Frico Tatra User manual

Tatra
.... 14
EN ....18 SE
Original instructions
.... 22
NO .... 26 FR .... 31 DE
.... 36
NL .... 41 ES ....46 IT .... 51 PL .... 56 RU
.... 61
FI DK .... 66

Tatra
2
Introduktionssidorna består huvudsakligen av bilder. För översättning av de
engelska texter som används, se respektive språksidor.
SE
The introduction pages consist mainly of pictures. For translation of the English
texts used, see the respective language pages.
EN
Introduksjonssidene består hovedsakelig av bilder. For oversettelse av de
engelske tekstene, se de respektive språksidene
NO
Les pages de présentation contiennent principalement des images. Consulter la
page correspondant à la langue souhaitée.
FR
Die Einleitungsseiten bestehen hauptsächlich aus Bildern. Für die Übersetzung
der verwendeten Texte in englischer Sprache, siehe die entsprechenden
Sprachseiten.
DE
De inleidende pagina's bevatten hoofdzakelijk afbeeldingen. Voor een vertaling
van de gebruikte Engelse teksten, zie de pagina's van de resp. taal.
NL
Las páginas introductorias contienen básicamente imágenes. Consulte la
traducción de los textos en inglés que las acompañan en las páginas del idioma
correspondiente.
ES
Le pagine introduttive contengono prevalentemente immagini. Per le
traduzioni dei testi scritti in inglese, vedere le pagine nelle diverse lingue.
IT
Początkowe strony zawierają głównie rysunki. Tłumaczenie wykorzystanych
tekstów angielskich znajduje się na odpowiednich stronach językowych.
PL
RU Страницы в начале Инструкции состоят в основном из рисунков, схем и
таблиц. Перевод встречающегося там текста приведен в разделе RU.
Esittelysivut koostuvat lähinnä kuvista. Suvuilla olevien enlanninkielisten
sanojen käännökset löytyvät ko. kielisivuilta.
FI
Introduktionssiderne består hovedsageligt af billeder. For oversættelse af de
engelske tekster, se siderne for de respektive sprog.
DK

Tatra
3
Tatra
L
[mm]
TA6017 1650
TA6022 2200
TA6028 2750
L
[mm]
TA6017+TA6FF 1710
TA6022+TA6FF 2260
TA6028+TA6FF 2810
Vertical mounting
Horizontal mounting
60
625
L
551
507
G1” - DN25
G1” - DN25
59
507
230
61 61
230
551
625
181
L
TA6FF - Floor frame
2DN25 (1"),
outside thread
2DN25 (1"), outside thread
FC
FC

Ø 11
140
Ø 7
10
12
34
40
280
Ø 11
140
Ø 7
10
12
34
40
280
Tatra
4
Horizontal mounting
300
Minimum distance.
Item
number
Type Consists of
397713 TA6AB 4 x appliance brackets
382973 TA6ABE 2 x appliance brackets
TA6AB - Appliance brackets
L
Distance appliance brackets
x4
L
[mm]
TA6017 1600
TA6022 2150
TA6028 2700
2 x Tatra

1004
115
805
660
580
400
320
230
60
Tatra
5
TA6WK - Wall kit
1004
617
807
1004
115
805
660
580
400
320
230
60
Item
number
Type Consists of
397712 TA6WK 2 x wall brackets + 4 x appliance brackets + 4 x threaded rods (M10, 1000 mm) + nuts
382975 TA6WKE 1 x wall bracket + 2 x appliance brackets + 2 x threaded rods (M10, 1000 mm) + nuts
x4 x4
x2
1004
617
807
Horizontal mounting

Tatra
6
TA6CK - Ceiling kit
Item
number
Type Consists of
382976 TA6CK 2 x ceiling brackets + 4 x appliance brackets + 4 x threaded rods (M10, 1000 mm) + nuts
382977 TA6CKE 1 x ceiling bracket + 2 x appliance brackets + 2 x threaded rods (M10, 1000 mm) + nuts
x4 x4
x2
Horizontal mounting
55
1100
55
1100
109
1100
1026
870
636
500
266
105
131
61
55
211
109

