Furniture of America CM6911-SF User manual

1 / 8
MODEL #
CM6911-SF
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
VERSION # 19-08-23
2 - Persons
Phillips
Screwdriver
(Not Included)
(Included)
Allen Wrench
Recommended
Furniture of America

2 / 7
Thank you for your purchase!
We hope you enjoy this new addition to your home for many years to come.
Our commitment to providing quality products does not simply end when you purchase
our product. We fully stand behind our products from start to finish. Our customer
service department is available Monday – Friday 8:30 AM – 5:30 PM Pacific and can
help with assembly questions as well as, if necessary, replacing damaged or missing
parts. To help expedite our service, please have these assembly instructions readily
available, along with your order receipt.
E-MAIL
[e-mail]
Furniture of America
WEBSITE
www.foagroup.com
FOA Intro
FurnitureOfAmerica
foagroup
Monday to Friday
8:30AM- 5:30PM (PST)
Consumer Hotline
Toll-Free 1-888-980-5122
Prep Time!
Please review the assembly instructions and all
diagrams prior to assembling. Arrange parts as
recommended on Page 7 and group identical
hardware together to make assembling easier.
Check out our Quick Tips!
We recommend reviewing the pre-assembly
handouts. Even experts need a refresher now and
then!
Are you missing anything?
Double-check all parts, hardware and
accessories listed on Page 6 are
accounted for.
Should we send any replacements?
Are there any irregularities or flaws in the
parts? We can send replacements!
CHECK
BEFORE STARTING

PRE ASSEMBLY
INTRODUCTION
3 / 7
Suitable Location
Assembling near the area of the
intended location is highly
recommended.
Avoid Scratches
Use cardboard, blankets or a
carpeted area while assembling
furniture to prevent scratches.
Teamwork
ALWAYS have at least two people
to help with transporting and
assembling the product to avoid
potential injury and/or damage.
Flat Surface
Make sure the furniture rests on
a flat and level surface with each
leg evenly touching the floor.
Sufficient Space
Make sure you have enough
space to move around during the
assembly.
We understand building ready-to-assemble furniture can be a challenging
experience for some. To help avoid confusion, we have provided some helpful
tips that may speed up the process.

4 / 7

SOFA
CM6911-SF
#1 1pc
Arm Left Arm Right
#2 1pc #3 1pc
5 / 8
#4 1pc #6 3pcs
#7 2pcs
#A 1pc
Jcbc Screw
M6x50MM
#B 2pcs
Jcbc Screw
M6x70MM
#C 4pcs
Lock Washer
1/4''
#D 7pcs
Bend Washer
15x25x2MM
#E 2pcs
Barrel Nut
M6x13MM
#F 2pcs
Allen Key
M4
#G 1pc
Wood Dowel
Ø10x35MM
#H 6pcs
Csk Screw
M4x32MM
#I 12pcs #J 4pcs
Wood Button
Ø14.5x9MM
Jcbc Screw
M6x35MM
#5 3pcs
#K 4pcs
L - Bracket
#L 8pcs
ChipBoard Screw
M4x12MM
#10 2pcs
Lumber
Pillow
#11 1pc
Square
Pillow
Front Rail Back Deck Back Rest
Cushion
Cushion Seat
Seat Deck Center Seat
Deck
#8 1pc #9 1pc
Support
Rail

ASSEMBLY INSTRUCTIONS
1
2
Part #1 x1pc
6 / 8
Part #3 x1pc
Part #4 x1pc
Hardware #H x6pcs
Part #2 x1pc
Hardware #B x2pcs
Hardware #C x4pcs
Hardware #D x6pcs
Hardware #E x2pcs
Hardware #F x2pcs
#1
#3
#4
2x
#H
4x
2x #D
#C
2x
From Inside
#E #B
#D
#F
#C
#D
#2
2x
Ensure that the rail support on the front rail (#3) is as shown in the diagram.
Insert dowels (#H) to back
desk (#4) and front rail (#3),
then align them both
to left arm (#1).
Align the right arm to the back
desk (#4) and front rail (#3),
then secure arms (#1,2) by
following the diagram on the
requird hardware pieces to use.

ASSEMBLY INSTRUCTIONS
3
4
7 / 8
Part #8 x1pc
Hardware #A x1pc
Part #7 x2pcs
Hardware #I x12pcs
12x
#I
Part #8 x1pc
Adjustable Leveler
Hardware #D x1pc
#8
#7
#8
#7
Part #9 x1pc
#9
#D
#A
Hardware #K x4pcs
Hardware #L x8pcs
4x
#K
#L
#K #L
4x Secure arms to back deck by aligning
L brackets (#K) and securing with screws (#K).
Attach support rail (#9) to center seat deck (#8)
by using bolts (#A) with washers (#D).
Align seat decks (#7,8) to frame, then secure by using screw (I).

ASSEMBLY INSTRUCTIONS
5
8 / 8
Part #5 x3pcs
Hardware #J x4pcs
Part #6 x3pcs
4x
#J
#5
#6 #10 #11
Part #10 x2pcs
Part #11 x1pc
Attach caps (#J) to bolt holes.
