FujiFilm Revoria Press SC180 User manual

Control Panel
Features of Control Panel
Pressing the Home button displays the Home screen.
1. Power/Power Saving button
The power switches on.
Note
■When “Please wait...”is displayed, the ma-
chine is warming up. The use of machine is
not available during this time.
■If the power does not switch on, confirm
that the power plug is inserted.
2. NFC touch area
This is an area for you to hold up your NFC-supported
mobile devices over. To communicate interactively, the
NFC function of this machine needs to be enabled.
3. Data indicator
This indicator blinks while data is being sent from the
machine or data is being received from the client com-
puter.
Also, this indicator lights up when documents are saved
in the machine.
4. Status display lamp
The lamp lights up in green at an instant of operation
reception. When an error occurs, the lamp blinks in
orange.
5. Login
The user is authenticated when the user enters the
User ID and logs in.
When the user is logged in with the administrator
rights, [Administrator] is shown in this area. While the
user is authenticated, tapping on the authentication
information display area logs out the user, and the state
becomes as unauthenticated.
User's Manual
2
Home Button
[Pause]
[Pins] [Address]
[Apps]
1
3
4
7
5
6
Before using the machine, please read this manual thoroughly. Be sure to keep this manual for future reference.
6. Opening menu
Tap this to open the menu for change and check of the
settings of the machine.
Tap on [<] to close the menu.
7. Home Screen
Apps/Pins/Address Screens can be displayed.
• [Apps]: You can tap on any of the application icons
and use its functions.
• [Pins]: You can execute a job again using Job Direc-
tion History and the job direction history of which pin
is created with [Create Pin] by user. If you create a
pin of the job direction history, you can also directly
activate a job without opening an application.
• [Address]: You can register addresses and other
information. You can activate an application from a
registered address.
After activating an application, the selected address
is set as the destination of the application.
The PDF manual is available by clicking “PDF Manuals”on
the help of Internet Services.
Revoria Press SC180
Revoria Press SC170
June 2023 GM1829E5-2 Edition 1
https://product1.iotconnectup.com/webui_help/global/revoria_press_sc180/en/top.html
■
This manual may not be edited, modified or copied in whole or part without the written consent of the publisher.
■
Some parts of this manual are subject to change without prior notice.
■
The screen shots and the illustrations in this manual are used as examples. They may differ from yours depending
on the model, the software, or the OS.

2
Switching the Power On
The printer warms up and becomes ready to print within
about 5 minutes after powered on.
Note
The warm-up time may vary with an initial tempera-
ture of the printer.
1. Press the Power/Power Saving button.
The operation panel turns on.
Note
After being inactive for a while, the printer automat-
ically enters the Power Saver mode to reduce power
consumption.
Switching the Power Off
When the power is switched off, all the machine functions
are stopped.
Important
Do not switch the power off when the machine is in
the following states. If the power is switched off, the
data that is being processed may be deleted.
-During data reception (Data indicator is lit)
-Within 5 seconds after ejection of paper
-During copying or scanning
1. Press the Power/Power Saving button.
Note
Long pressing the Power/Power Saving button also
switches off power.
2. Tap on [Power Off Device].
Note
■When you switch the power off, the Power/Pow-
er Saver button on the control panel may continue
blinking even after the touch screen goes dark. Do
not switch the main power off until the light of the
Power/Power Saver button goes off. (You can turn on
the printer again.)
■When powering the printer on after it has been
switched off, wait 10 seconds or more after the
touch screen has gone dark.
■You can also switch the power off by clicking [Power
Off Device] on Internet Services under [Home] tab >
[Support].
Creating Pin
If you create a pin of Job Direction History of a job that is
executed in the past, you can easily execute the job with the
same settings.
Note
■Job direction histories and created pins are managed
by each user.
■Pinned job direction histories are not overwritten.
■A pin created in an Administrator mode is shared by
all users.
■Change/deletion of a shared pin can be performed in
an Administrator mode.
Creating Pin of Job Direction History
1. Log in.
2. On the Home screen, tap on [Pins].
3. Tap on on the right side of the history
for which you want to create a pin and
tap on [Create Pin].
Executing the Job from the Pinned Job
Direction History
On the [Pins] screen, tap on at the right
side of the pinned job and tap on [Start
Now].
Main Power Switch
If you turn off the main power, the power consumption can
be reduced. (but cannot be reduced to zero.)
Important
■When the printer is at a high temperature, switching
the main power off immediately after switching the
power off prevents cooling of the machine, and this
might cause problems, e.g. damage to the printer, or
deterioration or clogging of toner inside the printer.
Make sure the Power/Power Saving button is out and
then switch off the main power.
■Cooling down may take up to 60 minutes.

