USER’S MANUAL
Inverter for Home Elevator
PLC Function Manual
<Type: HHE-3.0CL1S-7GH1>

Preface
Thank you for purchasing Fuji Inverter for Home Elevator.
This user's manual describes the specifications and operations of the PLC function of the Inverter for Home Elevator.
Read this manual carefully to ensure correct operation. When using modules or peripheral devices, be sure to read the
corresponding user's manuals listed below:
* In addition to the above manuals, the following Fuji Electric FA Components & Systems Co., Ltd. site offers various manuals
and technical documents associated with MICREX-SX.
URL http://www.fujielectric.co.jp/fcs/eng/
Notes
1. This manual may not be reproduced in whole or part in any form without prior written approval by the manufacturer.
2. The contents of this manual (including specifications) are subject to change without prior notice.
3. If you find any ambiguous or incorrect descriptions in this manual, please write them down (along with the manual No.
shown on the cover) and contact FUJI.
Title Manual No. Contents
User's Manual Instruction,
MICREX-SX SPB series FEH202 Explains the memory, language and system definitions of the MICREX-SX SPB series.
User's Manual D300win <Reference>,
MICREX-SX series FEH257 Explains the installation procedure, functions and operations o
f
D300winV3.
User's Manual D300win <LD/FBD Editor>,
MICREX-SX series FEH257-1 Explains the operations of LD/FBD added to D300winV3.

Safety Precautions
Be sure to read the "Safety Precautions" thoroughly before using the module.
Here, the safety precautions items are classified into "Warning" and "Caution".
Warning
Caution
: Incorrect handling of the device may result in death or serious injury.
: Incorrect handling of the device may result in minor injury or physical damage.
Even some items indicated by "Caution" may result in a serious accident.
Both safety instruction categories provide important information. Be sure to strictly observe these instructions.
Warning
Never touch any part of charged circuits as terminals and exposed metal portion while the power is turned ON.
It may result in an electric shock to the operator.
Turn OFF the power before mounting, dismounting, wiring, maintaining or checking, otherwise, electric shock, erratic
operation or troubles might occur.
Place the emergency stop circuit, interlock circuit or the like for safety outside the PLC. A failure of PLC might break or
cause problems to the machine.




Safety Precautions
Do not use one found damaged or deformed when unpacked, otherwise, fire, failure or erratic operation might be
caused.
Do not shock the product by dropping or tipping it over, otherwise, it might be damaged or troubled.
Follow the directions of the operating instructions when mounting the product.
If mounting is improper, the product might drop or develop problems or erratic operations.
Use the rated voltage and current mentioned in the operating instructions and manual. Use beyond the rated values
might cause fire, erratic operation or failure.
Operate (keep) in the environment specified in the operating instructions and manual. High temperature, high humidity,
condensation, dust, corrosive gases, oil, organic solvents, excessive vibration or shock, might cause electric shock, fire,
erratic operation or failure.
Select a wire size to suit the applied voltage and carrying current. Tighten the wire terminals to the specified torque.
Inappropriate wiring or tightening might cause fire, malfunction, failure or might cause the product to drop from its
mounting.
Contaminants, wiring chips, iron powder or other foreign matter must not enter the device when installing it, otherwise,
fire, accident, erratic operation or failure might occur.
Periodically make sure the terminal screws and mounting screws are securely tightened.
Operation at a loosened status might cause fire or erratic operation.
Sufficiently make sure of safety before program change, forced output, starting, stopping or anything else during the
system running. Wrong operation might break or cause problems to the machine
Engage the loader connector in a correct orientation, otherwise, an erratic operation might occur.
Before touching the PLC, discharge any static electricity that may have been collected on your body. To discharge it,
touch a grounded metallic object. Static electricity might cause erratic operation or failure.
Be sure to install the electrical wiring correctly and securely, observing the directions of the operating instructions and
manual. Wrong or loose wiring might cause fire, accident or failure.
When disengaging the plug from the outlet, do not pull the cord, otherwise, break of cable might cause fire or failure.
Do not press on the key switches with an object having a sharp edge, such as tweezers and tool. Do not press them too
strongly Otherwise, they might be flawed or damaged.
Do not attempt to repair the module by yourself, but contact your Fuji Electric agent. When replacing the batteries,
correctly and securely connect the battery connectors, otherwise, fire, accident or failure might occur.
Do not remodel or disassemble the product, otherwise, failure might occur.
Follow the regulations of industrial wastes when the device is to be discarded.
If you intend to use the modules covered in these operating instructions for special applications, such as for nuclear
energy control, aerospace, medical or transportation, please consult your Fuji Electric agent.
Be sure to provide protective measures when using the module covered in these operating instructions in equipment
which, in the event of failure, can lead to loss of human life or other grade results.
Caution




















