Fri-Jado CSD 180 Hot Manual

CSD 180 Hot
en / 2-II 9123529 / 0712
DIRECTIONS FOR USE EN 2-1
GEBRAUCHSANLEITUNG DE 3-1
MODE D'EMPLOI FR 4-1
INSTRUCCIONES DE MANEJO ES 5-1
www.frijado.com

CSD 180 Hot
en / 2-II 9123529 / 0712
KEEP THIS USER MANUAL FOR FUTURE USE
© 2006 Fri-Jado BV, Etten-Leur, The Netherlands
We advise you to contact your supplier for the guarantee period and conditions. Further we refer to our
General Terms and Conditions for Sales and Delivery that are available upon request.
The manufacturer does not accept any liability for damage or injury caused by the failure to adhere to these
regulations or by not observing the usual caution or care in actions, operation, maintenance or repair
activities, even if not explicitly described in this manual.
As a result of constant commitment to improvement, it may happen that your unit deviates in detail from what
is described in this manual. For this reason the given instructions are only a guideline for the installation, use,
maintenance and repair of the unit referred to in this manual.
This manual has been composed with the utmost care. The manufacturer shall, however, not be held
responsible for any mistakes in this manual nor for any consequences thereof.
The user is allowed to copy this manual for his own use. Further all rights are reserved and nothing in this
manual may be reproduced and/or made public in any way

CSD 180 Hot
en / 2-1 9123529 / 0712
Volume
1. Safety, hygiene and environment............................................................................2-2
1.1. General.............................................................................................................................................2-2
1.2. CE-mark...........................................................................................................................................2-2
1.3. Identification.....................................................................................................................................2-2
1.4. Icons and symbols ...........................................................................................................................2-3
1.5. Safety measures ..............................................................................................................................2-3
1.6. Service, maintenance and repairs ...................................................................................................2-4
1.7. Materials used and the environment................................................................................................2-4
1.8. Guarantee ........................................................................................................................................2-4
2. Description of the unit..............................................................................................2-5
2.1. Operation..........................................................................................................................................2-5
2.2. Intended use.....................................................................................................................................2-5
2.3. Parts.................................................................................................................................................2-5
2.4. Technical specifications...................................................................................................................2-6
3. Install .........................................................................................................................2-7
3.1. Unpack.............................................................................................................................................2-7
3.2. Installation........................................................................................................................................2-7
3.3. Warm through...................................................................................................................................2-8
3.4. Move.................................................................................................................................................2-8
4. Operation...................................................................................................................2-9
4.1. Switch the unit on and off.................................................................................................................2-9
4.2. Set the temperature .........................................................................................................................2-9
4.3. Load product ..................................................................................................................................2-10
4.4. Fill the water tray............................................................................................................................2-10
5. Maintenance and cleaning .....................................................................................2-11
6. Problems .................................................................................................................2-12
6.1. Replace the lamp...........................................................................................................................2-13

CSD 180 Hot
en / 2-II 9123529 / 0712
1. Safety, hygiene and environment
1.1. General
The manufacturer accepts no liability whatsoever for loss or injury caused by failure to strictly
adhere to the safety guidelines and instructions in this manual or due to carelessness during
installation, use, maintenance and repair of the unit referred to in this manual and any of its
accessories.
The unit may be operated by qualified and authorised persons only. Anyone who works on or with
this unit must be familiar with the contents of this manual and carefully follow all guidelines and
instructions. Never change the order of the steps to be performed.
The management must instruct the personnel on the basis of this manual and follow all instructions
and regulations.
1.2. CE-mark
The unit was built in accordance with European Guidelines and standards as specified in the CE
declaration delivered with your unit.
To ensure its proper functioning, use the unit solely in accordance with its purposes as stated in
EN 292-1. In this standard ‘intended use’ means the use for which this technical unit is suitable in
accordance with the technical specifications of the manufacturer inclusive of the directions in the
sales brochure.
In case of doubt it is the use which can be deducted from the construction, the model and the
function of the technical unit as being normal use. Operating the unit within the limits of its intended
use also involves following the instructions in the user manual and observing the inspection and
maintenance conditions.
1.3. Identification
The identification plate is located on the service side
and contains the following data:
•Name of the supplier or the manufacturer
•Model
•Serial number
•Year of manufacture
•Mains voltage
•Frequency
•Rated current

