Fri-Jado Modular Table Top User manual

MTT
USA EN 9124856 / 2310
USER MANUAL ‒USA version
Modular Table Top
WARNING
Read the instructions before using the machine.

MTT
USA 2/20
KEEP THIS USER MANUAL FOR FUTURE USE!
© 2023 Fri-Jado B.V., Oud Gastel, The Netherlands.
We advise you to contact your supplier for the guarantee period and conditions. Further we refer to
our General Terms and Conditions for Sales and Delivery that are available upon request.
The manufacturer does not accept any liability for damage or injury caused by failing to adhere to
these regulations or by not observing the usual caution or care in actions, operation, maintenance
or repair activities, even if not explicitly described in this manual.
As a result of constant commitment to improvement, it may happen that your unit deviates in detail
from what is described in this manual. For this reason, the given instructions are only a guideline for
the installation, use, maintenance and repair of the unit referred to in this manual.
This manual has been composed with the utmost care. The manufacturer shall, however, not be
held responsible for any mistakes in this manual nor for any consequences thereof.
The user is allowed to copy this manual for own use. Further all rights are reserved and nothing in
this manual may be reproduced and/or made public in any way.
Modifications:
In case of unauthorized modifications in or on the unit, every liability on the part of the manufacturer
becomes null and void.

MTT
USA 3/20
CONTENTS
1. INTRODUCTION..............................................................................................................4
1.1 General.............................................................................................................................4
1.2 Identification of the unit.....................................................................................................4
1.3 Pictograms and symbols...................................................................................................4
1.4 Safety instructions ............................................................................................................5
1.4.1 General........................................................................................................................5
1.4.2 Moving (when applicable)............................................................................................6
1.4.3 Outdoor use restrictions...............................................................................................6
1.5 Hygiene ............................................................................................................................6
1.6 Service and technical support...........................................................................................7
1.7 Storage.............................................................................................................................7
1.8 Disposal............................................................................................................................7
2. DESCRIPTION OF THE UNIT..........................................................................................8
2.1 Technical description........................................................................................................8
2.2 Intended use.....................................................................................................................8
2.3 Accessories......................................................................................................................8
3. INSTALLATION AND FIRST USE ...................................................................................9
3.1 Unpacking the unit............................................................................................................9
3.2 Installation and positioning..............................................................................................10
3.2.1 Applying price rail......................................................................................................10
3.3 Repositioning the glass shelves......................................................................................10
3.4 Air blockers.....................................................................................................................10
3.5 Installation of plinth set ...................................................................................................12
3.6 First use..........................................................................................................................12
4. OPERATION AND USE ................................................................................................. 13
4.1 Operating........................................................................................................................14
5. CLEANING AND MAINTENANCE................................................................................. 16
5.1 Maintenance schedule....................................................................................................16
5.2 Daily Cleaning.................................................................................................................16
5.3 Weekly Cleaning.............................................................................................................16
5.4 Cleaning Glass Panes ....................................................................................................17
6. MALFUNCTIONS AND SERVICE..................................................................................18
6.1 Replace the mains cord..................................................................................................18
7. TECHNICAL SPECIFICATIONS .................................................................................... 19

MTT
USA 4/20
1. INTRODUCTION
1.1 General
This manual is intended for the user of the MTT (Modular Table Top). The features and controls are
being described, along with directions for the safest and most efficient use, in order to guarantee a
long life of the unit.
This appliance is intended to be used for commercial applications, for example in kitchens of
restaurants, canteens, hospitals and in commercial enterprises such as bakeries, butcheries, etc.,
but not for continuous mass production of food.
All pictograms, symbols and drawings in this manual apply to all available MTT (USA) models.
1.2 Identification of the unit
The identification plate can be found on the outside of the machine, and contains the following data:
•Name of the supplier or the manufacturer.
•Model.
•Serial number.
•Year of construction.
•Voltage.
•Frequency.
•Power consumption.
1.3 Pictograms and symbols
In this manual, the following pictograms and symbols are used:
WARNING
Possible physical injury or serious damage to the unit, if the instructions are
not carefully followed.
WARNING
Hazardous electrical voltage.
WARNING
Danger of getting injured by hot surfaces.
SAFETY
Wear safety gloves for installation and dismantling.
Suggestions and recommendations to simplify indicated actions.
Recycling symbol.

