FUFU & GAGA KF250008-01 User manual

1/21
Version:10/09/2022
Shoe cabinet

2/21

I x 4
A x 28 B x 24 C x 4 E x 5D x60
F x 32 G x 4 H x 4 J x 2
K x 4 M x 28 N x 1
M3.5 x 40 mm M3.5 x 14 mm M4 x 20 mm
J1 J2
M6 x 25 mm
M6 x 40 mm 15 x 12 mm
TOOL
3/21
12 x 10 mm
L x 1
M8

4/21

5/21

6/21
Ix 4
1
D
x 4
M3.5 x 14 mm M6 x 25 mm
D c
M3.5 x 40 mmM3.5 x 14 mm
D
I
I
L
Lx 1
M8
I
Fix No.23 leg support to No.2 plate using screw(D),
rotate part(L) into No.23 as shown.
Fix No.22 leg to No.2 plate with screw(I) as shown.
I
I
D

7/21
2
Ax 8
M6 x 40 mm
J1
D
D
3
Jx 1
D
x 2
M3.5 x 14 mm
J1
D c
M3.5 x 40 mmM3.5 x 14 mm
A
A
A
A
A
A
A
A
A
DD
J1
Insert quickfit screw(A) into corresponding
holes in No.2 plate with a screwdriver as shown.
Separate glide into two parts at first.
Fix slide rail(J1) to No.5 plate with screw(D) as shown.

8/21
4
Jx 1
D x 2
M3.5 x 14 mm
J1
D c
M3.5 x 40 mmM3.5 x 14 mm
D
D
D
J1
5
Ax 8
M6 x 40 mm
AA
AA
AA
A
D
J1
Fix slide rail(J1) to No.6 plate with
screw(D) as shown.
Insert quickfit screw(A) into corresponding holes in
No.5 and No.6 plate with a screwdriver as shown.
A
A

9/21
6
Bx 8
15 x 12 mm
BK
15 x 12 mm 12 x 10 mm
B
B
B
B
B
B
B
B
B
Connect No.5 and No.6 plate with No.7 and No.8, then turn cam lock(B)
in No.7,8 plate clockwise to tighten as shown.
Slide No.9 plate into slots between No.5 and No.6 plate as shown.

10/21
7
Bx 4
15 x 12 mm
B
B
B
B
B
BK
15 x 12 mm 12 x 10 mm
Attach the component to No.2 plate, then turn cam lock(B) in No.5,6
plate clockwise to tighten as shown.

11/21
8
F
Bx 4
15 x 12 mm
B
B
B
B
B
9
BK
15 x 12 mm 12 x 10 mm
Attach No.3 and No.4 to No.2 plate, then turn cam lock(B)
in No.3,4 plate clockwise to tighten as shown.
Slide No.9 and No.10 plate
into available slots as shown.

12/21
10
Ax 8
M6 x 40 mm
Bx 8
15 x 12 mm
Fx 32
F
F
F
F
F
F
FF
F
F
F
F
F
F
B
BB
B
B
BB
B
A
A
A
A
A
A
A
A
F
A
BK
15 x 12 mm 12 x 10 mm
Insert quickfit screw(A) into corresponding holes in
No.1 plate with a screwdriver as shown.
Cover No.1 plate to the top, then turn cam lock(B)
in No.3,4,5,6 plate clockwise to tighten as shown.
Insert part(F) into corresponding holes in No.3,4,5,6
plates as shown.

11
13/21
Ex 2
12
D x 8
M3.5 x 14 mm M4 x 20 mm
D c
M3.5 x 40 mmM3.5 x 14 mm
G x 4
GH
E1
E2
E2
E2
E2
D
D
D
D
D
DD
DD
G
G
G
G
G
D
E1
Place No.11 and No.12 shelf in.
Fix hinge(G) to No.18
and No.19 plate
respectively with
screw(D) as shown.
Fix handle(E1) using
screw(E2) as shown.
E2
E2
E1

13
Hx 4
14/21
Ex 2
D x 8
M3.5 x 14 mm M4 x 20 mm
D c
M3.5 x 40 mmM3.5 x 14 mm
GH
D
D
DD
D
D
DD
DD
H
H
H
H
HE2
E2
E2 E2
E1
E1
14
D
x 32
M3.5 x 14 mm
D c
M3.5 x 40 mmM3.5 x 14 mm
H
D
DD
D
DG
D
D
H
Fix hinge(H) to No.20 and No.21
plate respectively with screw(D)
as shown.
Fix handle(E1) using screw(E2)
as shown.
Attach No.18 door plate to No.3; No.19 door plate to No.4; No.20 door
plate to No.5; No.21 door plate to No.6 by fixing hinge with screw(D) as
shown.
E2 E2
E1

15
15/21
Ax 4
M6 x 40 mm
Kx 4
12 x 10 mm
16
BK
15 x 12 mm 12 x 10 mm
K
K
K
K
K
K
Insert quickfit screw(A) into No.13 plate with a screwdriver at first.
Attach No.14 and No.15 plate to No.13, turn cam lock(K) clockwise
to tighten as shown.
Slide No.17 plate into available slots as shown.
A
A
A
A
A
A

C
C
C
C
16
D
D
D
D
J2
J2
J2
E2
17
Cx 4
16/21
D c
M3.5 x 40 mmM3.5 x 14 mm
M3.5 x 40 mm
18
Jx 2
Ex 1
D
x 4
M3.5 x 14 mm M4 x 20 mm
D c
M3.5 x 40 mmM3.5 x 14 mm
J2
DD
C
CAttach No.16 plate and fix with No.14
and No.15 using screw(C) as shown.
Fix runner(J2) to No.14 and No.15
plate using screw(D) as shown.
E2
E1

19
17/21
20
M x 28
M
M
M
M
MM
M
MM
M
M
MM
M
M
MM
M
M
M
MM
M
M
MM
M
M
M
Align rails, slide the drawer.
Reinforce back plate using
part(M) as shown.

21
Nx 1
18/21
N
Install anti-tipping device(N) as shown.

22
19/21

WARRANTY CLAIMS
•There is a 30-day warranty for broken furniture or any other problems that do not
work properly. The warranty will start from the date of purchase which must be
verified by proof of purchase.
•Before making a claim, we may be able to answer your query, simply call us. Please
leave your purchase order number, along with some details of the problem, if you
want a replacement part. We will arrange within 48 hours. If there is out of stock,
we will reply with a shipping date.
•The product must be used in accordance with the instructions provided. For health
reasons.
•For other reasons, if the furniture needs to be returned, it must be cleaned and dried
and operated within 30 days of receipt.
Type of Warranty Claim
•Failure to follow the furniture instructions will invalidate the warranty. Attention please.
•Does not include damage during installation, but includes damage during transportation.
Scope of responsibility
•Shall not bear any responsibility for misuse or user damage and / or loss of parts during
the installation of furniture.
•After using, the damage and scratches of the furniture are not covered by the warranty.
The Warranty Relates to All Bought in The Us and Covers The
Following Areas
•Sheet parts: 1 month from the date of purchase.
•Electrical parts: 1 month from the date of purchase.
WARRANTY