1.4. Icons and symbols
1.4.1. Manual
In this manual the following icons and symbols are used:
Danger of personal injury or serious damage to the unit
Electric voltage
Hot surfaces
Danger of fire
Additional information
Environmental aspects
1.4.2. Unit
The icons given below have been attached to the unit. Never cover or remove them. Immediately
replace or repair illegible or damaged icons.
Electric voltage
Hot surfaces
1.5. Safety measures
•Never change the technical specifications mentioned in this manual.
•Use the unit in a technically perfect condition only.

CSD 180 Hot
en / 2-IV 9123529 / 0712
1.6. Service, maintenance and repairs
Regularly clean the unit to ensure its continued proper functioning.
WARNING
•Clean the unit daily. Keep to the maintenance intervals (see chapter 5).
•In case of disruption, follow the clues. (see chapter 6).
WARNING
Do not clean the unit using a water hose.
This manual clearly makes a distinction between service, maintenance and repair
activities that can be carried out by the user and those which exclusively should be
carried out by qualified and authorised service engineers.
1.7. Materials used and the environment
1.7.1. Packaging material
All packaging materials are suitable for re-use.
Do not dispose of the packaging material with the industrial waste.
The following materials have been used:
•Untreated wood
•Cardboard
•Polyethylene foil
•Styropor
•Polypropylene tape
1.7.2. Remove
If required, the Fri-Jado supplier can advise on how to remove the unit. The Fri-Jado supplier can
also indicate which parts contain valuable substances and materials.
Treat the materials in accordance with the current local environmental regulations.
1.8. Guarantee
In case of unauthorised modifications in or on the unit, any liability on the part of the manufacturer
becomes null and void.
For contact data see the back of this manual.

2. Description of the unit
2.1. Operation
The display warmer keeps the products warm by means of a warm airflow with a high humidity
level. The fan in the display ensures an even distribution of heat. The products maintain the
required quality in the display for a maximum of three hours.
The display has glass on three sides and the rear side has a reflecting rear window, allowing
optimum presentation of the products.
2.2. Intended use
WARNING
The display-warmer is exclusively designed for keeping warm products warm and for
presenting them.
Any other use shall be considered to be not in conformity with the intended use. The manufacturer
accepts no liability whatsoever with regard to loss or injury that may be the consequence hereof.
The unit was built in accordance with European Guidelines and standards as specified in the CE
declaration delivered with your unit. Use the unit solely in technically perfect condition and in
conformity with the intended use described above.
2.3. Parts
2.3.1. Overview of the unit
A4
A6
A5
A7
A8
A9
A10
4
5
6
1
2
3
A3
A1
A2
A11
A1 On/Off switch
A2 Temperature display
A3 Temperature setting
A4 Water tray rear side
A5 Door rear side
A6 Lighting beneath plateaus
A7 Display/slide holder and lighting of upper
plateau
A8 Plateau (3 pieces)
A9 Flap window customer side (3 pieces)
A10 Covering panel of water tray
A11 Water tray

CSD 180 Hot
en / 2-VI 9123529 / 0712
2.4. Technical specifications
WARNING
See the identification plate for the correct specifications of the unit. The electrical
installation data may vary between different countries.
CSD 180 Hot
Dimensions Width mm 728
Depth mm 576
Height mm 877
Weight kg 63
Voltage 230V 1N~
Frequency Hz 50…60
Max. rated current A 11,3
Power to be supplied W 2610
Plug
two-pole earthed
plug
Cable length m approx. 2.40
Sound pressure dB(A) < 70
Water tray Max volume l 8
Max. water use per
hour l 1,2
Standard accessories User manual

