FujiFilm VisualSonics Vevo MD User manual

Manufacturer
FUJIFILM SonoSite, Inc.
21919 30th Drive SE
Bothell, WA 98021 USA
T: [phone] or [phone]
F: [phone]
ECAuthorized Representative
Emergo Europe
Molenstraat 15
2513 BH, The Hague
The Netherlands
Australia Sponsor
FUJIFILM SonoSite Australasia Pty Ltd
114 Old Pittwater Road
BROOKVALE, NSW, 2100
Australia
Caution: United States federal law restricts this device to sale by
or on the order of a physician.
SonoSite, VisualSonics, Vevo, Vevo MD and the VisualSonics logo are registered and
unregistered trademarks of FUJIFILM SonoSite, Inc. in various jurisdictions. All other
trademarks are the property of their respective owners. FUJIFILM VisualSonics, Inc. is a
subsidiary of FUJIFILM SonoSite, Inc.
Patents: CA 2501647; CA 2525220; CN 201430080125.0; CN ZL200380101220.3; CN ZL200380105066.7; CN ZL20040013162.3;
CN ZL200480019107.5; CN ZL200580020418.8; CN ZL200680014137.6; CN 200680018668; CN 200680050246; CN
ZL200780016016.X; CN ZL200780027688.0; EU 1853169; FR 1465531; FR 1625630;FR 1642154; FR 1715897; FR 1738407; FR
1853169; FR 1952175; FR 2029025; DE 1465531; DE 1738407; DE 1853169; DE 1952175; DE 2029025; DE 602004007521; DE
602004010098; DE 602005021057; HK 1085109; HK 1087316; HK 1129243; HK 1132644; IE 1465531; IT 1465531; IT 1715897; IT
1738407; IT 1952175; JP 4713339; JP 4331720; JP 4805140; JP 4805254; JP 4807761; JP 4869932; JP 4942666; JP 5254867; JP
5415086; JP 2014-7668; JP 2014-7669; JP 2014-7671; NL 1465531; NL 1715897; NL 1738407; ES 1465531; ES 1952175; GB
1465531; GB 1625630; GB 1642154; GB 1715897; GB 1738407; GB 1952175; GB 2029025; US 6,851,392; US 6,984,284; US
7,052,460; US 7,133,713; US 7,230,368; US 7,255,678; US 7,426,904; US 7,434,542; US 7,674,228; US 7,750,536; US 7,798,963; US
7,808,156; US 7,830,069; US 7,901,358; US 8,078,256; US 8,275,449; US 8,316,518; US 8,317,714; US 8,343,289; US 8,529,452; US
8,708,909; US 8,827,907; US 8,847,467; US 8,945,014 and pending.
Part Number: 53152 1.0
Publication Date: April 2017
Copyright © 2017 FUJIFILM SonoSite, Inc. All rights reserved.

Vevo MDGetting Started Guide - English
Overview 4
Unpack the box 5
Set up the ramp 6
Remove the system 8
Set up the system 10
Connect the system to power 13
Basic operating instructions 16
3 Vevo MDGetting Started Guide - English

Overview
The Vevo MD Getting Started Guide explains how to unpack, set up, and begin using
the Vevo MD Imaging System.
For more in-depth instructions on how to use the system, see either:
lVevo MD Help, available on the system. To access Help on the system, tap
MORE and then tap Help.
lVevo MD User Guide, available on the Instructions for Use USB flash drive
included with the system.
Overview 4

Unpack the box
The packing box includes an accessory box, and a crate that holds the system in
place.
1Remove the straps from the packing box.
2Raise the lid on the packing box. Avoid damaging the lid, as it will be used later as a
ramp.
Figure 1-1 The Vevo MD Imaging System packing box with lid.
3Remove the sides of the packing box.
4If a transducer is included with the system, remove the transducer box:
aRemove the strap from the transducer box on the back of the crate.
bRemove the transducer box and set aside.
5 Vevo MDGetting Started Guide - English

Set up the ramp
The crate lid can be used as a ramp that allows you to remove the system from the
crate.
1With a box cutter, cut all four corners of the lid so that it lays flat.
2With the corrugated ramp supports on the bottom, place the highest end of the ramp
next to the base of the crate.
3Insert the end flaps of the lid into the metal brackets.
Figure 1-2 Placing the ramp.
Set up the ramp 6

