FRANCO BELGE 134 10 09 Camargue User manual

Description of the appliance
Installation instructions
Operating instructions
Spare parts
Warranty certificate
Technical manual
to be saved
by the user
for future reference
Document n° 759-4 EN ~ 04/02/2000
Les Fonderies Franco-Belges
59660 MERVILLE
Phone : [phone]
Fax : [phone]
RC Hazebrouck 445750565B
Subject to modifications
Camargue
Wood stove
CGBfD-NFD35-376
Model 134 10 09
Outpout : 10 kW
Français
English

Productinformation .................... 3
Package..............................3
Optional equipment .......................3
General characteristics .....................3
Description ............................3
Principle of operation ......................3
Installationinstructions .................. 4
Theroom .............................4
Flue ................................4
Connection to flue ........................4
Mounting the cast iron legs and the bottom heat shield ....5
Fitting of the handle .......................5
Assemblyoffluespigotandblankingplates..........5
Pre-utilisation check .......................6
Chimney maintenance and sweeping ..............7
Instructionsforuser .................... 7
Fuel ................................7
Instructionsforusewithwood..................7
Controloffire...........................8
Cleaning..............................8
Maintenanceofthestove ....................8
Trouble Shooting .........................8
Sparesparts......................... 9
Page
CONTENTS
Document n° 759-4 EN ~ 04/02/2000
Ref. 134 10 09 Camargue Wood stove
2Technical manual

Warning to the user
A wood stove should only be installed by competent personnel, in the strict
application of normal practices and all safety precautions.
An incorrectly installed wood stove can cause serious accidents (chimney fires,
burning of plastic insulation materials, in partition walls, etc.).
The manufacturer’s responsibility shall be limited to the supply of the equipment.
1.Product information
1.1. Package
- 1 package : Stove complete.
1.2. Optional equipment
- Set of 4 high legs.
1.3. General characteristics
Reference .................... 1341009
Maximumoutput...............kW 10
Volumeheated ............... m
3300to400
Draught requirement . . . . . . . . mm water 1.5 to 2
Grate dimensions:
-width ....................mm 450
-depth ....................mm 230
- usable height . . . . . . . . . . . . . . . . mm 200
Max.logsize ................cm 38
Ash pan capacity . . . . . . . . . . . . . litres 3
Netweight ................ KGs 130
1.4. Description
Stove C G B f D - NF D 35-376
C:Continuous-burning wood-fired heater.
G: Wood burnt on grate.
B:Wood burning stove.
f: Enclosed combustion chamber with refractory brick
walls.
D: Removable appliance, to be installed near a wall.
• Detachable flue spigot for rear or top chimney
connection.
• Detachable top for easy handling and cleaning (rear
smoke exit only).
• Optional kit for burning solid smokeless fuels.
• Adjustable air controls for controlling the burning rate.
• Large ash-pan.
1.5. Principle of operation
The “Camargue” is designed for operation with thedoor
closed.
Heat is mainly diffused by radiation, through the window
and body of the appliance.
Combustion occurs on the grate, with draught entry
through the top of the grate, which assists the
combustion of volatile materials helping to keep the
glass clean during normal operation.
Figure 1 - Dimensions in mm
Document n° 759-4 EN ~ 04/02/2000
Wood stove Camargue Ref. 134 10 09
Technical manual 3

2.Installation instructions
2.1. The room
Ventilation :
For satisfactory operation with a natural draught, check
that sufficient air for combustion is available in the
room.
Chimney position :
For new chimney installations, select a central position
within the building, to provide a good heat distribution
around the building.
Hearth :
The hearth must be suitable for use with solid fuel
burning appliances and must comply with Current
Building Regulations. If in doubt, consult your Dealer or
local Building Inspector.
Rear wall and ceiling :
The appliance must not be positioned close to
combustible materials, wall & ceiling surfaces etc.,
Consult your Dealer or local Building Inspector if in
doubt.
2.2. Flue
Existing flue :
- The flue must be in good condition and must provide
sufficient draught.
- The flue must be suitable for the installation of solid
fuel burning appliances and comply with Current
Building Regulations.
- The flue must be clean. It should be swept to remove
soot and dislodge tar deposits.
- The flue must be well insulated. If the flue inner wall
surfaces are cold, a good thermal draw is impossible
causing condensation problems (tar formation etc) to
occur.
- The flue must not be shared with other appliances.
- The recommended minimum flue height is 5 metres.
- If the chimney has any down draught tendency, due to
its position in relation to nearby obstacles, then an
anti-down draught cowl must be installed on the
chimney or the chimney height must be increased.
- If the decompression in the chimney is excessive, a
draught stabiliser must be installed.
Chimney to be built / Flue non-existent :
- The flue must not be supported by the stove.
- Consult a chimney specialistforadvice on suitable flue
systems for solid fuel appliances.
2.3. Connection to flue
The stove must be installed as close as possible to the
chimney.
- The stove should be connected to the flue by a smoke
pipe, approved forinstallation with combustion products
(e.g. stainless steel 1 mm thick, 20g, or vitreous
enamel.).
- Pipe diameter must not be less than the appliance
spigot diameter.
- The connection can be either vertical orhorizontal. For
horizontal connections, avoid right angle bends.
- The join between the connection pipe and the
stovepipe, and the flue, must be leak tight.
- The connection pipe and any draught stabiliser must
have access for cleaning.
To avoid damage during transport, the four legs and the
bottom heat shield are not mounted when the stove is
shipped from the factory. These parts should be fitted
carefully to avoid damaging the appliance.
Document n° 759-4 EN ~ 04/02/2000
Ref. 134 10 09 Camargue Wood stove
4Technical manual

