Control Panel
Features of Control Panel
Pressing the Home button displays the Home
screen.
1. Power/Power Saving button
The power switches on.
Note
■When “Please wait...”is displayed, the ma-
chine is warming up. The use of machine is
not available during this time.
■If the power does not switch on, confirm
that the power plug is inserted.
2. NFC touch area
This is an area for you to hold up your NFC-supported
mobile devices over. To communicate interactively, the
NFC function of this machine needs to be enabled.
3. Data indicator
This indicator blinks while data is being sent from the
machine or data is being received from the client com-
puter.
Also, this indicator lights up when documents are saved
in the machine or the fax is stored in a local folder.
4. Status display lamp
The lamp lights up in green at an instant of operation
reception. When an error occurs, the lamp blinks in
orange.
5. Login
The user is authenticated when the user enters the
User ID and logs in.
When the user is logged in with the administrator
rights, [Administrator] is shown in this area. While the
user is authenticated, tapping on the authentication
information display area logs out the user, and the state
becomes as unauthenticated.
User's Manual
2
Home Button
[Pause]
[Pins] [Address]
[Apps]
1
3
4
7
5
6
Reference Guides are available on the official website.
Please go to our website then select your country to proceed.
Search the model name of your machine using the search bar on our official website.
Before using the machine, please read this manual thoroughly. Be sure to keep this manual for future reference.
6. Opening menu
Tap this to open the menu for change and check of the
settings of the machine.
Tap on [<] to close the menu.
7. Home Screen
Apps/Pins/Address Screens can be displayed.
• [Apps]: You can tap on any of the application icons
and use its functions.
• [Pins]: You can execute a job again using Job Direc-
tion History and the job direction history of which pin
is created with [Create Pin] by user. If you create a
pin of the job direction history, you can also directly
activate a job without opening an application.
• [Address]: You can register addresses and other
information. You can activate an application from a
registered address.
After activating an application, the selected address
is set as the destination of the application.
ApeosPro C810
ApeosPro C750
ApeosPro C650
April 2022 GM1525E2-1 Edition 1
https://fujifilm.com/fbglobal/eng/support
■This manual may not be edited, modified or copied in whole or part without the written consent of the publisher.
■Some parts of this manual are subject to change without prior notice.
■The screen shots and the illustrations in this manual are used as examples. They may differ from yours depending
on the model, the software, or the OS
.

2
Switching the Power Off
When the power is switched off, all the machine functions
are stopped.
Important
Do not switch the power off when the machine is in
the following states. If the power is switched off, the
data that is being processed may be deleted.
- During data reception (Data indicator is lit)
- Within 5 seconds after ejection of paper
- During copying or scanning
1. Press the Power/Power Saving button.
Note
Long pressing the Power/Power Saving button also
switches off power.
2. Tap on [Power Off Device].
Creating Pin
If you create a pin of Job Direction History of a job that is
executed in the past, you can easily execute the job with the
same settings.
Note
■Job direction histories and created pins are managed
by each user.
■Pinned job direction histories are not overwritten.
■A pin created in an Administrator mode is shared by
all users.
■Change/deletion of a shared pin can be performed in
an Administrator mode.
Creating Pin of Job Direction History
1. Log in.
2. On the Home screen, tap on [Pins].
3. Tap on on the right side of the history
for which you want to create a pin and
tap on [Create Pin].
Executing the Job from the Pinned Job
Direction History
On the [Pins] screen, tap on at the right
side of the pinned job and tap on [Start
Now].

