User’s Manual Addendum MCF5282UMAD
Rev. 15, 05/2007
Table of Contents
This errata document describes corrections to the
MCF5282 ColdFire Microcontroller User’s Manual,
order number MCF5282UM. For convenience, the
addenda items are grouped by revision. Please check our
website at http://www.freescale.com for the latest
updates.
MCF5282 User’s Manual Errata
by: Microcontroller Division
1 Errata for Revision 2.3.........................................2
2 Errata for Revision 2.1 & 2.2 ...............................5
3 Errata for Revision 2.0.........................................6
4 Errata for Revision 1.0.........................................7
5 Revision History ................................................16

MCF5282 User’s Manual Errata, Rev. 15
Errata for Revision 2.3
Freescale Semiconductor2
1 Errata for Revision 2.3
Table 1. MCF5282UM Rev 2.3 Errata
Location Description
Table 2-1/Page 2-4 Remove last sentence in C bit field description.
Table 2-3/Page 2-7 Change PC’s Written with MOVEC entry to “No”.
Section 2.5/Page 2-8 Change last bullet to “Use of separate system stack pointers for user and supervisor
modes”
Section 2.5/Page 2-9 Change last sentence in fourth paragraph (step 2) to “The IACK cycle is mapped to special
locations within the interrupt controller's address space with the interrupt level encoded in
the address."
Figure 3-6/Page 3-8 Add minus sign to the exponent so that it is “–(i + 1 – N)”.
Table 4-3/Page 4-5 Change reset value of ACR0, ACR1 to “See Section” since some of the bits are undefined
after reset.
Figure 4-2/Page 4-6 Change CACR fields to R/W, since they may be read via the debug module.
Table 4-5/Page 4-8 For split instruction/data cache entry, swap text in parantheses in the description field.
Instruction cache uses the upper half of the arrays, while data cache uses the lower half.
Figure 4-3/Page 4-9 Change reset value of ACR: Bits 31-16, 14-13, 6-5, and 2 are undefined, and other bits are
cleared.
Change ACR fields to R/W, since they may be read via the debug module.
Section 4.4.2.2/Page 4-9 Change note to:
NOTE
Peripheral(IPSBAR)spaceshouldnotbecached.The
combination of the CACR defaults and the two ACRn
registers must define the non-cacheable attribute for
this address space.
Figure 5-1/Page 5-2 Change RAMBAR fields to R/W, since they may be read via the debug module.
Table 5-1/Page 5-2 The PRI1/PRI2 text description does not match the table below it. It should be: “If a bit is
set, CPU has priority. If a bit is cleared, DMA has priority.”
Chapter 8 Remove any references to the core watchdog timer being able to reset the device. It is only
able to interrupt the processor. Use the peripheral watchdog timer described in
Chapter 18 if needing a watchdog timer to reset the device.
Table 9-4/Page 9-7 In the table for MFD bit definition, footnote (1) equation should read:
Where fsys(max) is the maximum system frequency for the particular MCF5282 device
(66MHz or 80MHz)
Section 10.3.6/Page 10-11 Include the following text in the section description and as a note in Figure 10-9.
“It is the responsibility of the software to program the ICRnx registers with unique and
non-overlapping level and priority definitions. Failure to program the ICRnx registers in
this manner can result in undefined behavior. If a specific interrupt request is completely
unused, the ICRnx value can remain in its reset (and disabled) state.”
Figure 10-6/Page 10-9 Interrupt Force Register Low (INTFRCLn) is illustrated as read-only in the figure. However,
this register should be read/write.
fsys fref 2MFD 2+()×
2RFD
----------------------------------------------fref 2MFD 2+()×fsys max()
fsys fsys max() ≤;≤;=

