FUFU & GAGA KF200053-01 User manual

Sideboard
Version:06/16/2022 1/14
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA

2/14
please read the entire manual before starting to assemble
and/or using this product.follow the manual thoroughly and
keep it for further reference.
IMPORTANT INFORMATION!
It is important that any product which is assembled using any kind of screw is re-tightened
2 weeks after assembly,and once every 3 months - in order to assure stability through-out
the lifespan of the product.
For regular maintenance and cleaning of the product, for the frame, please use a rag dipped
in neutral detergent to fully wipe it, and then dry it with a clean rag.For glass materials, wipe
with a rag dampened with water glass cleaner, and then dry with a dry rag.
Do not use an electric screwdriver, and do not use too much force when installing, because
the board is easy to break.
IMPORTANT !
Overturned furniture can cause serious or fatal crush injuries. To prevent tipping over, be sure
to use the wall attachment, if not included with this product. Please purchase the wall
attachment that fit your wall. If unsure, seek professional advice. Please read and follow each
step of the instructions carefully.
ANTI-TOPPLE WARNING !
Try to find a partner to install
with you, which can speed up
the installation efficiency and
shorten the time.
IMPROVE EFFICIENCY !
In order to avoid scratching this
furnuture should be assembled
on a soft layer-could be a rug.
AVOID SCRATCHES!
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA

7 x 35 mm
A x 9
L x 12
M x 1 N x 1
B x 12 C x 12 D x 1 E x 2
F x 8 I x 20 J x 4 K x 12
15 x 9 mm4 x 35 mm
3.5 x 12 mm 4 x 14 mm
3/14
4 x 16 mm
O x 2 P x 1
DL x 1 DR x 1
CL x 1
CR x 1
mm
mm
2.5 x 14 mm
6 x 30 mm
mmmm
6 x 30 mm
3.5 x 14 mm
When installing, please carefully confirm whether
each screw corresponds to the manual, accessories
with similar shapes can be distinguished by size
Please prepare the following tools
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA

4/14
1
2
3
4
5
8
9
6
7
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA

1
A x 4
2
5/14
Fix part 1 and 3 to part 2 using screw (A)
A
A
Fit part 4 into groove between part 1.2 and 3.
4 x 35 mm
1
A
A
A
A
2
3
4
1
23
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA

3
4
Insert quickfit screw (B) to panel 5.
Secure handle (D) on to the assembled
drawer using screw (E).
7 x 35 mm
15 x 9 mm
B x 4
C x 4
III III
C
C
C
C
1
3
4
180° 5
6/14
C
B
BB
BB
E
E
D
Insert cam lock (C) to panel 1 and 3.
Fit panel 5 to panel 1 and 3.
Turn cam locks clockwise to tighten.
E
E
D
5
D x 1 E x 2
4 x 16 mm
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA

5
6
Carefully turn drawer upside down.
Fix inner drawer runner (DR) to panel 1 and (DL)
to panel 3 using screws (F) , as show.
Fix leg plates (J) to part 8 using screw (I).
DL x 1F x 4 DR x 1
3.5 x 12 mm mm mm
F
F
F
F
F
F
DL
DR
DR 3
4
5
I x 20
4 x 14 mm
J x 4
I
J
8J
J
J
J
I
I
I
I
7/14
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA

Insert qucikfit screws (B) to part 6 and 7.
Fix outer drawer runner (CL) to panel 6
and (CR)
to panel 7 using screw (F) ,
as shown.
7
CL x 1
F x 4 CR x 1
mm mm
3.5 x 12 mm
F
F
F
F
CL
CR
6
7
7 x 35 mm
B x 4
B
B
B
B
B
8/14
CL
CL
F
F
F
F
CR
CR
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA

