Fujitsu PRIMERGY TX1330 M2 User manual

Operating Manual - English
FUJITSU Server PRIMERGY TX1330 M2
Operating Manual
Edition November 2015

Comments…Suggestions…Corrections…
The User Documentation Department would like to
know your opinion of this manual. Your feedback helps
us optimize our documentation to suit your individual
needs.
Feel free to send us your comments by e-mail to
[email protected].
Certified documentation
according to DIN EN ISO 9001:2008
To ensure a consistently high quality standard and
user-friendliness, this documentation was created to
meet the regulations of a quality management system
which complies with the requirements of the standard
DIN EN ISO 9001:2008.
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de
Copyright and Trademarks
Copyright © 2015 Fujitsu Technology Solutions GmbH.
All rights reserved.
Delivery subject to availability; right of technical modifications reserved.
All hardware and software names used are trademarks of their respective manufacturers.
– The contents of this manual may be revised without prior notice.
– Fujitsu assumes no liability for damages to third party copyrights or other rights arising from
the use of any information in this manual.
– No part of this manual may be reproduced in any without the prior written permission of
Fujitsu.
Microsoft, Windows, Windows Server, and Hyper V are trademarks or registered trademarks of
Microsoft Corporation in the USA and other countries.
Intel and Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries
in the USA and other countries.

TX1330 M2 Operating Manual
Before reading this manual
For your safety
This manual contains important information for safely and correctly using this
product.
Carefully read the manual before using this product. Pay particular attention to
the accompanying manual "Safety Notes and Regulations" and ensure these
safety notes are understood before using the product. Keep this manual and the
manual "Safety Notes and Regulations" in a safe place for easy reference while
using this product.
Radio interference
This product is a "Class A" ITE (Information Technology Equipment). In a
domestic environment this product may cause radio interference, in which case
the user may be required to take appropriate measures. VCCI-A
Aluminum electrolytic capacitors
The aluminum electrolytic capacitors used in the product's printed circuit board
assemblies and in the mouse and keyboard are limited-life components. Use of
these components beyond their operating life may result in electrolyte leakage
or depletion, potentially causing emission of foul odor or smoke.
As a guideline, in a normal office environment (25°C) operating life is not
expected to be reached within the maintenance support period (5 years).
However, operating life may be reached more quickly if, for example, the
product is used in a hot environment. The customer shall bear the cost of
replacing replaceable components which have exceeded their operating life.
Note that these are only guidelines, and do not constitute a guarantee of
trouble-free operation during the maintenance support period.
High safety use
This product has been designed and manufactured to be used in commercial
and/or industrial areas as a server.
When used as visual display workplace, it must not be placed in the direct field
of view to avoid incommoding reflections (applies only to TX server systems).
The device has not been designed or manufactured for uses which demand an
extremely high level of safety and carry a direct and serious risk of life or body
if such safety cannot be assured.

Operating Manual TX1330 M2
These uses include control of nuclear reactions in nuclear power plants,
automatic airplane flight control, air traffic control, traffic control in mass
transport systems, medical devices for life support, and missile guidance
control in weapons systems (hereafter, "high safety use"). Customers should
not use this product for high safety use unless measures are in place for
ensuring the level of safety demanded of such use. Please consult the sales
staff of Fujitsu if intending to use this product for high safety use.
Measures against momentary voltage drop
This product may be affected by a momentary voltage drop in the power supply
caused by lightning. To prevent a momentary voltage drop, use of an AC
uninterruptible power supply is recommended.
(This notice follows the guidelines of Voltage Dip Immunity of Personal
Computer issued by JEITA, the Japan Electronics and Information Technology
Industries Association.)
Technology controlled by the Foreign Exchange and Foreign Trade
Control Law of Japan
Documents produced by Fujitsu may contain technology controlled by the
Foreign Exchange and Foreign Trade Control Law of Japan. Documents which
contain such technology should not be exported from Japan or transferred to
non-residents of Japan without first obtaining authorization in accordance with
the above law.
Harmonic Current Standards
This product conforms to harmonic current standard JIS C 61000-3-2.
Only for the Japanese market: About SATA hard disk drives
The SATA version of this server supports hard disk drives with SATA / BC-SATA
storage interfaces. Please note that the usage and operation conditions differ
depending on the type of hard disk drive used.
Please refer to the following internet address for further information on the
usage and operation conditions of each available type of hard disk drive:
http://jp.fujitsu.com/platform/server/primergy/harddisk/