Tatra
7
Vertical mounting
300
Minimum distance
Note! The air
curtain must be
secured in the wall
or ceiling.
TA6FF - Floor frame
TA6TB - Top bracket
Joining brackets x2
(included in delivery)
Max 6,6 m
Mounting on top of each other

Tatra
8
547
480 Ø 11 x 6
305
235
441 416 380
20
60
TA6FF - Floor frame
TA6TB - Top bracket
max 425
min 112
287 190 145
80
35
23,5
max 425
min 112
287 190 145
80
35
23,5
Item
number
Type
280021 TA6FF
382758 TA6TB
547
480 Ø 11 x 6
305
235
441 416 380
20
60
Vertical mounting

Tatra
9
Open the unit.
1004
617
807
Water connection 2
NOTE! Use a pipe wrench or a similar
tool to grip the air curtain connections
to prevent straining of the pipes.
Item
number
Type Consist of Dimension
264883 TA6EF 1 pcs Ø480 x 100 mm
330955 FH1025 2 pcs DN25, 1000 mm TA6EF
Accessories 2
FH1025
SDM
VPFC
Valve systems
Item
number
Type DN Flow range
[l/s]
238293
VPFC15LF DN15 0,012-0,068
238294
VPFC15NF DN15 0,024-0,13
238295
VPFC20 DN20 0,058-0,32
238296
VPFC25 DN25 0,10-0,60
238297
VPFC32 DN32 0,22-1,03
See separate manual.
TACAV

Tatra
10
Item
number
Type Name Dimensions
74684
FCDA
FC Direct 89x89x26 mm (FCCF)
74685
FCSA
FC Smart 89x89x26 mm (FCCF)
74686
FCPA
FC Pro 89x89x26 mm (FCCF)
74687
FCBA
FC Building 89x89x26 mm (FCCF)
Control systems
FCBC05/10/25
FCSC10/25
FCDCFCWTA
FCTXRF
FCBC05FCDCFCCF
Item
number
Type Dimensions
74694
FCRTX
39x39x23 mm
74695
FCOTX
39x39x23 mm
74699
FCLAP
89x89x26 mm
74702
FCWTA for water heated units
17495
FCDC
74718
FCBC05 5 m
74719
FCBC10 10 m
74720
FCBC25 25 m
74721
FCSC10 10 m
74722
FCSC25 25 m
74703
FCTXRF for FC Smart, FC Pro
89x89x26 mm
Accessories
FCDA - FC Direct FCSA - FC Smart
FCPA - FC Pro FCBA - FC Building
FCLAP
See separate manual for FC.
FCBC10FCDCFCCF FCLAP
FCBC10FCDCFCCF FCLAP FCTXRF FCBC10FCDCFCCF FCBAP
FCSC10
FCRTX
FCSC10
FCOTX
FCSC10
The air curtain must be supplemented with a control system.

*1) Low/high airow (2/10V).
*2) Sound power (LWA) measurements according to ISO 27327-2: 2014, Installation type E.
*3) Sound pressure (LpA). Conditions: Distance to the unit 5 metres. Directional factor: 2. Equivalent
absorption area: 200 m². At low/high airow (2/10V).
*4) ∆t = temperature rise of passing air at maximum heat output and high airow.
*5) Applicable at water temperature 60/40 °C, air temperature, in +18 °C.
*6) Applicable at water temperature 80/60 °C, air temperature, in +18 °C.
Tatra
11
Technical specications Tatra
1Ambient, no heat - TA6000 A (IP44)
Item
number
Type Output
[kW]
Airow*1
[m3/h]
Sound
power*2
[dB(A)]
Sound
pressure*3
[dB(A)]
Motor
[W]
Amperage
motor
[A]
Weight
[kg]
247348 TA6017A 0 3400/9900 87 4471 920 4,0 55
247349 TA6022A 0 5100/13400 87 45/71 1230 5,5 71
247350 TA6028A 0 6100/17500 93 53/77 1540 6,7 88
2Water heat - TA6000 W (IP44)
Item
number
Type Output*5
[kW]
Output*6
[kW]
Airow*1
[m3/h]
∆t*4,5
[°C]
∆t*4,6
[°C]
Water
volume
[l]
Sound
power*2
[dB(A)]
Sound
pressure*3
[dB(A)]
Motor
[W]
Amp.
motor
[A]
Weight
[kg]
247351 TA6017W 31 55 3400/9300 10 17 3,4 84 43/68 920 4,0 64
247352 TA6022W 41 75 4700/13300 9 17 4,5 86 45/70 1230 5,6 83
247353 TA6028W 54 97 6100/17000 9 17 5,5 86 45/70 1540 6,9 103
Voltage motor: 220-240V~