Revision
*The manual No. is printed at the bottom right of the cover of this manua
l.
Printed on *Manual No. Revision contents
Jan. 2006 FEH425 First edition
Feb. 2006 FEH425a Some mistakes were corrected.
Oct. 2006 FEH425b The product type was changed.
Old type: FRN3.0CL1S-7GH
New type: HHE-3.0CL1S-7GH1

Contents
Preface
Safety Precautions
Revision
Contents
Section 1 PLC Specifications
1-1 Performance Specifications..................................................................................................... 1-1
1-2 PLC Internal Memory ................................................................................................................ 1-3
1-2-1 Memory map ................................................................................................................................. 1-3
1-2-2 I/O address assignment ............................................................................................................... 1-4
1-2-3 External interrupt input .................................................................................................................. 1-6
1-2-4 System memory ............................................................................................................................ 1-7
1-2-5 Memory for inverter communication ............................................................................................. 1-16
Section 2 System Definition
2-1 Overview of System Configuration.......................................................................................... 2-1
2-2 System Definition ...................................................................................................................... 2-1
2-2-1 List of system definition ................................................................................................................ 2-2
2-2-2 Setting parameter of the PLC........................................................................................................ 2-2
Section 3 Inverter Communication
3-1 Memory for Inverter Communication ...................................................................................... 3-1
3-2 Data Write Program .................................................................................................................. 3-2
3-3 Data Read Program .................................................................................................................. 3-3
3-4 Error Code ................................................................................................................................. 3-4
3-5 Inverter Function Code and Write/Read No. .......................................................................... 3-4
Section 4 High-speed Counter
4-1 High-speed Counter Specifications ......................................................................................... 4-1
4-1-1 List of specifications ..................................................................................................................... 4-1
4-1-2 Pin layout of encoder input ........................................................................................................... 4-2
4-1-3 List of system memory for high-speed counter........................................................................... 4-2
4-1-4 Operation modes of high-speed counter .................................................................................... 4-4
4-1-5 Timing chart .................................................................................................................................. 4-6
4-2 How to Use High-speed Counter .............................................................................................. 4-7
4-2-1 Setting system definition .............................................................................................................. 4-7
4-2-2 Catching the current value ............................................................................................................ 4-8
4-2-3 Resetting the current value ........................................................................................................... 4-8
4-2-4 Presetting the current counter value ............................................................................................ 4-8
4-2-5 Setting comparison value ............................................................................................................. 4-8
4-2-6 Match interrupt ............................................................................................................................... 4-8
Page

Contents
Appendix 1 Access Restriction by Password
Appendix 1-1 Overview ................................................................................................................... App.1-1
Appendix 1-2 Specifications of Access Restriction Function ...................................................... App.1-2
Appendix 1-2-1 Operating range for each access level ....................................................................... App.1-2
Appendix 1-2-2 Functions to manage password ................................................................................. App.1-3
Appendix 1-3 How to Use Password .............................................................................................. App.1-4
Appendix 1-3-1 Registering password ................................................................................................. App.1-4
Appendix 1-3-2 Password authentication ............................................................................................. App.1-7
Appendix 1-3-3 Changing password .................................................................................................... App.1-8
Appendix 1-3-4 Clearing password ...................................................................................................... App.1-10
Appendix 1-4 Notes on Use............................................................................................................. App.1-11
Page