TX1330 M2 Operating Manual
Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.1 Concept and target groups for this manual . . . . . . . . . . 9
1.2 Documentation overview . . . . . . . . . . . . . . . . . . . 10
1.3 Notational conventions . . . . . . . . . . . . . . . . . . . . 11
2 Functional overview . . . . . . . . . . . . . . . . . . . . . . 13
2.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.2 Server specification . . . . . . . . . . . . . . . . . . . . . . 23
3 Installation steps, overview . . . . . . . . . . . . . . . . . . 29
4 Important information . . . . . . . . . . . . . . . . . . . . . 31
4.1 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . 31
4.2 ENERGY STAR . . . . . . . . . . . . . . . . . . . . . . . . . 39
4.3 CE conformity . . . . . . . . . . . . . . . . . . . . . . . . . 39
4.4 FCC Class A Compliance Statement . . . . . . . . . . . . . 40
4.5 Transporting the server . . . . . . . . . . . . . . . . . . . . 41
4.6 Notes on installing the server in the rack . . . . . . . . . . . 41
4.7 Environmental protection . . . . . . . . . . . . . . . . . . . 43
5 Hardware installation . . . . . . . . . . . . . . . . . . . . . . 45
5.1 Unpacking the server . . . . . . . . . . . . . . . . . . . . . 46
5.2 Setting up the floorstand model . . . . . . . . . . . . . . . . 47
5.3 Installing/removing the rack model . . . . . . . . . . . . . . 48
5.4 Connecting devices to the server . . . . . . . . . . . . . . . 50

Operating Manual TX1330 M2
Contents
5.5 Connecting the server to the mains . . . . . . . . . . . . . . 51
5.5.1 Using cable ties (standard PSU) . . . . . . . . . . . . . . . . . 52
5.5.2 Using cable ties (hot-plug PSU) . . . . . . . . . . . . . . . . . 53
5.6 Notes on connecting/disconnecting cables . . . . . . . . . . 54
6 Starting up and operation . . . . . . . . . . . . . . . . . . . . 57
6.1 Access to the drives (floorstand model) . . . . . . . . . . . . 57
6.1.1 Enabling access to the accessible drives . . . . . . . . . . . . . 57
6.1.2 Access to the HDD modules (floorstand model) . . . . . . . . . 59
6.2 Control elements and indicators . . . . . . . . . . . . . . . . 60
6.2.1 Front of the server . . . . . . . . . . . . . . . . . . . . . . . . 60
6.2.1.1 Control elements . . . . . . . . . . . . . . . . . . . . . . . 61
6.2.1.2 Indicators on the control panel . . . . . . . . . . . . . . . . 62
6.2.1.3 ID card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
6.2.1.4 Indicators on the drives . . . . . . . . . . . . . . . . . . . . 65
6.2.2 Rear of server . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
6.2.2.1 Indicators on the connector panel . . . . . . . . . . . . . . . 66
6.3 Switching the server on and off . . . . . . . . . . . . . . . . 71
6.4 Configuring the server . . . . . . . . . . . . . . . . . . . . . 73
6.4.1 Configuring the onboard SATA controller . . . . . . . . . . . . . 73
6.4.2 Configuring the SAS/SATA RAID controller
(PCIe expansion card) . . . . . . . . . . . . . . . . . . . . . . 74
6.4.3 Configuring the server and installing the operating system
with the ServerView Installation Manager . . . . . . . . . . . . . 75
6.4.4 Configuring the server and installing the operating system
without the ServerView Installation Manager . . . . . . . . . . . 76
6.5 Cleaning the server . . . . . . . . . . . . . . . . . . . . . . . 77
7 Property and data protection . . . . . . . . . . . . . . . . . . 79
7.1 BIOS Setup security functions . . . . . . . . . . . . . . . . . 79
8 Troubleshooting and tips . . . . . . . . . . . . . . . . . . . . 81
8.1 Power-on indicator remains unlit . . . . . . . . . . . . . . . . 81
8.2 Server switches itself off . . . . . . . . . . . . . . . . . . . . 82

