DESKPOWER P300 Series User’s Manual
Fujitsu endeavours to ensure that the information in this document is correct, but accepts no liability
for any error or omission in the same. Any procedures described in this document for operating Fujitsu
products should be read and understood by the operator before such products are used. To ensure
that Fujitsu products function without risk to safety and health, such procedures should be strictly
observed by the operator. The development of Fujitsu products and services is continuous and
published information may not be up to date. Any particular issue of a product may contain facilities
not described herein. It is important to check the current position with Fujitsu. Specifications and
statements as to performance in this document are Fujitsu estimates intended for general guidance.
They may require adjustment in particular circumstances and should therefore not be taken as formal
offers or commitments.
DESKPOWER is a trademark of Fujitsu Limited. The following are registered trademarks of Microsoft
Corporation: MS, MS-DOS, Windows ®NT, Windows ®98, Windows Millennium, Window ®2000 and
Windows XP.
Intel and Pentium are registered trademarks of Intel Corporation in the U.S.
Celeron is a registered trademark of Intel Corporation in the U.S.
Other product names are trademarks or registered trademarks of respective companies.
Other products are copyrighted by individual companies.
All other trademarks referenced are trademarks or registered trademarks of their respective owners,
whose protected rights are acknowledged.
Copyright ©Fujitsu PC Asia Pacific
All rights, including rights of translation, reproduction by printing, copying or similar methods, in part
or in whole, are reserved.
Offenders will be liable for damages.
Allrights,includingrightscreatedbypatentgrantorregistrationofautilitymodelordesign,arereserved.
Delivery subject to availability. Right of teachnical modification reserved.
DECLARATION OF CONFORMITY
according to FCC Part 15 Class B
This device complies with Part 15 Class B of the FCC Rules. Operations are subject to the following
two conditions:
(1) This device may not be allowed to cause harmful interference, (2) This device must accept any
interference received, including interference that may cause undesired operation.
Wesbite: www.fujitsu-pc-asia.com
CHAPTER 0 Washingtons (INTRO) 9/12/12, 10:43 AM1

ii
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions carefully. Save these instructions for future reference.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
4. Do not use this product near water.
5. Do not place thisproduct on an unstablecart, stand, or table.The product may fall,causing serious
damage to the product.
6. Slots and openings in the cabinet and the back or bottom are provided for ventilation; to ensure
reliable operation of the product and to protect it from overheating, these openings must not be
blocked or covered. The openings should never be blocked by placing the product on a bed, sofa,
rug, or other similar surface. This product should never be placed near or over a radiator or heat
register, or in a built-in installation unless proper ventilation is provided.
7. This product should be operated from the type of power indicated on the marking label. If you are
not sure of the type of power available, consult your dealer or local power company.
8. This product is equipped with a 3-wire grounding-type plug, a plug having a third (grounding) pin.
This will only plug into a grounding-type power outlet. This is a safety feature. If you are unable to
insertthe plug intothe outlet, contact yourelectrician to replaceyour obsolete outlet. Do not defeat
the purpose of the grounding-type plug.
9. Do not allow anything to rest on the power cord. Do not locate this product where persons will
walk on the cord.
10. If an extension cord is used with this product, make sure that the total ampere rating of the
equipment plugged into the extension cord does not exceed the extension cord ampere rating.
Also, make sure that the total rating of all products plugged into the wall outlet does not exceed
15 amperes.
11. Never pushobjectsof any kind into thisproductthrough cabinet slots astheymay touch dangerous
voltagepointsthat could result in a fireorelectricshock. Never spill liquid of anykindonthe product.
12. Do not attempt to service this product yourself, as opening or removing covers may expose you
to dangerous voltage points or other risks. Refer all servicing to qualified service personnel.
CHAPTER 0 Washingtons (INTRO) 9/12/12, 10:43 AM2

iii
13. Unplug this product from the wall outlet and refer servicing to qualified service personnel under
the following conditions:
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally when the operating instructions are followed. Adjust
only those controls that are covered by the operating instructions since improper adjustment
of other controls may result in damage and will often require extensive work by a qualified
technician to restore the product to normal condition.
e. If the product has been dropped or the cabinet has been damaged.
f. If the product exhibits a distinct change in performance, indicating a need for service.
14. CAUTION. When replacing the battery, be sure to install it with the polarities in the correct
position. There is a danger of explosion if the battery is replaced with an incorrect type or
is mistreated. Do not recharge, disassemble or dispose of in fire. Replace only with the
same or equivalent type recommeded by the manufacturer. Dispose of the used battery
according to the manufacturer’s instructions.
15. Use only the proper type of power supply cord set (provided in your accessories box) for this unit.
It should be a detachable type: UL listed/CSA certified, BS1363,ASTA,SS145 certified, rated 10A
250V minimum, VDE approved or its equivalent. Maximum length is 15 feet (4.6 meters).
16. NOTE:
Pleasetake extra precaution when connectingthe LAN cable; do notconnect the LAN cable
to the peripheral device’s connector, that might have excessive voltage.
CHAPTER 0 Washingtons (INTRO) 9/12/12, 10:43 AM3

