FuelTech FTSPARK 750mJ User manual

OWNER’S MANUAL
C
M
Y
CM
MY
CY
CMY
K

3
FTSPARK
1. Index
2. Presentation........................................................................................................... 5
3. Warranty terms ....................................................................................................... 5
4. Characteristics........................................................................................................ 6
5. Installation .............................................................................................................. 8
5.1 Mounting ......................................................................................................... 8
5.2 Power supply ................................................................................................... 8
5.3 Harness connections table ................................................................................ 9
5.4 Connection diagrams...................................................................................... 15
5.5 Wiring harness installation ................................................................................ 21
5.6 Wiring harness positioning ............................................................................... 22
5.7 Coils.............................................................................................................. 22
5.8 Spark plug wires............................................................................................. 22
5.9 Spark plugs ................................................................................................... 23
6. FTSPARK control .................................................................................................. 23
6.1 Individual triggering .......................................................................................... 23
6.2 Serial bus triggering......................................................................................... 23
6.3 Input signal trigger edge................................................................................... 24
6.4 CAN network ................................................................................................. 24
6.5 Energy level selection ...................................................................................... 25
6.6 Wasted spark operation (750mJ Only).............................................................. 26
6.7 Safety Features .............................................................................................. 26
6.8 Ignition delay time............................................................................................ 27
7. Recalibrating ignition and fuel map .......................................................................... 27
8. LED operation indicator ......................................................................................... 27
9. FTSPARK settings and operation............................................................................ 28
9.1 FTSPARK settings........................................................................................... 28
9.2 Ignition energy ................................................................................................ 29
9.3 Using two FTSPARK units in the same installation:.............................................. 29
9.4 Setup on engines with sequential ignition........................................................... 30
9.5 Datalogger channels ....................................................................................... 32

4
FTSPARK
9.6 Status Events Information................................................................................. 33
10. FTCAN 2.0 protocol.............................................................................................. 34
10.1 Physical layer................................................................................................ 35
10.2 Features ...................................................................................................... 35
10.3 IDENTIFICATION............................................................................................ 35
10.4 DATA FIELD.................................................................................................. 36
10.5 Attachments ................................................................................................ 37
11. Dimensions.......................................................................................................... 42

5
FTSPARK
2. Presentation
FTSPARK is a high energy capacitive ignition module that meets the highest
levels of spark energy demand, being able to generate a spark with 750mJ
(mJ = mili Joules guaranteed minimum energy, can reach up to 850mJ) or
1500mJ (FTSPARK EXTREME - guaranteed minimum energy, can reach up
to 1700mJ) and it is capable of discharging with currents up to 140Amps and
475V in the primary coil circuit. With these features, the FTSPARK generates
a spark with approximately 5 times more energy and 10 times more current
compared to a SparkPRO, ensuring a complete combustion in any condition,
especially in extremely rich air fuel ratios.
FTSPARK Differentials:
- Compatible with rotary engines
- Programmable energy level over CAN bus or analog input for energy
level conguration
- 475V in the primary coil circuit, helps avoiding electromagnetic noise in
the system
- Up to 140Amps in the primary coil circuit using FuelTech CDI Racing
Ignition Coil
- Up to 175Amps in the primary coil circuit using FuelTech CDI Racing
Ignition Coil and FTSPARK 1500mJ (FTSPARK EXTREME)
- CAN communication with FuelTech Power FT product line, for diagnostics
and data logging
- Anodized aluminum housing
- Automotive connector with gold-plated terminals
- Serial bus (1 wire) allows the use of only one ECU output to trigger all
FTSPARK ignition outputs
3. Warranty terms
The use of this equipment implies in total accordance with the terms described
in this manual and exempts the manufacturer from any responsibility regarding
product misuse.
This product must be installed and tuned by specialized auto shops
or professionals with experience on engine tuning.
The oversight of any of the warnings or precautions described in this manual
can cause engine damage and lead to warranty void of this product warranty.
Before starting any electrical installation, disconnect the battery.
This product is not certied for aeronautic purposes or any ying vehicles, as
it has not been designed for such applications.

