FRANCO BELGE Limousin User manual

Description of the appliance
Installation instructions
Operating instructions
Spare parts
Warranty certificate
Technical manual
to be saved
by the user
for future reference
Document n° 1054-2 ~13/12/2000
Les Fonderies Franco-Belges
59660 MERVILLE
Phone : [phone]
Fax : [phone]
RC Hazebrouck 445750565B
Subject to modifications
LIMOUSIN
Wood stove
CGBfD-NFD35-376
Model : 134 10 12
Output : 10 kW

Product information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Package . . . . . . . . . . . . . . . . . . 3
Optional . . . . . . . . . . . . . . . . . . . 3
General characteristics . . . . . . . . . . 3
Description . . . . . . . . . . . . . . . . . 3
Principle of operation . . . . . . . . . . . 3
Installation instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
The room . . . . . . . . . . . . . . . . . . 4
Flue . . . . . . . . . . . . . . . . . . . . . 4
Assembly of flue spigot
and blanking plates . . . . . . . . . . . . 4
Connection to flue . . . . . . . . . . . . . 5
Mounting the tray . . . . . . . . . . . . . 5
Chimney maintenance and sweeping . . 5
Instructions for user . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Fuel . . . . . . . . . . . . . . . . . . . . . 6
Instruction for use with wood . . . . . . . 7
Instructions for use with solid fuel . . . . 7
Cleaning . . . . . . . . . . . . . . . . . . 7
Maintenance of the stove body . . . . . . 7
Trouble Shooting . . . . . . . . . . . . . . 8
Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
CONTENTS Page Page
FRANCO BELGE congratulates you on your choice.
FRANCO BELGE, which has been granted the ISO 9001 certification, guarantees the
quality of its appliances and is committed to meet its customers needs.
FRANCO BELGE, which can boast a 75-year experience in the industry of heating devices,
uses state-of-the-art technologies
to design and manufacture its whole range of products.
This document contains instructions on how to install your appliance and and make full
use of its functions, both for your comfort and safety.
Wood stove "LIMOUSIN"
2Technical manual

Warning to the user
A wood stove should only be installed by competent personnel, in the strict
application of normal practices and all safety precautions.
An incorrectly installed wood stove can cause serious accidents (chimney fires,
burning of plastic insulation materials, in partition walls, etc.).
The manufacturers responsibility shall be limited to the supply of the equipment.
1.Product information
1.1. Package
1 package : Stove complete.
1.2. Optional
•Boiler
•Coal grate
1.3. General characteristics
Reference.................... 1341012
Maximumoutput...............kW 10
...................... Btu/hr 34000
Chimneydraftrequired........... Pa 10
Grate dimensions
-width ....................mm 540
-depth ....................mm 250
-usableheight................mm 200
Log dimensions
-Lenght ................... cm 50
-Diameter.................. cm 10à16
Ashpancapacity .............litres 6,8
Netweight.................. kg 160
Volumeheated ............... m
3
380
Autonomy ................... h 10
1.4. Description
Stove, CGBfD- NF D 35-375
C : Continuous-burning heating appliance.
G: Wood burnt on grate
B:Wood burning stove
f:Enclosed combustion chamber with refractory brick
walls.
D: Removable appliance, to be installed near a wall.
•Detachable flue spigot for rear or top chimney
connection.
•Detachable top for easy handling and cleaning (rear
smoke exit only).
•Adjustable air controls for controlling the burning rate.
•Spin wheel for lighting.
•Large ash-pan.
•Side loading door.
1.5. Principle of operation
The “ Limousin ” is designed for operation with the door
closed.
Heat is mainly diffused by radiation, through the window
and body of the appliance.
Combustion occurs on the grate, with draught entry
through the top of the combustion chamber when using
wood and under the grate when using coal.
433
198
575
741
638
Ø 153
459
Product information
Figure 1 - Dimensions in mm
"LIMOUSIN" Wood stove
Technical manual 3

