Instruction assembly FS360 horseshoe
Unload the machine using fork lift truck and later remove the brackets (A1 and B1) used for this
function:
Front side loading
Chassis A
A
Chassis B
Chassis C
A1
B1

FROMM Wrapping Systems S.r.l.
Viale del Lavoro 21
IT-37013 Caprino V.se. (VR)
ITALY
Office. 0039 045 205 7300
Fax. [phone]
[email protected]
www.fromm-stretch.com
Bank. Banca Popolare di Verona | IT-37010 |ITALY
Account Nr. 000000000227 | Swift Nr. IT-BAPPIT21130
Iban. IT11-W-05034-85830-000000000227
Vat Nr. 04146150232 | EORI. IT 04146150232
Fig.1
Fig.2
Fig.3

FROMM Wrapping Systems S.r.l.
Viale del Lavoro 21
IT-37013 Caprino V.se. (VR)
ITALY
Office. 0039 045 205 7300
Fax. [phone]
[email protected]
www.fromm-stretch.com
Bank. Banca Popolare di Verona | IT-37010 |ITALY
Account Nr. 000000000227 | Swift Nr. IT-BAPPIT21130
Iban. IT11-W-05034-85830-000000000227
Vat Nr. 04146150232 | EORI. IT 04146150232
Assembling Telaio C and connection the proximity for the safety following Fig.4 here below
Fig.4
Left or Right side loading
Move the reflector on the perimeter of the disk, following page “Horseshoe FS360 Open side
for loading”.
Remove Chassis A and Chassis B, unscrew its bolts and connections them in the front positions.
Remove the Tap (C) to pass with the cable and later connection the proximity for the safety.
For Right side loading, there is already prepared a cable (arrow here below) in the machine to
connect it at the proximity for the safety.
C

FS1.0330AE Horse shoe Ø1500mm
Part no. RIF Description Specification English Q.ty
FS1.0247 1 Group Group adjustable foot 2
FS1.0297 2 Group Group motor carter Blue Sablè RAL 5010 1
FS1.0326A 3 Group Group enter horseshoe Blue Sablè RAL 5010 1
FS1.0327A 4 Group Group lateral carter inside Blue Sablè RAL 5010 2
FS1.0328A 5 Group Group lateral carter outside Blue Sablè RAL 5010 2
FS1.0329E 6 Group Group disk Yellow RAL 1021 antislip finish 1
FS1.0332 7 Group Group motorgear 1
FS1.0340A 8 Group Group carter chain Blue Sablè RAL 5010 1
FS1.0341 9 Group Group proximity turntable 1
FS1.2606Z 10 Support SUPPORT MAGNET DOOR ZINCED 2
FS1.2648Z 11 Plate CENTRAL PLATE ZINCED 1
FS1.2666A 12 Base BASE HORSE SHOE BLUE SABLE' RAL 5010 1
FS1.2674Z 13 Bracket BRACKET TO FIX THE CARTER ZINCED 2
FS1.2675Z 14 Carter CARTER CABLES ZINCED 1
FS3.0226 15 Group GROUP RUBBERED WHEEL 2
FS3.2344 16 Label FORKLIFT TRUCK LABEL 1
FS3.2375 17 Spacer SPACER 3
FS3.2389Z 18 Washer SPECIAL ZINCED WASHER 1
FS4.1449 19 Spring POLIURETANIC SPRING D.I.=10.5 L=20 2
N1.1225 20 Bolt BUTTON HEAD BOLT M5x16 ZINCED UNI 7380 8
N1.1228 21 Bolt BUTTON HEAD BOLT M10x25 ZINCED UNI 7380 6
N1.1548 22 Bolt BUTTON HEAD BOLT M10x20 ZINCED UNI 5739 6
N1.1557 23 Bolt BUTTON HEAD BOLT M8x25 ZINCED UNI 5739 4
19/06/2018 FS1.0330AE.V01.01.xls