TX1330 M2 Operating Manual
Contents
8.3 Screen remains blank . . . . . . . . . . . . . . . . . . . . . 82
8.4 Flickering stripes on monitor screen . . . . . . . . . . . . . 83
8.5 No screen display or display drifts . . . . . . . . . . . . . . 83
8.6 No mouse pointer displayed on screen . . . . . . . . . . . . 83
8.7 Incorrect date and time . . . . . . . . . . . . . . . . . . . . 84
8.8 Drives reported as “dead” when starting system . . . . . . 84
8.9 Added drive reported as defective . . . . . . . . . . . . . . 84
8.10 Error message on screen . . . . . . . . . . . . . . . . . . . 85
8.11 Expansion cards or onboard devices not recognized . . . . 85
8.12 Temperature warning . . . . . . . . . . . . . . . . . . . . . . 85
8.13 No effect of keyboard or mouse . . . . . . . . . . . . . . . . 85
8.14 Optical drive cannot read data . . . . . . . . . . . . . . . . 86

Operating Manual TX1330 M2
Contents

TX1330 M2 Operating Manual 9
1 Introduction
The PRIMERGY TX1330 M2 is the ideal robust and cost-efficient server for
small and medium-sized businesses (SMB) or branch offices. It offers best
Intel
®
Xeon
®
E3 performance and solid expandability thanks to hot-plug storage
drives.
The optionally redundant power supply and a choice of different RAID
controllers ensure high availability and peace of mind. Thanks to its compact
housing and extremely low operating noise the server is ideally suited for
showrooms or offices, for example under the desk. The optional support of
legacy PCI adapter cards makes the PRIMERGY TX1330 M2 optimally suited
for special solutions, such as telephone or security systems.
Furthermore, the comprehensive Fujitsu ServerView
®
Suite provides support
for administrators during server installation, deployment and administration.
The PRIMERGY TX1330 M2: an excellent long-term investment.
The floorstand model can be converted to a rack model using an optional
conversion kit. The rack model occupies 4 height units in the rack.
1.1 Concept and target groups for this manual
This operating manual describes how to install, set up and operate your server.
This operating manual is intended for those responsible for installing the
hardware and ensuring that the system runs smoothly. It contains all the
information you need to put your PRIMERGY TX1330 M2 into operation.
To understand the various expansion options, you will need to be familiar with
the fields of hardware and data transmission and you will require a basic
knowledge of the underlying operating system.

10 Operating Manual TX1330 M2
Introduction
1.2 Documentation overview
More information on your PRIMERGY TX1330 M2 can be found in the following
documents:
– "Quick Start Hardware - FUJITSU Server PRIMERGY TX1330 M2"
– "ServerView Quick Start Guide"
– "Safety Notes and Regulations" manual
"安全上のご注意 " for the Japanese market
– "Warranty" manual
"保証書 " for the Japanese market
– "ServerView Suite Local Service Concept - LSC" manual
– "Returning used devices" manual and "Service Desk" leaflet
"サポー ト ＆サービス " for the Japanese market
– "FUJITSU Server PRIMERGY TX1330 M2 Upgrade and Maintenance
Manual"
– "D3373 BIOS Setup Utility for FUJITSU Server PRIMERGY TX1330 M2
Reference Manual"
IAll documentation on PRIMERGY hardware and ServerView software is
available online from the Fujitsu manuals server at:
– For the EMEA market: http://manuals.ts.fujitsu.com
– For the Japanese market:
http://jp.fujitsu.com/platform/server/primergy/manual
The complete PRIMERGY documentation set can also be downloaded
as a DVD ISO image at:
– For the EMEA market: ftp://ftp.ts.fujitsu.com/images/serverview/manuals
– For the Japanese market: http://jp.fujitsu.com/primergy/downloads
IFor the Japanese market:
Before using the product, please check for additional information that
may be available under the following URL:
http://jp.fujitsu.com/platform/server/primergy/products/note/

TX1330 M2 Operating Manual 11
Introduction
Further sources of information:
– ServerView Suite Glossary
– Manual for the monitor
– Documentation for the boards and drives
– Operating system documentation
– Information files in your operating system
1.3 Notational conventions
The following notational conventions are used in this manual:
Text in italics indicates commands or menu items.
"Quotation marks" indicate names of chapters and terms that are being
emphasized.
Êdescribes activities that must be performed in the order
shown.
VCAUTION! pay particular attention to texts marked with this symbol.
Failure to observe this warning may endanger your life,
destroy the system or lead to the loss of data.
Iindicates additional information, notes and tips.