2.Installation instructions
2.1. The room
Ventilation :
For satisfactory operation with a natural draught, check
that sufficient air for combustion is available in the
room.
Chimney position :
For new chimney installations, select a central position
within the building, to provide a good heat distribution
around the building.
Hearth :
The hearth must be suitable for use with solid fuel
burning appliances and must comply with Current
Building Regulations. If in doubt, consult your Dealer or
local Building Inspector.
Rear wall and ceiling :
The appliance must not be positioned close to
combustible materials, wall & ceiling surfaces etc.,
Consult your Dealer or local Building Inspector if in
doubt.
2.2. Flue
Existing flue :
-The flue must be in good condition and must provide
sufficient draught.
-The flue must be suitable for the installation of solid
fuel burning appliances and comply with Current
Building Regulations.
-The flue must be clean. It should be swept to remove
soot and dislodge tar deposits.
-The flue must be well insulated. If the flue inner wall
surfaces are cold, a good thermal draw is impossible
causing condensation problems (tar formation etc) to
occur.
-The flue must not be shared with other appliances.
-The recommended minimum flue height is 5 metres.
-If the chimney has any down draught tendency, due to
its position in relation to nearby obstacles, then an
anti-down draught cowl must be installed on the
chimney or the chimney height must be increased.
-If the decompression in the chimney is excessive, a
draught stabiliser must be installed.
-The flue must not be supported by the stove.
-Consult a chimney specialist for advice on suitable
flue systems for solid fuel appliances.
2.3. Assembly of flue spigot
and blanking plates
The stove is supplied with a connection flue spigot with
an inner diameter of 153 mm.
2.3.1. Smoke exit at rear
Figure 2
•Remove the top plate 4.
•Remove the flue baffle (# 37, fig. 7, p. 11).
•Fit the sealing rope 2in the groove at rear and fix the
flue collar 1with 3 bolts and washers supplied.
•Replace the flue baffle (# 37, fig. 7, p. 11).
•Replace the top plate.
•Remove the cut-out in the rear heat shield and re fit
(fig. 3)
1
2
3
4
5
Installation instructions
1- Flue collar
2-Ceramicrope
3- Blanking plate
4- Top plate
5- Vis de 6 x 20
Figure 2 - Rear flue outlet Figure 3 - Rear heat shield
Wood stove "LIMOUSIN"
4Technical manual

2.3.2. Smoke exit on the top
Figure 4
•Remove the top plate 4.
•Remove the flue baffle (# 37, fig. 7, p. 11).
•Remove the blanking plate 3and the clamp 5and refit
them at the rear, ensuring there is a good seal.
•Fix the flue collar1on the top with 3 bolts and washers
supplied, ensuring there is a good seal.
•Replace the flue baffle (# 37, fig. 7, p. 11).
•Replace the top plate.
In this case, the cut-out of the heat shield must not be
remove.
2.4.Connectiontoflue
-The stove must be installed as close aspossible to the
chimney.
-The stove should be connected to the flue by a smoke
pipe, approved for installation with combustion
products (e.g. stainless steel 1 mm thick, 20g, or
vitreous enamel.).
-Pipe diameter must not be less than the appliance
spigot diameter.
-The connection can be either vertical or horizontal.For
horizontal connections, avoid right angle bends.
-Thejoinbetweentheconnectionpipeandthe
stovepipe, and the flue, must be leak tight.
-The connection pipe and any draught stabiliser must
have access for cleaning.
2.5. Mounting the tray
To avoid damage during transport, the tray has been
stored behind the main door.
-Fix the tray, on the appliance (ill. 5). Center on tab “A”
and lower into place.
2.6. Chimney maintenance and sweeping
Very important : To avoid accidents (chimney fire,
etc.), regular maintenance should be carried out. If the
stove is regularly used, the chimney should be swept
several times per year, together with the stovepipe
connection section.
First remove the two retainer grates (# 30, fig. 7, p. 11),
the three side bricks (# 15, 27 & 28, fig. 7, p. 11) and
the flue baffle (# 37, fig. 7, p. 11)
Chimney condition should be checked at least once per
year.
1
2
3
4
5
6
2
A
Installation instructions
1- Flue collar
2- Ceramic rope
3- Blanking plate
4- Top plate
5-Clamp
6-Vis6x25
Figure 4 - Smoke exit from top
Figure 5 - Mounting the tray
"LIMOUSIN" Wood stove
Technical manual 5