3
Note
■The machine needs more time to warm up if
switched on after the main power is off.
■Switching off the main power may damage the hard
disk and the memory or cause a printer malfunction,
please adhere to the following guidelines.
-Do not switch the main power off while the touch
screen displays a screen or the Power/Power Saver
button blinks.
-Switch the main power off first when unplugging
the power cord.
-Do not switch off the main power immediately af-
ter switching on the main power.
1. Open Machine Front Cover and push the
lower side of the switch to <O> (OFF).
The Power/Power Saving indicator goes out on the con-
trol panel.
Circuit Breaker Switch
The switch is normally in the upper position.
If the machine will be moved or unused for an extended pe-
riod of time, turn off the switch by pressing it to the lower
position.
Circuit Breaker Switch
TEST button
When fault current is detected, the circuit breaker is auto-
matically turned off to discontinue the electrical flow. Do not
touch the breakers under normal condition. For information
on fault current, refer to the “Safety Notes”.
Refer
For Circuit Breaker Switch of the optional units, refer
to Reference Guide Optional Units.
Loading Paper
Important
■Do not place paper or other objects in the reserved
space of the tray. It may cause paper jams or ma-
chine malfunction.
■While the printer is processing a job, do not remove
the Paper Tray used for the job.
Note
Before loading the paper into the Paper Tray, fan a
stack of paper well. This will separate the sheets,
and it can prevent paper jamming.
This section explains how to load the plain paper into the
tray 1 to 3.
Loadable Paper
Paper size Standard size:
Max: A3, 11×17”
Min: A5
Non-standard size:
140×182 mm to 330×488 mm
Paper weight 64 to 256 g/m2
1. Pull out the Paper Tray until it stops.
Note
The illustration here shows Tray 1 as an example, but
the procedures are the same for Trays 2 and 3.
2. When paper is already loaded in the tray,
take out the paper.
3. Pinch the guide clip(s) and adjust to the
correct paper size.
4. Fan a stack of paper, face the print sur-
face down, and then load the paper with
edges aligned according to the direction
of the arrow.
Important
Do not load paper above the maximum fill line. It
may cause paper jams or machine malfunction.
Note
Adjust the guide clip(s) correctly to the size of paper.
If the guide clip(s) is not adjusted correctly, the
machine cannot feed the paper properly, resulting in
paper jams.
5. Push in the Paper Tray.

4
6. When you have changed the paper type,
set the Paper Tray on the Device screen.
1. Tap on > [Device] > [Paper Tray Settings].
2. After tapping on the number for the Paper Tray
you have loaded the paper, configure the paper
items, and then tap on [OK].
7. When printing, configure the paper set-
tings from the printer driver.