3. Install
3.1. Unpack
1. Remove all parts from the unit.
2. Remove the foil from all metal parts.
3. Remove all packaging materials from the unit.
4. Check the unit for damage.
5. Make sure that all parts that belong to the model
you have ordered are present.
6. Read the manual before proceeding.
If any parts are missing or damaged, contact your supplier.
3.2. Installation
WARNING
•There should be at least 100 mm clearance between the sides and other
equipment or walls.
•Position the unit flatly on a sufficiently sturdy base using a spirit level. Here take
the weight of the unit into account.
Follow the procedure below when storing a unit that will not be used for some time:
•Thoroughly clean the unit.
•Pack the unit dustproof.
•Store the unit in a dry place.
Find a suitable place for the unit. Points of interest:
•The products in the unit must be well visible.
•There must be sufficient room to operate and maintain the unit.
•Make sure that the unit is accessible for maintenance and service activities.
•Be sure that the environmental temperature is not less than 20 °C and not more than 30 °C.
•In connection with the danger of short circuit the unit is not suited for use in a rainy or very
moist environment.
1. Clean the inside, the removable parts and the accessories thoroughly with soapsuds before
putting the unit into use.
2. After cleaning, wipe the unit with a cloth moistened with clean water to remove soapsuds residues
and then dry the entire unit.
3. Attach all (optional) parts and/or accessories.
4. Insert the plug into the socket.
5. Fill the water tray with clean cold water. Preferably use softened water.
•The presentation plateaus have different dimensions. A mark has been provided for
easy placement. The bottom plateau has been marked with one groove, the middle
plateau has two grooves and the top plateau three.
•The water tray can be placed on the customer side as well as on the service side.

CSD 180 Hot
en / 2-VIII 9123529 / 0712
Install slide:
Insert a slide if the unit has been provided with
a slide holder.
WARNING
Remove the plug from the outlet.
1. Loosen the 7 screws in the ceiling around
the lighting, but do not remove them.
2. Carefully push against the slide holder
until the lighting module cannot slide in
further.
3. Remove the two transparent plastic plates
(A) from the slide holder and take them out
via the bottom of the unit.
4. Place the new slide (B) between the
plastic plates (A) and go through the steps
in reverse order.
A
B
3.3. Warm through
Let the unit warm through for at least half an hour at the highest temperature setting to
allow the metal odour that exudes from it when it is new to burn off.
3.4. Move
Before moving the unit:
1. Switch off the unit.
2. Remove the plug from the outlet.
3. Let the unit cool off for fifteen minutes.
4. Empty the water tray.

4. Operation
WARNING
Especially an empty water tray and the lamp holder can become very hot.
The windows can mist up during the heating period: the condensation will disappear
after approximately 15 minutes.
4.1. Switch the unit on and off
Switch on
1. Switch on the equipment using switch A1. The
lighting, the heating and the fans are activated.
2. Set the required temperature. See section 4.2 for
this.
3. Preheat the display to the required temperature for
appriximately 15 minutes.
Display A2 shows the temperature in the display during
use.
Switch off
1. Switch off the unit using switch A1.
A
1
A
2
4.2. Set the temperature
WARNING
Meat products should be kept in the
display-warmer at a minimum temperature
of 70°C; only then you can be sure that the
product temperature is above 65°C.
1. Set button A3 to the required position (1-6).
See the table.
Temperature setting A3 Temperature (°C)
1 approx. 22
2 approx. 35
3 approx. 48
4 approx. 61
5 approx. 74
6 approx. 87
When the temperature in the display is equal to the set
temperature, the heating element will switch off; the
other components remain in operation.
4
5
6
1
2
3
A3

CSD 180 Hot
en / 2-X 9123529 / 0712
4.3. Load product
WARNING
•Only place warm products.
•Make sure with packaged products that the packaging material is suitable for a
temperature of 100°C.
4.4. Fill the water tray
Regularly check the water level in the water tray
and fill up with warm water if necessary. The water
use is about 1.2 litre per hour.
Pull out the water tray before filling it. The water
tray can be filled both on the service side and on
the customer side.
On the customer side you can access the water
tray by opening the flap at the bottom side upward.