2.4. Mounting the cast iron legs and the
bottom heat shield
Remove the cast iron top from the stove (Fig.2),
unscrew the two bolts securing the stove to the pallet
and remove the stove from the pallet.
Tip the stove towards the rear and place it gently on the
floor on 2 timber battens.
Fix the legs and the shield using the bolts provided
(Fig. 3).
2.5. Fitting of the handle
In order to avoid the damaging of the threading, first put
the handle in operating position then screw it into the
taping of the lock (fig. 4).
2.6. Assembly of flue spigot and blanking
plates
The stove is supplied with a connection flue spigot with
an inner diameter of 153 mm.
Figure 2 - Removal of cast iron top
A
BCD
Figure 3 - Installation of legs and lower heat shield
Figure 4 - Fitting the handle
A: Stove base
B: Heat shield
C:Bolt
D: Leg
A: Baffle
Document n° 759-4 EN ~ 04/02/2000
Wood stove Camargue Ref. 134 10 09
Technical manual 5

2.6.1. Smoke exit at rear
Figure 6
- Lift the cast iron top from the stove (fig. 2, p. 5).
- Check that the two blanking plates are fixed to thecast
iron top.
- Remove the internal baffle and the rear heat shield.
- Fix the sealing rope in the groove and fit the flue
spigot, ensuring there is a good seal.
- Replace the internal baffle (fig. 8) and re-fit the cast
iron top.
- Remove the cut-out in the rear heat shield (fig. 5) and
re-fit.
2.6.2. Smoke exit on the top
Figure 7
- Lift the cast iron top from the stove.
- Remove the two blanking plates.
- Fit the sealing rope in the groove and attach the flue
spigot and the supplementary baffle A using the three
bolts and washers supplied.
- Remove the internal baffle and the rear heat shield.
- Position the sealing rope in the groove on the rear
aperture of the stove and fit the two blanking plates.
- Replace the internal baffle (fig. 8) and the cast iron
top.
2.7. Pre-utilisation check
- Check the condition of the filler seals, that the door
closes correctly and that the cast iron top is leak tight,
that the window is not damaged, that the smoke
passages are not obstructed by pieces of packaging or
removed parts. All removable parts (cast iron top,
baffle) must be correctly installed.
Figure 5 - Removing blanking plate on rear heat shield Figure 6 - Smoke exit at rear
A
Figure 7 - Smoke exit from top
Figure 8 - Fitting the flue baffle
A : Door lock
Document n° 759-4 EN ~ 04/02/2000
Ref. 134 10 09 Camargue Wood stove
6Technical manual

