Frico PAEC4000 NA Series User manual

PAEC4000 (NA)
Original instructions
.... 23
EN .... 28 FR
Frico AB certifies that PAEC4000W, PAEC4000E and PAEC4000A shown herein are licensed
to bear the AMCA Seal. The ratings shown are based on tests and procedures performed
in accordance with AMCA Publication 211 and AMCA Publication 311 and comply with the
requirements of the AMCA Certified Ratings Program.The AMCA Certified Ratings Seal applies
to airflow rate, average outlet velocity, outlet velocity uniformity, velocity projection and power
rating at free delivery only.

PAEC4000
2
Type Output
[kW]
Airflow*1
[m3/h]
Sound
power*2
[dB(A)]
Motor power
[W]
Voltage
motor
[V]
Amperage
motor
[A]
Weight
[kg]
PAEC4010A-NA 0 2330 80 500 208V1~ 3.02 46
PAEC4015A-NA 0 3270 81 673 208V1~ 4.52 59
PAEC4020A-NA 0 4650 82 1000 208V1~ 6.04 79
Type Output
steps
[kW]
Airflow*1
[m3/h]
Sound
power*2
[dB(A)]
FLA (full load
amperage)*3
[A]
Motor
power
[W]
Amperage
motor
[A]
Voltage [V]
Amperage [A]
(heat)
Weight
[kg]
PAEC4010E-208-NA 4/10 2330 80 31 500 3.02 208V3~/27 53
PAEC4015E-208-NA 5/15 3270 81 45 673 4.52 208V3~/40 74
PAEC4020E-208-NA 7/20 4650 82 60 1000 6.04 208V3~/54 98
PAEC4010E-480-NA 4/12 2330 80 18 500 3.02 480V3~/15 59
PAEC4015E-480-NA 6/18 3270 81 27 673 4.52 480V3~/22 79
PAEC4020E-480-NA 8/24 4650 82 35 1000 6.04 480V3~/29 105
PAEC4010E-600-NA 4/12 2330 80 15 500 3.02 600V3~/12 59
PAEC4015E-600-NA 6/18 3270 81 23 673 4.52 600V3~/18 79
PAEC4020E-600-NA 8/24 4650 82 30 1000 6.04 600V3~/24 105
Type Output*4
[kW]
Airflow*1
[m3/h]
Sound
power*2
[dB(A)]
Motor
power
[W]
Voltage
motor
[V]
Amperage
motor
[A]
Water
volume
[l]
Weight
[kg]
PAEC4010W-NA 14 2130 79 501 208V1~ 3.04 1.9 53
PAEC4015W-NA 21 3100 79 666 208V1~ 3.97 3.0 70
PAEC4020W-NA 30 4250 81 10 02 208V1~ 6.08 4.1 94
3Electrical heat - PAEC4000E (IP20)
2Water heat - PAEC4000W (IP21)
1Ambient, no heat - PAEC4000A (IP21)
*1) Highest airflow of totally 3 fan steps.
*2) Values shown are for total sound power levels for InstallationType A: free inlet, free outlet.The Sound
power level ratings shown are in decibels, referred to 10-12 watts, calculated per AMCA Standard 301.
*3) FLA: total amperage for motor and heat.
*4) Applicable at water temperature 80/60 °C, air temperature, in +18 °C.
Above table is valid for 208V/1ph/60Hz. Also approved for 230V/1ph/60Hz. Product performance for
230V/1ph/60Hz will differ from stated data.
Protection class for units with electrical heating: IP20.
Protection class for units without heating and units with water heating: IP21.
CE compliant.
Metric chart
Type Nozzle
deep x width
[mm]
Max Velocity
at nozzle
[m/s]
Outlet Velocity
[m/s]
Outlet Velocity
Uniformity
[%]
PAEC4010A/E-208/E-480/E-600 960x70 15,92 13,9 89
PAEC4015A/E-208/E-480/E-600 1470x70 15,51 13,54 87
PAEC4020A/E-208/E-480/E-600 1960x70 15,92 13,9 89
PAEC4010W-NA 960x70 12,86 11,5 85
PAEC4015W-NA 1470x70 15,21 12,71 87
PAEC4020W-NA 1960x70 12,86 11,5 85
Frico AB certifies that PAEC4000W, PAEC4000E and PAEC4000A shown herein are licensed
to bear the AMCA Seal. The ratings shown are based on tests and procedures performed
in accordance with AMCA Publication 211 and AMCA Publication 311 and comply with the
requirements of the AMCA Certified Ratings Program.The AMCA Certified Ratings Seal applies
to airflow rate, average outlet velocity, outlet velocity uniformity, velocity projection and power
rating at free delivery only.