1-1
Section 1 PLC Specifications
1-1 Performance Specifications
Item Specification
Control system Stored program, Cyclic scanning system (default task),
periodic task, event task
Programming language IL, ST, LD, FBD, SFC
No. of I/O points Input: 48 points (24V DC input: 22 points, 48V DC input: 26 points) Output: 36 points (24V DC Tr output: 35 points)
Encoder input: 2 channels (One channle is option.)
Instruction execution
speed Sequence instruction Contact: min. 0.38µs, Coil: min. 0.44µs
Applied instruction Timer: min. 16.22µs, Counter: min. 12.05µs
Program memory capacity (Note 2) 8192 steps
Max. program capacity in one POU 8192 steps
Memory
(Note 1)
I/O memory (I, Q) 512 steps
General memory (M) 4800 words
Retain memory (M) 2048 words
Instance memoryfor user FB (F) 2560 words
4096 words
Instance
memory for
system FB
Timer (T) 128 points
Integrating timer (T) 32 points
Counter (C) 64 points
Edge detection 256 points
Others 2048 words
Memory for inverter communication 544 words
System memory (SM) 512 words
Temporary memory 4096 words
Available basic data type (Note 3) BOOL, INT, DINT, UINT, UDINT, TIME, DT, WORD, DWORD
Max. No. of elements of array data type 16-bit data: 4096, 32-bit data: 2048
No. of structure data type members 200
Data type nesting 1 level (Array of arrays, Array of structures)
No. of tasks
Default tasks : 1
Periodic tasks: Max. 4,
Event tasks: Max. 4
* Total of periodic tasks and event tasks: Max. 4
No. of programs in one CPU Max. 256 (Max. no. of programs allowed in one task =128)
No. of user function blocks 512
No. of user functions 512
Nesting of user function and user FB 128 levels
Variable Global variable 8000
Local variable 8000
No. of user FB terminals Total of VAR_INPUT, VAR_OUTPUT, and VAR_IN_OUT: Max. 128
Library No. of registrations 16 (for one project)
Nesting 8 levels
Diagnostic function Self-diagnosis (memory check, ROM sum check), system configuration
supervising, fault monitioring
Security function Programs can be protected by password.
Calendar function Available up to 31 Dec. 2069 23:59:59 27s/month
Backup time Backup time by battery: Approx. 5 years (at ambient temperature of 25 )

Section 1 PLC Specifications
1-2
1-1 Performance Specifications
Note 1: The area sizes of the standard memory, retain memory, memory for user FB and memory for system FB can freely be
increased or decreased.
Note 2: The initial value setting areas of the standard memory and retain memory are included.
Note 3: This depends on each instruction.
Note 4: When the PLC is started up with data of the internal RAM lost, it operates as follows:
All data of the internal RAM are cleared to “0”.
The “ALM LED” lights up.
The nonfatal fault flag, memory error flag, and memory backup error flag are set to ON. You can check the error with
the diagnostic function of the loader.
To restore the system, set the memory backup error flag to OFF with the user program or loader, or power this board
off and on again. The nonfatal fault flag and memory error flag are set to OFF and the “ALM LED” goes out.
Backup
(Note 4)
Backup time Backup time by battery: Approx. 5 years (at ambient temperature of 25
)
Program, system definition area Built-in flash memory, built-in RAM: Backed up by battery
Data memory, RAS Built-in RAM: Backed up by battery
ZIP file Built-in flash memory
Calendar Built-inRAM: Backed up bybattery

1-3
Section 1 PLC Specifications
1-2 PLC Internal Memory
1-2-1 Memory map
Note 1: The size of standard memory, retain memory, user FB memory, and system FB memory may be increased or
decreased by the loader settings. Default values are shown in the figure above. For details of the setting, “2-3-3 (2)
Memory allocation setting.”
Note 2: For the input/output address assignments, refer to “1-2-2 I/O address assignment.”
Note 3: It is possible to set the initial values of standard memory and retain memory using the free space of program memory.
Initial values require 2.5 steps for one address.
%IW %QW
%MW1.0
%MW3.0
%MW8.0
%MW10.0
Input/output memory
(I/Q)
512 words (8192 points)
Standard memory
(M)
4800 words
Retain memory
(M)
2048 words
User FB memory
(M)
2560 words
System FB
instance memory
(M)
4096 words
Inverter communication
memory
(M)
544 words
Program memory
8192 steps
Initial value setting area
for standard memory and
retain memory (Note 3)
Temporary area
4096 words
Note 2
Note 1
(Input) (Output)
System memory
(SM)
512 words

