FriFri RETRO FRI0802015BLP User manual

MODEL (RETRO): FRI0802015BLP
THE AIR FRYER
RETRO
User manual

Carefully read the user manual before
using the appliance and keep it in order
to consult later if needed.
• This appliance shall not be used by
persons (including children under the age
of 8) whose physical, sensorial or mental
capacities are reduced, nor by persons
lacking experience or knowledge, except
when having received supervision or
instructions from another person
responsible for their security about the
use of this appliance in advance
• Never immerse the complete appliance
into water or do not hold it under the tap,
since it contains electronical parts.
Risks of electrical shock!
• Always place the ingredients you want
to bake in the basket, to avoid contact
with the heating elements
• Never cover the air inlet and outlet
when operating the appliance
• Never fill the pan with oil, this could
cause fire
• Never touch the inside of the appliance
while it is working
• Before plugging in the appliance, check
if the voltage indicated on the appliance
matches the mains voltage of your house
• Do not use the appliance if the plug,
electrical cord or appliance are damaged
• If the electrical cord is damaged it must
be replaced by the technical department,
after sales service or similarly qualified
service from the manufacturer
• Supervise children and don’t let them
play with the appliance
• When the appliance is working,
or cooling down, the appliance and
the electrical cord should be held out
of reach of children under the age of 8
• Make sure het electrical cord does not
come into contact with hot surfaces
• Never plug in the appliance nor touch
the control panel with wet hands
• The appliance should always be plugged
into a grounded plug, make sure it always
is connected correctly
• Never operate the appliance with
separate timers, this could be dangerous
• Never place the appliance near
inflammable objects, such as clothing,
curtains, etc
• Never place the appliance against a wall
or another appliance. Keep at least 10 cm
on all sides of the appliance. Don’t place
anything on top of the appliance
• Only use this appliance for what it is
intended
• Never operate the appliance unattended
• When frying without oil, hot steam
might come out of the openings of the
appliance. Always keep hands and face at
a safe distance from the openings. Also,
always be careful with the steam and hot
air that comes out of the appliance when
removing the food out of the appliance
• When the appliance is working,
the surface on which it stands can
become very hot
• If there is smoke coming out of
the appliance, immediately pull the plug
from the socket. Remove the food from
the appliance when there is no smoke
anymore. Place the appliance on
a horizontal, flat and stable surface
• If the appliance is used incorrectly,
or for professional purposes, or if it is
not used as prescribed in the user manual,
the warranty shall expire, and we could be
entitled to decline all responsibility
for possible damage
• The repairs can only be executed by
a recognized agent or repair service.
Never repair the appliance yourself,
this would invalidate the warranty
• Always unplug the appliance after use
• Let the appliance cool down for
30 minutes before moving or cleaning it
• Make sure to remove the food when
golden brown and not black or dark brown.
Remove burned parts
Thank you fr your purchase !
THE air fryer Retro from Frifri wil alow you to quickly and eficiently prepare ALL TYPES OF FOOD
to have a real treat evry day ! THE air fryer Retro from Frifri uses the hot air technolgy in combination
with a fast air circulation to bake your ingredients perfectly without ading oil.
SAFETY PRESCRIPTIONS
EN

DESCRIPTION OF THE APPLIANCE
A. FRYING BASKET
B. RELEASE BUTTON OF THE BASKET
C. HANDLE
D. PAN
E. FRYING NET
F. TEMPERATURE INDICATOR
G. AIR OUTLET
H. ELECTRICAL CORD STORAGE
I. ELECTRICAL CORD
J. AIR INLET
K. CONTROL BUTTON
FOR THE BAKING TIME - TIMER
L. ON/OFF INDICATOR
M. CONTROL BUTTON
FOR THE TEMPERATURE - THERMOSTAT
A
B
C
D
G H
E
F
J
K
L
M
I
EN
AIR FRYER, 1500 W