FS1.0330AE Horse shoe Ø1500mm
Part no. RIF Description Specification English Q.ty
N1.1582 24 Bolt HEXAGON HEAD BOLT M10x75 UNI 5739 DIN 933 ZN 2
N1.1588 25 Bolt HEXAGON HEAD BOLT M8x80 UNI 5739 DIN 933 ZN 1
N1.2147 26 Bolt SOCKET CTRS. HD BOLT DIN 7991 M8x20 ZINCED 1
N1.4202 27 Tap FISCHER FBN 10/15-23 2
N1.5108 28 Nut NUT M10 DIN 934 ZINCED 2
N1.5301 29 Nut NUT M6 AUTOBLOCK. DIN 985 ZINCED 2
N1.5957 30 Rivet RIVET M5 22
N1.6109 31 Washer WASHER M8 DIN 9021 24x8,4x2 1
N1.6130 32 Washer WASHER 10,5x30x2,5 6
N1.6138 33 Washer WASHER 8,4x21x4 4
N1.6167 34 Washer PLAIN WASHER M5 5.3x10x1 DIN 433 ZINCED 2
N1.6201 35 Washer SPRING LOCK WASHER DIN 127 -B- M10 6
N1.6215 36 Washer SPRING LOCK WASHER DIN 127 -B- M8 8
N1.6217 37 Washer SPRING LOCK WASHER DIN 127 -B- M5 6
N1.6308 38 Washer SPECIAL WASHER 26x38x0.5 2
N1.7333 39 Screw SCREW M4x10 ZINCED UNI8112 DIN7500-C 4
N1.7334 40 Screw SCREW M4x10 ZINCED UNI8112 DIN7500-C 4
N2.1105 41 Seeger SEEGER d.25 DIN 471 TYPE A 2
N4.5129 42 Tap TAP D.25 2
N4.7238 43 Pinion PINION WITH BALL BEARINGS 1/2"x5/16" Z=18 3
N4.7379 44 Chain CHAIN 1/2"x5/16" 1
N4.7413 45 Link SPRING CLIP (LINK) 1/2"X5/16" ISO 08B-1 1
N5.3428 46 Base BASE TO FIX CABLE TIE 8
N11.1118 47 Screw CYLINDRI. HEAD CAP SCREW M5x10 UNI5931 DIN912 2
N11.1121 48 Screw CYLINDRI. HEAD CAP SCREW M6x10 UNI5931 DIN912 4
N11.1141 49 Screw CYLINDRI. HEAD CAP SCREW M8x20 UNI5931 DIN912 3
N11.1147 50 Screw CYLINDRI. HEAD CAP SCREW M5x16 UNI5931 DIN912 2
N11.1199 51 Screw CYLINDRI. HEAD CAP SCREW M6x70 UNI5931 DIN912 2
N11.6104 52 Washer PLAIN WASHER 15x5,3x1.2 ISO 4759/3 2
19/06/2018 FS1.0330AE.V01.01.xls

Part no. RIF Description Specification English Q.ty
FS1.2373Z 1 Bracket Bracket zinced 1
N1.1211 2 Screw Button head bolt M8x20 black cl.10.9 2
N1.1584 3 Screw Hexagon head bolt M10x35 galvanized UNI5739 DIN 933 1
N1.5108 4 Nut Nut M10 galvanized cl.8 PG DIN934-UNI5588/65 1
N1.6215 5 Washer Washer grower M8 black UNI1751/52A 2
FS1.0247 Group adjustable foot
06/02/2018 N-FS1.0247.V01.01.xls

Part no. RIF Description Specification English Q.ty
FS1.2376A 1 Gear Painted motor carter (Blue Sablé RAL5010) 6
N1.1220 2 Screw Button head bolt M6x16 zinced UNI7380 6
N1.6204 3 Washer Spring lock washer M6 zinced DIN127-B- UNI1751/52A 1
FS1.0297A Group motor carter (Blue Sablé RAL5010)
30/01/2018 N-FS1.0297.V01.01.xls

FS1.0326A Group enter horseshoe Blue Sablè RAL 5010
Part no. RIF Description Specification English Q.ty
FS1.2654A 1 Carter CARTER RIGHT SIDE 1
FS1.2656A 2 Slide SLIDE ENTRY 1
FS1.2659A 3 Carter CARTER LEFT SIDE 1
N11.1173 4 Screw CYLINDRI. HEAD CAP SCREW M8x25 UNI5931 DIN912 2
N1.5313 5 Nut NUT M3 AUTOBLOCK. DIN 985 ZINCED 2
N1.7333 6 Screw SCREW M4x10 ZINCED UNI8112 DIN7500-C 14
N5.2645 7 Reflector REFLECTOR RL 116 41x52 1
N51.2619 8 Photocell PHOTOCELL E3F-1-RN21 1
19/06/2018 FS1.0326A.V01.01.xls

FS1.0327A Group lateral carter inside Blue Sablè RAL 5010
Part no. RIF Description Specification English Q.ty
FS1.2663A 1 Carter LATERAL CARTER INSIDE 1
N1.5957 2 Rivet RIVET M5 2
N1.6167 3 Washer PLAIN WASHER M5 5.3x10x1 DIN 433 ZINCED 2
N1.6217 4 Washer SPRING LOCK WASHER DIN 127 -B- M5 2
N11.1101 5 Screw CYLINDRI. HEAD CAP SCREW M5x12 ISO 4762 2
19/06/2018 FS1.0327A.V01.01.xls