FCBASE REA
230V IN
LPE
N
Trafo
N
Motor
L
Motor
GND 0-10V PWM Alarm
Sensor
I1 I2 O1O2
PE
A1 A2
GND GND
B1 B2 D1 D2
ON
OFF
Termination
+12V
HI LO
GND +12V
HI LO
BUS 1 BUS 2
GND
0-10V
L
N
PE
GND
0-10V
L
N
PE
GND
0-10V
PE
GND
L
N
TA6000 A
M M MM M
230V~
Tatra
12
TA6000 A
Wiring diagrams for control system in the FC manual.
TA6017: 3 motors
TA6022: 4 motors
TA6028: 5 motors

FCBASEPCB RW
230V IN
LPE
N
Trafo
N
Motor
L
Motor
GND 0-10V PWM Alarm
Sensor
I1 I2 O1O2
Inlet sensor
PE
Outlet sensor
A1 A2
GND GND
B1 B2 D1 D2
ON
OFF
Termination
+12V
HI LO
GND +12V
HI LO
BUS 1 BUS 2
GND
Actuator
24VWTA
E1 E2 - +
0-10V
L
N
PE
GND
230V~
0-10V
L
N
PE
GND
0-10V
PE
GND
L
N
TA6000 W
M M MM M
FCBASE REA
230V IN
LPE
N
Trafo
N
Motor
L
Motor
GND 0-10V PWM Alarm
Sensor
I1 I2 O1O2
PE
A1 A2
GND GND
B1 B2 D1 D2
ON
OFF
Termination
+12V
HI LO
GND +12V
HI LO
BUS 1 BUS 2
GND
0-10V
L
N
PE
GND
0-10V
L
N
PE
GND
0-10V
PE
GND
L
N
TA6000 A
M M MM M
230V~
Tatra
13
TA6000 W
Wiring diagrams for control system in the FC manual.
TA6017: 3 motors
TA6022: 4 motors
TA6028: 5 motors

Tatra
14
EN
Installation and operating instructions
General Instructions
Read these instructions carefully prior to
installation and use. Keep this manual for
future reference.
The product may only be used as set out in
the assembly and operating instructions. The
guarantee is only valid should the product be used
in the manner intended and in accordance with
the instructions.
Application
Tatra is a robust air curtain intended for vertical
or horizontal installation in large doorways
such as logistic centres, loading bays and
warehouses. Its recommended installation
height is 6 m. The air curtain is available
without heat and with water heating.
Protection class: IP44.
Operation
Air is drawn in at the top/rear of the unit and
blown downwards/outwards shielding the
door opening and minimizing heat loss. To
achieve the optimum air curtain effect the unit
must extend the full height/width of the door
opening.
The grille for directing the outlet air is
adjustable and is normally angled outwards to
achieve the best protection against incoming
air.
The eciency of the air curtain depends on
the air temperature, the pressure differencial
across the doorway and any wind load.
NOTE! Negative pressure in the building
considerably reduces the eciency of the air
curtain. The ventilation should therefore be
balanced.
Mounting
The Tatra unit is delivered secured by brackets
in a wooden crate. Due to its heavy weight,
the handling of the air curtain must be made
with a forklift or other lifting equipment. The
unit must be lifted in its wooden crate or by
the holes in the motor section. NOTE: The unit
can not be lifted by its mid section as the outlet
grille might be damaged. The delivery brackets
must be removed before use.
The Tatra units are symmetrical and can be
mounted horizontally or vertically. The product
must be mounted in such a way to allow future
service and maintenance. The FC terminal box
is placed on the unit's long side and must be
fully accessible after installation.
Horizontal mounting
The air curtain is installed horizontally with the
outlet air grille facing downwards as close to
the door as possible. Tatra can be mounted on
the wall or on the ceiling.
Mounting with wall brackets
A complete kit for wall mounting is available
containing wall brackets, appliance brackets
and threaded rods (TA6WK).
1. Mount the wall brackets on the wall.
Fasteners are not included.
2. Mount the appliance brackets on the unit
with supplied screws.
3. Use the threaded rods to hang the unit on
the wall brackets. Secure with supplied nuts.
Horizontal mounting on the ceiling
For ceiling mounting, a complete kit is available
containing a ceiling bracket, appliance brackets
and threaded rods (TA6CK).
1. Mount the ceiling bracket on the ceiling.
Fasteners are not included.
2. Mount the appliance brackets on the unit
with supplied screws.
3. Use the threaded rods to hang the unit on
the ceiling bracket. Secure with supplied nuts.
If another mounting solution is preferred,
the appliance brackets are also available
as a separate accessory (TA6AB). For the
protection of wider doorways, several units can
be mounted in series alongside each other.
Additional mounting kits must then be used.
See pictures in introduction pages.
Vertical mounting
The air curtain is mounted vertically as close
as possible to the door. For the best effect air
curtains should be placed on both sides of the
opening.
The air curtain must be mounted on the
oor frame TA6FF, available as accessory. The
frame is attached horizontally to the oor using
fasteners appropriate for the surface. The unit
can be turned and positioned on either side of
the door.
Several units can be mounted directly on
top of each other, they are fastened together
with the joining brackets supplied with the air
curtain. Maximum total height is 6,6 m. Note!
The air curtain must be secured in the wall
or ceiling. A top bracket for this purpose is
available as accessory.
See pictures in introduction pages.