3.Instructions for user
3.1. Fuel
•Recommended fuel :Wood with the grate provided
(code 309231)
-Use hard wood logs, which have been cut for at least
two years and stored, under shelter.
-Hardwood has a higher calorific value per cu metre
(oak, ash, maple, birch, elm, beech, etc.).
-Large logs must be split and cut to a usable length,
before being stored in a sheltered and ventilated
place.
•Recommended fuel with the coal grate (code
308712)
Smokeless fuels, including coolite nuts, phurnacite,
ancit and extracite.
•Not recommended as fuel :
-“Green wood”. Green or damp wood reduces stove
efficiency and soils the glass, the internal walls and
the flue (soot, tar, etc.).
-“used timbers”. Burning treated wood (railway
sleepers, telegraph poles, offcuts of plywood or chip
board, pallets, etc.) quickly clogs the flue ways (soot,
tar, etc.), pollutes the environment (pollution and
smell, etc.) and cause the fire to burn too quickly and
overheat.
“Green wood” and “recovered wood” can eventually
cause a chimney fire.
•Prohibited fuel : Homefire and any form of bituminous
coal or petroleum based coke.
A
B
B1 B2
C
C1 C2 C3
E
FG
H
Instructions for user
A:Door lock
B:Draught control when burning wood.
B1 = flap opened
B2 = flap closed (keep close when burning solid fuel).
C:Draught control when burning solid fuel.
C1 = wheel opened
C2 = wheel closed (keep close when burning wood).
C3 = de-ashing access
E:tool
F: Poker
G: Ash tray
H: Loading door lock
Figure 6 - Operating devices
Wood stove "LIMOUSIN"
6Technical manual

3.2. Instruction for use with wood
3.2.1. lighting
Figure 6
•Slide the top air control (# B1) and the lower air control
(# C1) to the right. Open the lower spin wheel (# C1).
•Open the front door and lay firelighters or rolled up
newspapers on the grate with a reasonable quantity, if
necessary, of dry kindling wood. Place 2 or 3 small logs
on top.
•Light the newspaper or firelighters using a long taper
and close the door (# A).
•When the fire is burning fiercely, add further logs of a
diameter up to 10 cms.
•When the stove body is very hot, close the lower air
control (# C2).
-The burning rate can now be adjusted by moving the
top air control to the left (# B1). Experience will show
you which settings are best for your situation.
Note : When the fire is lit for the first time, the stove may
give off fumes from the new paint. This is normal but
ensure the room is well ventilated during the first few
hours of operation.
3.2.2. Re-fuelling
Itisadvisabletowaitforthefiretobereducedtohot
embers before re-loading. The door should also be
opened slowly when re-loading.
3.3. Instructions for use with solid fuel
3.3.1. Lighting
•Closethetopaircontrolbyslidingittotheleft(#B2).
•Open the lower air control by sliding it to the right
(# C1).
•Lay firelighters or rolled up newspapers on the grate
with a reasonable quantity, if necessary, of dry kindling
wood. Place a small quantity of solid fuel on top.
•Light the newspaper or firelighters using a long taper
and close the door.
•When the fire is burning fiercely, add further fuel.
•When the stove body is hot, adjust the burning rate
with the lower air control (# C).
3.3.2. Re-fuelling
•Open the lower air control (# C1).
•Open the front door and add fuel.
•Leave the lower air control open for a few minutes to
allow the initial volatiles in the fuel to burn.
•Adjust the lower air control to the desired position
(# C).
3.4. Cleaning
It is essential to keep the grate free from a heavy build
up of ashes.
REMEMBER TO BURN SOLID FUEL CORRECTLY,
AlRSHOULDBEALLOWEDTOFLOWFROMTHE
ASH PIT AREA THROUGH THE GRATE AND
THROUGH THE FUEL. IF THE GRATE OR ASH PAN
ARE CONGESTED, THE PERFOMANCE WILL BE
EFFECTED.
If burning solid fuel, always empty the ash pan at least
once a day or whenever it is full of ashes. Never allow
the ashpan to overfill allowing ash to be in contact with
the underside of the grate. If this condition is allowed,
the grate will wear out pre-maturely.
3.5. Maintenance of the stove body
•The stove must be regularly cleaned.
•Remove all deposits from the combustion chamber
and clean the grate area.
•The vitro ceramic glass can only be cleaned using a
soft cloth and stove glass cleaner, available from your
Franco Belge Dealer. DO NOT USE ABRASIVES
•The vitro ceramic glass resists a temperature of 750°C.
If the glass should be broken, it is recommended that
only an original factory replacement should be fitted.
For enamelled finishes, the stove body can be cleaned
using a soft cloth either dry, or slightly damp with a very
mild detergent.
NEVER CLEAN ENAMEL SURFACES WHILST THE
STOVE IS HOT.
The cast iron body panels of non-enamelled stoves can
be cleaned with a proprietary stove cleaner or
re-sprayed / touched up using a stove paint. These
products are available from your Franco Belge Dealer.
Instructions for user"LIMOUSIN" Wood stove
Technical manual 7