PUTTING INTO SERVICE AND USE
Before the first use
• Remove all packaging material
• Remove glue and all labels from the appliance
• Clean the basket and the pan thoroughly with hot
soapy water and a soft sponge
Remark : these parts are dishwasher proof.
• Clean the inside and the outside of the appliance
with a soft cloth
The air fryer Retro from Frifri uses the hot air
technology. Never put oil or fat in the appliance
Preparation of the appliance
• Place the appliance on a horizontal, flat and stable
surface
• Place the appliance on a heat resistant surface
• Place the basket correctly in the appliance so that
it can operate
• Remove the electrical cord from the cord storage
Never put any oil or other fluid in the appliance.
Never put anything on the appliance, this could
obstruct the air circulation and diminish the operation
of baking with hot air.
Use
The air fryer Retro from Frifri can be used to bake
a variety of ingredients. Discover the baking table
below as well as the recipe booklet on frifri.be
• Plug in the plug in a wall socket
• Carefully remove the pan from the appliance
• Put the ingredients in the basket
• Place the pan in the appliance again
Never use the appliance without the basket. If the pan
is not placed correctly in the appliance, the appliance
will not work!
• Set the temperature by turning the thermostat
button
• Set the desired baking time by turning the timer.
If the appliance starts cold, add 5 minutes
of preheating time
Remark : If desired, you can preheat the appliance
without ingredients. In order to do this, turn the timer
on 5 minutes, and wait for the indicator to extinguish
before adding the ingredients in the basket.
• When the appliance starts, the ON/OFF indicator
and the temperature indicator will light up
• During operation of the air fryer, the temperature
indicator will go on and off. This indicates that
the heating elements continuously heat up and
stop heating again in order to maintain the desired
temperature.
• The timer will count down from the set time
• The excess oil from the ingredients will be collected
in the pan
• Some ingredients require shaking halfway through
the baking process. (See baking table below).
To shake the food, remove the pan from the appliance
with the handle and shake the ingredients. Replace
the pan in the appliance. Caution: do not press
the release button of the basket while shaking
Tip : to minimize the weight, remove
the basket from the pan and only
shake the basket. To do so, remove
the pan from the appliance and place it on a heat
resistant surface and press the release button on
the handle.
Tip: if you set the timer on half of the time a sound
signal will be heard to remind you to shake
the ingredients. However, do not forget to set
the baking time again once the ingredients have been
shaken. The appliance will automatically turn off and
on again once the pan is put back again.
To turn off the appliance manually, turn the button
clockwise to the OFF position.
• When you hear the sound signal, this means the set
time is finished. Remove the pan from the appliance
and place it on a heat resistant surface
Remark : you can also turn off the appliance
manually. To do so, turn the timer button to
the OFF position.
• Check if the ingredients are sufficiently baked.
Should this not be the case, replace the pan in
the appliance and add some time to the timer
• Once the ingredients are thoroughly baked, remove
the ingredients from the basket and put in on plates
or in a bowl
Caution : After use the air fryer and the ingredients
are still very hot. Depending on the ingredients steam
may come out of the pan.
EN

Tips :
• To remove small ingredients out of the basket
(e.g. fries), press the release button from
the basket (1) and remove the basket from
the pan (2).
Remark : Do not turn the basket upside down
when it is still in the pan. Any redundant oil
or residues in the pan will fall on your ingredients.
• To remove larger or fragile food from the pan:
use a kitchen pincer
• Once a serving of ingredients is ready,
the appliance is instantly ready for preparing
another serving
Caution : Never touch the appliance immediately
after use, it is very hot. Move the appliance by
the handles.
EN