Errata for Revision 2.3
MCF5282 User’s Manual Errata, Rev. 15
Freescale Semiconductor 3
Table 10-14/Page 10-15 Change flag clearing mechanism for sources 24-26. They should read as follows:
Write ERR_INT = 1 after reading ERR_INT = 1
Write BOFF_INT = 1 after reading BOFF_INT = 1
Write WAKE_INT = 1 after reading WAKE_INT = 1
Table 12-7/Page 12-7 BAM bit field description, the first example should read “So, if CSAR0 = 0x0000 and
CSMR0[BAM] = 0x0001” instead of “So, if CSAR0 = 0x0000 and CSMR0[BAM] = 0x0008”.
Table 10-2/Page 10-4 In footnote, remove mention of the SWIACK register, as it is not supported in the global
IACK space.
Section 10.3.7/Page 10-16 Change last paragraph to: “In addition to the IACK registers within each interrupt controller,
there are global LnIACK registers. A read from one of the global LnIACK registers returns
the vector for the highest priority unmasked interrupt within a level for all interrupt
controllers. There is no global SWIACK register. However, reading the SWIACK register
from each interrupt controller returns the vector number of the highest priority unmasked
request within that controller.”
Table 15-1/Page 15-3 NOP command entry. Replace “SRAS asserted” with “SDRAM_CS[1:0] asserted”
Table 15-5/Page 15-7 Add the following note to the DACRn[CBM] field description:
Note: It is important to set CBM according to the location of the command bit.
Section 16.5/Page 16-11 Remove last sentence in this section starting with “BCRndecrements...” since SAA bit is
not supported.
Chapter 17 The maximum buffer size of the FEC is 2032 bytes. Replace any mention of the max size
being 2047 bytes with 2032 bytes.
Section 17.4.6/Page 17-7 Add the following subsection entitled “Duplicate Frame Transmission”:
The FEC fetches transmit buffer descriptors (TxBDs) and the corresponding transmit data
continuously until the transmit FIFO is full. It does not determine whether the TxBD to be
fetched is already being processed internally (as a result of a wrap). As the FEC nears the
end of the transmission of one frame, it begins to DMA the data for the next frame. In order
to remain one BD ahead of the DMA, it also fetches the TxBD for the next frame. It is
possible that the FEC will fetch from memory a BD that has already been processed but not
yet written back (that is, it is read a second time with the R bit still set). In this case, the data
is fetched and transmitted again.
Using at least three TxBDs fixes this problem for large frames, but not for small frames. To
ensure correct operation for either large or small frames, one of the following must be true:
• The FEC software driver ensures that there is always at least one TxBD with the ready
bit cleared.
• Every frame uses more than one TxBD and every TxBD but the last is written back
immediately after the data is fetched.
• The FEC software driver ensures a minimum frame size, n. The minimum number of
TxBDs is then (Tx FIFO Size ÷(n+ 4)) rounded up to the nearest integer (though the
result cannot be less than three). The default Tx FIFO size is 192 bytes; this size is
programmable.
Table 17-9/Page 17-17 Correct MIB block counters end addresses to IPSBAR + 0x12FF.
Table 17-11/Page 17-19 Add RMON_R_DROP with an IPSBAR Offset of 0x1280 and a description of ‘Count of
frames not counted correctly’.
Figure 17-26/Page 17-41 Change EMRBR register address from “IPSBAR + 0x11B8” to “IPSBAR + 0x1188”.
Section 20.5.13/Page 20-12 Deleted reference to nonexistent CF bits in the figure and bit descriptions for the GPTFLG2
register.
Table 1. MCF5282UM Rev 2.3 Errata (continued)
Location Description

MCF5282 User’s Manual Errata, Rev. 15
Errata for Revision 2.3
Freescale Semiconductor4
Figure 23-18/Page 23-18 Remove the two 16-bit divider blocks from timer input, as the divider is not available using
external clock sources.
Section 23.5.1.2.2/Page
23-19 Remove 16-bit divider from equation, as the divider is not available using external clock sources.
Section 25.5.8/Page 25-25 Change end of last sentence from “...and can be written by the host to ‘0’.” to “...and can be
written by the host to ‘1’.”
Table 25-17/Page 25-29 Remove the following information from the BITERR and ACKERR descriptions as these
fields are read only: “To clear this bit, first read it as a one, then write it as a one. Writing
zero has no effect.” (This is a rescindment of a previous documentation errata.)
Change last sentence in ERRINT description from: “To clear this bit, first read it as a one,
then write as a zero. Writing a one has no effect.” to “To clear this bit, first read it as a
one, then write a one. Writing a zero has no effect.”
Add the following information to the BOFFINT and WAKEINT descriptions: “To clear this bit,
first read it as a one, then write it as a one. Writing zero has no effect.”
Table 25-17/Page 25-27 Definition of bits ERRINT and BOFFINT are incorrect for register ESTAT: ERRINT should
be bit 1, BOFFINT should be bit 2. They should be cleared by writing a one instead of a
zero.
Table 26-1/Page 26-5 Change description field for DTOUT1 from “DMA timer 1 output / Port TD[3]...” to “DMA
timer 1 output / Port TD[2]...”
Change description field for DTIN0 from “DMA timer 0 input / Port TD[3]...” to “DMA timer 1
output / Port TD[1]...”
Change description field for DTOUT0 from “DMA timer 0 output / Port TD[3]...” to “DMA
timer 1 output / Port TD[0]...”
Table 30-12/Page 30-14 Add the following note to the PBR[Address] field description:
Note: PBR[0] should always be loaded with a 0.
Table 30-20/Page 30-35 Change CSR’s initial state to 0x0000_0000.
Chapter 33 Add the following note:
“It is crucial during power-up that VDD never exceeds VDDH by more that ~0.3V. There
are diode devices between the two voltage domains, and violating this rule can lead to a
latch-up condition.”
Table 33-3/Page 33-3 In the VOH and VOL entries, change the respective IOH and IOL specs from “IOH = -2.0mA”
to “IOH = -5.0mA” and “IOL = +2.0mA” to “IOL = +5.0mA”
Table 33-8/Page 33-7 In the PLL Electrical Specifications table, only specs for the 80MHz MCF5282 device were
listed. Insert specs for the 66MHz device in the first 2 rows and also declare symbol
fsys(max), as shown below:
Table 1. MCF5282UM Rev 2.3 Errata (continued)
Location Description
Characteristic Symbol Min Max Unit
66MHz 80MHz
PLL Reference Frequency Range
Crystal reference
External reference
1:1 Mode
fref_crystal
fref_ext
fref_1:1
2
2
33.33
8.33
8.33
66.66
10.0
10.0
80
MHz
System Frequency 1
External Clock Mode
On-Chip PLL Frequency
fsys 0
fref / 32
fsys(max)
66.66
66.66
fsys(max)
80
80
MHz