4Using a 3/8-inch wrench, loosen and remove the wheel clamps.
Figure 1-3 Removing the wheel clamps
7 Vevo MDGetting Started Guide - English

Remove the system
1To unlock the wheels, press upon the rear of the locking lever on the wheels.
2Roll the system down the ramp.
Figure 1-4 Roll the system down the ramp.
3Remove the plastic bag and packaging materials from the system and inspect the
system for damage.
Remove the system 8

4Wheel the system to its intended destination. When transporting the system, push
forward instead of pushing downward on the bar or pushing the display monitor.
Figure 1-5 Push forward to wheel the system
5When the system is at its desired location, lock the wheels: press down on the
lever on the wheels.
9 Vevo MDGetting Started Guide - English

Set up the system
1Raise and adjust the display monitor:
aGrasp the display monitor on both sides and fold it upward.
Figure 1-6 Folding the display monitor up.
bGrasp the display monitor on both sides and tilt or rotate it to adjust its angle.
Set up the system 10

2Grasp both sides of the touch panel and pull it forward or push it backward to the
desired angle.
Figure 1-7 Angling the touch panel display.
11 Vevo MDGetting Started Guide - English

3When you are finished, your system should look as it does in Figure 1-8.
Figure 1-8 Vevo MD Imaging System
Set up the system 12

Connect the system to power
Warning: Verify that the supply voltage corresponds to the power supply
voltage range. Using incorrect voltage may damage the system.
Warning: Plug the system only into a grounded outlet. Using a non-
grounded outlet may damage the system.
Warning: Use only power cords provided by FUJIFILMSonoSite with the
system. Using power cords from other sources, may damage the system.
1Connect the AC power cord, located in the accessory box, to the stand base and
secure the AC power cord with the retainer wire.
2Connect the AC power cord to an outlet.
Figure 1-9 The AC power cord connector, retainer wire and power switch.
13 Vevo MDGetting Started Guide - English

3Turn the power switch to the ON position.
Symbol Description
ON
OFF
4When connected to AC power, the system can be turned on by the power button
and used immediately.
Figure 1-10 The power button.
Caution: Do not use the system if an error message appears on the
clinical display or control panel. Note the error code and turn off the
system. Call FUJIFILMSonoSite.
Connect the system to power 14

Caution: When using AC power, position the system to allow easy access
to disconnect it.
To disconnect from power
Before unplugging the AC power cord or using the power switch, turn off the system
using the power button.
1Press the power button.
2Turn off using the power switch.
3Unplug the AC power cord from the outlet.
4Release the retainer wire and disconnect the AC power cord from the stand base.
Note: Restarting the system while it is performing data-intensive background
activities, such as exporting data files, can result in loss of data.
FUJIFILMSonoSite recommends waiting at least 3 minutes before restarting an
unresponsive system. To power down an unresponsive system, press and hold
the power button until the system shuts down. This procedure may take 5
seconds or longer.
15 Vevo MDGetting Started Guide - English

Basic operating instructions
Note: For detailed instructions on using the Vevo MD Imaging System, please refer
to one of the following sources:
lVevo MD Help, available on the system. To access Help on the system, tap
MORE, and then tap Help.
lVevo MD User Guide, available on the Instructions for Use USB flash drive
included with this system.
To use the system, perform these basic operating steps:
1Turn on the system.
2Connect a transducer.
3Select the exam type.
4Enter patient information.
5Scan.
6Save data.
7Export data.
Connecting a transducer
Caution: Only transducers manufactured by FUJIFILMSonoSite may be
used with this system. Using transducers not manufactured by
FUJIFILMSonoSite will cause damage to the system.
Basic operating instructions 16

Caution: Only use coupling gels that are specifically approved for use with
the Vevo MD Imaging System. Using coupling gels that are not approved,
may cause damage to the transducers.
To connect the transducer
1Turn the lock handle clockwise to the vertical (unlocked) position.
2Slide the transducer connector into the transducerbay underneath the control panel.
3Push the transducer connector into the transducer interface.
4Rotate the lock handle counterclockwise into the horizontal (locked) position and
push down on the handle to lock the transducer.
Figure 1-11 Transducer Bay with Transducer Connected
17 Vevo MDGetting Started Guide - English

To disconnect the transducer
1Flip the lock handle up and rotate clockwise to the vertical (unlocked) position.
2Pull the transducer connector away from the transducer interface.
3Slide the connector up and out of the transducer bay.
Basic operating instructions 18

53152 1.0
*53152*