2.8. Chimney maintenance and sweeping
Very important : To avoid any incident (chimney fire,
etc.), regular maintenance should be carried out. If the
stove is regularly used, the chimney should be swept
several times per year, together with the stovepipe
connection section. Chimney condition should be
checked at least once per year.
3.Instructions for user
3.1. Fuel
Recommended fuel :Wood with the grate provided
- Use hard wood logs, which have been cut for at least
two years and stored, under shelter.
- Hardwood has a higher calorific value per cu metre
(oak, ash, maple, birch, elm, beech, etc.).
- Large logs must be split and cut to a usable length,
before being stored in a sheltered and ventilated place.
Recommended fuel with the coal grate 308710
Smokeless fuels, including coolite nuts, phurnacite,
ancit and extracite.
Not recommended as fuel :
- “green wood”. Green or damp wood reduces stove
efficiency and soils the glass, the internal walls and the
flue (soot, tar, etc.).
- “used timbers”. Burning treated wood (railway
sleepers, telegraph poles, offcuts of plywood or chip
board, pallets, etc.) quickly clogs the flue ways (soot,
tar, etc.), pollutes the environment (pollution and smell,
etc.) and cause the fire to burn too quickly and
overheat.
“Green wood” and “recovered wood” can eventually
cause a chimney fire.
Prohibited fuel : Homefire and any form of bituminous
coal or petroleum based coke.
3.2. Instructions for use with wood
3.2.1. Lighting
Figure 9
• Slide the top air controllever to the right (B2) and open
the lower spin wheel (C2).
• Place firelighters (or rolled newspaper and kindling
wood) on the grate and place two or three small logs on
top of the firelighters.
• Light the firelighters or paper and close the appliance
door.
• When the fire is burning fairly fiercely, add further logs
(max. diameter 10 cms).
• Further fuel should not be added if wood is smoking.
•Whenlightingupforthefirsttime,thefireshouldbe
built up gradually, to allow the components to expand
and set without shock.
Note : When the fire is lit for the first time, the stove may
give off fumes from the new paint. This is normal but
ensure the room is well ventilated during the first few
hours operation.
Similarly, the window can become cloudy by the
evaporation of the water in the refractory bricks.
A
B
B2
B1
C
C2 C1
C3
Figure 9 - Operating devices
B : Draught control
B1 - close B2 - open
C : Spin wheel
C1 : Close for normal operating
C2 : Open for lighting
C3 - De-ashing : Insert the poker into the upper hole
Document n° 759-4 EN ~ 04/02/2000
Wood stove Camargue Ref. 134 10 09
Technical manual 7

3.2.2. Re-fuelling
• Open the lower spin wheel.
• Open the glass door and add fuel.
• Leave the lower spin wheel open for a few minutes to
allow the initial volatiles in the fuel to burn.
• Adjust the lower spin wheel to the desired position.
3.3. Control of fire
The stove must operate with the door closed and the
cast iron top correctly installed. Burning rate is
controlled by the slide lever above the door. The lighting
flap (bottom spin wheel) must be closed during normal
operation.
To load fuel, the doorshould be opened slowly, avoiding
a sudden rush of intake air, so that smoke does not
escape into the room.
For a briskly burning fire, there should always be at
least two logs in the grate. The fire will burn better if
there are several logs (diameter 7.5 to 10 cms).
For a slower burning fire (for example, at night), select
larger logs.
3.4. Cleaning
Remove ash until glowing ashes start falling into the
pan.
Remove ashes daily, and never allow ash in the ash
compartment to touch the underside of the grate.
Failure to observe this instruction will cause premature
wear to the grate and other components.
Empty the ashes taking all the usual precautions for
handling glowing ashes.
3.5. Maintenance of the stove
• The stove must be regularly cleaned.
• Remove all deposits from the combustion chamber
and clean the grate area.
• The vitro ceramic glass can only be cleaned using a
soft cloth and stove glass cleaner, available from your
Franco Belge Dealer. DO NOT USE ABRASIVES
• The vitro ceramic glass resists a temperature of
750°C. If the glass should be broken, itis recommended
that only an original factory replacement should be
fitted.
For enamelled finishes, the stove body can be cleaned
using a soft cloth either dry, or slightly damp with a very
mild detergent.
NEVER CLEAN ENAMEL SURFACES WHILST THE
STOVEISHOT.
The cast iron body panels of non-enamelled stoves can be
cleaned with a proprietary stove cleaner or re-sprayed /
touched up using a stove paint. These products are avai-
lable from your Franco Belge Dealer.
Caution ! : The appearance of cracks when burning the enamelled units is quite usual and tends to disappear when
the appliance is cooling down. It should not be considered as a defect but rather as a patina of the enamel which
does not affect its quality nor its service ability. ❑
3.6. Trouble Shooting
Problem Probable causes −Action
Fire difficult to start
Fire goes out Wood green, too damp or poor quality. −- Use the recommended fuel.
Logs are too big. −- To light the fire, use small, very dry twigs. To maintain
the fire, use split logs.
Air starvation. −- Open lower spin wheel and top air control lever.
Insufficient draught. þ −- Check that the flue is not obstructed, sweep it if
necessary
- Seek advice from a chimney specialist.
Fire burns too quickly. Too much draught. −- Ensure that the lower spin wheel is closed
- Partially close the top air control lever.
Excessive draw. þ −- Install a draught stabiliser.Consult your Dealer.
Poor quality wood. −- Do not continuously burn small wood, sticks, bundles,
carpentry offcuts (plywood, pallets), etc.
Smokes when lighting up. Flue duct is cold. −- Burn paper and kindling wood to increase heat.
Room is in decompression. −- In houses equipped with mechanical ventilation, partly
open a window until the fire is well established.
Smokes while burning. Draught is insufficien. þ −- Consult a chimney specialist.
- Check that the flue is not obstructed, sweep if
necessary.
þ : This sign means that you should asked
for a qualified engineer to do the work.
Document n° 759-4 EN ~ 04/02/2000
Ref. 134 10 09 Camargue Wood stove
8Technical manual