iv
Before reading this manual
This section describes safety precautions and convention used in this manual. Be sure to read this.
For Safe Operation
This manual contains important information for using the DESKPOWER personal computer.
Readthismanualthoroughlybefore using your PC. In particular, “Safety Precautions”inthismanual
must be read and understood.
This manual including “Safety Precautions” must be readily available at all times.
This equipment is compliant with the PC industry standard (PC-11-1988) of the Japan Electronics
and Information Technology Industries Association.
Note
This product is a Class B Information Technology Equipment and conforms to the standard set by
the Voluntary Control Council for Interference by Technology Equipment (VCCI).This product is
designed to be used in a domestic environment, however, it may cause radio interference when
used in the vicinity of a radio or television receiver.
Make sure that you read the manual when using this product.
Fujitsu, as a member of the International Energy Star Program, recognizes that
this equipment is compliant with the standard of the International Energy Star
Program.
The International Energy Star Program is a worldwide program for promoting
energy saving for computers and other office equipment. The program aims at
promoting the development and use of products equipped with the functions that can effectively
reduce energy consumption and uses a voluntary system that allows enterprises to join at their
own discretion. The target products are office equipment including computers, displays, printers,
facsimiles, and copying machines. The standards for individual types of equipment and the mark
( ) prepared by the Program are used commonly among member countries.
Caution
Thisequipmentis class B information technology equipment basedonthe standard of the Voluntary
Control Council for Interference by Information Technology Equipment (VCCI). Although the
equipment is intended for use in residential environments, it may create interference if placed near
radio or television.
Handle the equipment in accordance with the manual.
CHAPTER 0 Washingtons (INTRO) 9/12/12, 10:43 AM4

v
Using this Product for High-Safety Applications
Thisproduct is for office,personal,home, ordinary industry andother general use. Itis not designed
and manufactured for use in high-safety applications.
Do not use this product for such applications without taking measures to satisfy the high-safety
requirements.
High-safety applications require extremely high level of safety, and involve serious hazards to life
and health if the required safety is not assured. High-safety applications include the following.
●Nuclear reaction control in nuclear facilities, automatic aviation control, air traffic control, mass-
transportation control, life-supporting medical equipment, and missile launch control.
Some parts (including the CRT display, LCD, or hard disk drive) used on this product have a limited
life. When used continuously for a prolonged period, these parts will need earlier replacement.
Backing Up the Data
Thecustomer is responsible for maintainingtheintegrity of data (includingthebasic and application
software)storedorinstalled on the product. We do not warranttheintegrityofdata stored or installed
onthe personal computer thecustomer sent for repair.Takeappropriate measures such asmaking
a backup.
We assume no responsibility for loss of data and any direct or incidental damage due to any cause
other than those specified in the warranty.
This computer is designed for use within the country. If you are using it abroad, please do so on
your own responsibility.
This equipment may be adversely affected by the momentary drop of the supplied voltage due to
lightning. Use of an AC uninterruptible power supply is recommended for measures against the
momentary drop of the supplied voltage.
(This message is based on the Japan Electronics and Information Technology Industries
Association’s guidelines for measures against momentary voltage drop in PCs.)
Since this equipment contains special materials controlled by the Foreign Exchange and Foreign
Trade Control Law. Authorization under the law may be required to export this equipment.
CHAPTER 0 Washingtons (INTRO) 9/12/12, 10:43 AM5

vi
Microsoft Service Pack
Microsoft Corp. offers Service Pack to provide the users of Microsoft®Windows®with more stable
system operation (http://www.microsoft.com/).
Thelatest version of the Service Pack helpsyou configure the most stable system usingMicrosoft®
Windows®provided at that time by Microsoft Corp.
We recommend you to use the latest version.
In some environments, however, the Service Pack may cause unexpected failure. Read
Readme.txt for the Service Pack before use.
Again, we recommend you to make a system backup in case of failed installation.
Components of this product (motherboard, CD-ROM, hard disk, and floppy disk drive) contain
traces of heavy metals (lead and chrome) and chemical (antimony).
CHAPTER 0 Washingtons (INTRO) 9/12/12, 10:43 AM6