MTT
USA 5/20
1.4 Safety instructions
WARNING
The outside and shelves of the unit can be very hot.
WARNING
The maximum load on top of the unit may never exceed 22 lbs.
WARNING
See installation instructions for grounding requirements.
1.4.1 General
The user of the unit will be fully responsible for abiding the locally prevailing safety- rules and
regulations.
The unit may be operated by qualified and authorized persons only. Anyone working on or with this
unit must be familiar with the contents of this manual and carefully follow all guidelines and
instructions. Never change the order of the steps to be performed. The management must instruct
the personnel on the basis of this manual and follow all instructions and regulations.
The pictograms, labels, instructions and warning signs attached to the unit, are part of the safety
measures. They may never be covered or removed, and have to be clearly visible during the entire
lifetime of the unit.
Immediately repair or replace damaged or illegible pictograms, warnings and instructions.
•To avoid short-circuiting, never clean the unit using a water hose. For cleaning instructions,
see section 5.
•The shelves, glass and back of the hot unit can get hot.
•The unit must be cleaned regularly to ensure proper functioning.
•Do not store explosive substances such as aerosol cans with flammable propellant in this
appliance.
•This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved.
•Children shall not play with the appliance.
•Cleaning and user maintenance shall not be performed by children without supervision.

MTT
USA 6/20
1.4.2 Moving (when applicable)
When moving the unit:
•Before moving the unit, first switch off the mains voltage by pulling the plug from the wall
socket.
•Remove pans containing a liquid product from the unit.
•Always keep the unit in upright position.
To prevent damage from moving/lifting the unit, remove the front panel by pulling
on one of the hinge pins. The hinge pins are located on the inside of the front panel.
1.4.3 Outdoor use restrictions
WARNING
To avoid short-circuiting, the units may not be used outdoors or in a rainy or very
moist environment.
1.5 Hygiene
WARNING
Immediately remove products in damaged packaging from the equipment and
destroy the products. Clean all components that have come in contact with products
from damaged packaging.
The quality of a fresh product always depends on hygiene. It is essential that products are packaged
immediately after preparation. Prevent fresh raw vegetables or already prepared, cooled products
from coming into contact with raw meat products to avoid transmitting salmonella. First thoroughly
clean hands and/or tools that have touched raw meat.
For hot products, the core temperature of the products at packaging should at least be 185ºF.
Be aware that high humidity levels may encourage the growth of biological organisms in the
environment.
Refer to the cleaning instructions of section 5.

MTT
USA 7/20
1.6 Service and technical support
The electrical schematics of your unit is included. In case of malfunctions you can contact your
dealer/service agent. Make sure you have the following data available:
•Model.
•Serial number.
This data can be found on the identification plate.
1.7 Storage
If the unit will not be used temporarily, and will be stored, follow these instructions:
•Clean the unit thoroughly.
•Wrap the unit from getting dusty.
•Store the unit in a dry, non-condensing environment.
•Ensure good ventilation.
1.8 Disposal
Dispose of the machine, any components or lubricants removed from it safely in
accordance with all local and national safety and environment requirements.