Errata for Revision 2.1 & 2.2
MCF5282 User’s Manual Errata, Rev. 15
Freescale Semiconductor 5
2 Errata for Revision 2.1 & 2.2
Table 33-8/Page 33-7 Change EXTAL Input High Voltage (VIHEXT) Crystal Mode minimum spec from “VDD -1.0”
to “VXTAL +0.4”.
Change EXTAL Input Low Voltage (VILEXT) Crystal Mode maximum spec from “1.0” to
“VXTAL -0.4”.
Section 33.13.1/Page 33-21 Remove second sentence:
“There is no minimum frequency requirement.”
Section 33.13.2/Page 33-22 Remove second sentence:
“There is no minimum frequency requirement.”
Remove second paragraph as this feature is not supported on this device:
“The transmit outputs (ETXD[3:0], ETXEN, ETXER) can be programmed to
transition from either the rising or falling edge of ETXCLK, and the timing is the
same in either case. This options allows the use of non-compliant MII PHYs. Refer
to the Ethernet chapter for details of this option and how to enable it.”
Table A-3/Page A-4 The CSMR1 and CSCR1 register addresses are incorrect. They should be
IPSBAR + 0x090 and IPSBAR + 0x096 respectively
Table 2. MCF5282UM Rev 2.1 & 2.2 Errata
Location Description
Figure 4-2/4-6 Changed bit 23 from DIDI to DISI
Table 4-6/4-9 Under ‘Configuration’ for ‘Instruction Cache’ the ‘Operation’ entry changed to “Invalidate
2 KByte data cache”
Table 4-6/4-9 Under ‘Configuration’ for ‘Data Cache’ the ‘Operation’ entry changed to “Invalidate 2 KByte
instruction cache”
Figure 6-3/6-6 Changed bit 8 to write-only instead of read/write
Table 6-10/6-15 Removed “selected by BKSL[1:0]” as these are internal signal names not necessary for
end-user.
Table 9-4/9-7 In the table for MFD bit definition, footnote (1) equation should read:
Where fsys(max) is the maximum system frequency for the particular MCF5282 device
(66MHz or 80MHz)
10.3.2/10-8 Add the following note: ‘If an interrupt source is being masked in the interrupt controller
mask register (IMR) or a module’s interrupt mask register while the interrupt mask in the
status register (SR[I]) is set to a value lower than the interrupt’s level, a spurious interrupt
may occur. This is because by the time the status register acknowledges this interrupt,
the interrupt has been masked. A spurious interrupt is generated because the CPU
cannot determine the interrupt source. To avoid this situation for interrupts sources with
levels 1-6, first write a higher level interrupt mask to the status register, before setting the
mask in the IMR or the module’s interrupt mask register. After the mask is set, return the
interrupt mask in the status register to its previous value. Since level seven interrupts
cannot be disabled in the status register prior to masking, use of the IMR or module
interrupt mask registers to disable level seven interrupts is not recommended.’
Table 1. MCF5282UM Rev 2.3 Errata (continued)
Location Description
fsys fref 2MFD 2+()×
2RFD
----------------------------------------------fref 2MFD 2+()×fsys max()
fsys fsys max() ≤;≤;=

MCF5282 User’s Manual Errata, Rev. 15
Errata for Revision 2.0
Freescale Semiconductor6
3 Errata for Revision 2.0
Chapter 17 The maximum buffer size of the FEC is 2032 bytes. Replace any mention of the max size
being 2047 bytes with 2032 bytes.
Table 17-2/17-5 In PALR/PAUR entry, delete “(only needed for full duplex flow control)”
Figure 17-23/17-39 Change FRSR to read/write instead of read-only.
25.4.10/25-16 Change CANICR to ICRn.
Table 25-17/25-29 Add the following information to BITERR and ACKERR descriptions: “To clear this bit, first
read it as a one, then write it as a one. Writing zero has no effect.”
Table 25-17/25-30 Change bit ordering: ERRINT should be bit 2 and BOFFINT should be bit 1.
Table 25-19/25-32 Change BUFnI field description from “To clear an interrupt flag, first read the flag as a one,
then write it as a zero” to “To clear an interrupt flag, first read the flag as a one, then write
it as a one.”
Chapter 33 It is crucial during power-up that VDD never exceeds VDDH by more that ~0.3V. There are
diode devices between the two voltage domains, and violating this rule can lead to a
latch-up condition.
Table 33-8/33-7 In the PLL Electrical Specifications table, only specs for the 80MHz MCF5282 device were
listed. Insert specs for the 66MHz device in the first 2 rows and also declare symbol
fsys(max), as shown below:
Table 3. MCF5282UM Rev 2.0 Errata
Location Description
Table 33-8/33-9 Reference to ‘TA = TL to TH’ was not deleted. Delete.
Table 2. MCF5282UM Rev 2.1 & 2.2 Errata (continued)
Location Description
Characteristic Symbol Min Max Unit
66MHz 80MHz
PLL Reference Frequency Range
Crystal reference
External reference
1:1 Mode
fref_crystal
fref_ext
fref_1:1
2
2
33.33
8.33
8.33
66.66
10.0
10.0
80
MHz
System Frequency 1
External Clock Mode
On-Chip PLL Frequency
fsys 0
fref / 32
fsys(max)
66.66
66.66
fsys(max)
80
80
MHz

