Specications
BasicTheory
Calibration
Assembly
Check Radio Control
Download Mission Planner
Connect AYK-350 to Computer
Connect the Datalink and Check Flight Controller
ChecklistbeforeEveryFlight
TestFlight
Autopilot
Applications
Appendix
ESC Calibration
Servo Checking and Required Mode Modication
Angle Deviation Compensation Checking
Default Setttings
Pixhawk Connections
2
3
4
4
5
5
5
8
12
13
15
16
17
17
19
22
23
24
Contents
FOXTECH AYK-350 User Manual

©2021 FOXTECH All Rights Reserved 2
Item Name
Version
Material
Wingspan
Length
Clearance to Ground
Max. Flying Height
Max. Cruising Speed
Stall Speed
Endurance
RTF Weight (excluding battery)
Max. Take-off Weight
Max Payload
Battery
Flight Controller
Radio Controller
FOXTECH AYK-350 VTOL
RTF Combo
Carbon Fiber
3500mm
1880mm
120mm
2000m
26m/s
19m/s
2.5H@7kg Payload
15.5kg
35kg
10kg(standard: 5-7kg)
6S 25000mAh Lipo Battery x4
Pixhawk 2.1 Standard Set with Here 3 GNSS
DA16S+ Radio Controller x1
Specifications
FOXTECH AYK-350 User Manual

©2021 FOXTECH All Rights Reserved 3
Basic Theory
AYK-350 is a heavy load VTOL with max 10kg loading capacity, which can be used for cargo delivery
or load heavy gimbal/mapping/multispectral cameras for inspection and survey jobs. It can realize 2.5H
endurance with 7kg payload.
The whole body of AYK-350 VTOL adopts quick-detach design, including the wings, arms and tail part,
ensuring a short assembly time and small packing size. The detachable payload cabin is also
convenient for loading different task equipment, it can load max.10kg payload. Foxtech AYK-350 is
made of carbon fiber and composite material, which makes the whole body light and durable, the
aerodynamic design and smooth surface ensure a low air resistance. AYK-350 has three reserved
GPS positions, so it can be equipped with dual GPS(DGPS) to improve positioning accuracy,
anti-interference ability and flight stability.
With large loading capacity, long flight time and stable flight performance AYK-350 VTOL can be used for
cargo delivery, for inspection and survey by loading different gimbal cameras or mapping cameras,
such as Foxtech 10x/30x zoom cameras, 3DM-V4 oblique camera and MS600 multispectral camera
etc.
FOXTECH AYK-350 User Manual

©2021 FOXTECH All Rights Reserved 4
Check Radio Control
Download Mission Planner
Connect AYK-350 to Computer
Download the latest Mission planner online or copy it from the SD card. Download link:
Download link: http://firmware.ardupilot.org/Tools/MissionPlanner/
1.Check transmitter mode(left hand throttle or right hand throttle).
2.Check channels on the transmitter.
1.Connect DA16S+ transmitter and computer with bluetooth.
2.Find the corresponding device and enter password.
Calibration
FOXTECH AYK-350 User Manual

©2021 FOXTECH All Rights Reserved 5
FOXTECH AYK-350 User Manual

©2021 FOXTECH All Rights Reserved 6
3. Enter the "Device Manager" interface and find its COM.
4. Select correct Com port, and click CONNECT
FOXTECH AYK-350 User Manual

©2021 FOXTECH All Rights Reserved 7
Connect the Datalink and Check Flight Controller
5. Connection completed.
Although the accelerometer was calibrated already for the PNP version before shipping, please calibrate
it again since it might be affected in the transportation.
Under Initial Setup, select Accel Calibration from the left-side menu. Mission Planner will prompt you to
place the vehicle each calibration position. Press any key to indicate that the autopilot is in position and
then proceed to the next orientation.
The calibration positions are: level, on right side, left side, nose down, nose up and on its back.
1.Calibrate the Accelerometer
Click this button to begin accelerometer
calibration.
This accelerometer trim can be used
to level the HUD horizon.
1. I’t is important that the vehicle is kept still immediately after pressing the key for each step.
2.The level position is the most important to get right as this will be the attitude that your
controller considers level while flying.
FOXTECH AYK-350 User Manual

©2021 FOXTECH All Rights Reserved 8
Onboard calibration produces better results.
2. Compass Calibration
AYK-350 VTOL uses high sensitivity compass and it has to be re-calibrated when fly in a new place.
Enter the compass setting page and click”start” , hold the plane and rotate it in order to hit all directions
on a sphere to calibrate the compass, when it’s done, a new offset would be given to the flight controller,
and a reboot is necessary.
3. Radio Control Calibration
Calibrating each of the transmitter controls/channels is a straightforward process - simply move each of
the enabled sticks/switches through their full range and record the maximum and minimum positions.