The table below will help you choose the settings for the ingredients you wish
to bake. These settings are merely indicative. We cannot guarantee the best
settings for each ingredient since each ingredient may differ from kind to kind,
brand to brand, but also from size, shape, content …
Thanks to the hot air technology, the air in the appliance heats up
instantly and removing the pan during the baking process barely affects
the baking.
Baking table
• In comparison to large ingredients, small ingredients need less baking time
• To bake larger portions the baking time will have to be longer, and for smaller
portions shorter
• When baking smaller ingredients, turning the ingredients might improve
the baking result
• Adding a little bit of oil on fresh potatoes can make the ingredients crispier.
Add oil before putting the ingredients in the basket. Bake the ingredients within
a few minutes after adding oil on them
• Every preparation that can be prepared in a traditional oven can be prepared
in an air fryer
• The best weight to obtain crispy fries is 800 gr.
• You can use the air fryer to heat up ingredients.
Set the temperature to 160°C, maximum baking time is 30 minutes
Remark :
Potatoes and Fries
Type Min-Max capacity
of ingredients (g) Time (minutes) Temperature (°C) To Do halfway the baking time Extra information
Thin frozen fries 300-700 12-16 200 Shake
Thick frozen fries 300-700 12-20 200 Shake
Fresh fries 300-800 18-25 180 Shake Add ½ spoon of oil
Rösti – potato slices 250 15-18 180 -
Potato gratin 500 18-22 180 -
EN

Meat
Type Min-Max capacity
of ingredients (g) Time (minutes) Temperature (°C) To Do halfway the baking time Extra information
Steak 100-500 8-12 180 Turn
Pork chops 100-500 10-14 180 Turn
Hamburger 100-500 7-14 180 Turn Add ½ spoon of oil
Sausages 100-500 13-15 200 Turn Add ½ spoon of oil
Drumstick 100-500 18-22 180 Turn Add ½ spoon of oil
Chicken breast 100-500 10-15 180 Turn Add ½ spoon of oil
Snack
Type Min-Max capacity
of ingredients (g) Time (minutes) Temperature (°C) To Do halfway the baking time Extra information
Spring roll 100-400 8-10 200 Turn Add ½ spoon of oil
Frozen Chicken nuggets 100-500 6-10 200 Turn Add ½ spoon of oil
Frozen Fish Sticks 100-400 6-10 200 - Add ½ spoon of oil
Croquettes 100-400 8-10 200 - Add ½ spoon of oil
Vegetables 100-400 10 180 -
Remark : Add 5 minutes to the baking time if the appliance starts cold.
EN

MAINTENANCE
Clean the appliance after each use. The inside of
the pan, the basket and the appliance are covered
with a non-stick coating. Do not use any metal kitchen
utensils or aggressive detergents to clean them.
This could damage the non-stick coating.
• Remove the plug from the socket and let
the appliance cool down. In order to make
the appliance cool down faster you can remove
the pan from the appliance
• Clean the pan with hot soapy water and a soft
sponge, put some hot water with detergent in
the pan. Put the basket in the pan, soak for about
ten minutes
Remark: The pan and the basket are dishwasher
proof.
• Clean the inside of the appliance with hot water
and a soft sponge
• Use a cleaning brush to clean the heating elements
to remove sticking residues
• Use a moist cloth to clean the outside of
the appliance
STORAGE
Make sure all parts are clean and dry.
Store the appliance in a clean and dry place.
ENVIRONMENTAL PROTECTION
NORM 2002/96/CE
In order to protect our environment and your
health, disposal at the end of the lifetime of electric
appliances must be treated under certain rules
and this requires involvement of everyone, supplier
or user. Therefore, your appliance cannot in any way
be disposed in a public waste bin or with normal
domestic waste, as indicated by the symbol on
the rating plate. When disposing of the appliance it is
your responsibility to bring the appliance to
an official collection center for recycling of electric
and electronic appliances. For more information on
the collection centers for recycling of appliances
at the end of their lifetime, please contact the local
authorities in your area, the household waste disposal
service provider or the store where you bought your
appliance.
ELECTRICAL CORD
Carefully check the electrical cord before each use.
If it is damaged, do not use the appliance.
The electrical cord can only be replaced by Dalcq S.A.,
her after sales service or a capable and authorized
person in order to avoid any danger for the user.
The electrical cord used is a HO5VV-F 3 G 0,75
mm2. These appliances comply to the 2006/95/ CE,
2004/108/CE, DEEE 2002/96/CE, rohs 2002/95/
CE norms and the 1935/2004 regulation of
the European Parliament on materials and articles
intended to come into contact with food.
WARRANTY
Dalcq S.A. provides a special warranty on all parts
of the appliance subject to conditions below.
The legal regulations about warranty as well as
the rights resulting from the legislation about
responsibility of the defective products remain
unaffected. Possible right to reimbursement of
the buyer in case of defaults remain valid,
if the conditions below are met.
1. Period of the warranty
The warranty applies to all parts
of the appliance and starts from
the date of purchase (date of invoice) of the appliance
and has a duration of 2 years when used privately.
2. Object of the warranty
Dalcq S.A. covers the material, construction and
manufacturing defaults, provided the default was
present at delivery and that the appliance was
correctly operated by the buyer. The warranty covers
free repair, or exchange of one or more defective
components, or the exchange of the appliance
for another appliance of the same value. It is up to
Dalcq S.A. to decide which measure to undertake.
3. Warranty case
When breakdown/default, you must immediately
advise :
• The store where you bought the appliance
• The after sales service (written or via email) that
the appliance will be returned, to provide an extended
description of the problem with pictures
4. Packaging
It is recommended to use the original packaging to
return the appliance. If you use a different packaging,
make sure it provides enough protection for typical
transport risks and that it offers sufficient protection.
A simple cardboard box filled with paper is not
sufficient. Dalcq S.A. cannot be held responsible for
damage resulting from insufficient packaging.
The warranty then expires. The after sales service
will inform you of the return procedure as well as of
the costs this implies.
EN