Down draught. þ −- Install an anti-down draught cowl.Consult your Dealer.
Room is in decompression. þ −- In houses equipped with Mechanical Ventilation, an
outside air intake must be installed for the chimney.
Low heat output. Incorrect Fuels. −- Use the recommended fuel.
4.Spare sparts
When ordering spare parts, specify the stove type and
serial number, including the colour index (on the
guarantee or identification plate), the name of the part
and the part number.
Example :
- Camargue wood stove,
-Ref.:1341009L,
- top 302141 77.
A= 134 10 09 L
B= 134 10 09 E
C= 134 10 09 J
D= 134 10 09 Y
1 100956 Axle ...............................A .....B .....C .....D .......01
2 102027 Firebrick ............................A .....B .....C .....D .......01
3 102028 Firebrick ............................A .....B .....C .....D .......01
4 105244 Firebrick ............................A .....B .....C .....D .......01
5 110405 Hinge pin ............... 6X35.........A .....B .....C .....D .......02
6 308710 Coal grate ...........................A .....B .....C .....D .......01
7 134749 Pin ................... 4X20.........A .....B .....C .....D .......01
8 142301 Adhesive rope .........................A .....B .....C .....D ......1,15m
9 158541 Handle .............................A .....B .....C .....D .......01
10 162296 Descriptive plate ........................A .....B .....C .....D .......01
11 166003 Spring .................11x15 ........A .....B .....C .....D .......01
13 161025 Touch-up paint .........................A ............................01
13 161029 Touch-up paint ................................B .....................01
13 161027 Touch-up paint .......................................C ..............01
14 181604 Ceramic rope ............. 10x4.........A .....B .....C .....D ......0,50m
15 188779 Ceramic glass .........................A .....B .....C .....D .......01
16 189103 Screw .................27x8x6 ........A .....B .....C .....D .......01
25 205330 Back panel ...........................A .....B .....C .....D .......01
26 221200 60 Striking plate ..........................A .....B .....C .....D .......01
27 224023 Ash-pan .............................A .....B .....C .....D .......01
30 259015 Fixing plate ...........................A .....B .....C .....D .......04
31 260537 Heat shield ...........................A .....B .....C .....D .......01
32 262316 Heat shield ...........................A .....B .....C ..............01
33 300121 77 B.L or F.R.leg .........................A ............................02
33 300121 MF B.L or F.R.leg ................................B .....................02
33 300121 79 B.L or F.R.leg .......................................C ..............02
33 300121 EF B.L or F.R.leg ..............................................D .......02
34 300217 77 B.R. or F.L. leg .........................A ............................02
34 300217 MF B.R. or F.L. leg ................................B .....................02
34 300217 79 B.R. or F.L. leg .......................................C ..............02
34 300217 EF B.R. or F.L. leg ..............................................D .......02
35 300455 77 Base ..............................A ............................01
35 300455 MF Base .....................................B .....................01
35 300455 79 Base ............................................C ..............01
35 300455 EF Base ...................................................D .......01
36 301515 77 Door lock ............................A ............................01
36 301515 MF Door lock ...................................B .....................01
36 301515 79 Door lock ..........................................C ..............01
36 301515 EF Door lock .................................................D .......01
37 301742 77 Air damper ...........................A ............................01
37 301742 MF Air damper ..................................B .....................01
37 301742 79 Air damper .........................................C ..............01
37 301742 EF Air damper ................................................D .......01
38 302141 77 Top plate ............................A ............................01
38 302141 MF Top plate ...................................B .....................01
38 302141 79 Top plate ..........................................C ..............01
38 302141 EF Top plate .................................................D .......01
39 303718 77 Blanking plate .........................A ............................01
39 303718 MF Blanking plate ................................B .....................01
39 303718 79 Blanking plate .......................................C ..............01
39 303718 EF Blanking plate ..............................................D .......01
40 303826 77 Flue collar .............Ø153int. .......A ............................01
40 303826 MF Flue collar .............Ø153int. ..............B .....................01
40 303826 79 Flue collar .............Ø153int. .....................C ..............01
40 303826 EF Flue collar .............Ø153int. ............................D .......01
41 306215 Back wall ............................A .....B .....C .....D .......01
N° Code Descriptiopn ............. Type.........A .....B .....C .....D ...... Qté
Document n° 759-4 EN ~ 04/02/2000
Wood stove Camargue Ref. 134 10 09
Technical manual 9