3.6. Trouble Shooting
Problem Probable causes -Action
Fire difficult to start
Fire goes out Wood green, too damp or poor
quality. -Use the recommended fuel.
Logs are too big. -To light the fire, use small, very dry twigs. To maintain
the fire, use split logs.
Air starvation. -Open lower air controll and top air control lever.
Insufficient draught. þ
-Check that the flue is not obstructed, sweep it if
necessary
-Seek advice from a chimney specialist.
Fire burns too quickly. Too much draught. -Ensure that the lower air control is closed
-Partially close the top air control lever.
Excessive draw. þ
-Install a draught stabiliser. Consult your Dealer.
Poor quality wood. -Do not continuously burn small wood, sticks, bundles,
carpentry offcuts (plywood, pallets), etc.
Smokes when lighting up. Flue duct is cold. -Burn paper and kindling wood to increase heat.
Room is in decompression. -In houses equipped with mechanical ventilation, partly
open a window until the fire is well established.
Smokes while burning. Draught is insufficient. þ
-Consult a chimney specialist.
-Check that the flue is not obstructed, sweep if
necessary.
Down draught. þ
-Install an anti-down draught cowl. Consult your Dealer.
Room is in decompression. þ
-In houses equipped with Mechanical Ventilation, an
outside air intake must be installed for the chimney.
Low heat output. Incorrect Fuels. -Use the recommended fuel.
þ : This sign means that you should
asked for a qualified engineer to do the
work.
Instructions for userWood stove "LIMOUSIN"
8Technical manual