6
FTSPARK
4. Characteristics
- Dimensions: 4.92 x 6.0 x 1.9 in.;
- Weight: 32.8 oz;
- Body: Anodized aluminum and plastic;
- Voltage supply required for full power: 14-26V. Minimum voltage during
cranking 8V;
- Maximum operating frequency: 670 Hz;
In some countries where an annual inspection of vehicles is enforced, no
modication in the OEM ECU is permitted. Be informed about local laws and
regulations prior to the product installation.
Important warning for proper installation of this product:
Always remove and insulate unused wires. NEVER roll up excess
wiring as this may create an antenna that captures electromagnetic
interference that may generate product malfunction.
Limited Warranty
This product warranty is limited to one year from the purchase date, only
covering manufacturing defects and requiring purchase invoice presentation.
Damages caused by misuse of the unit are not covered by the warranty.
Warranty void analysis is done exclusively by FuelTech technical support team.
WARNING:
Warranty seal violation results in product warranty void.
Manual Version 2.2 – August/2020
Specications **600mJ 750mJ 1500mJ
Minimum energy 600mJ 750mJ 1500mJ
Maximum Energy 680mJ 850mJ 1700mJ
Primary coil current 125A 140A 175A
Spark plug (non-resistive) current 1.70A 1.95A 2.50A
Spark duration 300uS 330uS 400uS
** Previous Version

7
FTSPARK
Wiring Harness
Wire harness length: 59 in. at power outputs
connected to coils and 118 in. at the other
cables.
Cylinders Sequential Wasted spark / 2 Stroke
4 22.500 RPM 11.250 RPM
4 (EXTREME) 11.250 RPM NOT COMPATIBLE
5 15.000 RPM NOT COMPATIBLE
6 15.000 RPM NOT COMPATIBLE
8 11.250 RPM NOT COMPATIBLE
8 (EXTREME) 11.250 RPM NOT COMPATIBLE
Rotors Rotary Units
2 11.250 RPM 1 x FTSPARK-4
3 15.000 RPM 2 x FTSPARK-4
4 11.250 RPM 2 x FTSPARK-4
Maximum rotary engine speed (with 16V battery)
Maximum piston engine speed (with 16V battery)
FTSPARK-4 (4 Coils) 20A @ 10000RPM
FTSPARK-6 (6 Coils) 30A @ 10000RPM
FTSPARK-8 (8 Coils) 40A @ 10000RPM
FTSPARK-4 EXTREME (4 Coils) 1500mJ 40A @ 10000RPM
FTSPARK-8 EXTREME (8 Coils) 1500mJ
(using 2 FTSPARK ignition module)
FTSPARK(A) - 40A @ 10000RPM
FTSPARK(B) - 40A @ 10000RPM
FTSPARK-4 (4 Coils): 23 Wires
FTSPARK-6 (6 Coils): 29 Wires
FTSPARK-8 (8 Coils): 35 Wires
FTSPARK-8 EXTREME (4 Coils): 21 Wires
FTSPARK-8 EXTREME (8 Coils): 42 Wires
IMPORTANT
FTSPARK EXTREME is not compatible with rotary engines.
Maximum Current Consumption

8
FTSPARK
5.1 Mounting
Mounting must be done using the rubber cushions. Always use the 4 spots
available on the FTSPARK body.
The FTSPARK must be installed as far away from heating sources as possible
(such as turbochargers and exhaust manifolds) because it generates a lot of
heat by itself.
If installed on the engine bay, it must be mounted where air ows best.
5.2 Power supply
Never Invert the FTSPARK power connections.
The FTSPARK power supply, as well as all other electric loads of the car, must
pass through the master switch for safety reasons and the master switch must
NEVER interrupt the battery ground, always the hot terminal.
IMPORTANT
- Always connect the power supply harness directly to the battery
with a 50A fuse for each FTSPARK BOX.
- Do not use the chassis or engine block to ground the FTSPARK.
Use the negative battery terminal.
To turn the FTSPARK on and off use a 12V switch connected to the analog
input on pin 12.
Do not connect the FTSPARK to a voltage booster, it demands current peaks
of more than 100A and will cause the system to malfunction. Do not use the
The FTSPARK on systems with over 20V power supply.
Do not use FTSPARK on systems with power supply voltage over 26V.
5. Installation
Capacitive ignition systems require special installation care for correct operation.
The vehicle’s electrical system suffers high current and voltage demand from
the FTSPARK ignition system. It is essential to follow the installation instructions
in this manual.
NOTE
If the LOG shows energy drop, it’s necessary to check the harness and
wires that go to the battery. And on situations where the FTSPARK is far
from the battery, it’s mandatory to increase wire gauge.
A good solution is to make a secondary power terminal from the battery,
using 2 AWG cable.