12 Operating Manual TX1330 M2
Introduction

TX1330 M2 Operating Manual 13
2 Functional overview
This section provides information on the features and technical data of the
PRIMERGY TX1330 M2 server. For information on key characteristics and
layout of the system board, see the "FUJITSU Server PRIMERGY TX1330 M2
Upgrade and Maintenance Manual".
2.1 Features
IFor the latest information on optional products provided for the
TX1330 M2 see the configurator of the server:
http://ts.fujitsu.com/products/standard_servers/index.html
(for the global market)
http://jp.fujitsu.com/platform/server/primergy/system/
(for the Japanese market)
Intel®Xeon®, Pentium®, Celeron®or Core™ i3 processor
The server has an Intel®Xeon®, Pentium®, Celeron®or Core™ i3 processor for
high-speed data processing.
Customer Self Service (CSS)
The PRIMERGY Customer Self Service (CSS) concept enables you to identify
and replace the affected component yourself in the case of certain error
scenarios.
In the CSS concept, you can replace the following components yourself in the
event of an error:
– Hot-plug HDD/SSD modules
– Hot-plug power supply units
– Memory modules
– Expansion cards
For information on replacing these components, see the "FUJITSU Server
PRIMERGY TX1330 M2 Upgrade and Maintenance Manual".
CSS indicators on the control panel and on the back of the PRIMERGY server
provide you with information if a CSS event arises.

14 Operating Manual TX1330 M2
Functional overview
You can also fit your server with a ServerView Local Service Panel, which
enables you to identify the type of component affected by the error directly on
the server.
In addition, CSS errors are displayed in the ServerView Operations Manager,
the server management software from Fujitsu.
In the event of errors, the ServerView Operations Manager refers you directly
to the affected component and its order information in the Illustrated Spares
catalog of the server in question. (This feature is not available for the Japanese
market.)
IFurther information on the CSS concept is provided in the "PRIMERGY
ServerView Suite Local Service Concept - LSC" manual.
System board
The features of the system board are described in the "FUJITSU Server
PRIMERGY TX1330 M2 Upgrade and Maintenance Manual" for the hardware
and in the "D3373 BIOS Setup Utility for FUJITSU Server PRIMERGY
TX1330 M2 Reference Manual" for the firmware.
Trusted Platform Module (TPM)
A Trusted Platform Module (TPM) for safer storage of keys can be implemented
as an option. This module enables programs from third party manufacturers to
store key information (e.g. drive encryption using Windows Bitlocker Drive
Encryption).
The TPM is activated via the BIOS system (for more information, refer to the
"D3373 BIOS Setup Utility for FUJITSU Server PRIMERGY TX1330 M2
Reference Manual").
VCAUTION!
– When using the TPM, note the program descriptions provided by the
third party manufacturers.
– You must also create a backup of the TPM content. To do this, follow
the third party manufacturer's instructions. Without this backup, if the
TPM or the system board is faulty you will not be able to access your
data.
– If a failure occurs, please inform your service about the TPM
activation before it takes any action, and be prepared to provide them
with your backup copies of the TPM content.

