Fromm FS3 Series User manual

FROMM
It is forbidden to duplicate this manual or parts of it in any way or any form without written permission of the author © 2015
www.fromm-stretch.com
FROMM
ASSEMBLY INSTRUCTIONS
Stretch Wrapping machine’s
FS3xx/FS1xx Toppress Art. FS3.2670
(Already included in the machine)
Version 01 Machines
List Rev01
Website : www.fromm-stretch.com
Assembly Instructions_FS3xx_FS1xx.V01.EN01/a.servisi/ © 01/15

FROMM Wrapping Systems S.r.l.
Viale del Lavoro 21
IT-37013 Caprino V.se. (VR)
ITALY
Office. 0039 045 205 7300
Fax. [phone]
[email protected]
www.fromm-stretch.com
Bank. Banca Popolare di Verona | IT-37010 |ITALY
Account Nr. 000000000227 | Swift Nr. IT-BAPPIT21130
Iban. IT11-W-05034-85830-000000000227
Vat Nr. 04146150232 | EORI. IT 04146150232
Assembly Instruction Toppress FS3xx/FS1xx
Group presser purchased with FS3xx/FS1xx serie wrapping machine.
Gruppo pressino acquistato con la macchina avvolgitrice serie FS3xx/FS1xx.
Fig.1 Packaging (first side)
Fig.2 Packaging (second side)
Fig.3
Details Fig.3
Fig.4
Remove yellow
Togliere il carter
Fig.5
Inserting the arm in the bracket (for
movement toppress) and adjustment.
Inserire il braccio nella staffa per la
movimentazione del toppress e
regolarla.
Fig.6
To connection the wires looks next
page for ELS “yellow remark”.
Per connettere i cavi guarda pagina
successiva ELS “evidenziati in
giallo”
Details Fig.6
Fig.7
Fig.8

FS3.0261 Toppress
Part no. RIF Description Specification English Q.ty
FS3.0264 1 Arm ARM 1
FS3.0277 2 Group GROUP MOTORGEAR 1
FS3.0278 3 Disk COMPLETE DISK 1
FS3.0295 4 Group GROUP CARRIAGE 1
FS3.0299 5 Group GROUP CARTER 1
FS3.2120 6 Polizene POLIZENE FOR PLATE CARRIAGE 4
FS3.2595 7 Mast MAST 1
FS3.2596 8 Plate PLATE FOR CABLE CHAIN 1
FS3.2597 9 Bracket BRACKET 1
FS3.2603 10 Tensioner TENSIONER FOR CHAIN 1
FS3.2610 11 Shaft SHAFT 1
FS3.2613 12 Carter CARTER 1
FS3.2650 13 Plate PLATE SLIDING CARRIAGE IN THE COLUMN 1
FS3.2652 14 Carter CARTER 1
FS3.2653 15 Block MECHANICAL BLOCK 2
FS3.2717 16 Lever LEVER FOR MICROSWITCH 1
FS3.2722 17 Plate PLATE 1
FS4.1516 18 Label LABEL BRAND FROMM 1
FS4.1521 19 Sticker RED STICKER PVC 1
N1.1219 20 Screw BUTTON HEAD SCREW ISO 7380 - M6 x 12 ZINCED 1
N1.1220 21 Screw BUTTON HEAD SCREW ISO 7380 - M6 x 16 4
N1.1225 22 Screw BUTTON HEAD SCREW ISO 7380 - M5 x 16 ZINCED 4
N1.1320 23 Bolt PHILIPS HEAD BOLT M3x16 ZN UNI 5931 2
N1.1425 24 Bolt HEXAGON HEAD BOLT DIN 933 - M10 x 80 ZINCED 1
N1.1510 25 Bolt HEXAGON HEAD BOLT DIN 933 - M12 x 120 ZINCED 1
N1.1546 26 Bolt HEXAGON HEAD BOLT DIN 933 - M10 x 25 ZINCED 4
N1.1556 27 Bolt HEXAGON HEAD BOLT DIN 933 - M4 x 12 ZINCED 2
N1.1937 28 Bolt PHILIPS HEAD BOLT M4x30 ZN UNI 5931 2
N1.5302 29 Nut PREVAILING HEXAGON TORQUE / NON MET. INS. M5 4
N1.5304 30 Nut PREVAILING HEXAGON TORQUE / NON MET. INS. M12 1
N1.5305 31 Nut PREVAILING HEXAGON TORQUE / NON MET. INS. M8 2
N1.6103 32 Washer PLAIN WASHER DIN 125 - 5,3 x 10 2
N1.6114 33 Washer PLAIN WASHER DIN 125 - M6 4
N1.6131 34 Washer PLAIN WASHER M6 6,4x18x1,6 DIN 9021B 9
N1.6164 35 Washer PLAIN WASHER DIN 125 - M8 4
N1.6188 36 Washer PLAIN WASHER M12 DIN 9021B 2
N1.6204 37 Washer SPRING LOCK WASHER DIN 127 -B- M6 13
N1.6215 38 Washer SPRING LOCK WASHER DIN 127 -B- M8 6
N1.6216 39 Washer SPRING LOCK WASHER DIN 127 -B- M10 5
N1.6219 40 Washer SPRING LOCK WASHER DIN 127 -B- M4 4
N1.7331 41 Screw HEAD PIN SCREW M5x10 ZINCED UNI 8112 8
N1.7333 42 Screw HEAD PIN SCREW M4x10 ZINCED UNI 8112 4
N1.7335 43 Screw HEAD PIN SCREW M4x10 ZINCED UNI 8113 4
N1.7338 44 Screw HEAD PIN SCREW M5x25 ZINCED UNI 8112 2
22/01/2015 FS3.0261.V01.02.xls