3
Loading Paper
Important
■Do not place paper or other objects in the reserved
space of the tray. It may cause paper jams or ma-
chine malfunction.
■While the printer is processing a job, do not remove
the Paper Tray used for the job.
Note
Before loading the paper into the Paper Tray, fan a
stack of paper well. This will separate the sheets,
and it can prevent paper jamming.
This section explains how to load the plain paper into the
tray 1 to 4.
Loadable Paper
Paper size (mm) Tray 1, 2
Width: 100 to 330
Length: 148 to 488
Tray 3, 4
Standard size:
Max: A4 /Letter
Min: JIS B5
Paper weight (g/m2) 52 to 300
1. Pull out the Paper Tray until it stops.
2. When paper is already loaded in the tray,
take out the paper.
3. When loading paper whose size is JIS
B4 or larger, pinch the knob and lift the
paper rear end guide, and set the guide
into the hole for the indicated size.
1
2
3
4. Pinch the guide clip(s) and adjust to the
correct paper size.
There are two guide clips on the tray 1 and 2 and one
guide clip on the tray 3 and 4.
5. Fan a stack of paper, face the print sur-
face down, and then load the paper with
edges aligned according to the direction
of the arrow.
Important
Do not load paper above the maximum fill line. It
may cause paper jams or machine malfunction.
Note
Adjust the guide clip(s) correctly to the size of paper.
If the guide clip(s) is not adjusted correctly, the
machine cannot feed the paper properly, resulting in
paper jams.
6. Push in the Paper Tray.
7. When you have changed the paper type,
set the Paper Tray on the Device screen.
1. Tap on > [Device] > [Paper Tray Set-
tings].
2. After tapping on the number for the Paper
Tray you have loaded the paper, configure
the paper items, and then tap on [OK].
8. When printing, configure the paper set-
tings from the printer driver.

4
Document Glass
Loadable paper
Paper size (mm) Width: Up to 297
Length: Up to 432
1. Open the Document Cover, and wipe
off any dirt from the Document Glass.
2. Load the document face down with the
document aligned with the upper left
corner of the Document Glass.
3. Close the Document Cover.
Copy/Fax/Scan
1. Set the document.
Document Feeder
Loadable paper
Paper size (mm) Width: 84 to 297
Length: 140 to 432
Paper weight (g/m2) Single side printing: 38 to 200
Double side printing: 50 to 200
Note
When the Fax Kit is installed, the loadable paper
size is up to 600 mm for the length.
1. Open the Document Cover.
2. Wipe off any dirt adhering to the glass
strip and white plastic area located in the
left side of the Document Glass.
3. Close the Document Cover.
4. Confirm that the document is free of tag
paper, adhesive tape, staples, and clips,
and stretch out the document if it is wrin-
kled or folded.
5. Align the upper left corner of the docu-
ment so that the original size is correctly
detected.
6. Load the document face up (when the doc-
ument is 2-sided, place the front side up) in
the center of Document Feeder.
Important
Do not set documents above the maximum fill line. It
may cause paper jams or machine malfunction.
Multiple
sheets
7. When the confirmation indicator lights up,
move the document guide to align with
both edges of the document.
8. Open the Document Stopper.
Document Feeder
Attention Light
Note
To prevent a document from being left behind,
“
Docu-
ment Feeder Attention Light
”
is turned on after the Scan
job is completed and turned off after approx. 3 sec.
1 sheet

5
2. On the [Apps] screen, tap on the desired Application icon.
FaxScanCopy
Copy
1. As needed, configure the setting items.
2. Tap on [Start].
Scan (Email)
Note
■[Scan to Folder], [Scan], [Scan to USB], and [Scan to
Desktop] are also available as methods for scanning.
■To send an e-mail, the e-mail settings need to be config-
ured in the Device beforehand.
1. Specify the recipient by directly entering us-
ing the keyboard or by tapping on the Address
Book ( ).
Note
■
When specifying multiple recipients by directly entering us -
ing the keyboard, tap on recipients to add.
■To change the recipient type (To/Cc/Bcc), tap on .
2. Tap on [Done] or [OK].
3. Tap on and configure the setting items
as needed.
4. Tap on [Start].
Fax
1. Enter by the keyboard or by tapping on the
Address Book ( ) or Redial ( ) to specify
the recipient.
2. Tap on [Done] or [OK].
3. Tap on and configure the setting items as
needed.
4. Tap on [Start].