5
Document Glass
Loadable paper
Paper size Max: A3
Min: A6
1. Open the Document Cover, and wipe
off any dirt from the Document Glass.
2. Load the document face down with the
document aligned with the upper left
corner of the Document Glass.
3. Close the Document Cover.
Copy/Scan
1. Set the document.
Document Feeder
Loadable paper
Paper size Max: A3, 11 x 17”
Min: A6
Non-standard sizes: 84.0×139.7 mm to
297×432 mm
Paper weight Single side printing: 38 to 200 g/m2
Double side printing: 50 to 200 g/m2
1. Open the Document Cover.
2. Wipe off any dirt adhering to the glass
strip and white plastic area located in the
left side of the Document Glass.
3. Close the Document Cover.
4. Confirm that the document is free of tag
paper, adhesive tape, staples, and clips,
and stretch out the document if it is wrin-
kled or folded.
5. Align the upper left corner of the docu-
ment so that the original size is correctly
detected.
6. Load the document face up (when the
document is 2-sided, place the front side
up) in the center of Document Feeder.
Important
Do not set documents above the maximum fill line.
It may cause paper jams or machine malfunction.
Multiple
sheets
7. When the confirmation indicator lights up,
move the document guide to align with
both edges of the document.
8. Open the Document Stopper.
Document Feeder
Attention Light
Note
To prevent a document from being left behind,
“
Docu-
ment Feeder Attention Light
”
is turned on after the Scan
job is completed and turned off after approx. 3 sec.
1 sheet

6
2. On the [Apps] screen, tap on the desired Application icon.
ScanCopy
Copy
1. As needed, configure the setting items.
2. Tap on [Start].
Scan (Email)
Note
■[Scan to Folder], [Scan], [Scan to USB], and
[Scan to Desktop] are also available as methods
for scanning.
■To send an e-mail, the e-mail settings need to be
configured in the Device beforehand.
1. Specify the recipient by directly enter-
ing using the keyboard or by tapping on
the Address Book ( ).
Note
■When specifying multiple recipients by directly
entering using the keyboard, tap on recipients to
add.
■To change the recipient type (To/Cc/Bcc), tap on
.
2. Tap on [Done] or [OK].
3. Tap on and configure the setting
items as needed.
4. Tap on [Start].

7
Electrical Safety
WARNING
This product shall be operated by the power source as indi-
cated on this product's data plate label. Consult your local
power company to check if your power source meets the
requirements.
WARNING: Connect this product to a protective
earth circuit.
This product is supplied with a plug that has a pro-
tective earth pin. The plug fits only into an earthed electri-
cal outlet. This is a safety feature. If the plug doesn't fit to
the outlet, contact an electrician to replace the outlet to
avoid risk of electric shock. Never use an earthed adapter
plug to connect the product to the electrical outlet that has
no earth connection terminal. Improper connection of a
grounding conductor may cause electric shock.
Plug the power cord directly into a grounded electri-
cal outlet. To prevent overheat and a fire accident,
do not use an extension cord, a multi-plug adaptor
or a multiple connector. Consult your local representative
to check if an outlet is grounded.
Connect this product to a branch circuit or an outlet
that has larger capacity than the rated ampere and
voltage of this product. See the data plate on the
rear panel of this product for its rated ampere and voltage.
Never touch the power cord with wet hands. It may
cause electric shock.
Do not put an object on the power cord.
Always keep the plug connection free of dust. The
dusty and damp environment may bring about
minute electric current in a connector. It may gener-
ate heat and eventually cause a fire accident.
To avoid the risk of electric shock and a fire accident,
only use the power cord supplied with this product
or the ones designated by our company. The power
cord is exclusive use for this product. Do not use it for any
other product. Do not damage or alter the power cord.
Damage and alteration may generate heat and eventually
cause electric shock or a fire accident. If the power cord is
damaged or insulated wires are exposed, contact your local
representative for its replacement. Do not use a damaged
or uninsulated cord to avoid the risk of electric shock and a
fire accident.
CAUTION
When cleaning this product, always switch off and
unplug it. Access to a live product interior may cause
electric shock.
Do not unplug or re-plug this product with the
switch on. Plugging and unplugging a live connector
may deform the plug and generate heat, and even-
tually cause a fire accident.
Hold the plug not the cord when unplugging this
product, or it may damage the cord and cause elec-
tric shock or a fire accident.
Always switch off and unplug this product when it is
not used over weekends or long holidays. It may
cause deterioration of insulations and eventually
electric shock or a fire accident.
Once a month, switch off this product and check if
■the power cord is plugged firmly into an electrical
outlet;
■the plug is not excessively heated, rusted or bent;
■the plug and electrical outlet are free of dust; and
■the power cord is not cracked or worn down.
Once you notice any unusual condition, switch off and unplug
this product first and contact your local representative.
Safety Notes
Before using this product, read “Safety Notes” carefully for
safety use.
This product and recommended supplies have been tested
and found to comply with strict safety requirements includ-
ing safety agency approvals and compliance with environ-
mental standards. Follow the following instructions for safe-
ty use.
WARNING
Any unauthorized alteration including an addition of new
functions or connection to external devices may not be cov-
ered by this product warranty. Contact your local represen-
tative for more information.
Follow all warning instructions marked on this product. The
warning marks stand for the followings:
DANGER
Used for item that if not followed
strictly, can lead death or severe
or fatal injuries and the possibility
to do it is comparatively high.
WARNING Used for items that if not followed
strictly, can lead to severe or fatal
injuries.
CAUTION
Used for items that if not followed
strictly, can cause injuries to user
or damages to machine.
: A symbol for items to pay attention to when handling
machine. Follow instructions carefully to use machine
safely.
Caution Caution for
electrostatic
breakage
Flammable Explodable Electric
shock
Heated
surface
: A symbol for prohibited items. Follow instructions
carefully to avoid any dangerous acts.
: A symbol for items that must be performed. Follow
instructions carefully to carry out these essential tasks.
Unplug Ground/EarthInstructions
Prohibited No fire Do not touch Do not use in
bathroom
Never touch
with wet hand
Keep away
from wet
Do not tear
down
Moving
object
Pinched fingers Rotating Parts
Hazard
Sharp Edge
Hazard