9
FTSPARK
Pin Wire Label Function
1 Orange COIL A (+)
Coil primary output. High voltage (Positive side)
2 Orange COIL B (+)
3 Orange COIL C (+)
4 Orange COIL D (+)
5 Orange COIL E (+)
6 Orange COIL F (+)
7 Orange COIL G (+)
8 Orange COIL H (+)
9 Yellow Energy level
Energy level selection; (ground trigger)
NOTE: If the FTSPARK is connected via the CAN network, it
is not necessary to use this wire.
10 Yellow/Blue -- Wiring harness CANBUS CAN LOW
11 Yellow/White -- Wiring harness CANBUS CAN HI
12 Red Switched 12V FTSPARK Switch ON/OFF
13 Orange/Black COIL A (-)
Coil primary output. Wire 750V. Twisted. (Power ground side)
14 Orange/Black COIL B (-)
15 Orange/Black COIL C (-)
16 Orange/Black COIL D (-)
17 Orange/Black COIL E (-)
18 Orange/Black COIL F (-)
19 Orange/Black COIL G (-)
20 Orange/Black COIL H (-)
21 Black -BAT
Power ground. Connect to battery22 Black -BAT
23 Black -BAT
24 Gray Ignition Input A Ignition trigger input A or Serial bus (1 wire)
25 Gray Ignition Input B Ignition trigger input B
26 Gray Ignition Input C Ignition trigger input C
27 Gray Ignition Input D Ignition trigger input D
28 Gray Ignition Input E Ignition trigger input E
29 Gray Ignition Input F Ignition trigger input F
30 Gray Ignition Input G Ignition trigger input G
31 Gray Ignition Input H Ignition trigger input H
32 Black GND Battery ground. Trigger signal reference
33 Red +BAT Power supply for FTSPARK. Connect to battery positive or
main switch when required.
34 Red +BAT
35 Red +BAT
5.3 Harness connections table
750mJ connection table

10
FTSPARK
CANBUS
CAN LOW
CAN HI
A
A
Ignition Input
#A
()Serial input
Ignition Input #B
Ignition Input #C
Ignition Input #D
Ignition Input #E
Ignition Input #F
Coil B
Coil C
Coil D
Coil E
Coil F
Coil A
Energy Level
Battery Ground (Signal Reference)
12V Switched (FTSPARK activa
tion)
FTSPARK-6 Connector Diagram
+BAT
A
-BAT
A
Fus 50Ae
FTSPARK-8 Connector Diagram
Ignition Input
#A
()Serial input
Ignition Input #B
Ignition Input #C
Ignition Input #D
Ignition Input #E
Ignition Input #F
Ignition Input #H
Ignition Input #G
Coil B
Coil C
Coil D
Coil E
Coil F
Coil H
Coil G
CANBUS
Coil A
Energy Level
CAN LOW
CAN HI
+BAT
A
-BAT
A
Battery Ground Signal Reference
()
Fus 50Ae
12V Switched (FTSPARK activa
tion)
A
CANBUS
CAN LOW
A
CAN HI
Ignition Input
#A
()Serial input
Ignition Input #B
Ignition Input #C
Ignition Input #D
Coil B
Coil C
Coil D
Coil A
Energy Level
Battery Ground (Signal Reference)
12V Switched (FTSPARK activa
tion)
FTSPARK-4 Connector Diagram
+BAT
A
-BAT
A
Fus 50Ae