6
Electrical Safety
WARNING
This product shall be operated by the power source as indi-
cated on the product's data plate. Consult your local power
company to check if your power source meets the require-
ments.
WARNING: Connect this product to a protective
earth circuit.
This product is supplied with a plug that has a pro-
tective earth pin. The plug fits only into an earthed electri-
cal outlet. This is a safety feature. If the plug doesn't fit to
the outlet, contact an electrician to replace the outlet to
avoid risk of electric shock. Never use an earthed adapter
plug to connect the product to the electrical outlet that has
no earth connection terminal. Improper connection of a
grounding conductor may cause electric shock.
Plug the power cord directly into a grounded electri-
cal outlet. To prevent overheat and a fire accident,
do not use an extension cord, a multi-plug adaptor
or a multiple connector. Consult your local representative
to check if an outlet is grounded.
Connect this product to a branch circuit or an outlet
that has larger capacity than the rated ampere and
voltage of this product. See the data plate on the rear
panel of this product for its rated ampere and voltage.
Never touch the power cord with wet hands. It may
cause electric shock.
Do not put an object on the power cord.
Always keep the plug connection free of dust. The
dusty and damp environment may bring about
minute electric current in a connector. It may gener-
ate heat and eventually cause a fire accident.
To avoid the risk of electric shock and a fire accident,
only use the power cord supplied with this product
or the ones designated by our company. The power
cord is exclusive use for this product. Do not use it for any
other product. Do not damage or alter the power cord.
Damage and alteration may generate heat and eventually
cause electric shock or a fire accident. If the power cord is
damaged or insulated wires are exposed, contact your local
representative for its replacement. Do not use a damaged
or uninsulated cord to avoid the risk of electric shock and a
fire accident.
CAUTION
Unplug this product to turn off power completely. In-
stall this product near an outlet to easily unplug it in
case of emergency.
When cleaning this product, always switch off and
unplug it. Access to a live product interior may cause
electric shock.
Do not unplug or re-plug this product with the
switch on. Plugging and unplugging a live connector
may deform the plug and generate heat, and even-
tually cause a fire accident.
Hold the plug not the cord when unplugging this
product, or it may damage the cord and cause elec-
tric shock or a fire accident.
Switch off and unplug the product when it (i.e., fax
function) is not used over weekends or long holidays.
Please note that it cannot receive fax message
during switch-off.
Once a month, switch off this product and check if
■the power cord is plugged firmly into an electrical
outlet;
■the plug is not excessively heated, rusted or bent;
■the plug and electrical outlet are free of dust; and
■the power cord is not cracked or worn down.
Once you notice any unusual condition, switch off and unplug
this product first and contact your local representative.
Safety Notes
Before using this product, read “Safety Notes” carefully for
safety use.
This product and recommended supplies have been tested
and found to comply with strict safety requirements includ-
ing safety agency approvals and compliance with environ-
mental standards. Follow the following instructions for safe-
ty use.
WARNING
Any unauthorized alteration including an addition of new
functions or connection to external devices may not be cov-
ered by the product warranty. Contact your local represen-
tative for more information.
Follow all warning instructions marked on this product. The
warning marks stand for the followings:
DANGER
Used for item that if not followed
strictly, can lead death or severe
or fatal injuries and the possibility
to do it is comparatively high.
WARNING Used for items that if not followed
strictly, can lead to severe or fatal
injuries.
CAUTION
Used for items that if not followed
strictly, can cause injuries to user
or damages to machine.
: A symbol for items to pay attention to when handling
machine. Follow instructions carefully to use machine
safely.
Caution Caution for
electrostatic
breakage
Flammable Explodable Electric
shock
Heated
surface
: A symbol for prohibited items. Follow instructions
carefully to avoid any dangerous acts.
: A symbol for items that must be performed. Follow
instructions carefully to carry out these essential tasks.
Unplug Ground/EarthInstructions
Prohibited No fire Do not touch Do not use in
bathroom
Never touch
with wet hand
Keep away
from wet
Do not tear
down
Moving
object
Pinched fingers Rotating Parts
Hazard
Sharp Edge
Hazard