PAEC4000
3
Type Output
[MBH]
Airflow*1
[cfm]
Sound
power*2
[dB(A)]
Motor power
[W]
Voltage
motor
[V]
Amperage
motor
[A]
Weight
[lb]
PAEC4010A-NA 01400 80 500 208V1~ 3.02 101
PAEC4015A-NA 0 1950 81 673 208V1~ 4.52 130
PAEC4020A-NA 0 2800 82 1000 208V1~ 6.04 174
Type Output
steps
[MBH]
Airflow*1
[cfm]
Sound
power*2
[dB(A)]
FLA (full load
amperage)*3
[A]
Motor
power
[W]
Amperage
motor
[A]
Voltage [V]
Amperage [A]
(heat)
Weight
[lb]
PAEC4010E-208-NA 14/34 1400 80 31 500 3.02 208V3~/27 117
PAEC4015E-208-NA 17/51 1950 81 45 673 4.52 208V3~/40 163
PAEC4020E-208-NA 24/68 2800 82 60 1000 6.04 208V3~/54 216
PAEC4010E-480-NA 14/41 1400 80 18 500 3.02 480V3~/15 130
PAEC4015E-480-NA 20/61 1950 81 27 673 4.52 480V3~/22 174
PAEC4020E-480-NA 27/82 2800 82 35 1000 6.04 480V3~/29 231
PAEC4010E-600-NA 14/41 1400 80 15 500 3.02 600V3~/12 130
PAEC4015E-600-NA 20/61 1950 81 23 673 4.52 600V3~/18 174
PAEC4020E-600-NA 27/82 2800 82 30 1000 6.04 600V3~/24 231
Type Output*4
[MBH]
Airflow*1
[cfm]
Sound
power*2
[dB(A)]
Motor
power
[W]
Voltage
motor
[V]
Amperage
motor
[A]
Water
volume
[US gal]
Weight
[lb]
PAEC4010W-NA 48 1300 79 501 208V1~ 3.04 0.49 117
PAEC4015W-NA 72 1900 79 666 208V1~ 3.97 0.78 154
PAEC4020W-NA 102 2600 81 1002 208V1~ 6.08 1.09 207
*1) Highest airflow of totally 3 fan steps.
*2) Values shown are for total sound power levels for InstallationType A: free inlet, free outlet.The Sound
power level ratings shown are in decibels, referred to 10-12 watts, calculated per AMCA Standard 301.
*3) FLA: total amperage for motor and heat.
*4) Applicable at water temperature 176/140F, air temperature, in +64F.
Above table is valid for 208V/1ph/60Hz. Also approved for 230V/1ph/60Hz. Product performance for
230V/1ph/60Hz will differ from stated data.
Protection class for units with electrical heating: IP20.
Protection class for units without heating and units with water heating: IP21.
CE compliant.
3Electrical heat - PAEC4000E (IP20)
2Water heat - PAEC4000W (IP21)
1Ambient, no heat - PAEC4000A (IP21)
Imperial chart
Type Nozzle
deep x width
[in]
Max Velocity
at nozzle
[fpm]
Outlet Velocity
[fpm]
Outlet Velocity
Uniformity
[%]
PAEC4010A/E-208/E-480/E-600 37.8x2.8 3133 2736 89
PAEC4015A/E-208/E-480/E-600 57.9x2.8 3053 2665 87
PAEC4020A/E-208/E-480/E-600 77.2x2.8 3133 2736 89
PAEC4010W-NA 37.8x2.8 2531 2263 85
PAEC4015W-NA 57.9x2.8 2994 2501 87
PAEC4020W-NA 77.2x2.8 2531 2263 85
Frico AB certifies that PAEC4000W, PAEC4000E and PAEC4000A shown herein are licensed
to bear the AMCA Seal. The ratings shown are based on tests and procedures performed
in accordance with AMCA Publication 211 and AMCA Publication 311 and comply with the
requirements of the AMCA Certified Ratings Program.The AMCA Certified Ratings Seal applies
to airflow rate, average outlet velocity, outlet velocity uniformity, velocity projection and power
rating at free delivery only.