Errata for Revision 1.0
MCF5282 User’s Manual Errata, Rev. 15
Freescale Semiconductor 7
4 Errata for Revision 1.0
Table 4. MCF5282UM Rev 1.0 Errata
Location Description
1.1/1-1 Change ‘Real time debug support, with two user-visible hardware breakpoint registers’
To ‘Real time debug support, with one user-visible hardware breakpoint register’
Table 2-2/2-7 Change the I field description to read: “Interrupt level mask. Defines the current interrupt
level. Interrupt requests are inhibited for all priority levels less than or equal to the current
level, except the edge-sensitive level 7 request, which cannot be masked.”
Table 5-1/5-2 Replace the description of PRI1 and PRI2 with the following:
Table 5-1/5-3 Add the following note to the SPV bit description: “The BDE bit in the second RAMBAR
register must also be set to allow dual port access to the SRAM. For more information,
see Section 8.4.2, ‘Memory Base Address Register (RAMBAR).’”
Description
Priority bit. PRI1 determines if DMA or CPU has priority in upper 32K bank of
memory. PRI2 determines if DMA or CPU has priority in lower 32K bank of
memory. If bit is set, DMA has priority. If bit is reset, CPU has priority. Priority is
determined according to the following table.
NOTE: The Motorola-recommended setting for the priority bits is 00.
PRI[1:2] Upper Bank
Priority Lower Bank Priority
00 DMA Accesses DMA Accesses
01 DMA Accesses CPU Accesses
10 CPU Accesses DMA Accesses
11 CPU Accesses CPU Accesses

MCF5282 User’s Manual Errata, Rev. 15
Errata for Revision 1.0
Freescale Semiconductor8
Figure 6-2/6-4 Replace Figure 6-2, “CFM 512K Array Memory Map,” with the figure below.
Figure 6-2. CFM 512K Array Memory Map
Table 6-12/6-16 Change value for page erase verify command to 0x06.
Table 6-13/6-20 Change value for page erase verify command to 0x06.
Table 8-3/8-5 Add the following note the BDE bit description: “The SPV bit in the CPU’s RAMBAR must
also be set to allow dual port access to the SRAM. For more information, see Section
5.3.1, ‘SRAM Base Address Register (RAMBAR).’”
Figure 9-1/9-3 Remove ÷ 2 from CLKGEN block.
10.3.6/10-11 Add this text to the end of the first paragraph: “If a specific interrupt request is completely
unused, the ICRnx value can remain in its reset (and disabled) state.”
10.5/10-17 Add the following note: “The wakeup mask level taken from LPICR[6:4] is adjusted by
hardware to allow a level 7 IRQ to generate a wakeup. That is, the wakeup mask value
used by the interrupt controller must be in the range of 0–6.”
Figure 12-4/12-8 Change CSCRn to reflect that AA is set to ‘1’ at reset.
13.5/13-15 Remove final paragraph. The paragraph incorrectly states that the MCF5282 does not have
a bus monitor.
Table 4. MCF5282UM Rev 1.0 Errata (continued)
Location Description
0x0007 FFFF
0x0004 000C
0x0000 0000
0x0000 0004
0x0000 0008
0x0000 000C
0x0003 FFFF
0x0004 0000
0x0004 0004
0x0004 0008
3H[1] 3L[1]
2H[1] 2L[1]
3H[0] 3L[0]
2H[0] 2L[0]
1H[1] 1L[1]
0H[1] 0L[1]
1H[1] 1L[1]
0H[0] 0L[0]
Logical Block 1 (256 Kbytes)
Memory
Array 2H
2H[31] 2L[31]
Memory
Array 2L
2H[0] 2L[0]
Flash Physical Block 2 Flash Physical Block 3
3H[31] 3L[31]
3H[0] 3L[0]
Memory
Array 3H Memory
Array 3L
Logical Block 0 (256 Kbytes)
Memory
Array 0H
0H[31] 0L[31]
Memory
Array 0L
0H[0] 0L[0]
Flash Physical Block 0 Flash Physical Block 1
1H[31] 1L[31]
1H[0] 1L[0]
Memory
Array 1H Memory
Array 1L
Each memory array = 64 Kbytes
(16 bits wide ×32K)
Each physical block = 128 Kbytes
(32 bits wide ×32K)
Configuration Field
(0x0000_0400–
0x0000_0417)