8
Machine Installation
WARNING
Do not locate this product where people might step
on or trip over the power cord. Friction or excessive
pressure may generate heat and eventually cause
electric shock or a fire accident.
CAUTION
Never locate this product in the following places:
■Near radiators or any other heat sources
■Near volatile flammable materials such as curtains
■In the hot, humid, dusty or poorly ventilated environment
■In the place receiving direct sunlight
■Near cookers or humidifiers
Keep away the packing materials of product from
small children. The thin film may cling to nose and
mouth and prevent breathing.
Locate this product on a level and sturdy surface
that can withstand a weight of 302 kg (minimum
configuration). Otherwise, if tilted, this product may
fall over and cause injuries.
Locate this product in a well-ventilated area. Do not
obstruct ventilation openings of this product. Keep
the minimum clearance as follows for ventilation and
an access to the power plug. Unplug this product if an ab-
normal condition is noted.
Minimum configuration
(Unit: mm)
831
604
300
3431
2920
1720
696
1300
900
Do not incline this product at more than 10°angle.
Otherwise, it may fall over and cause injuries.
10°
10
°10°10
°
Always lock the wheels of this product after installa-
tion. Otherwise, it may fall over or slide and cause
injuries.
To keep this product in a good performance and
condition, always use it in the following environ-
ment:
Temperature: 10 to 32°C
Humidity: 15 to 85%
When this product is left in a chilly room and the room is
rapidly warmed up by heater, dew condensation may form
inside this product and cause a partial deletion on printing
or scanning.
To bundle wires and cables, always use the cable ties
and spiral tubes that our company supplies. Other-
wise, it may cause some defects.
Operational Safety
WARNING
The operator’s product maintenance procedures are
described in the manuals supplied with this product.
Do not carry out any other maintenance procedures
not described in the manuals.
This product features safety design not to allow op-
erators access to hazard areas. The hazard areas are
isolated from operators by covers or protectors
which require a tool to remove. To prevent electric shock
and injuries, never remove those covers and protectors.
To avoid the risk of electric shock and a fire accident,
switch off and unplug this product promptly in the
following conditions, then contact your local repre-
sentative.
■This product emits smoke or its surface is unusually hot.
■This product emits unusual noise or odor.
■This power cord is cracked or worn down.
■A circuit breaker, fuse or any other safety device becomes
activated.
■Any liquid is spilled into this product.
■This product is soaked in water.
■Any part of this product is damaged.
Do not insert any object into slots or openings of this
product. Do not put any of the followings on this
product:
■Liquid container such as flower vases or coffee cups
■Metal parts such as staples or clips
■Heavy objects
If liquid is spilled over or metal parts are slipped into this
product, it may cause electric shock or a fire accident.
Do not place liquid, particles, small metal pieces or
their containers in Consumables Storage Unit. Spills
may cause electric shock or fire due to short-circuit.
Do not place dangerous objects (e.g., fragiles, vola-
tile and flammable chemicals, creatures) in Consum-
ables Storage Unit. Otherwise, it may cause catching
fire.
Do not use conductive paper such as origami paper,
carbonic paper or conductively-coated paper. When
paper jam occurs, it may cause short-circuit and
eventually a fire accident.
When cleaning this product, use the designated
cleaning materials exclusive to it. Other cleaning ma-
terials may result in poor performance of this prod-
uct. Never use aerosol cleaners to avoid catching fire and
explosion.
If you need to pull out a tray to remove paper jam,
contact your local representative. Do not pull out a
tray, otherwise it may cause injuries.
When you play the media (e.g., CD-ROM, DVD) sup-
plied with this product, always use said media-en-
abled device. Otherwise, large sound may damage
its speakers or your ears.
Laser Safety
CAUTION: Any operations or adjustments not stated
in the operation manual may cause hazardous light
exposure and eventually burn injuries or loss of eyesight.
This product has been tested and found to comply with
the Class 1 Laser Equipment requirements defined by the
international standard IEC60825-1:2014 and has no light
exposure hazard. This product has no hazardous light emis-
sion as it features light protection components and covers
to shut in all light beam during operation and maintenance.