Tatra
15
EN
outwards to withstand the load. Generally
speaking, the higher the load, the greater the
angle required.
Basic setting fan speed
The fan speed when the door is open is
set using the control. Note that the airow
direction and the fan speed may need ne
adjustment depending on the loading of the
door.
Filter (W)
The unit is not equipped with an internal lter.
The water coil can be cleaned by loosening
the motor section (see Opening the unit). An
external lter is available as accessory which
provides an easier maintenance, since the unit
does not need to be opened. The external lter
is easily fastened with the four supplied velcro
stickers. If the lter is clogged or damaged, it
may need to be changed.
Opening the unit / Service, repairs and
maintenance
For all service, repair and maintenance rst
carry out the following:
1. Disconnect the power supply.
2. Loosen the motor section on the unit's top
(horizontal), back (vertical) by removing its
screws.
3. Fold the section towards the cable side.
NOTE: Be careful to prevent the section from
falling.
4. After service, repairs and maintenance, put
the section back in reverse order.
Maintenance
Since fan motors and other components are
maintenance-free, no maintenance other than
cleaning is necessary. The level of cleaning can
vary depending on local conditions. Undertake
cleaning at least twice a year. Inlet and exhaust
grilles, impeller and elements can be vacuum
cleaned or wiped using a damp cloth. Use a
brush when vacuuming to prevent damaging
sensitive parts. Avoid the use of strong alkaline
or acidic cleaning agents.
Temperature control
Temperature control of FC maintains the
exhaust temperature. Should the temperature
exceed the preset value, the overheating alarm
will activate. For more information see the FC
manual.
Electrical installation
The installation, which should be preceded by
an isolator switch with a contact separation
of at least 3 mm, should only be wired by a
competent electrician and in accordance with
the latest edition of IEE wiring regulations.
The air curtain has an integrated PC board
which is connected to the selected external
control system FC. FC must be ordered
separately. The PC board is located in the
terminal box on the unit's long side. FC is
supplied pre-programmed. Communication and
sensor cables are connected to the PC board.
Should more than one air curtain be
controlled by a single FC, an additional
communication cable FCBC per unit will be
required. See manual for FC.
The electrical connection is made on the top
of the unit (horizontal) or on the back (vertical).
Tarta is equipped with a 1,8 m cable without
plug.
Connecting the water coil (W)
The installation must be carried out by an
authorised installer.
The water coil has copper tubes with
aluminium ns and is suitable for connection
to a closed water heating system. The heating
coil must not be connected to a mains pressure
water system or an open water system.
Note that the unit shall be preceded by a
regulating valve, see Frico valve kit.
The water coil is connected on the long
side of the unit via connections DN25 (1’’),
external thread. Flexible hoses are available as
accessories.
NOTE: Care must be taken when connecting
the pipes. Use a pipe wrench or a similar
tool to grip the air curtain connections to
prevent straining of the pipes and subsequent
water leakage during connection to the water
supply pipe-work.
The connections to the heating coil must be
equipped with shut off valves to allow trouble-
free removal.
The water coil is equipped with vent valves.
Adjustment of the air curtain and airow
The direction and speed of the airow should
be adjusted considering the load on the
opening. Pressure forces affect the airstream
and force it inwards towards the premises
(when the premises are heated and the
outdoor air is cold).
The airstream should, therefore, be directed