Errata for Revision 1.0
MCF5282 User’s Manual Errata, Rev. 15
Freescale Semiconductor 9
Table 17-13/17-26 Change encodings for bits 31–9 to:
0The corresponding interrupt source is masked.
1The corresponding interrupt source is not masked.
Chapter 19 Change PIT1–PIT4 to PIT0–PIT3 throughout chapter. When a timer is referenced
individually, PIT1 should be PIT0, PIT2 should be PIT1, PIT3 should be PIT2, and PIT4
should be PIT3. Other chapters in the user’s manual use the correct nomenclature:
PIT0–PIT3.
19.6.3/19-7 Change timeout period equation to the equation below.
Figure 23-11 Change UISR bits 5–3 to reserved bits
24.6.1/24-11 Change ‘I2CR = 0xA’ to ‘I2CR = 0xA0.’
27.2.1/27-2 Change ‘When interfacing to 16-bit ports, the port C and D pins and PJ[7:6] (BS[3:2]) can
be configured as general-purpose input/output (I/O)’
To ‘When interfacing to 16-bit ports, the port C and D pins and PJ[5:4] (BS[1:0]) can be
configured as general-purpose input/output (I/O)’
32.2/32-7 Added additional device number order information to Table 32-2.
Chapter 33 Delete references to ‘TA = TL to TH’.
Table 33-1/33-1 The Digital Input Voltage (VIN) absolute maximum rating should be -0.3 to 6.0 V
Table 33-6/33-8 The normal operation analog supply current (IDDA) maximum value has been changed to
5.0 mA.
Table 4. MCF5282UM Rev 1.0 Errata (continued)
Location Description
Timeout period PRE[3:0] (PM[15:0] 1)+2××
system clock
-----------------------------------------------------------------------------=
Table 32-2. Orderable Part Numbers
Motorola
Part Number Description Speed Temperature
MCF5280CVF66 MCF5280 RISC Microprocessor, 256 MAPBGA 66.67 MHz -40°to +85°C
MCF5280CVF80 MCF5280 RISC Microprocessor, 256 MAPBGA 80 MHz -40°to +85°C
MCF5281CVF66 MCF5281 RISC Microprocessor, 256 MAPBGA 66.67 MHz -40°to +85°C
MCF5281CVF80 MCF5281 RISC Microprocessor, 256 MAPBGA 80 MHz -40°to +85°C
MCF5282CVF66 MCF5282 RISC Microprocessor, 256 MAPBGA 66.67 MHz -40°to +85°C
MCF5282CVF80 MCF5282 RISC Microprocessor, 256 MAPBGA 80 MHz -40°to +85°C

MCF5282 User’s Manual Errata, Rev. 15
Errata for Revision 1.0
Freescale Semiconductor10
Figure 33-5/33-16 Replace Figure 33-5, ‘SDRAM Read Cycle’ with the figure below.
Figure 33-5. SDRAM Read Cycle
Table 14-3/14-11 Change ‘Internal Pull-Up’ column to pull-up indications in the table below.
Table 14-3. MCF5282 Signals and Pin Numbers Sorted by Function
MAPBGA Pin Pin Functions Description Primary
I/O
Internal
Pull-up
1
Primary2Secondary Tertiary
Reset
R11 RSTI — — Reset in IYes
P11 RSTO — — Reset out O —
Clock
T8 EXTAL — — External clock/crystal in I —
Table 4. MCF5282UM Rev 1.0 Errata (continued)
Location Description
A[23:0]
SRAS
D[31:0]
ACTV NOP
SDRAM_CS[1:0]
READ
Column
CLKOUT
0
DRAMW
BS[3:0]
12345678910 11 12 13
D1
D2
D4
D6
D5
D4
1
DACR[CASL] = 2
SCAS
1
NOP
D4
Row
D3
PRE

Errata for Revision 1.0
MCF5282 User’s Manual Errata, Rev. 15
Freescale Semiconductor 11
R8 XTAL — — Crystal drive O —
N7 CLKOUT — — Clock out O —
Chip Configuration/Mode Selection
R14 CLKMOD0 — — Clock mode select IYes
T14 CLKMOD1 — — Clock mode select IYes
T11 RCON — — Reset configuration enable IYes
H1 D26 PA2 —Chip mode I/O —
K2 D17 PB1 —Chip mode I/O —
K3 D16 PB0 —Chip mode I/O —
J4 D19 PB3 —Boot device/data port size I/O —
K1 D18 PB2 —Boot device/data port size I/O —
J2 D21 PB5 —Output pad drive strength I/O —
External Memory Interface and Ports
C6:B6:A5 A[23:21] PF[7:5] CS[6:4] Address bus O Yes
C4:B4:A4:B3:A3 A[20:16] PF[4:0] — Address bus O Yes
A2:B1:B2:C1:
C2:C3:D1:D2 A[15:8] PG[7:0] — Address bus O Yes
D3:D4:E1:E2:
E3:E4:F1:F2 A[7:0] PH[7:0] — Address bus O Yes
F3:G1:G2:G3:
G4:H1:H2:H3 D[31:24] PA[7:0] —Data bus I/O —
H4:J1:J2:J3:
J4:K1:K2:K3 D[23:16] PB[7:0] —Data bus I/O —
L1:L2:L3:L4:
M1:M2:M3:M4 D[15:8] PC[7:0] —Data bus I/O —
N1:N2:N3:P1:
N5:T6:R6:P6 D[7:0] PD[7:0] —Data bus I/O —
P14:T15:R15:R16 BS[3:0] PJ[7:4] — Byte strobe I/O Yes
N16 OE PE7 — Output enable I/O —
P16 TA PE6 —Transfer acknowledge I/O Yes
P15 TEA PE5 — Transfer error acknowledge I/O Yes
N15 R/W PE4 — Read/write I/O Yes
N14 SIZ1 PE3 SYNCA Transfer size I/O Yes3
Table 14-3. MCF5282 Signals and Pin Numbers Sorted by Function (continued)
MAPBGA Pin Pin Functions Description Primary
I/O
Internal
Pull-up
1
Primary2Secondary Tertiary