vii
Conventions Used in This Manual
Introduction
This manual tells you how to put your PC into operation and how to operate it in daily use.
Depending on the configuration level chosen some of the hardware components described may not
be available on your PC. Please observe the notes on your operating system.
You can incorporate operable drives (for example DAT drive) as well as other boards.
Depending on the configuration selected, the operating system is preinstalled on your hard disk (e.g.
Windows XP).
Your PC has a number of security features to ensure that no unauthorised persons can access your
data, for example, you can activate a screen saver with password protection. For example, you can
activate a screen saver with password protection. The security functions in the BIOS Setup also allow
you to protect your data by means of passwords.
Notational conventions
The meanings of the symbols and fonts used in this manual are as follows:
Indicates information which is important for your health or for preventing
physical damage.
Indicates important information which is required to use the system properly.
Text which follows this symbol describes activities that must be performed in the order shown.
Text in this typeface indicates screen outputs.
"Quotation marks" indicate names of chapters or terms.
CAUTION
CHAPTER 0 Washingtons (INTRO) 9/12/12, 10:43 AM7

viii
Important Notes
Inthis chapter youwill find information regarding safety which isessential to takenote of when working
with your PC. The manufacturer's notes contain helpful information on your PC.
Safety
CAUTION
During installation and before operating the device, please observe the instructions on
environmental conditions in the chapter entitled "Technical data" as well as the instructions in the
chapter "Preparing for Use".
Please check whether the device is correctly set for the local power supply (see "Preparing for
Use" chapter).
Themain switch and theON/OFF switch do notdisconnect the system unitfrom the mains voltage.
To completely disconnect the mains voltage, remove the power plug from the grounded mains
outlet.
Replacethe lithium batteryon the systemboard in accordance with the instructions in the "System
expansions - Replacing lithium battery" chapter.
Caution: components in the system can get very hot.
Manufacturer’s notes
Keep this operating manual together with your device. If you pass on the device to third parties,
you should include this manual.
Energy saving
When the PC is delivered, some energy-saving functions are already set
If you are not using your PC, switch it off.
In the BIOS Setup you may set further energy-saving functions for the PC.
Depending on the operating system, you can set additional power-management features.
Energy saving under Windows 2000/XP
The Screen Saver tab allows you to set energy-saving functions for your screen. Select the
following item in the menu: Start →Settings →Control Panel →Display →Display Properties →
Screen Saver →Energy saving features of monitor.
With the default setting Control Panel →Power Options →Advanced additional power
management features of Windows 2000/XP are available.
CHAPTER 0 Washingtons (INTRO) 9/12/12, 10:43 AM8

ix
FCC Class B Compliance Statement
Thefollowing statement applies to theproductscovered in this manual,unlessotherwise specified
herein. The statement for other products will appear in the accompanying documentation.
NOTE:
This equipment has been tested and found to comply with the limits for a "Class B" digital device,
pursuant to Part 15 of the FCC rules and meets all requirements of the Canadian Interference-
Causing Equipment Regulations. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in strict accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between equipment and the receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
Fujitsu is not responsible for any radio or television interference caused by unauthorised
modifications of this equipment or the substitution or attachment of connecting cables and
equipment other than those specified by Fujitsu. The correction of interference caused by such
unauthorised modification, substitution or attachment will be the responsibility of the user.
The use of shielded I/O cables is required when connecting this equipment to any and all optional
peripheral or host devices. Failure to do so may violate FCC rules.
CHAPTER 0 Washingtons (INTRO) 9/12/12, 10:43 AM9

x
Transporting the PC
CAUTION
Transport all parts separately in their original packaging or in a packaging which protects them
from knocks and jolts, to the new site. Do not unpack them until all transportation manoeuvres
are completed.
Never drop the monitor!
Cleaning the PC
CAUTION
Turn off all power and equipment switches and remove the power plug from the mains supply.
Do not clean any interior parts yourself, leave this job to a service technician.
Do not use any cleaning agents that contain abrasives or may corrode plastic.
Ensure that no liquid enters the system.
Ensure that the ventilation areas of the system unit and the monitor are free.
Cleaning the system unit and the monitor
Wipe the system unit and monitor casing with a dry cloth. If particularly dirty, use a cloth that has
been moistened in mild domestic detergent and then carefully wrung out.
Cleaning the keyboard and the mouse
Use disinfectant wipes to clean the keyboard and the mouse.
The mouse mechanism and the mouse ball can be cleaned by removing the retaining ring on the
underside of the mouse.
Additional information can be found in the documentation for your keyboard and mouse.
CHAPTER 0 Washingtons (INTRO) 9/12/12, 10:43 AM10