FS3.0261 Toppress
Part no. RIF Description Specification English Q.ty
N1.7339 45 Screw HEAD PIN SCREW M5x16 ZINCED UNI 8112 8
N2.4902 46 Rivet CYLINDRICAL HEAD CAP RIVET C15 D.1,85x4,76 NICK. 6
N4.7238 47 Pinion PINION 1/2"X5/16" Z=18 + BALL BEARING 1
N4.7375 48 Chain CHAIN 1/2"X5/16" 377 LINKS 1
N4.7413 49 Link LINK 1/2"X5/16" 2
N5.2355 50 Microswitch MICROSWITCH 1
N5.3332 51 Cablegland CABLEGLAND PG. 13.5 1
N5.3413 52 Cablegland CABLEGLAND 2
N5.3772 53 Cable chain CABLE CHAIN 1
N5.3773 54 Bracket BRACKET FOR CABLE CHAIN 1
N5.3822 55 Plastic PLASTIC FOR CABLES 1
N5.6701 56 Clamp CLAMP 1
N11.1102 57 Bolt CYLINDRICAL HEAD CAP SCREWS DIN 912 M8 x 16 4
N11.1115 58 Screw CYLINDRICAL HEAD CAP SCREWS DIN 912 M4 x 8 2
N11.1143 59 Screw CYLINDRICAL HEAD CAP SCREWS DIN 912 M6 x 20 8
N11.1173 60 Bolt CYLINDRICAL HEAD CAP SCREWS DIN 912 M8 x 25 2
22/01/2015 FS3.0261.V01.02.xls

FS3.0264G Arm Toppress
Part no. RIF Description Specification English Q.ty
FS3.1195 1 Flange FLANGE 1
FS3.2630G 2 Tube TUBE YELLOW RAL 1021 1
FS3.2632 3 Shaft SHAFT 1
FS3.2635Z 4 Bracket ADJUSTABLE BRACKET ZINCED 1
FS3.2636Z 5 Disk DISK ZINCED 4
FS3.2637Z 6 Bracket BRACKET ZINCED 1
FS3.2659G 7 Tube TUBE YELLOW RAL 1021 1
FS3.2716G 8 Support SUPPORT FOR PHOTOCELL YELLOW RAL 1021 1
N1.1517 9 Bolt HEXAGON HEAD SCREW DIN 933 - M8 x 50 1
N1.1556 10 Screw HEXAGON HEAD SCREW M4x12 ZINCED UNI 5739 8
N1.1597 11 Bolt HEXAGON HEAD SCREW DIN 933 - M12 x 60 1
N1.1914 12 Screw CYLINDRICAL HEAD CAP SCREWS DIN 7985 M3 x 16 2
N1.3221 13 Bolt BOLT M8x16 DIN 914 GLVANIZED 3
N1.5134 14 Nut NUT M12 INOZ 1
N1.6115 15 Washer PLAIN WASHER DIN 125 - M4 8
N1.6190 16 Washer PLAIN WASHER DIN 125 - M3 2
N1.6214 17 Washer SPRING LOCK WASHER DIN 127 -B- M12 1
N1.6215 18 Washer SPRING LOCK WASHER DIN 127 -B- M8 1
N1.6219 19 Washer SPRING LOCK WASHER DIN 127 -B- M4 8
N1.6318 20 Washer WASHER TYPE "SS" D.12X18X1,2 DIN 988 6
N1.6334 21 Washer WASHER TYPE "PS" D.25X35X1,5 DIN 988 2
N1.7336 22 Screw HEAD PIN SCREW D.3.5 L=10 IRON C15 1
N2.5289 23 Spring SPRING 2
N3.1106 24 Ball bearing BALLBEARING 12 x 28 x 8 2
N3.3184 25 Bush BUSH 1
N3.3187 26 Bush BUSH 25x28x21,5 1
N3.4703 27 Ball bearing BALLBEARING 25x42x11 1
N4.4305 28 Joint JOINT 1
03/08/2015 FS3.0264.V01.01.xls