MCF5282 User’s Manual Errata, Rev. 15
Errata for Revision 1.0
Freescale Semiconductor12
M16 SIZ0 PE2 SYNCB Transfer size I/O Yes4
M15 TS PE1 SYNCA Transfer start I/O Yes
M14 TIP PE0 SYNCB Transfer in progress I/O Yes
Chip Selects
L16:L15:L14:L13 CS[3:0] PJ[3:0] — Chip selects 3-0 I/O Yes
C6:B6:A5 A[23:21] PF[7:5] CS[6:4] Chip selects 6-4 O Yes
SDRAM Controller
H15 SRAS PSD5 — SDRAM row address strobe I/O —
H16 SCAS PSD4 — SDRAM column
address strobe I/O —
G15 DRAMW PSD3 — SDRAM write enable I/O —
H13:G16 SDRAM_CS[1:0] PSD[2:1] — SDRAM chip selects I/O —
H14 SCKE PSD0 — SDRAM clock enable I/O —
External Interrupts Port
B15:B16:C14:C15:
C16: D14:D15 IRQ[7:1] PNQ[7:1] —External interrupt request I/O —
Ethernet
C10 EMDIO PAS5 URXD2 Management channel
serial data I/O —
B10 EMDC PAS4 UTXD2 Management channel clock I/O —
A8 ETXCLK PEH7 —MAC Transmit clock I/O —
D6 ETXEN PEH6 —MAC Transmit enable I/O —
D7 ETXD0 PEH5 —MAC Transmit data I/O —
B11 ECOL PEH4 —MAC Collision I/O —
A10 ERXCLK PEH3 —MAC Receive clock I/O —
C8 ERXDV PEH2 —MAC Receive enable I/O —
D9 ERXD0 PEH1 —MAC Receive data I/O —
A11 ECRS PEH0 —MAC Carrier sense I/O —
A7:B7:C7 ETXD[3:1] PEL[7:5] —MAC Transmit data I/O —
D10 ETXER PEL4 —MAC Transmit error I/O —
A9:B9:C9 ERXD[3:1] PEL[3:1] —MAC Receive data I/O —
B8 ERXER PEL0 —MAC Receive error I/O —
Table 14-3. MCF5282 Signals and Pin Numbers Sorted by Function (continued)
MAPBGA Pin Pin Functions Description Primary
I/O
Internal
Pull-up
1
Primary2Secondary Tertiary

Errata for Revision 1.0
MCF5282 User’s Manual Errata, Rev. 15
Freescale Semiconductor 13
FlexCAN
D16 CANRX PAS3 URXD2 FlexCAN Receive data I/O —
E13 CANTX PAS2 UTXD2 FlexCAN Transmit data I/O —
I2C
E14 SDA PAS1 URXD2 I2C Serial data I/O Yes5
E15 SCL PAS0 UTXD2 I2C Serial clock I/O Yes6
QSPI
F13 QSPI_DOUT PQS0 —QSPI data out I/O —
E16 QSPI_DIN PQS1 —QSPI data in I/O —
F14 QSPI_CLK PQS2 —QSPI clock I/O —
G14:G13:F16:F15 QSPI_CS[3:0] PQS[6:3] —QSPI chip select I/O —
UARTs
R7 URXD1 PUA3 —U1 receive data I/O —
P7 UTXD1 PUA2 —U1 transmit data I/O —
N6 URXD0 PUA1 —U0 receive data I/O —
T7 UTXD0 PUA0 —U0 transmit data I/O —
C10 EMDIO PAS5 URXD2 U2 receive data I/O —
B10 EMDC PAS4 UTXD2 U2 transmit data I/O —
D16 CANRX PAS3 URXD2 U2 receive data I/O —
E13 CANTX PAS2 UTXD2 U2 transmit data I/O —
E14 SDA PAS1 URXD2 U2 receive data I/O Yes5
E15 SCL PAS0 UTXD2 U2 transmit data I/O Yes6
K16 DTIN3 PTC3 URTS1/
URTS0 U1/U0 Request to Send I/O —
K15 DTOUT3 PTC2 URTS1/
URTS0 U1/U0 Request to Send I/O —
K14 DTIN2 PTC1 UCTS1/
UCTS0 U1/U0 Clear to Send I/O —
K13 DTOUT2 PTC0 UCTS1/
UCTS0 U1/U0 Clear to Send I/O —
J16 DTIN1 PTD3 URTS1/
URTS0 U1/U0 Request to Send I/O —
Table 14-3. MCF5282 Signals and Pin Numbers Sorted by Function (continued)
MAPBGA Pin Pin Functions Description Primary
I/O
Internal
Pull-up
1
Primary2Secondary Tertiary

MCF5282 User’s Manual Errata, Rev. 15
Errata for Revision 1.0
Freescale Semiconductor14
J15 DTOUT1 PTD2 URTS1/
URTS0 U1/U0 Request to Send I/O —
J14 DTIN0 PTD1 UCTS1/
UCTS0 U1/U0 Clear to Send I/O —
J13 DTOUT0 PTD0 UCTS1/
UCTS0 U1/U0 Clear to Send I/O —
General Purpose Timers
T13:R13:P13:N13 GPTA[3:0] PTA[3:0] —Timer A IC/OC/PAI I/O Yes
T12:R12:P12:N12 GPTB[3:0] PTB[3:0] —Timer B IC/OC/PAI I/O Yes
N14 SIZ1 PE3 SYNCA Timer A synchronization input I/O Yes3
M16 SIZ0 PE2 SYNCB Timer B synchronization input I/O Yes4
M15 TS PE1 SYNCA Timer A synchronization input I/O Yes
M14 TIP PE0 SYNCB Timer B synchronization input I/O Yes
DMA Timers
K16 DTIN3 PTC3 URTS1/
URTS0 Timer 3 in I/O —
K15 DTOUT3 PTC2 URTS1/
URTS0 Timer 3 out I/O —
K14 DTIN2 PTC1 UCTS1/
UCTS0 Timer 2 in I/O —
K13 DTOUT2 PTC0 UCTS1/
UCTS0 Timer 2 out I/O —
J16 DTIN1 PTD3 URTS1/
URTS0 Timer 1 in I/O —
J15 DTOUT1 PTD2 URTS1/
URTS0 Timer 1 out I/O —
J14 DTIN0 PTD1 UCTS1/
UCTS0 Timer 0 in I/O —
J13 DTOUT0 PTD0 UCTS1/
UCTS0 Timer 0 out I/O —
Queued Analog-to-Digital Converter (QADC)
T3 AN0 PQB0 ANW Analog channel 0 I/O —
R2 AN1 PQB1 ANX Analog channel 1 I/O —
T2 AN2 PQB2 ANY Analog channel 2 I/O —
R1 AN3 PQB3 ANZ Analog channel 3 I/O —
Table 14-3. MCF5282 Signals and Pin Numbers Sorted by Function (continued)
MAPBGA Pin Pin Functions Description Primary
I/O
Internal
Pull-up
1
Primary2Secondary Tertiary