5. Maintenance and cleaning
WARNING
•Remove the plug from the wall socket when carrying out maintenance and
cleaning activities.
•Do not clean the unit using a water hose.
•In view of hygiene and an optimal condition of the unit it is important to adhere to a
fixed cleaning pattern from the very beginning.
•It is best to remove meat residual and grease shortly after using the unit, while it is
lukewarm. Optimum cleaning results are achieved by using ‘Fri-Jado Clean’.
Item Action Cleaning
frequency
Interior and exterior •Switch off the unit.
•Take the products out of the unit.
•Allow the equipment to cool off.
•Clean the interior with hot soapsuds or Fri-Jado Clean.
•After cleaning, dry the interior with a clean cloth. Make sure
no traces of cleaning agent are left behind.
Daily
Glass •Clean the glass parts with hot water and a cleaning agent for
glass. Daily
Presentation
plateaus
•Clean the interior with hot soapsuds or Fri-Jado Clean. Daily
Water tray •Clean the water tray with hot soapsuds or Fri-Jado Clean.
•Remove any scaling from the water using warm water and
vinegar.
Weekly
WARNING
•The heating element above the water tray can still be hot!
•Do not clean the unit using steel wool.
•Fri-Jado Clean may in some cases irritate a sensitive skin. Wear rubber gloves
when using it.
•
Follow the instructions on the label of ‘Fri-Jado Clean’.

CSD 180 Hot
en / 2-XII 9123529 / 0712
6. Problems
WARNING
•If the problem is not solved by consulting the table below, proceed as follows:
1. Switch off the unit.
2. Remove the plug from the outlet.
3. Contact your supplier/service agency. Make sure you have the following data
at hand: model and serial number.
•If the lead is damaged, immediately contact your supplier/service station.
•All windows used in the unit are made of tempered glass. If windows must be
replaced, use the same material.
•The required electric diagrams are supplied with the manual.
Item Problem Action
Unit Does not function. •Is the plug in the outlet?
•Is the power supply OK?
Check the fuses and the
earth leakage switch in the
meter cupboard.
•Are all switches in the
correct position?
Unit The set temperature is not
reached within half an hour.
•Close all windows.
Unit The temperature rises too
much.
•Check the set temperature.
•Switch off the unit.
•Remove the plug from the
outlet.
•Contact your
supplier/service agency.
Lamp A lamp is defective. •See paragraph 6.1

6.1. Replace the lamp
WARNING
Let the unit cool off for at least half an hour with all windows open.
The lamps are found in the upper cover and beneath
the presentation plateaus.
1. Remove the plug from the outlet.
2. Open all windows and let the unit cool off for at
least half an hour.
For the lamp in the upper cover:
3. Loosen the 7 screws in the ceiling around the
lighting, but do not remove them.
4. Carefully push against the slide holder until the
lighting module cannot slide in further.
5. Remove the two transparent plastic plates (A) from
the slide holder and take them out via the bottom of
the unit.
6. Remove the PL lamp by pulling it lengthwise out of
the holder. Do this carefully to avoid breaking.
7. Replace the lamp by one of the same type and go
through the steps you have just carried out in
reverse order.
For the lamp beneath the presentation plateau:
3. Dismount the neon lamp by turning it a quarter turn.
4. Replace the lamp by one of the same type.
A

CSD 180 Hot
9123529 / 0712
Uw leverancier
Your supplier
Ihr Fachhändler
Votre revendeur
Su suministrador
Fri-Jado BV
Oude Kerstraat 2
4878 AA Etten-Leur
The Netherlands
Tel: [phone]
Fax: [phone]
www.frijado.com