11
FTSPARK
Pin Wire Label Function
1 Orange COIL A (+)
Coil primary output. High voltage (Positive side)
2 Orange COIL B (+)
3 Orange COIL C (+)
4 Orange COIL D (+)
5 Not Used
- Not Used
6 Not Used
7 Not Used
8 Not Used
9 Yellow Energy level
Energy level selection; (ground trigger)
NOTE: If the FTSPARK is connected via the CAN network, it is
not necessary to use this wire.
10 Yellow/Blue - Wiring harness CANBUS CAN LOW
11 Yellow/White - Wiring harness CANBUS CAN HI
12 Red Switched 12V FTSPARK Switch ON/OFF
13 Orange/Black COIL A (-)
Coil primary output. 750V wire. Twisted. (Power ground side)
14 Orange/Black COIL B (-)
15 Orange/Black COIL C (-)
16 Orange/Black COIL D (-)
17 Not Used
- Not Used
18 Not Used
19 Not Used
20 Not Used
21 Black -BAT
Power ground. Connect to battery22 Black -BAT
23 Black -BAT
24 Gray Ignition Input A Ignition trigger input A or Serial bus (1 wire)
25 Gray Ignition Input B Ignition trigger input B
26 Gray Ignition Input C Ignition trigger input C
27 Gray Ignition Input D Ignition trigger input D
28 Not Used
- Not Used
29 Not Used
30 Not Used
31 Not Used
1500mJ (FTSPARK EXTREME) connection table - 4 Cylinder

12
FTSPARK
Pin Wire Label Function
32 Black GND Battery ground. Trigger signal reference
33 Red +BAT
Power supply for FTSPARK. Connect to battery positive or main
switch when required..
34 Red +BAT
35 Red +BAT
A
CANBUS
CAN LOW
A
CAN HI
Ignition Input
#A
()Serial input
Ignition Input #B
Ignition Input #C
Ignition Input #D
Coil B
Coil C
Coil D
Coil A
Energy Level
Battery Ground (Signal Reference)
12V Switched (FTSPARK activa
tion)
FTSPARK-4 Connector Diagram
+BAT
A
-BAT
A
Fus 50Ae
4 Cylinder engine FTSPARK EXTREME Connector
diagram
Pin Wire Label Function
1 Orange COIL A (+)
Coil primary output. High voltage (Positive side)
2 Not Used -
3 Not Used -
4 Orange COIL D (+)
5 Not Used -
6 Orange COIL F (+)
7 Orange COIL G (+)
8 Not Used -
9 Yellow Energy level
Energy level selection; (ground trigger)
NOTE: If the FTSPARK is connected via the CAN network, it is
not necessary to use this wire.
10 Yellow/Blue - Wiring harness CANBUS CAN LOW
11 Yellow/White - Wiring harness CANBUS CAN HI
12 Red Switched 12V FTSPARK Switch ON/OFF
1500mJ (FTSPARK EXTREME) connection table - 8 Cylinder (BOX A)

13
FTSPARK
Pin Wire Label Function
13 Orange/Black COIL A (-)
Coil primary output. 750V wire. Twisted. (Power ground side)
14 Not Used -
15 Not Used -
16 Orange/Black COIL D (-)
17 Not Used -
18 Orange/Black COIL F (-)
19 Orange/Black COIL G (-)
20 Not Used -
21 Black -BAT
Power ground. Connect to battery22 Black -BAT
23 Black -BAT
24 Gray Ignition Input A Ignition trigger input A or Serial bus (1 wire)
25 Not Used - Not Used
26 Not Used - Not Used
27 Gray Ignition Input D Ignition trigger input D
28 Not Used - Not Used
29 Gray Ignition Input F Ignition trigger input F
30 Gray Ignition Input G Ignition trigger input G
31 Not Used - Not Used
32 Black GND Battery ground. Trigger signal reference
33 Red +BAT
Power supply for FTSPARK. Connect to battery positive or main
switch when required.
34 Red +BAT
35 Red +BAT
Bobina #B
Bobina H
Bobina G
Ignition Input #A
Ignition Input #D
Ignition Input #F
Battery (signal Reference)Ground
Ignition Input #G
Energy Level
CAN LO
CAN HI
COIL A
COIL D
COIL F COIL G
CANBUS
12V Switched (FTSPARK activation)
+BAT
A
-BAT
A
Fus 50Ae