PAEC4000
4
Output charts water PAEC4000
*1) Recommended outlet air temperature for good comfort and optimized output.
*2) Nominal output at given supply and return water temperature.
Supply water temperature:80 °C
Room temperature: +18 °C
Outlet air temperature: +35 °C*1
Water temperature: 80/60 °C
Room temperature: +18 °C
Type Fan
position
Airflow
[m3/h]
Output
[kW]
Return
water temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
Output*2
[kW]
Outlet
air temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
PAEC4010W-NA max 2130 14.9 31 0.07 2.7 28.4 50 0.35 40.5
PAEC4015W-NA max 3100 19.3 29 0.09 1.6 40.2 53 0.49 30.6
PAEC4020W-NA max 4250 28.3 30 0.14 1.6 56.6 53 0.69 26.9
Supply water temperature: 60 °C
Room temperature: +18 °C
Outlet air temperature: +35 °C*1
Water temperature: 60/40 °C
Room temperature: +18 °C
Type Fan
position
Airflow
[m3/h]
Output
[kW]
Return
water temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
Output*2
[kW]
Outlet
air temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
PAEC4010W-NA max 2130 15.4 37 0.17 11. 5 16.5 37 0.20 16.2
PAEC4015W-NA max 3100 20.1 35 0.19 6.2 23.4 38 0.28 12.2
PAEC4020W-NA max 4250 28.3 35 0.27 5.5 32.9 38 0.40 10.7
Metric chart
Imperial chart
*1) Recommended outlet air temperature for good comfort and optimized output.
*2) Nominal output at given supply and return water temperature.
Supply water temperature:176 °F
Room temperature: +64 °F
Outlet air temperature: +95 °F*1
Water temperature: 176/140 °F
Room temperature: +64 °F
Type Fan
position
Airflow
[cfm]
Output
[MBH]
Return
water temp.
[°F]
Water
flow
[US gal/h]
Pressure
drop
[kPa]
Output*2
[MBH]
Outlet
air temp.
[°F]
Water
flow
[US gal/h]
Pressure
drop
[kPa]
PAEC4010W-NA max 1300 50.9 88 69.4 2.7 96.9 122 330.0 40.5
PAEC4015W-NA max 1900 65.9 84 86.6 1.6 137.2 127 466.1 30.6
PAEC4020W-NA max 2600 96.6 86 130.3 1.6 193.2 127 657.2 26.9
Supply water temperature: 140 °F
Room temperature: +64 °F
Outlet air temperature: +95 °F*1
Water temperature: 140/104 °F
Room temperature: +64 °F
Type Fan
position
Airflow
[cfm]
Output
[MBH]
Return
water temp.
[°F]
Water
flow
[US gal/h]
Pressure
drop
[kPa]
Output*2
[MBH]
Outlet
air temp.
[°F]
Water
flow
[US gal/h]
Pressure
drop
[kPa]
PAEC4010W-NA max 1300 52.6 99 156.9 11. 5 56.3 99 190.2 16.2
PAEC4015W-NA max 1900 68.6 95 183.6 6.2 79.9 100 269.2 12.2
PAEC4020W-NA max 2600 96.6 95 257.8 5.5 112.3 100 379.5 10.7

PAEC4000
5
The introduction pages consist mainly of pictures. For translation of the
English texts used, see the respective language pages.
EN
Les pages de présentation contiennent principalement des images. Pour la
traduction des textes en anglais, consultez la page correspondante à la langue
souhaitée.
FR

