desired mode.
NOTE:
The light does not retain the mode in memory. Once you turn the
flashlight ON, you will have to re-select the mode you desire.
When the light is ON in any mode, a rear green warning light will flash
(excluding Picatinny model).
MODE BATTERY LIFE LUMENS
MOMENTARY 3 hours 380
CONTINUOUS HIGH 3 hours 380
CONTINUOUS LOW 8 hours 70
TURBO-STROBE™5 hours 380
*Battery life may vary according to mode selected, battery quality and prevailing ambient conditions.
BATTERY LIFE (940K-010PIC)

6
The flashlight is easily securable and removable by using the unique SideSlide
Release Lever.
TO INSERT THE FLASHLIGHT INTO THE HOLDER:
INSERTING AND REMOVING THE
SIDESLIDE FROM THE HOLDER
1. Insert the flashlight by pushing it into the beveled opening on the front of
the Holder.
2. Once locked, the Release Lever falls into a groove on the handle, securing
the flashlight in place.
TO REMOVE THE FLASHLIGHT FROM THE HOLDER:
12
1. Press and hold the Release Lever.
2. While keeping the Release Lever pressed, pull flashlight out of the Holder.
12

7
INSTALLATION OF YOUR
SIDESLIDE MOUNT
SIDESLIDE C-CLAMP
The C-Clamp can be mounted on the right or left side of the helmet, above or
below the brim (based on user preference).
TO MOUNT ON THE RIGHT SIDE OF A HELMET:
Place mount on helmet at desired location and tighten thumbscrews.
TO MOUNT ON THE LEFT SIDE OF A HELMET:
There are two (2) screws which allow you to separate the C-Clamp from the
Holder and flip it 180° so that it can be worn on the left side of a helmet.
1. Using a 2 mm AF Hex Key* twist the screws counter-clockwise to remove.
2. Pull C-Clamp mount away from Holder.
3. Spin C-Clamp mount 180°.
4. Align holes on the C-Clamp mount with holes on the Holder. Re-insert
screws and tighten with Hex Key, turning clockwise until secured.
OPTIONAL TIP: Apply Loctite™as needed to secure screws.
*2 mm AF Hex Key not included
12 3 4

8
INSTALLATION OF YOUR
SIDESLIDE MOUNT
SIDESLIDE BOLT
This mount has the ability to rotate and provide usable light at eight (8) distinct
positions, every 45°.
NOTE: Three (3) M4.0 Cap Head screws are needed to attach the mount to a
helmet. Length of screws is determined by thickness of the users helmet.
SIDESLIDE PICATINNY
Mounts on rifle, shotgun and helmet with Picatinny/MIL-STD 1913 rail.

9
WARRANTY AND OTHER
INFORMATION
PRODUCT DURABILITY
Meets NFPA 1971-2007 Fire
Resistant Requirements: 500°F
(260°C) for 30 minutes
REFLECTIVE STICKER
For P/N 940K-010FI & 940K-010RSC
only. For your safety, and increased
visibility, a reflective sticker (enclosed
in box) may be placed on the side of
the SideSlide.
CARE/CLEANING
Your FoxFury product is a
professional tool, but regular
maintenance and care of your light
will maximize performance for you. As
needed, wash your FoxFury product
using a soft washcloth, clean water
and a mild soap. Be sure that the
flashlight’s Tailcap is SEALED before
washing. When done, pat dry with a
damp cloth.
AVAILABLE ACCESSORIES
C-Clamp Adaptor, P/N 85-010
Bolt Adaptor, P/N 85-011
Picatinny Adaptor, P/N 85-012
Flashlight for C-Clamp & Bolt
P/N 940-010FI
Flashlight for Picatinny
P/N 940-012
Pressure Switch Cap
(Picatinny Only), P/N 50-150
18650 Rechargeable Battery,
P/N 70-18650R
Battery Charger & Adaptor -
AA, 18650, P/N 600-155
WARNINGS
FoxFury, LLC is not responsible for
the incorrect use of any FoxFury
Lighting product.
Lights are strong enough to
cause damage to the human eye.
Do not stare into LEDs for long
periods of time or from a close
range (less than 2 ft).
FoxFury, LLC is not responsible
for any injury or damage caused
during the use of this product.
Usage of this product must be
supervised by an adult when it is
being used by a minor.
Any FoxFury product should
be operated at speeds safe
enough to maneuver around
surrounding obstacles.
Do not use under the influence
of drugs or alcohol.
LIMITED LIFETIME
WARRANTY
FoxFury, LLC (“FoxFury”) warrants
this product to be free from defects
in material for a lifetime of use except
for batteries, LEDs, abuse, and
normal wear. We will repair or replace
this product should we determine it
to be defective. This limited lifetime
warranty excludes rechargeable
IPX7
1 M 2 M

10
batteries, chargers, switches, and
electronics, which have a 2-year
warranty with proof of purchase.
This limited lifetime warranty is
given only to the original end user of
the accompanying product. If you
purchased a product from someone
other than an authorized FoxFury
reseller/distributor or if the product
was used, (including but not limited
to demo models, show models or
refurbished product by someone
other than FoxFury) prior to your
purchase, you are not the Original
Purchaser and the product that you
purchased is not covered by this
warranty. This limited warranty is
VOID if this Product has been altered
or modified in any way (including but
not limited to attempted warranty
repair without authorization from
Foxfury and/or alteration/removal
of the serial number). To expedite
warranty concerns, we encourage
the end user to register their FoxFury
Product at www.foxfury.com/pages/
warranty-registration.
THIS IS THE ONLY WARRANTY,
EXPRESSED OR IMPLIED,
INCLUDING ANY WARRANTY OF
MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE.
INCIDENTAL, CONSEQUENTIAL
OR SPECIAL DAMAGES ARE
EXPRESSLY DISCLAIMED EXCEPT
WHERE SUCH LIMITATION IS
PROHIBITED BY LAW.
You may have other specific legal
rights which vary by jurisdiction. Go
to www.foxfury.com/pages/warranty
for a complete copy of the warranty.
Retain your receipt for proof of
purchase.
CONTACT FOXFURY
FoxFury, LLC
Oceanside, CA 92056 USA
Toll-Free: 844-FOXFURY
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Web: FoxFury.com
All FoxFury products are designed in
Oceanside, CA. All FoxFury products
are manufactured with the highest
quality USA and foreign parts.
Products are assembled in either
FoxFury’s controlled plant in Asia or
the USA, under strict quality control.

11