Notes
Instructions for user"LIMOUSIN" Wood stove
Technical manual 9

4.Spare parts
When ordering spare parts, specify the stove type and
serial number, including the colour index (on the
guarantee or identification plate), the name of the part
and the part number.
Example : Wood stove, réf. 134 10 12 Y, top plate
352124 EF.
N° Code Description.........Type.....Qty
1 100939 Axle .....................04
2 101048 Axle .....................02
3 110404 Hinge pin ........... 6x30 ....02
4 110405 Hinge pin ........... 6x35 ....02
5 134107 Glove .....................01
6 134711 Pin .............. 6x30 ....02
7 134749 Pin .............. 4x20 ....02
8 142301 Adhesive rope ...............1,32m
9 162721 Descriptive plate ....... 9 .....01
10 181607 Ceramic rope ........Ø9,5...1,00m
11 181614 Ceramic rope ........d.9,5...3,40m
12 181615 Ceramic rope ........ d.12 ...1,77m
13 188780 Ceramic glass ...... 439x272x4 . . 01
14 205391 Back panel ...........14.....01
15 209915 Protector ...................01
16 222609 Suppl. flue baffle ..............01
17 237413 60 Reducing plate ...............01
18 259015 Fixing plate .................04
19 270409 Air control flap ................01
20 270410 60 Air control flap ................01
21 300122 EF Leg ......................04
22 300462 EF Base .....................01
23 300991 EF Handle ....................02
24 303515 EF Loading door ................01
25 303718 EF Blanking plate ................01
26 303826 EF Flue collar .........Ø153int....01
27 305015 Wall .....................01
28 305150 Back wall ...................01
29 306278 EF Back wall ...................01
30 307422 Fuel retainer .................02
31 308712 Coal grate ..................01
32 309897 EF Front plate ..................01
33 310729 EF R. side panel ................01
34 310826 EF L. side panel .................01
35 314607 Inner door ..................01
36 315602 Air duct ....................01
37 323211 Flue baffle ..................01
38 325304 EF Reducing plate ...............03
39 327901 EF Tray .....................01
40 331108 EF Main door ..................01
41 352124 EF Top plate ...................01
42 406816 EF Clamp ....................01
43 415504 60 Poker .....................01
44 624043 Ash-pan ...................01
45 808001 ED Hand tool ..................01
46 262608 Heat shield .................01
Spare partsWood stove "LIMOUSIN"
10 Technical manual


!
!
#
$
%
&
'



!
"
#
$
%
&
'


!
"
#
$
%
&
'
!
!
!
!!
!"
!#
!$
!%
!&
!'
"
"
"
""
"#



"
"
$
%


!
!
!&
!&
"! 


"$
Stove - exploded view
Figure 7 - Stove - exploded view
"LIMOUSIN" Wood stove
Technical manual 11

❧Warranty certificate ❧
❧Legal warranty
Our products are guaranteed for twelve months against any
defect, flaw or imperfection. During this time, all parts judged
defective by our Warranty control department may be repla-
ced in our workshops. Incidental costs of transportation and
packing payable by the buyer.
Some parts or components have a longer warranty period :
- Cast-iron shell of boiler : 3 years
- Steel shell of boiler : 3 years
- Removable or independent stainless steel hot water cylin-
der : 5 years
- Independent enamelled steel hot water cylinder : 3 years
- Incorporated circulating pump : 2 years.
❧Terms of the warranty
This warranty is only valid if :
- The unit has been installed and checked by a professional
installer before operating,
- All installation and adjustment instructions listed in the
technical manual supplied with the unit have been followed,
- All operation and maintenance instructions have been
followed.
❧This warranty does not cover :
- Lamps, fuses, spark plugs, cast iron parts directly in con-
tact with burning coal and wood, firebricks, flue baffles,
glasses .
- Any damage resulting from the use of fuel not recommen-
ded in our instructions ;
- Parts which are damaged by external causes such as
unadapted chimneys, thunderstorms, damp, faulty pressure
or fail in pressure, thermic anomalies, explosions, etc...
- Electrical parts which are deteriorated by any connection
or use on a supply circuit with voltage within 10% of the
indicted voltage (230 V in EU).
Material subject to modifications without prior notice. This
manual does not engage the responsibility of
FRANCO BELGE.
* Nameandaddressoftheinstaller: _____________________________
______________________________________________
( Telephone: _______________________________________
* Name and address of the customer : _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
______________________________________________
Date of installation : __ __ / __ __ /__ __ __ __
Modeloftheappliance:
Color :
Serial number : ___ ___ ___ ___ ___ ___
• This certificate has to be completed and kept carefully.
In case of claims, send a copy of this to :
Les Fonderies Franco-Belges, rue Orphée Variscotte, 59660 MERVILLE, FRANCE.
q : 134 10 12
q :Y