9
CAUTION
Always follow all warning instructions marked on or
supplied with this product. To avoid the risk of burn
injuries and electric shock, never touch the area with
the “Heated surface”or “Electric shock”marks on.
Keep electrical and mechanical safety interlocks ac-
tive. Keep the safety interlocks away from magnetic
materials. Magnetic materials may accidentally acti-
vate this product and cause injuries or electric shock.
A ground fault interrupter is embedded in this prod-
uct. If current leakage occurs, the ground fault inter-
rupter automatically cuts off power circuit to prevent
electric shock and a fire accident. The ground fault inter-
rupter is normally ON (in the “|”state). Check once a
month if the ground fault interrupter works properly in ac-
cordance with the following procedures:
1. Switch off this product.
2. Press the TEST button.
Circuit Breaker Switch
TEST button
3. Check that the switch is turned off and in the “O” state.
4. Set the switch to “ON” (in the “|” state).
If the circuit does not work properly, contact your local rep-
resentative.
Do not attempt to remove a paper deeply jammed
inside this product, particularly a paper wrapped
around the fusing unit or the heat roller. Otherwise, it
may cause injuries or burns. Switch off this product imme-
diately and contact your local representative.
Never touch the paper output area of the fin-
isher during operation. It may cause injuries.
Be careful in removing jammed staples.
Be careful not to get injured by waste staples when
detaching a staple waste container.
Waste staples may come out with output paper. Be
careful not to get injured by the staples.
Never touch safety interlocks. When a front cover is
open, safety interlocks become activated to stop this
product. Do not apply pressure on safety interlocks
with a coin or screwdriver. Otherwise, this product may be-
come activated and cause injuries.
Do not staple punched holes of paper. Sharp points
of a staple may cause injuries.
Do not place objects weighing more than 80 kg in
Consumables Storage Unit. Heavy loads may deform
or break them.
Do not put your weight on or lift up a door of Con-
sumables Storage Unit. It may cause deforming or
breaking it.
Do not forcibly open a door of Consumables Storage
Unit. It may cause deforming or breaking it.
Be careful not to drop an object when you bring it
out from Consumables Storage Unit. Otherwise, you
may get injured.
Grip the handhold on a door of Consumables Stor-
age Unit when you open and close it. Do not hold an
upper or bottom edge of the door. Otherwise, you
may get injured.
Do not add a shock to a door of Consumables Stor-
age Unit. Otherwise, the door may break to drop off
and you may get injured.
Do not apply excessive force to hold thick document
on the document glass. It may break the glass and
cause injuries.
To move this product to another location, contact
your local representative.
Ventilate well during extended operation or mass
copying or printing. It may affect the office air envi-
ronment due to odor such as ozone in a poorly venti-
lated room. Provide proper ventilation to ensure the com-
fortable and safe environment.
Consumable
WARNING
Store all consumables in accordance with the in-
structions given on its package or container.
Never use a vacuum cleaner for spilled toner and re-
sidual toner in this product, toner cartridge or waste
toner container. It may catch fire by electric sparks
inside a vacuum cleaner and cause explosion. Use a broom
or a wet cloth to wipe off the spills. If you spill a large vol-
ume of toner, contact your local representative.
Never throw a toner cartridge into an open flame.
Remaining toner in the cartridge may catch fire and
cause burn injuries or explosion. If you have a used
toner cartridge no longer needed, contact your local repre-
sentative for its disposal.
Never throw a waste toner container into an open
flame. Toner may catch fire and cause burn injuries
or explosion. If you have a used waste toner contain-
er no longer needed, contact your local representative for
its disposal.
CAUTION
Keep toner cartridges out of the reach of children. If
a child accidentally swallows toner, spit it out, rinse
mouth with water, drink water and consult a physi-
cian immediately.
When replacing toner cartridges, be careful not to
spill the toner. In case of any toner spills, avoid con-
tact with clothes, skin, eyes and mouth as well as in-
halation.
■If toner spills onto your skin or clothing, wash it off
with soap and water.
■If you get toner particles in the eyes, wash it out
with plenty of water for at least 15 minutes until
irritation is gone. Consult a physician if necessary.
■If you inhale toner particles, move to a fresh air location
and rinse your mouth with water.
■If you swallow toner, spit it out, rinse your mouth with
water, drink plenty of water and consult a physician im-
mediately.