Section 1 PLC Specifications
1-4
1-2-2 I/O address assignment
Signals are assigned to the I/O memory as follows:
(1) I/O connector layout
The figure below shows the I/O connector layout of this board.
1-2 PLC Internal Memory
(2) Signal assignment to I/O area
To the I/O memory, in addition to I/Os for external devices, signals for the inverter are assigned.
CNIN1
CNIN2
CNIN3
CNIN4
CNOUT1
CNOUT2
24V DC input
48V DC input
24V DC Tr output
For encoder input
CN17
Di00 to Di11
Di12 to Di21
Di22 to Di27
Di28 to Di47
Do00 to D015
Do16 to D034
PLC loader connector
Common terminal for I/O
%IW0.0
%IW0.1
%IW0.2
%IW0.3
%QW0.0
%QW0.1
%QW0.2
%QW0.3
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Di00
Do00Do01Do02Do03Do04Do05Do06Do07Do08Do09Do10Do11Do12Do13Do14Do15
Do16Do17Do18
Do32
X1X2X3X4X5X6X7X8
Do33Do34FWDREV
Do19Do20Do21Do22Do23Do24Do25Do26Do27Do28Do29Do30Do31
Di16Di17Di18Di19Di20Di21Y1Y2Y3Y4Y5
Di01Di02Di03Di04Di05Di06Di07Di08Di09Di10Di11Di12Di13
30B
Di14Di15
Di22Di23Di24Di25Di26Di27Di28Di29Di30Di31
Di38Di39Di40Di41Di42Di43Di44Di45Di46Di47
Di32Di33Di34Di35Di36Di37

1-5
Section 1 PLC Specifications
1-2 PLC Internal Memory
(3) Explanation of signals
Signal name Description
Di00 - Di21 24V DC input
Di22 - Di47 48V DC input Di22 can be used as external interrupt input.
Y1* Inverter running
Y2* Speed match
Y3* Brake control
Y4* Accelerating
Y5* Decelerating
30B* Warning input Warning input from inverter
Do00 - 34 24V DC Transistor sink output
FWD* Forward command to inverter
REV* Reverse command to inverter
X1 - X3* Speed command 0 to 7 steps
X4* Warning reset
By setting this flag to ON, warning input from inverter (30B) is set to OFF.
X5* Enable coast-to-stop
X6 - X8* Universal DI
Note: I/O signal assignment to the inverters with an asterisk (*) can be changed. The table above describes the initial settings.
(4) Address representation
The address representation in a PLC application is as follows:
%[Prefix] [Unit No.]. [Word No.] [Bit address]
Prefix ..................... Input I (bit), IW (word), ID (double-word)
Output Q (bit), QW (word), QD (double-word)
Word No. .............. For this board, fixed to 0 (zero).
Bit address .......... This is a bit address (0 to 15) of each word.

Section 1 PLC Specifications
1-6
1-2 PLC Internal Memory
1-2-3 External interrupt input
Di22 (No. 1 pin of CNIN3) has the external interrupt input function to activate an event task other than ordinary 48V DC input.
(1) Interrupt circuit configuration
External interrupt input A
N
D
Interrupt activation
%MX10.268.3 %MX10.266.3
%MX10.268.15
Ordinary 48V DC digital input
External
input signal
Latch
CNIN3
No. 1 pin
Interrupt
enabled/diasled
Power-on reset or
reset by interrupt
acceptance
Batch reset of
interrupt factor latch
(2) Assigning the intterupt activation flag to an event task
To activate an event task by an external interrupt signal, it is necessary to assign the external interrupt activation flag
(%MX10.266.3) to an event variable.
Interrupt input is held temporarily by an internal latch circuit. The default of the latch circuit status is “0” (reset).
To enable interrupt, set the external interrupt enable flag (%MX10.268.3) to ON. The interrupt is disabled (the flag is set OFF)
by default.
If the interrupt is enabled when an interrupt input is already held, the interrupt is activated immediately.
To reset a latch circuit, set the system memory (%MX10.268.15) to ON. When the flag is set to ON, all the latch circuits will
be reset. The latch circuits for comparison match interrupts of high-speed counter are reset at the same time.
When an interrupt program is started, the interrupt latch circuits are reset automatically.