7
Machine Installation
WARNING
Do not locate this product where people might step
on or trip over the power cord. Friction or excessive
pressure may generate heat and eventually cause
electric shock or a fire accident.
CAUTION
Never locate this product in the following places:
■Near radiators or any other heat sources
■Near volatile flammable materials such as curtains
■In the hot, humid, dusty or poorly ventilated environment
■In the place receiving direct sunlight
■Near cookers or humidifiers
Keep away the packing materials of product from
small children. The thin film may cling to nose and
mouth and prevent breathing.
Locate this product on a level and sturdy surface
that can withstand a weight of 250 kg (minimum
configuration). Otherwise, if tilted, the product may
fall over and cause injuries.
Locate this product in a well-ventilated area. Do not
obstruct ventilation openings of the product. Keep
the minimum clearance as follows for ventilation and
an access to the power plug. Unplug the product if an ab-
normal condition is noted.
Minimum configuration
100
793
663
23580
20
1791
1759
1659
(Unit: mm)
Do not incline the product at more than 10°angle.
Otherwise, it may fall over and cause injuries.
10°
10
°10°10
°
Always lock the wheels of this product after installa-
tion. Otherwise, it may fall over or slide and cause
injuries.
To bundle wires and cables, always use the cable ties
and spiral tubes that our company supplies. Other-
wise, it may cause some defects.
Operational Safety
WARNING
The operator’s product maintenance procedures are
described in the manuals supplied with this product.
Do not carry out any other maintenance procedures
not described in the manuals.
This product features safety design not to allow op-
erators access to hazard areas. The hazard areas are
isolated from operators by covers or protectors
which require a tool to remove. To prevent electric shock
and injuries, never remove those covers and protectors.
To avoid the risk of electric shock and a fire accident,
switch off and unplug the product promptly in the
following conditions, then contact your local repre-
sentative.
■The product emits smoke or its surface is unusually hot.
■The product emits unusual noise or odour.
■The power cord is cracked or worn down.
■A circuit breaker, fuse or any other safety device becomes
activated.
■Any liquid is spilled into the product.
■The product is soaked in water.
■Any part of the product is damaged.
Do not insert any object into slots or openings of this
product. Do not put any of the followings on the
product:
■Liquid container such as flower vases or coffee cups
■Metal parts such as staples or clips
■Heavy objects
If liquid is spilled over or metal parts are slipped into the
product, it may cause electric shock or a fire accident.
Do not place liquid, particles, small metal pieces or
their containers in consumable storage spaces. Spills
may cause electric shock or fire due to short-circuit.
Do not place dangerous objects (e.g., fragiles, vola-
tile and flammable chemicals, creatures) in consum-
able storage spaces. Otherwise, it may cause catch-
ing fire.
Do not use conductive paper such as origami paper,
carbonic paper or conductively-coated paper. When
paper jam occurs, it may cause short-circuit and
eventually a fire accident.
When cleaning this product, use the designated
cleaning materials exclusive to it. Other cleaning ma-
terials may result in poor performance of the prod-
uct. Never use aerosol cleaners to avoid catching fire and
explosion.
When you play the media (e.g., CD-ROM, DVD) sup-
plied with the product, always use said media-en-
abled device. Otherwise, large sound may damage
its speakers or your ears.

8
CAUTION
Always follow all warning instructions marked on or
supplied with this product. To avoid the risk of burn
injuries and electric shock, never touch the area with
the “High Temperature”or “High Voltage”marks on.
Keep electrical and mechanical safety interlocks ac-
tive. Keep the safety interlocks away from magnetic
materials. Magnetic materials may accidentally acti-
vate the product and cause injuries or electric shock.
A ground fault interrupter is embedded in this prod-
uct. If current leakage occurs, the ground fault inter-
rupter automatically cuts off power circuit to prevent
electric shock and a fire accident. The ground fault inter-
rupter is normally ON. Check once a month if the ground
fault interrupter works properly in accordance with the fol-
lowing procedures:
1. Switch off the product.
2. Press the RESET button to the reset position. The button
will be depressed even after the pushing force is re-
leased.
RESET button
3. Press the TEST button lightly with a sharp edge such as a
pen tip. The depressed RESET button will stick out again.
This is the end of the check procedure.
TEST button
4. Press the RESET button back to the depressed position.
If the circuit does not work properly, contact your local rep-
resentative.
Do not attempt to remove a paper deeply jammed
inside the product, particularly a paper wrapped
around the fusing unit or the heat roller. Otherwise, it
may cause injuries or burns. Switch off the product imme-
diately and contact your local representative.
Never touch the paper output area of the fin-
isher during operation. It may cause injuries.
Be careful in removing jammed staples.
Be careful not to get injured by waste staples when
detaching a staple waste container.
Waste staples may come out with output paper. Be
careful not to get injured by the staples.
Never touch safety interlocks. When a front cover is
open, safety interlocks become activated to stop the
machinery. Do not apply pressure on safety inter-
locks with a coin or screwdriver. Otherwise, the machinery
may become activated and cause injuries.
Do not staple punched holes of paper. Sharp points
of a staple may cause injuries.
Be careful not to drop an object when you bring it
out from consumable storage spaces. Otherwise,
you may get injured.
Grip the handhold on a door of consumable storage
spaces when you open and close it. Do not hold an
upper or bottom edge of the door. Otherwise, you
may get injured.
Do not add a shock to a door of consumable storage
spaces. Otherwise, the door may break to drop off
and you may get injured.
Do not apply excessive force to hold thick document
on the document glass. It may break the glass and
cause injuries.
For continuous operation more than 1 hour, take a
10 - 15 minute break every hour to rest your eyes.
To move this product to another location, contact
your local representative.
Ventilate well during extended operation or mass
copying or printing. It may affect the office air envi-
ronment due to odor such as ozone in a poorly venti-
lated room. Provide proper ventilation to ensure the com-
fortable and safe environment.
Consumable
WARNING
Store all consumables in accordance with the in-
structions given on its package or container.
Never use a vacuum cleaner for spilled toner and re-
sidual toner in this product, toner cartridge or waste
toner container. It may catch fire by electric sparks
inside a vacuum cleaner and cause explosion. Use a broom
or a wet cloth to wipe off the spills. If you spill a large vol-
ume of toner, contact your local representative.
Never throw a toner cartridge into an open flame.
Remaining toner in the cartridge may catch fire and
cause burn injuries or explosion. If you have a used
toner cartridge no longer needed, contact your local repre-
sentative for its disposal.
Never throw a waste toner container into an open
flame. Toner may catch fire and cause burn injuries
or explosion. If you have a used waste toner contain-
er no longer needed, contact your local representative for
its disposal.
CAUTION
Keep drum cartridges and toner cartridges out of the
reach of children. If a child accidentally swallows
toner, spit it out, rinse mouth with water, drink water
and consult a physician immediately.
When replacing drum cartridges and toner cartridg-
es, be careful not to spill the toner. In case of any
toner spills, avoid contact with clothes, skin, eyes
and mouth as well as inhalation.
■If toner spills onto your skin or clothing, wash it off
with soap and water.
■If you get toner particles in the eyes, wash it out
with plenty of water for at least 15 minutes until
irritation is gone. Consult a physician if necessary.
■If you inhale toner particles, move to a fresh air location
and rinse your mouth with water.
■If you swallow toner, spit it out, rinse your mouth with
water, drink plenty of water and consult a physician im-
mediately.