FS3.0277 Group motorgear Toppress
Part no. RIF Description Specification English Q.ty
FS3.2591 1 Pinion PINION 1
FS3.2592 2 Shaft SHAFT 1
N1.1546 3 Bolt HEXAGON HEAD SCREW DIN 933 - M10 x 25 2
N1.6196 4 Washer WASHER M10 - 10.5x40x2.5 2
N1.6216 5 Washer SPRING LOCK WASHER DIN 127 -B- M10 2
N2.3314 6 Key PARALLEL KEY DIN 6885 - A 8 x 7 x 25 1
N2.3355 7 Key PARALLEL KEY DIN 6885 - A 8 x 7 x 35 2
N51.1136 8 Motor+gear MOTOR+GEAR 1
03/12/2014 FS3.0277.V01.01.xls

FS3.0278 Complete disk Toppress
Part no. RIF Description Specification English Q.ty
FS3.2645Z 1 Plate PLATE ZINCED 1
FS3.2719 2 Topplate TOPPLATE 1
FS4.1736 3 Sponge SPONGE 1
03/08/2015 FS3.0278.V01.01.xls

FS3.0295 Group carriage Toppress
Part no. RIF Description Specification English Q.ty
FS3.2643 1 Spring SPRING 4
FS3.2767Z 2 Bracket BRACKET ZINCED 1
FS3.2768Z 3 Plate PLATE ZINCED 1
FS3.2770Z 4 Bracket BRACKET ZINCED 1
FS3.2771Z 5 Distance pie. DISTANCE PIECE FOR MICRO ZINCED 1
N1.1137 6 Screw CYLINDRICAL HEAD CAP SCREWS DIN 912 M12 x 30 2
N1.1576 7 Screw HEXAGON HEAD SCREW DIN 933 CL 8.8 M8 X 60 1
N1.5108 8 Nut NUT DIN 934 - M10 4
N1.6130 9 Washer PLAIN WASHER M5 DIN 433 8
N1.6131 10 Washer PLAIN WASHER M6 6,4x18x1,6 DIN 9021B 3
N1.6201 11 Washer SPRING LOCK WASHER DIN 127 -B- M10 4
N1.6204 12 Washer SPRING LOCK WASHER DIN 127 -B- M6 7
N1.6214 13 Washer SPRING LOCK WASHER DIN 127 -B- M12 2
N5.3838 14 Distance pie. DISTANCE PIECE M6 L=20MM 4
N11.1123 15 Screw CYLINDRICAL HEAD CAP SCREWS DIN 912 M6 x 30 3
N12.1125 16 Screw CYLINDRICAL HEAD CAP SCREWS DIN 912 M10 x 20 4
03/08/2015 FS3.0295.V01.01.xls

FS3.0299G Group carter Toppress
Part no. RIF Description Specification English Q.ty
FS3.2772G 1 Plate PLATE YELLOW RAL 1021 2
FS3.2773G 2 Bracket CARTER YELLOW RAL 1021 1
FS3.2774G 3 Bracket CARTER YELLOW RAL 1021 1
N1.1219 4 Screw BUTTON HEAD SCREW ISO 7380 - M6 x 12 ZINCED 4
N1.6131 5 Washer PLAIN WASHER M6 6,4x18x1,6 DIN 9021B 4
N1.6204 6 Washer SPRING LOCK WASHER DIN 127 -B- M6 4
N1.7333 7 Screw CYLINDRICAL HEAD SCREW UNI 8112 - M4 x 10 8
03/08/2015 FS3.0299.V01.01.xls