5. Cleaning
If you don’t clean the parts or the appliance before
returning it, Dalcq S.A. will invoice a cleaning set rate.
It is the responsibility of the buyer to prove the real
costs of cleaning are inferior to the invoiced set rate.
6. Withdrawal of the right to warranty
The right to warranty is withdrawn by :
• Incorrect use, treatment and storage. (for example,
defaults caused by humidity, high temperatures)
• Repairs, repair attempts, modifications of any kind
and use of non-original parts, etc. which were not
executed by Dalcq S.A. or by an authorized company
• Insufficient packaging and bad transport
• Inappropriate mechanical influences on
the appliance or on the parts of the appliance
• Defaults that are not caused by the finishing
or production of the appliance, such as fall, collision,
damage, fire, earthquake, damage by flood, lightning,
etc
• Use other than household use, especially in
a commercial environment
• The costs incurred by Dalcq S.A. because of
the returning of the appliance by the buyer, without
warranty or right to restitution will be for the buyer
7. After Sales Service
Dalcq S.A. - Rue du Hainaut 86
6180 Courcelles - Belgium
[email protected]
Trouble shooting
Problem Possible Cause Solution
The appliance doesn’t work The plug is not plugged in 1. Insert the plug into the socket
2. Turn the timer button to set he time
The ingredients are not
baked through
1.There are too much ingredients in the basket
2.The set baking temperature is too low
3.The set baking time is too short
1. Put smaller quantities in the basket. Smaller quantities will allow
more regular baking.
2. Set the temperature button to the desired temperature
(see ‘Settings’ in the chapter ‘Use’)
3. Turn the timer button to set the baking time
(see ‘Settings’ in the chapter ‘Use’)
The ingredients are not
equally baked.
Some ingredients need to be shaken halfway
through the baking process
Shake ingredients which are piled up (f.ex. fries) halfway through
the baking process (see ‘Settings’ in the chapter ‘Use’)
The fried ingredients are not crispy The used snacks are not suited for air frying Always use oven snacks or slightly grease the ingredients
with oil for a crispier result
I cannot slide the pan into
the appliance correctly The basket is too full Do not fill the basket too much
White smoke is coming out
of the appliance
1. You use very greasy ingredients
2. There are some residues from prior bakings
in the pan
1. When baking greasy ingredients, the redundant oil drips on
the hot pan and causes smoke. This will not affect the final
cooking result
2. The white smoke is caused by heated grease in the pan.
Clean the pan after every use
Fresh fries are fried unequally You didn’t put any oil on the fries before baking Use fresh potatoes, make sure they don’t break during baking
The fries are not crispy The crispiness depends on the amount
of water and oil in the fries
1. Carefully dry the fries before you grease them with oil
2. Cut smaller fries, they will be lighter and crispier
3. Grease with some oil, they will be lighter and crispier
EN
