Fri-Jado GO Combi User guide

Mounting instruction
How to mount a stand
EN (Original Instruction) Revision 08/2023, SW: 0.7.1
GO Combi

2
GO Combi

3
GO Combi
GO Combi mounting instruction, revision 08/2023, SW: 0.7.1
General information 4
Target group....................................................................................... 4
Technical changes............................................................................... 4
More documentation.......................................................................... 4
Warranty ............................................................................................ 4
Permissions......................................................................................... 4
Safety information 5
Before replacement 6
Tools ............................................................................................. 6
Spare parts ......................................................................................... 6
Estimated working time...................................................................... 6
Stand overview 7
Mounting the stand 8
Assembling the frame......................................................................... 8
Mounting the legs on a standard stand............................................... 8
Mounting the legs on a Stackit and table stand .................................. 9
Mounting the supports....................................................................... 9
Mounting the oven on a stand.......................................................... 10
Mounting a oven with fat separation on a stand............................... 13
Mounting HydroShield water filter on the stand................................ 14
Different stand models 17
Table of contents

4
GO Combi
General information
Target group
This document is aimed at service technicians who have been trained in installing and servicing the
oven. The oven must only be installed and serviced by qualified service technicians.
Technical changes
This document is subject to changes without notice.
More documentation
You find more documentation about the oven at our website.
Warranty
You find more information about warranty at our website.
Permissions
Log in as “Technician” (576021) to have the necessary rights to be able to change the oven setup,
use the test functions, update software, etc.

5
GO Combi
GO Combi mounting instruction, revision 08/2023, SW: 0.7.1
Safety information
Read this document before using, installing or servicing the product.
Installation and operation must comply with local regulations and accepted
codes of good practice.
Read the safety instructions in the user manual, installation manual and
service manual before you perform any work on the oven.
All maintenance and repair must be carried out by qualified installation and
service technicians only. Installation and/or service by others than qualified
service technicians may result in injury to the operator and/or damage to the
oven.

6
GO Combi
Before replacement
• Make sure the required tools are available.
• Unpack the spare parts and check if all parts are available
• Make sure the working area is tidied up, clean and safe to prevent personal injury and damage
to the equipment.
Tools
• Slotted screwdriver
• 8 mm socket screwdriver
• 8 mm wrench
Spare parts
The stand comes in many variations. The spare part number depends on the stand and accessories
that you have ordered.
• 107954, Basic stand 1/1GN, including standard feet, with fat separation
• 107955, Basic stand 1/1GN, including standard feet without fat separation
• 107957, Basic stand 2/1GN, including standard feet with fat separation
• 107956, Basic stand 2/1GN, including standard feet without fat separation
• 107977, Stand for table and Stackit 1/1GN including standard feet with fat separation
• 106171, Stand for table and Stackit 1/1GN including standard feet without fat separation
• 107978, Stand for table and Stackit 2/1GN including standard feet with fat separation
• 106172, Stand for table and Stackit 2/1GN including standard feet without fat separation
• 107970, Floor mount
• 107971, Castors
• 107972, Racks 1/1GN
• 107973, Exterior cabinet doors 1/1GN-EN
• 107974, Exterior cabinet doors 2/1GN
• 107975, Bracket for filter
• 107976, Racks 2/1GN
• 110176, Rack support locking system
Estimated working time
Approximately 30 minutes.

7
GO Combi
GO Combi mounting instruction, revision 08/2023, SW: 0.7.1
Stand overview
Basic stand
Stand for table and Stackit

8
GO Combi
Mounting the stand
Assembling the frame
1. Place the two parts of the frame on a flat surface with the bottom pointing
upwards.
2. Push the tow parts of the frame together
3. Fasten the two M5x10 screws on each side using a slotted screwdriver.
Mounting the legs on a standard stand
1. Place the frame on a flat surface with the bottom pointing upwards.
2. Place the leg in the corner of the frame and fasten it with four M5x10 screws.
3. Mount the other three legs in the same way.

9
GO Combi
GO Combi mounting instruction, revision 08/2023, SW: 0.7.1
Mounting the supports
1. Place the frame with the legs pointing upwards
2. Fasten the two supports (A) on the right-hand and left-hand side with the FRH
M5x12 screws using a flexible socket screwdriver.
3. Fasten the two supports (B) in the front and back in the same way as above.
Mounting the legs on a Stacking kit and table stand
1. Place the frame on a flat surface with the bottom pointing upwards.
2. Place the leg in the corner of the frame and fasten it with four M5x10 screws.
3. Mount the other three legs in the same way.

10
GO Combi
Mounting the oven on a stand
In case of a Stacking kit solution, always mount the bottom oven
on the stand before mounting the upper oven on the bottom
oven.
1. Detach the hose for the drip tray.
2. If the oven is a table model, remove the four legs from the oven.

11
GO Combi
GO Combi mounting instruction, revision 08/2023, SW: 0.7.1
3. Place the oven on the stand.
4. Fasten the oven to the stand using 4 x hex screws and 4 x washers.
The illustration below shows how to mount the oven on a standard stand. The
procedure is the same for mounting a stand on a table or Stacking model.
5. Fasten the two M5x10 screw on both the right-hand and left-hand side of the
oven.

12
GO Combi
6. Attach the hose for the drip tray.

13
GO Combi
GO Combi mounting instruction, revision 08/2023, SW: 0.7.1
Mounting an oven with fat separation on a stand
In case of a Stacking kit solution, always mount the bottom oven
on the stand before mounting the upper oven on the bottom
oven.
1. Follow step 1-3 in section “Mounting the oven on a stand”.
2. Fasten the oven to the stand using 4 x hex screws and 4 x washers as well as 2 x
M5x10 screws.
3. Follow step 5 and 6 in section “Mounting the oven on a stand”.

14
GO Combi
Mounting water filter on the stand
Not roll-in and Stacking kit.
The water filter can be mounted on the oven stands for the following oven types:
• Fri-Jado GO 6-1/1 GN
• Fri-Jado GO 10-1/1 GN
• Fri-Jado GO 6-2/1 GN
• Fri-Jado GO 10-2/1 GN
On all other oven types and sizes, the water filter must be placed on the floor next to
the oven.
1. Fasten the bracket with 5 mm screws.
2. Remove the two M5 screws.

15
GO Combi
GO Combi mounting instruction, revision 08/2023, SW: 0.7.1
3. Remove the side plate.
4. Fasten the brack beneath the oven. Use two M5 screws.

16
GO Combi
5. Slide the filter head into the bracket.
6. Mount the filter on the filter head by turning the filter counterclockwise into the
filter head.
7. Connect the hoses according to the section “Connecting the oven to a Water
filter” in the installation manual.

17
GO Combi
GO Combi mounting instruction, revision 08/2023, SW: 0.7.1
Different stand models
You can buy different accessories to the basic stand. The table below shows the different possibilities as well as which pre-drilled
holes to use when mounting the racks.
Type of rack Position of pre-drilled hole
1/1 GN
2/1 GN

18
GO Combi
Type of rack Position of pre-drilled hole
400x600 EN
US sheet

19
GO Combi
GO Combi mounting instruction, revision 08/2023, SW: 0.7.1
Updated section
Rack support locking system
Type of rack Position of pre-drilled hole
Cabinet
Castors
Floor mounting feet
Rack support locking system
Table 1