10
Other
WARNING
This equipment is compliant with Class A of CISPR 32. In a
residential environment this equipment may cause radio in-
terference.
Regulation
Shielded interface cables must be used with this
product to maintain compliance with EMI standard.
Shielded cables must be used with this equipment to
maintain compliance with Council Directive
2014/30/EU
FCC CAUTION(USA and Canada)
Changes or modifications not expressly approved by
the party responsible for compliance could void the
user’s authority to operate the equipment.
USA Only
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
Contact: FUJIFILM North America Corporation
Phone: [phone]
Address: 200 Summit Lake Drive, Valhalla, NY 10595-1356,
U.S.A.
■Product Safety Certification (CB)
This product is certified by the following agency using the
safety standards listed.
Agency Standard
TUV Rheinland IEC60950-1:ed. 2, IEC62368-1
■This product will be intended for professional use only.
■For the European Union
Hereby, we declare this product is in compliance with Di-
rective 2014/53/EU. The full text of the EU declaration of
conformity is available at the following internet address:
https://support-fb.fujifilm.com/setupWorldwide.do
■Regulatory Information for RFID
This product contains Radio Frequency Identification sys-
tem device (RFID) and it is certified in compliance with
applicable local laws and/or regulations.
■This product is equipped with RFID. Its operating frequen-
cies are as follows.
Operating frequency: 13.56 MHz
This product is equipped with Bluetooth. Its output power
is as follows.
Max TX Power +10dBm
■This device complies with part 15 of the FCC Rules. This
device complies with part 15 of FCC Rules and Innovation,
Science and Economic Development Canada’s licence-ex-
empt RSS(s). Operation is subject to the following two con-
ditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Le présent appareil est conforme à la partie 15 des règles
de la FCC et aux normes des CNR d’Innovation, Sciences et
Développement économique Canada applicables aux appa-
reils radio exempts de licence. L’exploitation est autorisée
aux deux conditions suivantes : (1) l’appareil ne doit pas
produire de brouillage, et (2) l’appareil doit accepter tout
brouillage subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
■This device contains licence-exempt transmitter(s)/receiv-
er(s) that comply with Innovation, Science and Economic
Development Canada’s licence-exempt RSS(s). Operation is
subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference, including inter-
ference that may cause undesired operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le
présent appareil est conforme aux CNR d’Innovation, Sci-
ences et Développement économique Canada applicables
aux appareils radio exempts de licence. L’exploitation est au-
torisée aux deux conditions suivantes :
1. L’appareil ne doit pas produire de brouillage;
2. L’appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d’en comprom-
ettre le fonctionnement.
■This equipment complies with FCC radiation exposure lim-
its set forth for an uncontrolled environment and meets
the FCC radio frequency (RF) Exposure Guidelines as this
equipment has very low levels of RF energy.
■This equipment complies with ISED radiation exposure
limits set forth for an uncontrolled environment and meets
RSS-102 of the ISED radio frequency (RF) Exposure rules as
this equipment has very low levels of RF energy.
Cet équipement est conforme aux limites d’exposition aux
rayonnements énoncées pour un environnement non con-
trôlé et respecte les règles d’exposition aux fréquences ra-
dioélectriques (RF) CNR-102 de l’ISDE puisque cet appareil
a une niveau tres bas d’energie RF.