MTT
USA 8/20
2. DESCRIPTION OF THE UNIT
2.1 Technical description
The panels are made of galvanized steel plating, stainless steel or aluminium. Some of the visible
internal and external parts have been provided with a powder coating. The glass used is tempered.
The controls for operating the appliance have been mounted on the operator side of the unit. The
product contact parts are made of stainless steel AISI 304 or AISI 430 and tempered glass.
Heating in the unit is achieved by means of heated shelves in combination with an hot-air curtain per
shelf. The air curtain isolates the hot air inside the unit from the ambient air.
An electronic thermostat controls the temperature. The MTT has a multi temperature controller which
allows each shelf to have its own operation temperature. The electronic thermostat has been set at
the correct value at the factory. The set temperature can be changed between 104ºF and 158ºF.
One LED-module per level provides for lighting of the products. The LED-lighting and the heating
are switched on and off together. There are two MTT user variants; a solid back version and a pass
through version which allows the user to (re)fill products via the back side.
2.2 Intended use
MTT models have been designed solely to keep packaged products warm and to display them.
Any other use will not beregarded as intended use. The manufacturer accepts no liability whatsoever
for loss or injury caused by failing to strictly adhere to the safety guidelines and instructions in this
manual or due to carelessness during installation, use, maintenance and repair of the unit referred
to in this manual and any of its accessories.
Use the unit in perfect technical condition only.
2.3 Accessories
Your unit contains the following standard accessories:
•User manual.
•Power supply cord.
For optional accessories contact [e-mail].

MTT
USA 9/20
3. INSTALLATION AND FIRST USE
All packing materials used for this unit are suited for recycling.
Before and during unpacking, check the state of the unit. In case of damage, store the packing
material, and contact the transporter within fifteen working days after receiving the goods.
3.1 Unpacking the unit
1. Unpack the unit as initiated on the unpacking instruction on the packaging.
2. Remove all remaining packing materials from the unit.
3. Remove the protective foil from all the parts.
4. Take off the standard accessories.

MTT
USA 10/20
3.2 Installation and positioning
WARNING
Electric chock hazard. Grounding instructions: only connect the appliance to an
alternating current provided by a grounded wall socket, with a mains voltage in
accordance with the information indicated on the data plate of the appliance.
It is the consumer's responsibility to make sure the electrical installation conforms
with current national and local codes and wiring regulations.
Do not use a multi plug or extension cord. Such can result in fire, electrical shock, or
other personal injury.
Failure to follow these instructions can result in death or serious injury.
WARNING
Position the unit on a flat and horizontal surface. A temporally inclined plane of
maximum 5° is allowed.
•Be sure that the personnel have sufficient room to work with the unit.
•Keep a distance of at least 1 inch between the back wall and the unit.
•While positioning, keep the unit out of children’s reach.
•Do not position a unit near a doorway, a ventilation device or a refrigerator in order to avoid
any negative effects on the unit’s operation by a cold airflow. The unit is designed for a
maximum draft of 0.65 ft./sec.
•Do not place into direct sunlight.
•The unit should not be used below 68ºF ambient temperatures.
•The unit has a mains plug, and must be connected to a wall socket with the proper mains
voltage. The wall socket must be mounted by a certified electrician.
3.2.1 Applying price rail
Optional price rails can be mounted using the front screws underneath each of the shelves.
3.3 Repositioning the glass shelves
The top shelf can be positioned at two angled positions (0º and 3º). Refer to installation manual.
3.4 Air blockers
It is important that the air blockers remain on the shelf. Because without the air blockers the
performance of the MTT cannot be guaranteed! The installation of the air blockers is shown on the
next page.
The air blockers have the following numbers:

MTT
USA 11/20
These 4 types of air blockers need to be installed according the next steps:
1. Mount the air blockers under the shelf at the 4 positions.
2. Mount air blocker 1 and 2 on the right hand side of the shelf and mount
air blocker 3 and 4 on the left hand side of the shelf with 6 screws (hand tight).
1.
2.

MTT
USA 12/20
3.5 Installation of plinth set
Install the plinth set as initiated on the installation instruction (9124862).
If the power cord needs to go underneath the unit, the back plinth will have an
opening which needs to be facing upwards. If the power cord goes around the unit,
the opening of the back plinth must face downwards.
3.6 First use
Before starting to use the unit, clean the inside thoroughly with mild detergent and water.
After cleaning it wipe it with a cloth moistened with clean water to remove residual detergent, then
dry the entire unit.

