FUFU & GAGA Lockers User manual

Version:07/04/2022 1/12
Lockers

please read the entire manual before starting to assemble
and/or using this product.follow the manual thoroughly and
keep it for further reference.
IMPORTANT INFORMATION!
It is important that any product which is assembled using any kind of screw is re-tightened
2 weeks after assembly,and once every 3 months - in order to assure stability through-out
the lifespan of the product.
For regular maintenance and cleaning of the product, for the frame, please use a rag dipped
in neutral detergent to fully wipe it, and then dry it with a clean rag.For glass materials, wipe
with a rag dampened with water glass cleaner, and then dry with a dry rag.
Do not use an electric screwdriver, and do not use too much force when installing, because
the board is easy to break.
IMPORTANT !
Overturned furniture can cause serious or fatal crush injuries. To prevent tipping over, be sure
to use the wall attachment, if not included with this product. Please purchase the wall
attachment that fit your wall. If unsure, seek professional advice. Please read and follow each
step of the instructions carefully.
ANTI-TOPPLE WARNING !
Try to find a partner to install
with you, which can speed up
the installation efficiency and
shorten the time.
IMPROVE EFFICIENCY !
In order to avoid scratching this
furnuture should be assembled
on a soft layer-could be a rug.
AVOID SCRATCHES!
2/12

When installing, please carefully confirm whether
each screw corresponds to the manual, accessories
with similar shapes can be distinguished by size
Please prepare the following tools
3/12
15 x 9 mm
6 x 35 mm
4 x 35 mm 4 x 14 mm
6 x 30 mm
A x 8 B x 8 C x 16
G x 8 H x 4
P x 2
J x 14
E x 4 F x 32
M x 1
N x 12
D x 4
K x 4 L x 1
Q x 14
3 x 16mm
4 x 30 mm
4 x 25 mm

4/12
1
2
10
4
5
5
6
5
12
11
3
8
9
7

Please pay attention to the
holes where the accessories
are inserted and don't use
an electric screwdriver or
use force to rotate, may cause crack.
11
5/12
15 x 9 mm
6 x 35 mm 6 x 30 mm
A x 4 B x 4 C x 8
IIIIII
2
15 x 9 mm
6 x 35 mm 6 x 30 mm
A x 4 B x 4 C x 4
C
C
C
C
A
C
C
A
B
B
B
A
CB
CA
2
6
3
4
A
C
A
C
B
B
C
A
A
C
3
1
62A
A
A
B
B
BA
CB C
CC
1
3
Insert quickfit screw(A) and wooden dowel(C)
into No.2 and No.3 plates as shown.
Attach No.4 and No.6 plates to the two plates,
turn cam locks(B)clockwise to tighten as shown.
Insert quickfit screw(A) and wooden
dowel(C) into No.1 plate at fisrt.
Cover No.1 plate to the component,
turn cam locks(B)clockwise
to tighten as shown.

3
6/12
4
6 x 30 mm
E x 4
C x 4
4 x 35 mm
1
4
3
6
2
11
10
12
3
11
10
7
CC
CCE
E
E
E
E
E
3
Insert No.10 and No.11 plates into available
slots as shown. Please note connect No.11
and No.10 plates with No.12.
Cover No.7 plate to the component with
wooden dowel(C), use screw(E) to fix.

5
7/12
D x 4 K x 4
6
F x 16 G x 8
H x 4 P x 2
4 x 14 mm
D
K
D
D
D
D
1
4
3
6
2
7
8
9
HH
P
G
FF
9
8
FF
FF
FF
FF
FF
FF
FF
FF
HH
HH
G
G
G
G
G
G
G
G
P
P
4 x 30 mm
4 x 25 mm
7
Fix leg(K) to the No.7 with screw(D) as shown.
Fix hinge(G) into No.8 and No.9
plates with screw(F) as shown.
Fix handle(P) to No.8 and
No.9 plates with screw(H)
as shown.

7
8/12
N x 12
5
5
5
6
3
1
2
OR
OR
N
N
N
NN
N
N
N
N
N
N
N
N
NN
Insert part(N) into sides of No.2 and No.3 plates as shown.
Put No.5 plates.

8
9/12
F x 16
4 x 14 mm
2
8
F
F
F
F
F
F
F
F
F
F
3
1
210
5
6
5
5
9
8
Attach No.8 to No.2, No.9 to No.3 by
fixing hinge with screw(F) as show.

9
If there is misalignmAent after you install,
adjust the screw to the best condition