11
Radio Frequency Emissions (Class A digital
device) (USA)
Note: This equipment has been tested and found to comply
with the limits for a Class A digital device, pursuant to Part
15 of the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference when the equipment is operat-
ed in a commercial environment.
This equipment generates, uses, and can radiate radio fre-
quency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference
to radio communications.
Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be re-
quired to correct the interference at his own expense.
Changes or modifications to this equipment not specifically
approved by our company may void the user’s authority to
operate this equipment.
Radio Frequency Emissions (Class A digital
device) (European Union)
WARNING: This is a Class A product. In a domestic environ-
ment this product may cause radio interference in which
case the user may be required to take adequate measures.
WARNING: In order to allow this equipment to operate in
close proximity to Industrial, Scientific and Medical (ISM)
equipment, the external radiation from ISM equipment may
have to be limited or special mitigation measures taken.
Changes or modifications to this equipment not specifically
approved by our company may void the user’s authority to
operate this equipment.
Radio Frequency Emissions (Class A digital
device) (India)
WARNING: This is a Class A product. In a domestic environ-
ment this product may cause radio interference in which
case the user may be required to take adequate measures.
WARNING: In order to allow this equipment to operate in
close proximity to Industrial, Scientific and Medical (ISM)
equipment, the external radiation from ISM equipment may
have to be limited or special mitigation measures taken.
Changes or modifications to this equipment not specifically
approved by our company may void the user’s authority to
operate this equipment.
■Equipment complying with EN61000-3-12.
This equipment is suitable for use only in premises having a
service current capacity equal to or greater than 100 Amps
per phase.
Environment
Proper disposal is required for consumables no longer need-
ed. Do not open consumables. Return them to your local
representative.
USA Only
Perchlorate Material - special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate.
Disposal of Electrical and Electronic Equip-
ment in Professional/Business Equipment
This symbol on the product, or in the manual and in
the warranty, and/or on its packaging indicates that
this product shall not be treated as household
waste. Instead it should be disposed in compliance
with agreed national procedures.
By ensuring this product is disposed of correctly, you will
help prevent potential negative consequences to the en-
vironment and human health, which could otherwise be
caused by inappropriate waste handling of this product.
Please contact your local representative prior to disposal.
This symbol on the batteries or accumulators indi-
cates that those batteries shall not be treated as
household waste.
If your equipment contains easy removal batteries or accu-
mulators, please dispose these separately according to your
local requirements.
The recycling of materials will help to conserve natural re-
sources. For more detailed information about recycling this
product, please contact your local authorities and ask for the
correct way of disposal.
Support
Our company will store the spare parts necessary to main-
tain the function of the machine for 7 years after the produc-
tion termination of the machine.