TX1330 M2 Operating Manual 15
Functional overview
Hard disk drives
The server is shipped with one of the following drive cages:
– For up to twelve 3.5-inch SAS/SATA hard disk drives:
Up to twelve 3.5-inch SAS/SATA HDD modules can be used in the drive
cage. Each HDD module can accommodate an SAS/SATA hard disk drive
with a maximum height of 1 inch. The HDD modules are connected to the
SAS/SATA backplane wirelessly. This allows HDD modules to be plugged in
or pulled out easily.
IUp to four SATA hard disk drives are controlled by the onboard SATA
controller. An additional SAS/SATA RAIDcontroller must be installed
to control additional SATA hard disk drives or SAS hard disk drives.
IConfigurations with Eco SATA can only be mixed with BC SATA HDD
type. SAS and BC SATA drives with the same size can be mixed, but
not used in the same logical RAID volume.
– For up to twenty four 2.5-inch SAS/SATA hard disk drives or 2.5-inch SATA
SSD drives:
Up to twenty four 2.5-inch HDD/SSD modules can be used in the drive cage.
Each module can accommodate SAS/SATA hard disk drive or an SATA SSD
drive with a 2.5-inch format. The HDD/SSD modules are connected to the
SAS/SATA backplane wirelessly. This allows modules to be plugged in or
pulled out easily.
IUp to eight SAS/SATA hard disk drives are controlled by the
SAS/SATA RAID controller already installed.
IConfigurations with Eco SATA can only be mixed with BC SATA HDD
type. SAS and BC SATA drives with the same size can be mixed, but
not used in the same logical RAID volume.
Hybrid configurations of SATA HDD and SATA SSD modules are supported.
If the server has the corresponding RAID configuration, the HDD modules can
also be replaced during operation.
Onboard SATA controller
A SATA controller is integrated on the system board; up to four SATA hard disk
drives can be connected to the controller. The LSI Embedded MegaRAID
software (SATA Software RAID) supports RAID levels 0, 1 and 10.

16 Operating Manual TX1330 M2
Functional overview
For more information on configuring the controller, see section "Configuring the
onboard SATA controller" on page 73.
SAS/SATA RAID controller
The server is available with the following SAS/SATA RAID controllers for
operating the internal SAS/SATA hard disk drives:
– Modular RAID 0/1 controller with "Integrated RAID" (SAS IR) for SAS3.0
RAID levels 0 and 1 are supported for internal hard disk drive configurations.
– Modular RAID 0/1 controller with "MegaRAID functionality"
(SAS MegaRAID) for SAS3.0
RAID levels 0, 1, 10, 1E, 5 and 50 are supported for internal hard disk drive
configurations.
– Modular RAID 5/6 controller with "MegaRAID functionality"
(SAS MegaRAID) for SAS3.0
RAID levels 0, 1, 10, 1E, 5, 50, 6 and 60 are supported for internal hard disk
drive configurations. As an option, a Flash backup unit (FBU) can save the
memory content even if the power fails. Cache memory size of 1GB or 2GB
are available.
IFor more information on configuring the controller, see section
"Configuring the SAS/SATA RAID controller (PCIe expansion card)" on
page 74.
Further information on SAS/SATA RAID controllers is provided in the
"Modular RAID Controller Installation Guide" (on the Fujitsu manuals
server under x86 Servers - Expansion Cards - Storage Adapters - LSI RAID /
SCSI Controllers).
Further information on other SAS/SATA RAID controllers (e.g. for
operating external SAS/SATA hard disk drives or tape drives) is available
on the Fujitsu manuals server under x86 Servers - Expansion Cards -
Storage Adapters - LSI RAID / SCSI Controllers.

TX1330 M2 Operating Manual 17
Functional overview
Accessible drives
The server has three 5.25-inch bays that can be used in various ways:
The individual bays can be equipped with any 3.5-inch drives (height:1.6 inch).
You can install a multibay (DVD-LSD/LSP) in the top bay. You can install a
slimline DVD drive and the ServerView Local Service Display or ServerView
Local Service Panel in the multibay (DVD-LSD/LSP).
As an option for the top bay, a slimline DVD / backup drive cage is available.
IPlease note the following:
– A DVD drive must have been installed in order to operate the server.
– The accessible drives cannot be replaced during operation.
– You are required to open the drive cover of system when you access
to the 5.25-inch drives.
Power supply
In its basic configuration the server has a standard power supply unit or a hot-
plug power supply unit that adjusts automatically to any mains voltage in the
range 100 V - 240 V. Besides the hot-plug power supply unit, a second hot-plug
power supply unit can be installed optionally to serve as a redundant power
supply. If one power supply unit fails, the second power supply unit in the
redundant configuration ensures operation can continue uninterrupted.
Fujitsu battery unit
FJBU behaves as a modular UPS in the server. When power fail happened, the
server can operate by FJBU battery for a while.
FJBU supports hot plugging, and can be replaced during operation.
You can download the management software (FJBU management software) for
the following OS:
– Windows Server 2012 R2, Windows Server 2012,
–
Windows Server 2008 R2 SP1, Windows Server 2008 R2 SP2
IFJBU (Fujitsu battery unit) management software is not available in Red
Hat Enterprise Linux environment. Please use the IPMI function at Linux
environment.