8
C x 4
Insert qucikfit wooden dowels (K) to
part 6 and 7.
Insert part 6 and 7 to part 9.
Insert camlocks (C) to part 9 .
Turm camlocks clockwise to tighten.
C
180°
9
K
C
C
C
C
K
K
K
6
7
K x 4
15 x 9 mm 6 x 30 mm
9/14
III III
K
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA

9
A x 4
Insert wooden dowels (K) to part 6 and 7.
Fix panel 8 to part 6 and 7 unit using screws (A).
4 x 35 mm
10
B x 4
B
B
B
B
B
A
A
A
A
7 x 35 mm
K x 4
6 x 30 mm
K
K
K
K
K
A
6
7
8
Insert qucikfit screws (B) and wooden
dowels (K) to part 10.
10/14
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA

11
C x 4 K x 4
6 x 30 mm
C
180°
Insert camlocks (C) to part 6 and 7.
Insert part 10 to part 6 and 7.
Turm camlocks clockwise to tighten. III III
K
K
K
K
KC
C
C
C
6
7
15 x 9 mm
11/14
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA

12
L x 12
13
Fix part 11 onto back of assembled unit using nails (L).
Screw legs 12 into leg
plates (J) as shown.
2.5 x 14 mm
L
L
L
L
L
L
L
L
L
L
L
L
L
8
12/14
J
J
J
J
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA

14
Slide drawer into assembled unit.
DL
CL
13/14
CR
DR
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA

15
A x 1 P x 1
N x 1 O x 2
14/14
A
A
MO
N
P
P
O
O
O
M
N
For extra stability , it is recommended that you
fix your shelf to the wall using the additional
hardware ( A , M , N , O and P ) , as shown .
Should you choose not to affix the product to the
wall , serious injury may be caused if the
product tips over.
Please consider the wall
mounting and fixing guide
when securing your product .
4 x 35 mm 6 x 30 mm 3.5 x 14 mm
M
WALL
drilling hole
Ø6x30mm
WALL
N
M x 1
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA

WARRANTY CLAIMS
•There is a 30-day warranty for broken furniture or any other problems that do not
work properly. The warranty will start from the date of purchase which must be
verified by proof of purchase.
•Before making a claim, we may be able to answer your query, simply call us. Please
leave your purchase order number, along with some details of the problem, if you
want a replacement part. We will arrange within 48 hours. If there is out of stock,
we will reply with a shipping date.
•The product must be used in accordance with the instructions provided. For health
reasons.
•For other reasons, if the furniture needs to be returned, it must be cleaned and dried
and operated within 30 days of receipt.
Type of Warranty Claim
•Failure to follow the furniture instructions will invalidate the warranty. Attention please.
•Does not include damage during installation, but includes damage during transportation.
Scope of responsibility
•Shall not bear any responsibility for misuse or user damage and / or loss of parts during
the installation of furniture.
•After using, the damage and scratches of the furniture are not covered by the warranty.
The Warranty Relates to All Bought in The Us and Covers The
Following Areas
•Sheet parts: 1 month from the date of purchase.
•Electrical parts: 1 month from the date of purchase.
WARRANTY
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA
FUFU&GAGA

CHANGED YOUR MIND AND NEED TO RETURN YOU ITEM?
PLEASE FOLLOW THE BELOW INSTRUCTIONS:
•If you have purchased and have simply changed your mind, follow the retailer’s
instructions for returns.
DEFECTIVE ITEMS
•If your item is defective in any way, i.e. it doesn’t work but you can’t identify why, in
the first instance, please consult our FAQ section at [email protected] as there
may be a simple solution to the issue.
DAMAGED ITEMS
•If you receive an order with obvious shipping damage from the retailer, then we suggest
the delivery is refused. If the delivery has been accepted and then shipping damage is
found, please follow the specific instructions advised by the retailer.
In all circumstances please save all packaging material and paperwork for the order.
Please be aware that if you dispose of packaging material or attempt to return the
merchandise without contacting the fulfiller, you jeopardise your chances of making a
claim, and you may not receive a credit for the return.