xi
Disposal and recycling
This device has been manufactured to the highest possible degree from materials which can be
recycled or disposed of in a manner that is not environmentally damaging. The device may be taken
back after use to be recycled, provided that it is returned in a condition that is the result of normal use.
Any components not reclaimed will be disposed of in an environmentally acceptable manner.
Do not throw lithium batteries into the household waste. They must be disposed of in accordance
with local regulations concerning special waste.
Reference to products
In this manual, the product names are referred to as follows:
This manual includes information on other operating systems.
Product name Description used in the manual
Microsoft®Windows®XP Professional
Microsoft®Windows®XP Home Edition
Microsoft®Windows®2000 Professional
Windows*
Windows
XP
Windows XP
Professional
Windows XP
Home Edition
Windows 2000
CHAPTER 0 Washingtons (INTRO) 9/12/12, 10:43 AM11

xii
Warning and caution labels
Your PC bears the warning and caution labels as shown below.
The warning and caution labels must not be removed or damaged.
Rear of the PC main unit
ATTENTION
115V of voltage switch in the power supply corresponds to 100-127V
230V of voltage switch in the power supply corresponds to 200-240V
WARNING
• Before mounting or dismounting an optional unit in/from your PC, switch off
the PC and all connected units and unplug all power cords from respective
outlets to prevent electric shock.
Electric shock
WARNING
To prevent electric shock,
switch off the PC and
connected peripherals and
unplug power cords from
respective outlets before
disassembling the unit and
installing a built-in option.
Electric shock
WARNING
To prevent electric
shock and/or fire, do
not remove the cover
of this unit, which
includes a high
voltage section.
Inside the PC main unit
CHAPTER 0 Washingtons (INTRO) 9/12/12, 10:43 AM12

xiii
Before Reading This Manual
This section contains cautions for safe operation, representations and symbols used in this manual.
Be sure to read this first!
Chapter 1Preparing for Use
This chapter provides the names and functions of individual parts.
Chapter 2Operation
Thissection describes thelocation of installationand installation of the computer.
Chapter 3Troubleshooting and Tips
This chapter provides the basic information on the PC and operation.
Chapter 4System Expansion
Thischapter provides basic information onhowto handle the peripheralsinstalled
(or can be installed) on the PC.
Chapter 5Technical Data
This chapter describes the specifications of this PC.
Organization of This Manual
CHAPTER 0 Washingtons (INTRO) 9/12/12, 10:43 AM13

xiv
Contents
CHAPTER 1 Preparing for Use
1 Preparing for Use ..............................................................................2
Unpacking and Checking the Delivery ............................................................. 2
Steps for Initial Setup ....................................................................................... 2
Setting Up the PC ............................................................................................ 3
Connect the Monitor, Mouse and Keyboard ..................................................... 3
Connecting the PC to the Mains Voltage .......................................................... 5
Initial Switch-on: Software will be Installed ....................................................... 6
Connecting External Devices ........................................................................... 8
CHAPTER 2 Operation
1 Operation .........................................................................................12
Switching On the PC ...................................................................................... 12
Switching Off the PC ...................................................................................... 13
Indicators on the PC....................................................................................... 14
2 Keyboard .........................................................................................15
3 Floppy Disks ...................................................................................17
Working with Floppy Disks ............................................................................. 17
Settings in BIOS Setup .................................................................................. 18
Property and Data Protection ......................................................................... 18
Access Protection Under Windows ................................................................ 18
BIOS Setup Security Functions ...................................................................... 19
CHAPTER 3 Troubleshooting and Tips
1 Troubleshooting and Tips ..............................................................22
Installing New Software .................................................................................. 22
Power-on Indicator Remains Unlit After You Have Switched on Your Device . 22
No Mouse Pointer Displayed on the Screen................................................... 24
The Floppy Disk Cannot be Read or Written .................................................. 24
Time and/or Date is Not Correct .................................................................... 25
Tips ................................................................................................................ 25
CHAPTER 0 Washingtons (INTRO) 9/12/12, 10:43 AM14

xv
CHAPTER 4 System Expansion
1 System Expansions ........................................................................28
Information about boards ............................................................................... 28
Opening the casing ........................................................................................ 29
Closing the casing .......................................................................................... 29
Installing and Removing a Board ................................................................... 30
Low-Profiles boards ....................................................................................... 34
Installing an Additional Serial Port ................................................................. 34
Installing and Removing the Hard Disk Drives ............................................... 35
Replacing Lithium Battery .............................................................................. 37
CHAPTER 5 Technical Data
1 Technical Data.................................................................................40
List of Specifications ...................................................................................... 40
Electrical Data ................................................................................................ 42
CHAPTER 0 Washingtons (INTRO) 9/12/12, 12:14 PM15