18 Operating Manual TX1330 M2
Functional overview
Cool-safe
®
Advanced Thermal Design
The Cool-safe
®
Advanced Thermal Design option allows you to operate the
system within a wider temperature range of 5 °C to 40 °C.
VCAUTION
In a system that has the Cool-safe® Advanced Thermal Design Option,
only components that support the higher operating range may be
installed. Further information on this is available in the configurator.
High level of availability and data security
When memory data is accessed, 1-bit errors are identified in the main memory
and automatically corrected with the error correcting code (ECC) method.
ASR&R (Automatic Server Reconfiguration and Restart) restarts the system in
the event of an error and automatically "hides" the defective system
components.
The PDA (Prefailure Detection and Analysis) technology from Fujitsu analyzes
and monitors all components that are critical for system reliability.
A RAID controller supports different RAID levels and increase the availability
and data security of the system.
The hot-plug HDD modules provide additional availability.
This option can only be ordered from the manufacturer and is
indicated by the logo on the identification rating plate.

TX1330 M2 Operating Manual 19
Functional overview
iRMC S4 with integrated management LAN connector
The iRMC S4 (integrated Remote Management Controller) is a Baseboard
Management Controller (BMC) with integrated management LAN connector
and expanded functionality that was previously only available with additional
plug-in cards. In this way, the iRMC S4 enables complete control of PRIMERGY
servers, regardless of system status, and thus particularly the control of
PRIMERGY servers that are in the "out-of-band" system status.
Major functions supported by the iRMC S4 include the following:
● Browser access via iRMC S4´s own Web server
● Secure communication (SSH, SSL)
● Power Management for the managed server (depending on its system
status)
● Power Consumption Management
● Connecting virtual drives as remote storage
● Text-based and graphic console bypass (Advanced Video Redirection)
● Remote Storage
● Command Line Interface (CLI)
● Simple, interactive or script-based iRMC S4configuration
● Customer Self Service (CSS)
● iRMC S4´s own user management
● Multi-computer, global iRMC S4 user administration using an LDAP
Directory Service
● Automatic network configuration via DNS / DHCP
● Power supply of the iRMC S4 via the system standby supply
● Full-coverage alarm management
● System Event Log (SEL) reading and processing
● IPMI support
● CIM / WS-MAN support
● Internal Event Log for user login / logout auditing

20 Operating Manual TX1330 M2
Functional overview
More information about the iRMC S4 can be found in the "iRMC S4 - integrated
Remote Management Controller" user guide (on the Fujitsu manuals server
under x86 Servers - Software - ServerView Suite - Out-Of-Band Management).
Server management
Server management is implemented using the ServerView Operations Manager
supplied and the PDA (Prefailure Detection and Analysis) technology from
Fujitsu. PDA reports the threat of a system error or overload at an early stage,
allowing preventive measures to be taken.
The ServerView Operations Manager enables the management of all
PRIMERGY servers in the network via a central console. The ServerView
Operations Manager supports the following functions:
● Round-the-clock monitoring, regardless of server status
● High-performance, graphical console bypass (AVR) protected by
HTTPS/SSL (128 bit)
● Remote storage via USB
● Remote power on
● Intrusion detection in the floorstand model
● Temperature monitoring of the CPU and the surrounding area
● Detailed status and error reports for processors and main memory
● Watchdog timer for Automatic Server Reconfiguration and Restart (ASR&R)
in the event that memory modules or processors fail
● Power monitoring
● End-of-life monitoring of fans with prompt notification before failure
● Watchdog timer for monitoring the operating system with ASR&R
Further information on the ServerView Operations Manager is provided in the
associated documentation.