Errata for Revision 1.0
MCF5282 User’s Manual Errata, Rev. 15
Freescale Semiconductor 15
R4 AN52 PQA0 MA0 Analog channel 52 I/O —
T4 AN53 PQA1 MA1 Analog channel 53 I/O —
P3 AN55 PQA3 ETRIG1 Analog channel 55 I/O —
R3 AN56 PQA4 ETRIG2 Analog channel 56 I/O —
P4 VRH — — High analog reference I —
T5 VRL — — Low analog reference I —
Debug and JTAG Test Port Control
R9 JTAG_EN — — JTAG Enable I —
P9 DSCLK TRST —Debug clock / TAP reset IYes7
T9 TCLK — — TAP clock IYes7
P10 BKPT TMS —Breakpoint/TAP test mode
select IYes7
R10 DSI TDI —Debug data in / TAP data in IYes7
T10 DSO TDO —Debug data out / TAP data out O —
C12:D12:A13:B13 DDATA[3:0] PDD[7:4] —Debug data I/O —
C13:A14:B14:A15 PST[3:0] PDD[3:0] —Processor status data I/O —
Test
N10 TEST —Test mode pin I —
Power Supplies
R5 VDDA — — Analog positive supply I —
P5:T1 VSSA — — Analog ground I —
P2 VDDH — — ESD positive supply I —
N8 VDDPLL — — PLL positive supply I —
P8 VSSPLL — — PLL ground I —
A6:C11 VPP — — Flash (stress) programming
voltage I —
A12:C5:D5:D11 VDDF — — Flash positive supply I —
B5:B12: VSSF — — Flash module ground I —
N11 VSTBY — — Standby power I —
Table 14-3. MCF5282 Signals and Pin Numbers Sorted by Function (continued)
MAPBGA Pin Pin Functions Description Primary
I/O
Internal
Pull-up
1
Primary2Secondary Tertiary

MCF5282 User’s Manual Errata, Rev. 15
Revision History
Freescale Semiconductor16
5 Revision History
Table 5 provides a revision history for this document.
E6-E11:F5:F7-F10:
F12:G5:G6:G11:
G12:H5:H6:H11:
H12:J5:J6:J11:J12:
K5:K6:K11:K12:L5:
L7-L10:L12:
M6-M11
VDD — — Positive supply I —
A1:A16:E5:E12:F6:
F11:G7-G10:H7-H10:
J7-J10:K7-K10:L6:
L11:M5:M12:T16
VSS — — Ground I —
NOTES:
1Pull-ups are not active when GPIO functions are selected for the pins.
2The primary functionality of a pin is not necessarily its default functionality. Pins that have GPIO functionality will
default to GPIO inputs.
3Pull-up is active only with the SYNCA function.
4Pull-up is active only with the SYNCB function.
5Pull-up is active only with the SDA function.
6Pull-up is active only with SCL function.
7Pull-up is active when JTAG_EN is driven high.
Table 5. Revision History Table
Rev. Number Substantive Changes Date of Release
0 Initial release. 07/2003
1 Added page erase verify errata for Chapter 6, “ColdFire Flash Module (CFM).” 09/2003
2 • Added errata for UART interrupt status register.
• Added errata for PIT timer timeout equation.
• Added I2CR write errata.
• Added errata for ‘Internal Pull-Up’ column in ‘MCF5282 Signals and Pin
Numbers Sorted by Function’ table.
• Added errata for “SDRAM Read Cycle’ figure.
11/2003
3 • Added errata for Chapter 19. PIT1–PIT4 should be PIT0–PIT3. 01/2004
4 • Added errata for spurious interrupt.
• Added errata for Table 33-8. Single instance of TA= TLto THwas overlooked
in revision 2.0 of the manual. This instance has now been removed.
03/2004
5 • Added errata for Section 25.4.10: change CANICR to ICRn.
• Added errata for BITERR and ACKERR field descriptions.
• Added errata for BOFFINT and ERRINT bit sequence.
• Added errata for BUFnI field description.
03/2004
Table 14-3. MCF5282 Signals and Pin Numbers Sorted by Function (continued)
MAPBGA Pin Pin Functions Description Primary
I/O
Internal
Pull-up
1
Primary2Secondary Tertiary