12
E-WASTE MANAGEMENT GUIDELINES in India
PROPER HANDLING AND/OR RECYCLING OF THE PRINTERS
Under the E-Waste (Management) Rules, 2016 (hereafter referred to as the “E-Waste Rules”), it is incumbent for all con-
sumers, including the purchaser of this printer, to properly recycle and dispose of all electrical and electronic equipment
through authorized recyclers.
E-Waste of printer has been defined as “waste electrical and electronic equipment, whole or in part or rejects from their
manufacturing and repair process, which are intended to be discarded”.
E-Waste contains various hazardous materials like lead, mercury, cadmium, hexavalent chromium, polybrominated biphenyls
and polybrominated diphenyl ethers. Hence, improper handling and disposal of e-waste releases these hazardous materials
in the environment causing pollution, contamination of soil and water and various health hazards.
Though the product purchased by you is RoHS compliant and does not contain any hazardous material above the prescribed
limit under the E-Waste Rules, it is imperative that the product should be handled with utmost caution and as per the guide-
lines mentioned in this manual including the following Do’s and Don’ts –
Do’s Don’ts
Hand over the E-Waste to Authorized Recycler Never sell the e-waste to any unauthorized agencies, scrap
dealer
E-Waste should be segregated from household and other
wastes.
Never throw E-Waste in bins as part of household waste.
Keep the product in isolated area, after it becomes non-func-
tional/un-repairable so as to prevent its accidental breakage.
Never keep E-Waste in open and exposed area, accessible by
all.
The product should be opened only by authorized service
personnel.
The product should not be opened by the user himself/ her-
self. Dismantling of e-waste by the user can be dangerous
The following marking/symbol on the product or carton indicates that the product and its accessories/parts should not be
disposed of with other household waste at the end of their working life. Please separate these items from other types of
waste and recycle them responsibly for conservation of the environment and collective well-being.
E-WASTE RECYCLING PROGRAM
We have tied up with government approved e-waste recycler for facilitating the collection of e-waste from our channel
partners and customers for recycling. You are simply required to register your request for collection of e-waste. Once your
request is received, the representatives of the authorized recycler would collect the e-waste from your house/premises. For
more details and information on our E-Waste Recycling Program kindly visit our website www.fujifilm.in

13
Location of Warning and Caution Labels

14
Symbols Marked on the Machine
Some of the following symbols may not be used depending on the model.
DANGER, CAUTION,
AND WARNING
DO NOT USE ENVE-
LOPE
DO NOT COPY MO-
NEY
CAUTION (HEATED
SURFACE)
DO NOT USE WIN-
DOWED ENVELOPE
DO NOT THROW A
TONER CARTRIDGE
INTO AN OPEN FLA-
ME
DO NOT INSERT A
FINGER
DO NOT USE POST-
CARDS
DO NOT THROW
WASTE TONER
CONTAINER INTO AN
OPEN FLAME
DO NOT THROW
WASTE TRANSFER
UNIT INTO AN OPEN
FLAME
DO NOT USE FOL-
DED, CREASED, OR
CURLED PAPER
POWER / POWER
SAVING BUTTON
DO NOT TOUCH DO NOT USE FOLD-
ED PAPER
DO NOT USE CUT
AND PASTED DOCU-
MENT
DO NOT USE
CREASED PAPER
DO NOT USE BACK
CARBON PAPER
CAUTION (ELECTRIC
SHOCK)
DO NOT USE CURLED
PAPER
DO NOT USE INK JET
PRINTER PAPER
CAUTION (CUTTING
EDGES)
DO NOT USE THIN
DOCUMENT
DIRT ON THE OUT-
PUT PAPER
DO NOT INSERT A
FINGER
MIXED SIZE DOCU-
MENT
DO NOT INSERT A
FINGER
DO NOT USE TRANS-
PARENCIES FOR
COLOROUTPUT
COATED PAPER
DO NOT USE PAPER
WITH STAPLES OR
CLIPS
DO NOT USE TORN
PAPER
LONG PAPER
CAUTION (HEAVY
OBJECT)
RISK TO SINGLE
WORKER
PAPER JAM USB TERMINAL
MARKING
CLEANING OF SCAN-
NER
GENERAL INSTRUC-
TIONS
LAN TERMINAL
MARKING
FACE PRINT SUR-
FACE DOWN
FACE PRINT SUR-
FACE UP

15

16