1-7
Section 1 PLC Specifications
1-2-4 System memory
(1) PLC operation/state status %MW10.0 to 10.1 (Read only)
Address Name Description
%MX10.0.0 Run Set to "ON" while the PLC is running.
%MX10.0.1 Stop Set to "ON" while the PLC is down.
%MX10.0.2 Fatal fault Set to "ON" when a fatal PLC error has occurred.
%MX10.0.3 Nonfatal fault Set to "ON" when a non-fatal PLC error has occurred.
%MX10.0.4
|
%MX10.0.8 Not used
%MX10.0.9 Automatic operation mode Set to "ON" while in the automatic operation mode. In this mode, operation is started when this board is powered up.
This board is always set in this mode.
%MX10.0.10 Not used
%MX10.0.11 Battery-less operation mode
Set to "ON" while in the battery-less mode.
In this mode, all memories are initialized (assigned initial values or cleared
to 0) when this board is powered up. No checks is performed on battery
connection or voltage.
The battery-less operation mode is set by the "CPU running definition" unde
r
the "system definition".
%MX10.0.12
|
%MX10.0.15 Not used
%MX10.1.0 CPU number Fixed to 0 for this board
%MX10.1.1
|
%MX10.1.5 Not used
%MX10.1.6 User ROM card connection state ON: connected, OFF: unconnected
%MX10.1.7 User ROM card write protect ON: write-protected, OFF: write-permitted (enabled when %MX10.1.6=ON)
%MX10.1.8 STOP position Set ON if the set bit is OFF (STOP) when the remote RUN/STOP function is
used.
%MX10.1.9 Not used
%MX10.1.10 Remote RUN/STOP state Set ON when the remote RUN/STOP function is not used. In addition, set ON if the set bit is ON whenthe remote RUN/STOP function is
used.
%MX10.1.11
|
%MX10.1.15 Not used
1-2 PLC Internal Memory

Section 1 PLC Specifications
1-8
(3) CPU nonfatal fault factor %MW10.4 (Read only)
(4) CPU error factor %MW10.5 (Read only)
1-2 PLC Internal Memory
(2) CPU fatal fault factor %MW10.2 (Read only)
Address Name Description
%MX10.2.0 CPU error Set to "ON" when a fatal fault has occurred in this board.
%MX10.2.1 Not used
%MX10.2.2 Memory error Set to "ON" when an error has occurred in the memory of this board.
%MX10.2.3 Not used
%MX10.2.4 Application error Set to "ON" when an error has been found in an application program or system
definition.
%MX10.2.5 I/O error Set to "ON" when an expansion I/O error has occurred.
%MX10.2.6
|
%MX10.2.12 Not used
%MX10.2.13 Other hardware error Set to "ON" when an error has occurred on hardware other than CPU, memory and I/O
.
%MX10.2.14 Not used
%MX10.2.15 User fatal fault Set to "ON" when the user program turns on one of the user fatal fault flags
(%MX10.14.0 to %MX10.16.15).
Address Name Description
%MX10.4.0
%MX10.4.1 Not used
%MX10.4.2 Memory error Set to "ON" when an error has occurred in the memory of this board.
%MX10.4.3 Not used
%MX10.4.4 Application error Set to "ON" when an error has been found in an application program or system
definition.
%MX10.4.5 I/O error Set to "ON" when an I/O error has occurred.
%MX10.4.6
|
%MX10.4.13 Not used
%MX10.4.14 Battery error Set to "ON" when the voltage of the data backup battery falls below the threshold leve
l
or the battery is dead.
%MX10.4.15 User nonfatal fault Set to "ON" when the user program turns on one of the user non-fatal fault flags
(%MX10.18.0 to %10.20.15)
Address Name Description
%MX10.6.0 Arithmetic processor error Hardware error in the arithmetic LSIin this board.
%MX10.6.1
|
%MX10.6.15 Not used

1-9
Section 1 PLC Specifications
(5) Memory error factor %MW10.8, %MW10.9 (Read only)
System operation after a memory error has occurred
Any memory backup error resets the entire user memory area to 0 (zero). Note that in most cases, since %MX10.8.0 to
%MX10.8.3 are set to “ON” when a hardware fault has occurred, cycling the power source may cause a memory error to be
repeated.
(6) Application error factor %MW10.12, %MW10.13 (Read only)
1-2 PLC Internal Memory
Address Name Description Level
%MX10.8.0 System ROM error Set to "ON" when an error has occurred in the system ROM in
this board. Fatal fault
%MX10.8.1 System RAM error Set to "ON" when an error has occurred in the system RAM in
this board. Fatal fault
%MX10.8.2 Application ROM error
Set to "ON" when an error has occurred in the user program
ROM in this board.
Note: Set to "ON" when an error has occurred in the user ROM
card.
Fatal fault
%MX10.8.3 Application RAM error Set to "ON" when an error has occurred in the user program
RAM in this board. Fatal fault
%MX10.8.4
|
%MX10.8.14 Not used
%MX10.8.15 Memory backup error Set to "ON" when no power-failure-time data is retained. May
clear the error condition by using an application program. Nonfatal fault
Address Name Description Level
%MW10.12.0 System definition error Set to "ON" when an error has been found in the system
definition. Fatal fault
%MW10.12.1 Application program error Set to "ON" when an error has been found in the Application
program. Fatal fault
%MW10.12.2
|
%MW10.12.15 Not used
%MW10.13.0 Not used
%MW10.13.1 Application program error Set to "ON" when an error has been found in the Application
program. Nonfatal fault
%MW10.13.2
|
%MW10.13.3 Not used