Figure 10
Document n° 759-4 EN ~ 04/02/2000
Ref. 134 10 09 Camargue Wood stove
10 Technical manual

42 307416 Fuel retainer ..........................A .....B .....C .....D .......01
43 309215 Wood grate ...........................A .....B .....C .....D .......01
44 309859 77 Front plate ...........................A ............................01
44 309859 MF Front plate ..................................B .....................01
44 309859 79 Front plate .........................................C ..............01
44 309859 EF Front plate ................................................D .......01
45 309964 77 Main door ............................A ............................01
45 309964 MF Main door ...................................B .....................01
45 309964 79 Main door ..........................................C ..............01
45 309964 EF Main door .................................................D .......01
46 310711 77 R. side panel ..........................A ............................01
46 310711 MF R. side panel .................................B .....................01
46 310711 79 R. side panel ........................................C ..............01
46 310711 EF R. side panel ...............................................D .......01
47 310811 77 L. side panel ..........................A ............................01
47 310811 MF L. side panel .................................B .....................01
47 310811 79 L. side panel ........................................C ..............01
47 310811 EF L. side panel ...............................................D .......01
48 315601 Air duct .............................A .....B .....C .....D .......01
49 319707 Grate support ..........................A .....B .....C .....D .......01
50 222554 Flue baffle ...........................A .....B .....C .....D .......01
51 326601 Suppl. flue baffle ........................A .....B .....C .....D .......01
52 327801 Clamp ..............................A .....B .....C .....D .......01
53 415504 60 Poker ..............................A .....B .....C .....D .......01
54 442011 Sealing plate ..........................A .....B .....C .....D .......01
55 613301 EF Air control flap .........................A .....B .....C .....D .......01
56 808001 ED Hand tool ............................A .....B .....C .....D .......01
57 181615 Ceramic rope ............. Ø12.........A .....B .....C .....D ......3,14m
Document n° 759-4 EN ~ 04/02/2000
Wood stove Camargue Ref. 134 10 09
Technical manual 11

❧Warranty certificate ❧
❧Legal warranty
Our products are guaranteed for twelve months against any
defect, flaw or imperfection. During this time, all parts judged
defective by our Warranty control department may be repla-
ced in our workshops. Incidental costs of transportation and
packing payable by the buyer.
Some parts or components have a longer warranty period :
- Cast-iron shell of boiler : 3 years
- Steel shell of boiler : 3 years
- Removable or independent stainless steel hot water cylin-
der : 5 years
- Independent enamelled steel hot water cylinder : 3 years
- Incorporated circulating pump : 2 years.
❧Terms of the warranty
This warranty is only valid if :
- The unit has been installed and checked by a professional
installer before operating,
- All installation and adjustment instructions listed in the
technical manual supplied with the unit have been followed,
- All operation and maintenance instructions have been
followed.
This warranty does not cover :
- Lamps, fuses, spark plugs, cast iron parts directly in con-
tact with burning coal and wood, firebricks, flue baffles,
glasses .
- Any damage resulting from the use of fuel not recommen-
ded in our instructions ;
- Parts which are damaged by external causes such as
unadapted chimneys, thunderstorms, damp, faulty pressure
or fail in pressure, thermic anomalies, explosions, etc...
- Electrical parts which are deteriorated by any connection
or use on a supply circuit with voltage within 10% of the
indicted voltage (230 V in EU).
Material subject to modifications without prior notice. This
manual does not engage the responsibility of
FRANCO BELGE.
* Nameandaddressofinstaller:___________________________________________
__
________________________________________________________________
) Telephone:________________
* Nameandaddressofcustomer:__________________________________________
__
________________________________________________________________
Date of installation : ___ ___ / ___ ___ / ___ ___
Model of the appliance : ❑1341009
Color : ❑L❑E❑J❑Y
Serial number : ___ ___ ___ ___ ___ ___
This certificate has to be completed and kept carefully. In case of claims, send a copy of this to :
Fonderies FRANCO BELGE, rue Orphée Variscotte, 59660 MERVILLE, FRANCE.
Document n° 759-4 EN ~ 04/02/2000