14
FTSPARK
1500mJ (FTSPARK EXTREME) connection table - 8 Cylinder (BOX B)
Pin Wire Label Function
1 Not Used -
Coil primary output. High voltage (Positive side)
2 Orange COIL B (+)
3 Orange COIL C (+)
4 Not Used -
5 Orange COIL E (+)
6 Not Used -
7 Not Used -
8 Orange COIL H (+)
9 Yellow Energy level
Energy level selection; (ground trigger)
NOTE: If the FTSPARK is connected via the CAN network, it is
not necessary to use this wire.
10 Yellow/Blue - Wiring harness CANBUS CAN LOW
11 Yellow/White - Wiring harness CANBUS CAN HI
12 Red Switched 12V FTSPARK Switch ON/OFF
13
14 Orange/Black COIL B (-)
Coil primary output. 750V wire. Twisted. (Power ground side)
15 Orange/Black COIL C (-)
16 Not Used -
17 Orange/Black COIL E (-)
18 Not Used -
19 Not Used -
20 Orange/Black COIL H (-)
21 Black -BAT
Power ground. Connect to battery22 Black -BAT
23 Black -BAT
24 Gray Ignition Input A Ignition trigger input A or Serial bus (1 wire)
25 Gray Ignition Input B Ignition trigger input B
26 Gray Ignition Input C Ignition trigger input C
27 Not Used -
28 Gray Ignition Input E Ignition trigger input E
29 Not Used -
30 Not Used -

15
FTSPARK
Pin Wire Label Function
31 Gray Ignition Input H Ignition trigger input H
32 Black GND Battery ground. Trigger signal reference
33 Red +BAT
Power supply for FTSPARK. Connect on battery positive or when
main switch required.
34 Red +BAT
35 Red +BAT
Bobina E Bobina H
Bobina G
Ignition Input #B
Ignition Input #C
Ignition Input #E Ignition Input #H
CAN LO
CAN HI
COIL B
COIL C
COIL E COILH
CANBUS
Ignition Input A#
(Serial Input)
Ba Groundttery (signal Reference)
Energy Level
12V Switched (FTSPARK activa
tion)
+BAT
A
-BAT
A
Fus 50Ae
5.4 Connection diagrams
Individual FuelTech CDI Racing Ignition Coil
Bobina H
Bobina A
Bobina A
ABCABC ABCABC ABCABCABCABC
FTSPARK-4
A
A
ABCABC ABCABC ABCABC ABCABC
Cylinder #7 Cylinder #8Cylinder #1 C#2ylinder C#3ylinder C#4ylinder
Gray Output #5
Gray Output #6
Ignition input #E
Ignition input #F
Cylinder #5 Cylinder #6
Gray Output #1
Gray Output #2
Gray Output #3
Gray Output #4 Fus 50Ae
Battery Ground
(Signal Reference)
Power
Supply
12V Switched (FTSPARK activation)
Battery Ground
(Power Ground)
Ignition
Switched
Ignition input #A (Serial Input)
Ignition input #B
Ignition input #C
Ignition input #D
CAN Network Connection
Orange/Black wire
(GND from FTSPARK)
Orange wire
(+12 pulse from FTSPARK)
Coil GND
ABCABC

16
FTSPARK
4 Cylinder with Serial bus (Single wire - PowerFT ECU’s)
Cylinder #1 C#3ylinder C#4ylinder
Bobina H
ABCABC ABCABC ABCABCABCABC
Cilindro #2
FTSPARK-4
Gray Output #1 A
A
CAN Network Connection
Fus 50Ae
Battery Ground
(Signal Reference)
Power
Supply
12V Switched (FTSPARK activation)
Battery Ground
(Power Ground)
Ignition
Switched
Ignition input #A (Serial Input)
Orange/Black wire
(GND from FTSPARK)
Orange wire
(+12 pulse from FTSPARK)
Coil GND
ABCABC
4 Cylinder with multiple wires
Cylinder #1 C#2ylinder C#3ylinder C#4ylinder
Bobina H
ABCABC ABCABC ABCABCABCABC
FTSPARK-4
Gray Output #1
Gray Output #2
Gray Output #3
Gray Output #4
A
A
Fus 50Ae
Battery Ground
(Signal Reference)
Power
Supply
12V Switched (FTSPARK activation)
Battery Ground
(Power Ground)
Ignition
Switched
Ignition input #A (Serial Input)
Ignition input #B
Ignition input #C
Ignition input #D
CAN Network Connection
Orange/Black wire
(GND from FTSPARK)
Orange wire
(+12 pulse from FTSPARK)
Coil GND
ABCABC