Tatra
16
EN
Troubleshooting
If the fans are not running or do not perform
properly, check the following:
• The power supply.
• That the intake grille/lter is not dirty.
• That the motor's safety cut-out has not been
deployed.
• Functions and settings of the FC control
system, see the FC manual.
If there is no heat, check the following:
• Functions and settings of the FC control
system, see the FC manual.
For units with a water coil, also check the
following:
• That the water coil is air free.
• That there is sucient water ow and
pressure.
• That incoming water is heated adequately.
If the fault cannot be rectied, please contact a
qualied service technician.
Replacing the PC board
1. The PC board is located in the terminal box
on the unit's long side.
2. Mark and disconnect the cables to the PC
board.
3. Unhatch the board from its PCB snap-in
spacers and lift out.
4. Install the new PC board as above in reverse
order.
Safety cut-out
All motors are equipped with an integrated
safety cut-out. This will operate, stopping the
air curtain should the motor temperature rise
excessively or the electronics fail or overheat.
The cut-out will automatically reset when the
motor temperature has returned to within the
motor’s operating limits. Failure or damage to
electronics components may require repair or
replacement of such components or the entire
product.
Fan replacement
1. Determine which of the fans is not
functioning.
2. Disconnect the cables from the relevant fan.
3. Remove the screws securing the fan and lift
the fan out.
4. Install the new fan as above in reverse order.
Packaging
Packaging materials are chosen with
consideration to the environment and are
therefore recyclable.
Handling of product at end of working
life
This product may contain substances necessary
for the functionality of the product but
potentially dangerous for the environment. The
product should not be disposed of mixed with
general household waste but delivered to a
designated collection point for environmental
recycling. Please contact the local authority
for further details of your nearest designated
collection point.
Safety
• Keep the areas around the air intake and
exhaust grilles free from possible obstructions!
• The unit must not be fully or partially covered as
overheating can result in a re risk!
• Lifting equipment must be used to lift the unit.
• This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved. Children
Replacing the water coil (W)
A horizontally mounted unit must be
demounted and placed on a suitable working
level before accessing the water coil. The unit
must be lifted by the holes in the motor section.
NOTE: The unit can not be lifted by its mid
section as the outlet grille might be damaged.
1. Disconnect the power supply.
2. Shut off the water supply to the unit.
3. Disconnect the connections to the water coil.
4. If horizontally mounted, demount the unit.
5. Loosen the motor section on the unit's top
(horizontal), back (vertical) by removing its
screws.
6. Fold the section towards the cable side.
NOTE: Be careful to prevent the section from
falling.
7. Remove the mounting screws securing the
coil in the unit and lift out.
8. Install the new coil in reverse order to the
above.

Tatra
17
EN
shall not play with the appliance. Cleaning and
user maintenance shall not be made by children
without supervision.
• Children of less than 3 years should be kept
away unless continuously supervised.
• Children aged from 3 years and less than 8
years shall only switch on/off the appliance
provided that it has been placed or installed
in its intended normal operating position and
they have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved.
• Children aged from 3 years and less than 8
years shall not plug in, regulate and clean the
appliance or perform user maintenance.
CAUTION — Some parts of this product can
become very hot and cause burns. Particular
attention has to be given where children and
vulnerable people are present.

Art no: 391071, 2022-10-19 CH/HH
Main offi ce
Frico AB Tel: [phone]
Industrivägen 41
SE-433 61 Sävedalen [email protected]
Sweden www.frico.net
For latest updated information and information
about your local contact: www.frico.net