PAEC4000
6
PAEC4000
Ref Metric
[mm]
Imperial
[in]
Product type
A 1039 41.56 PAEC4010x
B 1549 61.96 PAEC4015x
C 2039 81.56 PAEC4020x
D 2549 101.96 PAEC4025x
E 40 1.60 PAEC4010/15/20x
F 39 1.56 PAEC4025x
G127 5.08
H 404 16.16
I102 4.08
J 235 9.40
K 43 1.72
L 40 1.60
M 36 1.44
N 295 11.80
O6 11 24.44
P 295 11.80
Q 36 1.44
R 1572 62.88 PAEC4015x
S 2062 82.48 PAEC4020x
T 2572 102.88 PAEC4025x
U1515 60.60 PAEC4015x
V 2004 80.16 PAEC4020x
W 2515 100.60 PAEC4025x
X 23 0.92
Y 40 1.60
Z6 11 24.44
611
L
295 36
40
127
A
43 235 102
404
1, 1,5 m:4 M8
2 m: 6 M8
2,5 m: 8 M8
DN20 (3/4"), outside thread
SIRe
PAEC 2; 2.5 m / 6.6; 8.2 ft
295 36 611
40
23
L2
L1
A / B / C / D
R / S / T
U / V / W
E / F G
O
Z
L
P Q
X
Y
H
MN
J IK
Metric
1 m: 4 x M8
1.5 m: 4 x M8
2 m: 6 x M8
2.5 m: 6-8 x M8
Imperial
3.3 ft: 4 x M8
4.9 ft: 4 x M8
6.6 ft: 6 x M8
8.2 ft: 6-8 x M8

PAEC4000
7
2
1
Fig. 1A: Open the unit by raising the front panel.
The front is blocked in open position with the
front hatch hook.
Fig. 2: Control card SIRe is integrated in the air
curtain at delivery.
SIRe
Fig. 1B: When the front has been removed it it
important to be sure it is firmly seated in the front
locks again.
min 100
Fig. 3: Minimum distance.
BA
Filling the water coil
Fig. 4
A B
C D

PAEC4000
8
AB
A
127L
B
127875875
AB
127770745745
Fig. 5: M8-holes for mounting.
PAEC4010x/PAEC4015x
PAEC4020x
PAEC4025x
Ref Metric
[mm]
Imperial
[in]
Product type
A127 5.08 PAEC4010/15/20/25x
B102 4.08 PAEC4010/15/20/25x
C 235 9.40 PAEC4010/15/20/25x
D 750 30.00 PAEC4010x
E 1260 50.40 PAEC4015x
F 875 35.00 PAEC4020x
G745 29.80 PAEC4025x
H 770 30.80 PAEC4025x
A
F
G GH
FA
A
C
C
C
D / E

PAEC4000
9
Fig. 6: See separate manual for PA34WB/PAWBL.
PAEC4000 + PA34WB/PAWBL
20 mm
A
B
C
D
E
F
PA34WB/ PAWBL
20 mm / 0,80"
79
19
120
11
40
40 40
Type Product type Quantity
included
Length
Metric
[mm]
Length
Imperial
[in]
Fig.
PA34WB15 PAEC4015x 2 pcs 400 15.75 Fig. 6
PA34WB20 PAEC4020x 3 pcs 400 15.75 Fig. 6
PA34WB30 PAEC4025x 4 pcs 400 15.75 Fig. 6
PAWBL15 PAEC4015x 2 pcs 560 22.05 Fig. 6
PAWBL20 PAEC4020x 3 pcs 560 22.05 Fig. 6
PAWBL30 PAEC4025x 4 pcs 560 22.05 Fig. 6
PA34WB
Ref Metric
[mm]
Imperial
[in]
A11 0.43
B19 0.75
C 80 3.15
D 40 1.58
E 40 1.58
F120 4.72
PAWBL
Ref Metric
[mm]
Imperial
[in]
A11 0.43
B19 0.75
C120 4.72
D 60 2.36
E 52.5 2.07
F165 6.50
A
C
B
D
E
D
F