17
FTSPARK
Cylinder #1 C#2ylinder C#3ylinder C#4ylinder
Bobina H
ABCABC ABCABC ABCABCABCABC
FTSPARK-4
A
A
ABCABC ABCABC
Gray Output #5
Gray Output #6
Ignition input #E
Ignition input #F
Cylinder #5 Cylinder #6
Gray Output #1
Gray Output #2
Gray Output #3
Gray Output #4 Fus 50Ae
Battery Ground
(Signal Reference)
Power
Supply
12V Switched (FTSPARK activation)
Battery Ground
(Power Ground)
Ignition
Switched
Ignition input #A (Serial Input)
Ignition input #B
Ignition input #C
Ignition input #D
CAN Network Connection
Orange/Black wire
(GND from FTSPARK)
Orange wire
(+12 pulse from FTSPARK)
Coil GND
ABCABC
6 Cylinder with multiple wires
Bobina H
Bobina A
Bobina A
ABCABC ABCABC ABCABCABCABC
FTSPARK-4
A
A
ABCABC ABCABC
Cylinder #1 C#2ylinder C#3ylinder C#4ylinder Cylinder #5 Cylinder #6
Gray Output #1
Fus 50Ae
Battery Ground
(Signal Reference)
Power
Supply
12V Switched (FTSPARK activation)
Battery Ground
(Power Ground)
Ignition
Switched
Ignition input #A (Serial Input)
CAN Network Connection
Orange/Black wire
(GND from FTSPARK)
Orange wire
(+12 pulse from FTSPARK)
Coil GND
ABCABC
6 Cylinder with Serial bus (Single wire - PowerFT ECU’s)

18
FTSPARK
FTSPARK EXTREME 8 Cylinder with multiple wires
Bobina A
Bobina A
ABCABC ABCABC ABCABC
Cylinder #1 Cylinder 4# Cylinder 6#
Ignition input #A
Ignition input #D
Bobina H
Ignition input #F
Gray Ouptu #6
Bobina ABobina A
ABCABC ABCABC ABCABC
Cylinder #2 Cylinder 3# Cylinder #5
Ignition input #B
Ignition input #C
Ignition input #E
Gray Ouptu #2
Gray Ouptu #3
Gray Ouptu #5
FTSPARK-8 BOX A
FTSPARK-8 BOX B
Gray Ouptu #1
Gray Ouptu #4
ABCABC
Cylinder 7#
Ignition input #G
Gray Ouptu #7
ABCABC
Cylinder 8#
Ignition input #H
Gray Ouptu #8 Fus 50Ae
Power
Supply
12V Switched
(FTSPARK activation)
Battery Ground
(Power Ground)
Fus 50Ae
Battery Ground
(Signal Reference)
Power
Supply
12V Switched
(FTSPARK activation)
Battery Ground
(Power Ground)
Orange/Black wire
(GND from FTSPARK)
Orange wire
(+12 pulse from FTSPARK)
Coil GND
ABCABC
Battery Ground
(Signal Reference)
Ignition
Switch
Ignition
Switch
Bobina A
Bobina A
ABCABC ABCABC ABCABC
Fus 50Aivel
Bobina H
Bobina ABobina A
ABCABC ABCABC ABCABC
FTSPARK-8 BOX A
FTSPARK-8 BOX B
ABCABC
ABCABC
Cylinder #1 Cylinder 4# Cylinder 6#
Ignition input #A
Cylinder #2 Cylinder 3# Cylinder #5
Ignition input #A
Gray Ouptu #1
Gray Ouptu #1
Cylinder 7#
Cylinder 8#
Fus 50Ae
Battery Ground
(Signal Reference)
Power
Supply
12V Switched
(FTSPARK activation)
Battery Ground
(Power Ground)
Fus 50Ae
Battery Ground
(Signal Reference)
Power
Supply
12V Switched
(FTSPARK activation)
Battery Ground
(Power Ground)
Orange/Black wire
(GND from FTSPARK)
Orange wire
(+12 pulse from FTSPARK)
Coil GND
ABCABC
Ignition
Switch
Ignition
Switch
FTSPARK EXTREME 8 Cylinder with Serial bus (Single wire)