9
Other
WARNING
This is a class A product. In a domestic environment this
product may cause radio interference in which case the user
may be required to take adequate measures.
Regulation
Shielded interface cables must be used with this
product to maintain compliance with EMI standard.

10

11

Software License Agreement
You must read and agree with the following terms and conditions before you open the package and use the media ac-
companying the device. By opening the package, you agree to be bound by the terms and conditions.
Term and conditions
• Our company does not provide any implicit or explicit guarantee on the contents, accuracy and safety of the media.
• The copyrights of the information provided in this media belongs to our company
• The contents of this media shall not be duplicated, modified, sold, published, read or disclosed to a third party for any
amount of money whatsoever.
Disclaimer
Our company is not liable for any direct, indirect or spillover damages; loss of data, program or intangible properties;
and lost profits arising out of the use of this software.
Read Before Using
Before using the machine, please read “License Agreement”(terms for using the Adobe Systems Inc. software) stored
on the “Software/Product Manual”disc.
“License Agreement”is stored in the “License”folder contained on the disc.
Use the software only after you agree with all applicable terms and conditions. By using the software, you are agreeing
to be bound by the terms and conditions. If you do not agree to “License Agreement”, please contact the dealer you
purchased the product.
More online support options.....
TO ACCESS MORE ONILNE SUPPORT OPTIONS
Please go to our website, https://fujifilm.com/fbglobal/eng/support and then select your country to proceed.
Drivers & Utilities
ACCESS THE LATEST PRODUCT SUPPORT TOOLS ONLINE
Fully tested printer drivers, utilities and software patches are available for our products.
Self Help
SELF DIRECTED SUPPORT READY WHEN YOU NEED IT
Solutions are provided in multiple languages. Download useful posters, “How-to” guides, video tutorials and more.
Designed for desktop and mobile viewing, our site provides fast and self-directed support in seconds and minutes.
Need more support?
eLogging
TECHNICAL SUPPORT CENTRE
Log hardware or software support requests online via your local support website.
Our people are highly skilled, industry certified professionals. Accessing state of the art laboratories and remote diagnostic
tools to replicate problems and provide timely solutions.
With direct access to product development and engineering, this focused team assists in the resolution of complex technical
issues.
Contact us
Localized Technical Support Centre phone details can be accessed via the “Contact” link for your country.
Go to, https://fujifilm.com/fbglobal/eng/support and then select your country to proceed.