PAEC4000
10
Fig. 7: PA34TR + PA34CB + PA34VD.
See separate manual for PA34TR.
Fig.8: PA34WS + PA34CB
See separate manual for PA34WS.
Fig. 9: See separate manual for PA4JK.
PA4JK
PA34WS
(PA34CB)
PA34TR
(PA34VD)
PA34CB
Type Product type Quantity
included
Length
Metric
Length
Imperial
PA34CB15 PAEC4010/15x 4 pcs
PA34CB20 PAEC4020x 6 pcs
PA34CB30 PAEC4025x 8 pcs
PA34WS15 PAEC4010/15x 4 pcs 3 m 9.8 ft
PA34WS20 PAEC4020x 6 pcs 3 m 9.8 ft
PA34WS30 PAEC4025x 8 pcs 3 m 9.8 ft
PA34TR15 PAEC4010/15x 4 pcs 1 m 3.3 ft
PA34TR20 PAEC4020x 6 pcs 1 m 3.3 ft
PA34TR30 PAEC4025x 8 pcs 1 m 3.3 ft
PA34VD15 PAEC4010/15x 4 pcs
PA34VD20 PAEC4020x 6 pcs
PA34VD30 PAEC4025x 8 pcs
Type Product type
PA4JK PAEC4000
Accessories

PAEC4000
11
Fig. 10: See separate manual for
PA4XT.
Accessories
See separate manual for PA4DW.
Type Product type Dimensions
Metric
[mm]
Dimensions
Imperial
[in]
PA4DW10 PAEC4010x 87x424x1006 3.48x16.96x40.24
PA4DW15 PAEC4015x 87x424x1516 3.48x16.96x60.64
PA4DW20 PAEC4020x 87x424x2006 3.48x16.96x80.24
PA4DW25 PAEC4025x 87x424x2516 3.48x16.96x100.64
Type Product type Length
Metric
[mm]
Length
Imperial
[in]
PA4XT10 PAEC4010x 130-200 5.20-8.00
PA4XT15 PAEC4015x 130-200 5.20-8.00
PA4XT20 PAEC4020x 130-200 5.20-8.00
PA4XT25 PAEC4025x 130-200 5.20-8.00
PAEC4010x: 2 pcs
PAEC4015x: 2 pcs
PAEC4020x: 3 pcs
PAEC4025x: 4 pcs
See separate manual for PA4DC.
Type Product type Length
Metric
[mm]
Length
Imperial
[in]
PA4DCS PAEC4000 200-300 8.00-12.00
PA4DCM PAEC4000 300-500 12.00-20.00
PA4DCL PAEC4000 500-900 20.00-36.00
PA4DXT PAEC4000 420 16.80
PA4DW
PA4DC

PAEC4000
12
Accessories
Note!The air curtain
must be secured in
the wall or ceiling.
Fig. 11: See separate manual for PA4JK.
PA4VDW
PA4JK

PAEC4000
13
AXP300PA4VDWPA4JK
Type Product type
PA4JK PAEC4000
PA4VDW15 PAEC4015x
PA4VDW20 PAEC4020x
PA4VDW25 PAEC4025x
PA4HE PAEC4000
PA4HEVDW PAEC4000
AXP300 PAEC4000
Accessories
Type Product type Length
Metric
Length
Imperial
PA34EF10 PAEC4010W-NA
PA34EF15 PAEC4025W-NA
PA34EF20 PAEC4020W-NA
PA34EF25 PAEC4025W-NA
DTV200S PAEC4000W-NA
FHDN20 PAEC4000W-NA 350 mm 13.8 in
FHDN2010 PAEC4000W-NA 1 m 3.3 ft
See separate manual for
FHDN20.
See separate manual for
PA34EF.
DTV200S
PA4HE(VDW)

PAEC4000
14
Type Dimensions
Metric
Length
Metric
Dimensions
Imperial
Length
Imperial
SIReBN
SIReACY
SIReAAY
SIReRTX 70x33x23 mm 2.80x1.32x0.92 in
SIReUR 114x70x50 mm 4.56x2.80x2.00 in
SIReWTA
SIReCJ4
SIReCJ6
SIReCC603 3 m 9.8 ft
SIReCC605 5 m 16.4 ft
SIReCC610 10 m 32.8 ft
SIReCC615 15 m 49.2 ft
SIReCC640 40 m 131.2 ft
SIReCC403 3 m 9.8 ft
SIReCC405 5 m 16.4 ft
SIReCC410 10 m 32.8 ft
SIReCC415 15 m 49.2 ft
Accessories
C
C
SIReBN SIReACY
SIReAAY
SIReRTX SIReUR SIReWTA SIReCCSIReCJ4/SIReCJ6
VLSP15NF-NA DN15 (1/2”)
VLSP20NF-NA DN20 (3/4”)
VLP15-NA DN15 (1/2”)
VLP20-NA DN20 (3/4”)
VKF
SDM24 ST23024
SD230 BPV10
VKF
VLSP-NA VLP-NA
Nipple
G-NPT
Nipple
G-NPT