CHAPTER 1
Preparing for Use
CHAPTER 1 Washingtons (01-10) 9/12/12, 10:44 AM1

2
1 Preparing for Use
CAUTION
Please take note of the safety information in the "Important notes" chapter.
■Unpacking and Checking the Delivery
It is recommended not to throw away the original packaging material! It may be required for
reshipment at some later date.
●Unpack all the individual parts.
●Check the delivery for damage incurred during transportation.
●Check whether the delivery agrees with the details in the delivery note.
Should you discover that the delivery does not correspond to the delivery note, notify your local
sales outlet immediately.
■Steps for Initial Setup
First-time setup includes the connection of the monitor, mouse and keyboard to the system unit
and the setup of the supplied software.
●External devices
If you have received other devices in addition to your PC (e.g. a printer or a modem), do
not connect these until after the initial installation. The following sections contain a
description of how to connect these external devices: "Connecting external devices to
the serial port" and "Connecting external devices to the parallel port".
●Drives and boards
If you have received drives or boards with your PC, please do not install them until after
first-time setup. How to install drives and boards is described in the chapter "System
expansions".
Perform the following steps in the prescribed order:
1. Decide where you are going to use the PC, and then set it up.
2. Connect the monitor, mouse and keyboard to the PC.
3. Check the rated voltage of the PC and connect it to the mains voltage.
4. Switch the PC on and follow the instructions on the screen.
CHAPTER 1 Washingtons (01-10) 9/12/12, 10:44 AM2

3
■Setting Up the PC
CAUTION
When installing your PC, give consideration to the recommendations and safety notes.
Set up the PC only in its correct orientation. The points to observe are illustrated on the following
pages.
We recommend that you place your equipment on a surface with good anti-slip qualities. In view
of the multitude of different finishes and varnishes used on furniture, it is possible that the rubber
feet of the devices will mark the surface they stand on.
Do not expose the PC to extreme environmental conditions (see chapter "Technical data") and
protect it from dust, humidity and heat.
Provide at least 200 mm of clearance on the left, in front of and behind the ventilator area of the
system unit to ensure adequate ventilation. Do not cover the ventilation areas of the monitor and
the system unit.
Do not place several system units one above the other.
■Connect the Monitor, Mouse and Keyboard
The ports for monitor, mouse and keyboard are on the rear and on the front of the system unit.
PS/2 keyboard port / purple PS/2 mouse port / green
Monitor port / blue USB port / black
Connecting the keyboard
Connecting standard keyboard
Use the supplied keyboard cable only.
●Plug the round keyboard cable connector into the port marked with this symbol on the
system unit.
CHAPTER 1 Washingtons (01-10) 9/12/12, 10:45 AM3

4
Connecting the mouse
Connecting a PS/2 mouse
●Connect the PS/2 mouse to the PS/2 mouse port on the system unit.
Connecting USB mouse
●Connect the USB mouse to the USB port on the system unit.
If you do not attach a mouse at the PS/2 mouse port , you can disable the mouse controller
in the BIOS Setup in order to free the IRQ12 for a different application.
CHAPTER 1 Washingtons (01-10) 9/12/12, 10:45 AM4

5
■Connecting the PC to the Mains Voltage
1 Notch for inserting the screwdriver
If the power supply of your PC does not have a slide-in or plug-in element for setting the rated
voltage, then your system automatically sets itself to the local rated voltage. If you have a PC with
a slide-in or plug-in element, then you must match the set rated voltage to the local rated voltage.
Check the voltage setting.
CAUTION
Devices with main power switch:
The value indicated with an arrow must be compatible with the local rated voltage:
• 115 = 100 V to 127 V
• 230 = 200 V to 240 V
If the voltage setting is incorrect, then lift out the manual voltage adjuster with a screwdriver (1),
turn it to the required setting and reinsert it.
Devices without main power switch:
The visible value must agree with the local mains voltage:
• 115 = 100 V to 127 V
• 230 = 200 V to 240 V
Ifan incorrect mains voltage is set, push the slide switch allthe way into the other possible position
with a pointed object.
200 V - 240 V
200 V - 240 V
100 V - 127 V
100 V - 127 V
a
a
a = Notch for inserting the screwdriver
3Check the voltage setting.
CHAPTER 1 Washingtons (01-10) 9/12/12, 10:45 AM5