19
FTSPARK
2 Rotors with individual coils
Bobina H
ABCABC ABCABC ABCABCABCABC
FTSPARK-4
A
A
Bobina ABobina A
Leading
rotor 1
(L1)
Trailing
rotor 1
(T1)
Leading
rotor 2
(L2)
Trailing
rotor 2
(T2)
Gray Output #1
Gray Output #2
Gray Output #3
Gray Output #4 Fus 50Ae
Battery Ground
(Signal Reference)
Power
Supply
12V Switched (FTSPARK activation)
Battery Ground
(Power Ground)
Ignition
Switched
Ignition input #A (Serial Input)
Ignition input #B
Ignition input #C
Ignition input #D
CAN Network Connection
Orange/Black wire
(GND from FTSPARK)
Orange wire
(+12 pulse from FTSPARK)
Coil GND
ABCABC
3 Rotors with individual coils - 2 FTSPARK-4 boxes
FTSPARK-8 BOX A
FTSPARK-8 BOX B
Bobina A
Leading
rotor 1
(L1)
Leading
rotor 2
(L2)
ABCABC ABCABC ABCABC
Leading
rotor 3
(L )3
Bobina A
ABCABC ABCABC ABCABC
Trailing
rotor 1
(T1)
Trailing
rotor 2
(T )2
Trailing
rotor 3
(T )3
Gray Output #1 - Learding rotor 1 (L1)
Gray Output #2 - Learding rotor 2 (L2)
Gray Output #3 - Learding rotor 3 (L3)
Fus 50Ae
Battery Ground
(Signal Reference)
Power
Supply
12V Switched
(FTSPARK activation)
Battery Ground
(Power Ground)
Ignition input #A
(Serial Input)
Ignition input #B
Ignition input #C
Gray Output #4 - Trailing rotor 1 (T1)
Gray Output #5 - Trailing rotor 2 (T2)
Gray Output #6 - Trailing rotor 3 (T3)
Ignition input #B
Ignition input #C
Ignition input #E
Fus 50Ae
Battery Ground
(Signal Reference)
Power
Supply
12V Switched
(FTSPARK activation)
Battery Ground
(Power Ground)
Orange/Black wire
(GND from FTSPARK)
Orange wire
(+12 pulse from FTSPARK)
Coil GND
ABCABC
Ignition
Switch
Ignition
Switch

20
FTSPARK
FTSPARK-4 managed by other aftermarket ECU’s
Bobina H
Bobina A
Bobina A
ABCABC ABCABC ABCABCABCABC
Cylinder #1 C#2ylinder C#3ylinder C#4ylinder
Fus 50Ae
FTSPARK-4
A
A
Battery Ground
Signal Reference()
Power
Supply
12V Switched (FTSPARK activation)
Battery Ground
(Power Ground)
Ignition
Switched
Energy level operate with minimum energy- Connected or supplying 12V will make FTSPARK
ing (0V) will make FTSPARKGround operate with maximum energy
ECUECU
Orange/Black wire
(GND from FTSPARK)
Orange wire
(+12 pulse from FTSPARK)
Coil GND
Ignition input #A
Ignition input #B
Ignition input #C
Ignition input #D
1st cylinder on firing order
2nd cylinder on firing order
3rd cylinder on firing order
4th cylinder on firing order
ABCABC
Ignition pins assignment
After FTSPARK installation, follow the steps
below if changes on the ignition outputs are
needed:
1 - Open the map on FTManager
2 - Click on “Sensors and calibration /
Outputs”
3 - Check which gray outputs are set as
ignition outputs. If you need to change
output order, proceed to step 4
4 - Click on “Engine settings / Advanced map
options”
5 - Click on “Ignition pins assignment
mode and change it from “Automatic” to
“Manual”
6 - Return to the “Sensors and calibration /
outputs” menu and change the ignition
outputs according to your installation