PAEC4000
15
PAEC4000A/W
H1 H2N
Id
SIRe B1EC
RoomC2 C1 Actuator 230V Supply 230V
PE L
N
Heating
L
N
~
L
Trafo
Motor
protection 0-10V
GND
PWM
LN
Motor
Internal
sensor
MMMM
4010WA
4025WA/4020WA/4015WA
208V1~

PAEC4000
16
PAEC4010/15E-208V-NA
H1 H2N
Id
SIRe B1EC
RoomC2 C1 Actuator 230V Supply 230V
PE L
N
Heating
L
N
~ L
Trafo
K2
K1
4010E
4015E 4010E/4015E
TS1
TS2
Motor
protection 0-10V
GND
PWM
LN
Motor
Internal
sensor
MMMM
208V3~
L1L2 L3
L1 K2
L2 K2
L3 K2
L1 K1
L2 K1
L3 K1
161121
PAEC/AREC4010E/4015E

PAEC4000
17
PAEC4020/25E-208V-NA
H1 H2N
Id
SIRe B1EC
RoomC2 C1 Actuator 230V Supply 230V
PE L
N
Heating
L
N
~
L
Trafo
K2
K1
K2
K1
4020E/4025E
!
2 X 208V3~
TS2
TS1
Motor
protection 0-10V
GND
PWM
LN
Motor
Internal
sensor
MMMM
PAEC/AREC 4020E/4025E
161123
208V3~
L1L2 L3
4025E/4020E 4020: 6 motors 4025: 7 motors
L1 K2
L2 K2
L3 K2
L1 K1
L2 K1
L3 K1
TS4 TS3
L1 K2
L2 K2
L3 K2
L1 K1
L2 K1
L3 K1

PAEC4000
18
PAEC4010/15E-480V/600V-NA
H1 H2N
Id
SIRe B1EC
RoomC2 C1 Actuator 230V Supply 230V
PE L
N
Heating
L
N
~ L
Trafo
K2
K1
4010E
4015E 4010E/4015E
TS1
TS2
Motor
protection 0-10V
GND
PWM
LN
Motor
Internal
sensor
MMMM
600/480V - 230V Transformer
2 x 10A FUSE
L1L2 L3
PAEC/AREC 4010E/4015E
215222
600V3~/480V3~

PAEC4000
19
PAEC4020/25E-480V/600V-NA
H1 H2N
Id
SIRe B1EC
RoomC2 C1 Actuator 230V Supply 230V
PE L
N
Heating
L
N
~
L
Trafo
K2
K1
K2
K1
4025E/4020E
4020E/4025E
!
2 X 600V3~/480V3~
TS2
TS1
TS3 TS4
Motor
protection 0-10V
GND
PWM
LN
Motor
Internal
sensor
MMMM
600V3~/480V3~
PAEC/AREC 4020E/4025E
215223
600/480V - 230V Transformer
FUSE 2 x 10A
L1L2 L3
L1L2 L3 L1L2 L3
4020: 6 motors 4025: 7 motors

C2
X5
C1
X4
ROOM
X3
Pot.
Unit ID ACTUATORSUPPLY
N L NL
PE
L
~
230V~
C2
X5
C1
X4
ROOM
X3
Pot.
Unit ID ACTUATORSUPPLY
N L NL
PE
L
~
230V~
C2
X5
C1
X4
ROOM
X3
Pot.
Unit ID ACTUATORSUPPLY
N L NL
PE
L
~
230V~
SIReCC6XX (max 50 m)
SIReCC6XX
(max 50 m)
SIReCC6XX
(max 50 m)
C
SIReUB1
SIReRTX
(optional)
L=2m
SIReB1/B2/B1EC
SIReB1/B2/B1EC
SIReB1/B2/B1EC
L = 2 m / 6' 7"
(max 50 m / 164')
(max 50 m / 164')
(max 50 m / 164')
PAEC4000
20
SIReB Basic
PAEC4000A/E
Wiring diagrams for SIReAC Competent, see manual for SIRe.
