FUFU & GAGA KF200165 User manual

Shoe Bench
Version:06/28/2022 1/13

please read the entire manual before starting to assemble
and/or using this product.follow the manual thoroughly and
keep it for further reference.
IMPORTANT INFORMATION!
It is important that any product which is assembled using any kind of screw is re-tightened
2 weeks after assembly,and once every 3 months - in order to assure stability through-out
the lifespan of the product.
For regular maintenance and cleaning of the product, for the frame, please use a rag dipped
in neutral detergent to fully wipe it, and then dry it with a clean rag.For glass materials, wipe
with a rag dampened with water glass cleaner, and then dry with a dry rag.
Do not use an electric screwdriver, and do not use too much force when installing, because
the board is easy to break.
IMPORTANT !
Overturned furniture can cause serious or fatal crush injuries. To prevent tipping over, be sure
to use the wall attachment, if not included with this product. Please purchase the wall
attachment that fit your wall. If unsure, seek professional advice. Please read and follow each
step of the instructions carefully.
ANTI-TOPPLE WARNING !
Try to find a partner to install
with you, which can speed up
the installation efficiency and
shorten the time.
IMPROVE EFFICIENCY !
In order to avoid scratching this
furnuture should be assembled
on a soft layer-could be a rug.
AVOID SCRATCHES!
2/13

When installing, please carefully confirm whether
each screw corresponds to the manual, accessories
with similar shapes can be distinguished by size
Please prepare the following tools
3/13
CL x 2 CR x 2
C x 16 D x 22
3 x 12 mm 6 x 35 mm 6 x 30 mm
4 x 35 mm 3 x 12 mm
15 x 9 mm
DL x 2
E x 22
H x 18
G x 10
F x 20
DR x 2

4/13
1
2
9
4
6
5
7
3
8
8
12
13
11
14
10
X2

11
5/13
2
CL x2 CR x 2
3 x 12 mm
Cx8
6 x 35 mm
D x 2
6 x 35 mm
D x 12
2
4
5
7
3
CL
CL
CR
CR
C
C
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
C
C
C
C
C
C
C
CR
CL
C
Fix slide rail(CL) and (CR) to No.3 and
No.4 plate with screw(C) as shown.
Insert quickfit screw(D) into corresponding
holes in No.3 and No.4 plate with a
screwdriver.
Insert quickfit screw(D) into corresponding
holes in No.2, No.5 and No.7 plate with a
screwdriver.

3
6/13
15 x 9 mm
E x4
6 x 30 mm
F x4
IIIIII
7
7
E
E
E
E
E
F
F
F
F
F
8
8
8
8
Attach No.8 plate to No.7 with wooden
dowel(F), then turn cam lock(E) in No.8
plate clockwise to tighten as shown.
180°

4
7/13
5
6 x 30 mm
F x2
4 x 35 mm
G x2
6 x 30 mm
F x2
4
7
F
F
G
G
G
F
F
F
4
4
7
6
6
Connect No.4 plate with No.7 using
wooden dowel(F), then fix with screw(G)
as shown.
Connect No.6 plate with No.4 using
wooden dowel(F) as shown.

6
8/13
IIIIII
6 x 30 mm
F x4
4
5
5
7
7
6
E x2
15 x 9 mm
E
E
E
F
F
F
F
Connect No.5 plate with No.6 and No.7
using wooden dowel(F),then turn cam
lock(E) in No.7 plate clockwise to tighten
as shown.
180°

7
9/13
IIIIII
4
3
3
7
7
6 x 30 mm
F x2
E x2
15 x 9 mm
E
E
E
F
F
F
F
Connect No.3 plate with No.7 using
wooden dowel(F),then turn cam lock(E)
in No.7 plate clockwise to tighten as
shown.
180°

8
10/13
IIIIII
4
3
2
2
6 x 30 mm
F x6
E x6
15 x 9 mm
E
E
E
E
E
E
E
F
F
F
F
F
F
F
F
Attach No.2 plate to the top of the
component using wooden dowel(F),
then turn cam lock(E) in No.3,4,5
plates clockwise to tighten as shown.
180°

9
11/13
10
3 x 12 mm
H x18
6 x 35 mm
D x8
4 x 35 mm
G x8
3
9
2
H
H
HH
H
H
H
H
H
H
HH
H
H
H
H
H
H
H
G
G
G
G
G
G
DD
DD
DD
X2
12
13
11 10
Fix No.9 back plate using screw(H) as shown.
Attach No.11 and No.12 plate to No.13 with
screw(G) as shown.
Insert quickfit screw(D) into No.10 plate
with a screwdriver.

11
12/13
12
IIIIII
E x8
15 x 9 mm
DR x2 DL x2 C x8
3 x 12 mm
X2
X2
12 12
13
11 11
14
14
14
10
10
180°
E
E
E
E
E
E
DR
DR
C
C
DR
C
C
C
C
DL
Slide No.14 plate into available
slots as shown.
Attach No.10 plate to
the component and
turn cam lock(E)
clockwise to tighten
as shown.
Fix runner(DL) and (DR) to No.11 and No.12 plate with screw(C)
as shown.

13
13/13
2
2
3
1
3
10
10
Align rails, slide drawers.
Put pad at the top.