Revision History
MCF5282 User’s Manual Errata, Rev. 15
Freescale Semiconductor 17
6 • Added errata for Table 17-2
• Added errata for FRSR register diagram 11/2004
7 • Added errata for Figure 4-2, Table 4-6, Figure 6-3, and Table 6-10 11/2004
Added the below errata for MCF5282UM Rev 2.3
8 • Added FEC max buffer size errata.
• Added VDD/VDDH power-up requirement.
• Added MFD bit definition footnote errata.
• Added PLL spec table entries for 66MHz device.
01/2005
9 • Added INTFRCLnfigure errata.
• Added BAM bit field example errata. 03/2005
10 • Added SDRAM NOP command errata.
• Added UART clock source errata. 07/2005
11 • Added PRI1/PRI2 text description errata.
• Added CSMR1/CSCR1 register address errata.
• Removed Table 23-5 errata that was added in revision 10 of this document,
as it was incorrect. Only the internal UART clock source is prescaled by the
16-bit divider.
• Added 2 UART external clock source errata, removing the 16-bit divider from
a figure and equation.
08/2005
12 • Added core watchdog unable to reset the device errata.
• Added EMRBR register address errata.
• Added IOH and IOL errata.
12/2005
13 • Added FlexCAN flag clearing mechanism errata in interrupt controller.
• Added FlexCAN ESTAT register description errata for various bits.
• Added ICRnx note regarding unique and non-overlapping level and priority
definitions.
• Added DTOUT1, DTIN0, DTOUT0 description field errata in GPIO chapter.
• Added FEC MII transmit and receive specification section errata.
08/2006
14 • Deleted reference to nonexistent CF bits in the figure and bit descriptions for
the GPTFLG2 register.
• Added RMON_R_DROP counter errata.
11/2006
15 • Added various core, EMAC, cache, SRAM and debug chapter errata.
• Added VIH and VIL crystal mode spec changes.
• Added DACRn[CBM] field description note.
• Added FEC MIB counter memory map errata.
• Added “Duplicate Frame Transmission” section to FEC chapter.
• Added DMA SAA bit errata.
• Added global IACK register space errata.
05/2007
Table 5. Revision History Table (continued)
Rev. Number Substantive Changes Date of Release

How to Reach Us:
Home Page:
www.freescale.com
E-mail:
suppor[email protected]
USA/Europe or Locations Not Listed:
Freescale Semiconductor
Technical Information Center, CH370
1300 N. Alma School Road
Chandler, Arizona 85224
[phone] or [phone]
suppor[email protected]
Europe, Middle East, and Africa:
Freescale Halbleiter Deutschland GmbH
Technical Information Center
Schatzbogen 7
81829 Muenchen, Germany
[phone] (English)
[phone] (English)
[phone] (German)
[phone] (French)
suppor[email protected]
Japan:
Freescale Semiconductor Japan Ltd.
Headquarters
ARCO Tower 15F
1-8-1, Shimo-Meguro, Meguro-ku,
Tokyo 153-0064, Japan
0120 191014 or [phone]
suppor[email protected]
Asia/Pacific:
Freescale Semiconductor Hong Kong Ltd.
Technical Information Center
2 Dai King Street
Tai Po Industrial Estate
Tai Po, N.T., Hong Kong
[phone]
suppor[email protected]
For Literature Requests Only:
Freescale Semiconductor Literature Distribution Center
P.O. Box 5405
Denver, Colorado 80217
1-800-441-2447 or 303-675-2140
Fax: [phone]
LDCForFreescaleSemicond[email protected]
Information in this document is provided solely to enable system and
software implementers touse Freescale Semiconductorproducts. There are
no express or implied copyright licenses granted hereunder to design or
fabricate any integrated circuits or integrated circuits based on the
information in this document.
Freescale Semiconductor reserves the right to make changes without further
notice to any products herein. Freescale Semiconductor makes no warranty,
representation or guarantee regarding the suitability of its products for any
particular purpose, nor does Freescale Semiconductor assume any liability
arising out of the application or use of any product or circuit, and specifically
disclaims any and all liability, including without limitation consequential or
incidental damages. “Typical” parameters that may be provided in Freescale
Semiconductordata sheets and/or specifications can and do vary in different
applications and actual performance may vary over time. All operating
parameters, including “Typicals”, must be validated for each customer
application by customer’s technical experts. Freescale Semiconductor does
not convey any license under its patent rights nor the rights of others.
FreescaleSemiconductorproductsare notdesigned,intended,or authorized
for useas components in systems intended for surgical implant into the body,
or other applications intended to support or sustain life, or for any other
application in which the failure of the Freescale Semiconductor product could
create a situation where personal injury or death may occur. Should Buyer
purchase or use Freescale Semiconductor products forany such unintended
or unauthorized application, Buyer shall indemnify and hold Freescale
Semiconductor and its officers, employees, subsidiaries, affiliates, and
distributors harmless against all claims, costs, damages, and expenses, and
reasonable attorney fees arising out of, directly or indirectly, any claim of
personal injury or death associated with such unintended or unauthorized
use, even if such claim alleges that Freescale Semiconductor was negligent
regarding the design or manufacture of the part.
Freescale™ and the Freescale logo are trademarks of Freescale
Semiconductor, Inc. All other product or service names are the property
of their respective owners.© Freescale Semiconductor, Inc. 2007. All rights
reserved.
MCF5282UMAD
Rev. 15
05/2007