Section 1 PLC Specifications
1-10
1-2 PLC Internal Memory
(7) User fatal fault %MW10.14 to 16, User nonfatal fault %MW10.18 to 20
1) User fatal fault %MW10.14 to 16
2) User nonfatal fault %MW10.18 to 20
Address Name Description
%MX10.14.0 User fatal fault factor 0 A fatal error has occurred and the CPU stops when either one of these bits is
set to "ON" by an application program.
||
%MX10.14.15 User fatal fault factor 15
%MX10.15.0 User fatal fault factor 16
||
%MX10.15.15 User fatal fault factor 31
%MX10.16.0 User fatal fault factor 32
||
%MX10.16.15 User fatal fault factor 47
Address Name Description
%MX10.18.0 User nonfatal fault factor 0 A non-fatal error has occurred and the CPU continues running when either on
e
of these bits is set to "ON" by an application program.
Changing the bit set to "ON" to "OFF" by an application program lets the
system recover from the non-fatal error state.
||
%MX10.18.15 User nonfatal fault factor 15
%MX10.19.0 User nonfatal fault factor 16
||
%MX10.19.15 User nonfatal fault factor 31
%MX10.20.0 User nonfatal fault factor 32
||
%MX10.20.15 User nonfatal fault factor 47

1-11
Section 1 PLC Specifications
1-2 PLC Internal Memory
(8) System stop error factor %MW10.22 to %MW10.27 (Read only)
Address Name Description Level
%MX10.22.0 Not used
%MX10.22.1 System definition error Set to "ON" when the contents of the system configuration definition in this board do not match
the actual system configuration. Fatal fault
%MX10.22.2
|
%MX10.22.9 Not used
%MX10.22.10 CPU operation definition error Set to "ON" when the CPU number in this board is different from the CPU number set in thec system
definition. Fatal fault
%MX10.22.11 CPU memory boundary definition error Setto"ON"whenthememoryspaceusedbyan application program exceeds the total memory
capacity. Fatal fault
%MX10.22.12
|
%MX10.22.14 Not used
%MX10.22.15 CPU operation definition 2 error Set to "ON" when the definition of operation of this
board is erroneous. Fatal fault
%MX10.23.0 CPU I/O group definition error
(for default tasks) Set to "ON" when input is defined for output.
Fatal fault
%MX10.23.1 CPU I/O group definition error
(for level 0 tasks)
%MX10.23.2 CPU I/O group definition error
(for level 1 tasks)
%MX10.23.3 CPU I/O group definition error
(for level 2 tasks)
%MX10.23.4 CPU I/O group definition error
(for level 3 tasks)
%MX10.23.5
|
%MX10.23.15 Not used
%MX10.24.0 Not used
%MX10.24.1 I/O initialization error Set to "ON" when an error is found in the operation
setting for the I/O. Fatal fault
%MX10.24.2
|
%MX10.26.15 Not used
%MX10.27.0 Inverter communication operation
definition error Set to "ON" when the definition of operation of inverter communication is erroneous. Fatal fault
%MX10.27.1
|
%MX10.27.15 Not used