MTT
USA 13/20
4. OPERATION AND USE
The display and/or set value is not the product/unit temperature.
Control Panel
On/Off Switch(es):
The main switch is located left underneath the
front of the unit.
Controls:
Note: The controls are located behind the front
panel of the unit.
To access the controls:
1. Push at the upper middle of the panel.
2. Stop pushing when you have reached the
end, then gently release to place the front
panel ajar.
3. Pull the front panel from the magnetic
lock to fully open the front panel.
To close the panel, attach the front panel to the
magnetic lock and keep pushing until you can
feel or hear the click again.
1
2
3
1. Temperature controller (heating).
2. On/Off switch.
1
2

MTT
USA 14/20
Display multi temperature controller
A controller for each shelf to switch it on/off and control it separately. The controllers are positioned
in the same way as the shelfs. So letter ´A´ shows the top shelf controller and letter ´B´ shows the
bottom shelf controller.
Using the multi-temperature controllers
The shelves can be controlled individually or even turned off completely. In this way optimal holding
conditions for different food groups can be achieved (for example: depending on holding time,
product quality, packaging and accessories used).
When set to the same temperature uniform temperatures can be attained throughout the cabinet and
energy can be saved. Although every combination of settings is possible (ranging from completely
off to a setpoint between 104ºF and 158ºF), certain settings may influence the time it takes for a
shelf to reach operating temperature.
For example, if only one shelf is turned on it may take over 60 minutes instead of approx. 30 minutes
when shelves are all set to the same temperature.
If different setpoints are required, it is advised to assign the highest setpoint to the
top shelf and the lowest setpoint to the bottom shelf for optimal performance and
energy savings.
If you need any assistance in determining the best setup for your hot food-to-go offering (such as
temperature setpoint, packaging and accessories), please contact Fri-Jado.
Temperature controller
Power on/off button*
UP-button
DOWN-button
SET SET-button
Image for reference only.
* Switch on/off: hold for several seconds.
4.1 Operating
The unit is set at 149ºF intake air temperature. If required, this temperature can be
adjusted.
At an ambient temperature of 68ºF and an initial core temperature of 185ºF these
factory settings of the unit’s temperature ensure a constant core temperature of at
least 149ºF for 4 hours.
Switching-on the unit
1. Switch on the power switch (the fans will start blowing).
2. Switch the heating on, by means of the temperature controller.
3. Preheat the unit (may take between 30 and 90 minutes depends on controller settings).

MTT
USA 15/20
Loading the unit
•Only place products that have a core temperature of at least 185ºF.
•The hot products needto be packaged in bags or containers that are suitable forthis purpose.
•To ensure a good contact with the heated trays, only place a single layer of products.
•The maximum loading height is 2 inch below the bottom of the shelf/air guide above.
•The maximum carrying-capacity per shelf is 20.2 lb/ft, by equal load.
Checking the temperature in the unit
•During operation the display of the thermostat shows thetemperature at the probe in the unit.
The indication ON will lit when the elements are active.
Checking the set temperature
1. Scroll through the folders with and until you find the folder Pb1, Pb2 or Pb3.
2. Press SET to view the value measured by the corresponding probe.
Adjusting the set temperature
1. During operation the display of the thermostat shows the temperature in the unit.
2. Push twice on the SET-button. The set temperature will appear on the display.
3. Push the -button and -button within 15 seconds.
4. Adjust the set temperature by means of the -button and the -button.
5. Push once on the SET-button to store the new set temperature.
Checking the product temperature
•Once every hour, the product temperature should be checked using a digital thermometer.
•Write down the measured values in a log.
•Always use a disinfected thermometer sensor.
Switching off
1. Remove all products from the unit. In order to avoid temperature drop of the products, store
them in another warm holding unit.
2. Switch the heating off.
3. Switch the main power off.