Section 1 PLC Specifications
1-12
1-2 PLC Internal Memory
(9) Application program error factor %MW10.38, %MW10.39
Note: The system definition error factor includes errors that do not occur during normal operation because the loader
suppresses them from occurring (for example, compile check).
(10) Annunciator relay %MW10.42, %MW10.43
Address Name Description Level
%MX10.38.0 Application WDT error Set to "ON" when the run time for a default task exceeds the
preset value of a watchdog timer. Fatal fault
%MX10.38.1 Application execution error Set to "ON" when an error has occurre d during user program
execution that causes "temporary size-over." Fatal fault
%MX10.38.2
|
%MX10.38.10 Not used
%MX10.38.11 FB instance setup error Set to "ON" when the specified storage address is not found. Fatal fault
%MX10.38.12 Initial setup value error Set to "ON" when the preset initial value exceeds the defined
range of a storage area. Fatal fault
%MX10.38.13 SFM boundary definition error Set to "ON" when a size greater than the maximum system
memory capacity value has been defined. Fatal fault
%MX10.38.14 Program instruction error Set to "ON" when an error has been found in the program
instruction. Fatal fault
%MX10.38.15 Task registration error Set to "ON" when a task registration error has been found. Fatal fault
%MX10.39.0 Missing level 0 task Set to "ON" when a task is missing. May clear the error
condition by using an application program. Nonfatal fau
lt
%MX10.39.1 Missing level 1 task
%MX10.39.2 Missing level 2 task
%MX10.39.3 Missing level 3 task
%MX10.39.4 Level 0 task slow-down Set to "ON" when program execution is deferred and the
predefined periodic time is not maintained. May clear the error
condition by using an application program. Nonfatal fau
lt
%MX10.39.5 Level 1 task slow-down
%MX10.39.6 Level 2 task slow-down
%MX10.39.7 Level 3 task slow-down
%MX10.39.8
|
%MX10.39.15 Not used
Address Name Description
%MX10.42.0 Initial flag Set to "ON" at the first startup after program download and at initial startup (cold
start). This flag never is set to "OFF" during operation.
%MX10.42.1 Power-off flag Set to "ON" when a power-off condition has occurred in the preceding session.
%MX10.42.2
|
%MX10.42.15 Not used
%MX10.43.0 Level 0 start flag Set to "ON" during the first execution of level 0 task.
%MX10.43.1 Level 1 start flag Set to "ON" during the first execution of level 1 task.
%MX10.43.2 Level 2 start flag Set to "ON" during the first execution of level 2 task.
%MX10.43.3 Level 3 start flag Set to "ON" during the first execution of level 3 task.
%MX10.43.4
|
%MX10.43.14 Not used
%MX10.43.15 Default task start flag Set to "ON" during the first execution of default task.

1-13
Section 1 PLC Specifications
1-2 PLC Internal Memory
(11) CPU running information %MW10.49 (Read only)
(12) CPU configuration/fault information %MW10.50, %MW10.51 (Read only)
* The status of this board is recognized by the combination of the configuration flag and error flag.
(13) System configuration/fault information %MW10.52 to 83 (Read only)
The status of the system is recognized by the combination of the system configuration information and system fault information.
Board configuration
information Board fault information Board status
OFF OFF Nonexistent
ON OFF Normal
ON ON Nonfatal fault
OFF ON Fatal fault or dropped
Address Name Description
%MX10.49.0 PLC running Set to "ON" while the PLC is running.
%MX10.49.1
|
%MX10.49.15 Not used
Address Name Description
%MX10.50.0 Configuration flag Set to "ON" while the PLC is running normally or in nonfatal fault condition.
%MX10.50.1
|
%MX10.50.15 Not used
%MX10.51.0 Error flag Set to "ON" when the PLC stops due to fatal fault or is running in nonfatal fault
condition.
%MX10.51.1
|
%MX10.51.15 Not used
Configuration flag Error flag Board status
OFF OFF Nonexistent
ON OFF Normal (run or stop)
ON ON Nonfatal fault (run or stop)
OFF ON Fatal fault (stop or drop)
Address Name Description
%MX10.52.0 I/O board 0 configuration Set to "ON" when the I/O is in normal or nonfatal fault condition.
%MX10.52.1
|
%MX10.67.13 Not used
%MX10.67.14 CPU configuration Set to "ON" when the PLC is in normal or nonfatal fault condition.
%MX10.67.15 Not used
%MX10.68.0 Expansion I/O board 0 error Set to "ON" when the I/O is in nonfatal or fatal fault condition.
%MX10.68.0
|
%MX10.83.13 Not used
%MX10.83.14 CPU error Set to "ON" when the PLC is in nonfatal or fatal fault condition.
%MX10.83.15 Not used