MTT
USA 16/20
5. CLEANING AND MAINTENANCE
WARNING
Never use a water hose for cleaning. Water can seep into the unit through the
ventilation holes of the unit.
Appliances must be disconnected from their power supply during cleaning or
maintenance and when replacing parts.
Because of hygiene aspects and optimum condition of the unit it is of utmost
importance to keep a daily cleaning pattern from first use onwards.
5.1 Maintenance schedule
Item
Action
Frequency
Inside
•Clean, see section 5.2.
Daily
Outside
•Clean, see section 5.3.
•Use Stainless Steel cleaning spray to remove
stains, and restoring the gloss.
Weekly
Glass panes
•Clean Glass panes, see section 5.4.
Weekly
5.2 Daily Cleaning
•Clean the inside of the unit with hot water and a suitable cleaner.
•After cleaning wipe the inside with a clean wet cloth. Be sure that the detergent is removed
properly.
5.3 Weekly Cleaning
WARNING
The control panel may only be cleaned using a damp cloth.
•Clean the outside of the unit with a small amount of hot water and a mild cleanser and using
a soft brush or sponge. After cleaning it dry the outside with a cloth.
•Treat all cleaned surfaces with a suitable antibacterial agent.
•Rub dry with a soft cloth or a paper towel.

MTT
USA 17/20
5.4 Cleaning Glass Panes
Cleaning the top air guide
WARNING
Do not usedetergents and other cleaning products thatmay damage polycarbonate.
Using inappropriate products to clean may tarnish, scratch or even crack any
polycarbonate surfaces.
The transparent air guide pane can be removed for cleaning.
•Lift up the back of the top air guide.
•Slide the top air guide out to the
front, slightly tilting it down at the
end to fully remove it.
•After cleaning, slide the top air guide
pane back in its position, making
sure it rests on the two pins in the
rear columns.
Cleaning the top glass pane
•To clean the inside of the top glass
pane, the top air guide needs to be
removed.
Cleaning the side double-glass pane
•To clean the inside of the side
double-glass panes, the air
blockers need to be removed (see
section 3.4 for instructions).

MTT
USA 18/20
6. MALFUNCTIONS AND SERVICE
Before you consult your dealer or the service agency when there is a fault, you can check the
following points yourself:
•Is the powersupply OK? Check thefuses and theearth leakage switch in the meter cupboard.
•Are all the switches in the correct position?
Item
Malfunction
Possible action
Unit
Unit does not work
•Check the power supply.
•Are all switches in the correct position?
Unit
Display shows error code
•Contact your supplier or service agency.
Unit
Unit does not reach set
temperature
•Check correct placing air blockers, see
section 3.4.
Lamp
Does not light up
•Switch ON.
Mains cord
Damaged
•Replace, see section 6.1.
Window
Damaged
•Replace, contact your supplier or service
agency.
6.1 Replace the mains cord
WARNING
Hazardous electrical voltage.
If the power cord is damaged it must be replaced, contact your supplier or service agent.

MTT
USA 19/20
7. TECHNICAL SPECIFICATIONS
WARNING
Consult the identification plate to get the proper specifications of the unit. The
electrical data may vary from country to country.
Model
MTT 24-2
MTT 36-2
Approved for
USA / CAN
USA / CAN
Width
23 5/9 in
35 7/16 in
Depth SB model
24 in
24 in
Depth PT model
25 3/16 in
25 3/16 in
Height on legs
26 3/8 in
26 3/8 in
Weight Net Approx.
130 lbs (SB)
139 lbs (PT)
174 lbs (SB)
187 lbs (PT)
Ambient Temperature
min. 68ºF
max. 86ºF
min. 68ºF
max. 86ºF
Relative humidity
max. 60%
max. 60%
Noise level (at workplace)
<55 dB(A)
<55 dB(A)
Voltage
1~ 208 V
1~ 208 V
Frequency
50/60 Hz
50/60 Hz
Max. nominal Current
5.6 A
8.4 A
Plug
NEMA 6-15P
NEMA 6-15P
Length power cord approx.
6 ft.
6 ft.

MTT
USA 20/20
Fri-Jado B.V.
Blauwhekken 2
4751 XD Oud Gastel
The Netherlands
Tel: [phone]
Fri-Jado Inc.
1401 Davey Road, Suite 100
Woodridge IL 60517
USA
Tel: [phone]
www.frijado.com
