Fusion3 EDGE Guide

EDGE 3D Printer
MAINTENANCE:
AIR FILTER REPLACEMENT
Revision 5/28/2022

AIR FILTER REPLACEMENT
How to replace the EDGE air filters.
Your EDGE printer shipped from the factory with a print chamber filter pre-installed. The HEPA and carbon
filter elements must be replaced regularly to maintain correct performance and effective filtration of the
exhaust air from the print chamber.
WHEN TO REPLACE
Replaced on a maintenance schedule - notification will appear when due for replacement
HOW TO REPLACE
1. EDGE should be idle and cold (bed & print head).
2. Manually move the X axis rail to the front of its travel.

3. Using your fingers, pry up the front or
back release tab on the filter carrier.
4. Slightly shift the carrier forward or backwards to disengage the other latch. Remove the assembly
from the printer.
5. Remove the spent HEPA and carbon filter elements from the carrier and discard them.
6. Install the new HEPA and carbon elements.

7. The carbon element goes in
first.
8. IGNORE the airflow direction
arrow on the filter; install it
as shown so that the foam
lip sticks out of the carrier.
9. Position the assembly over the filter base and gently press down on both ends to engage the
latches.
10.Make sure the latches are fully engaged by manually moving the X axis rail past the filter to the front
of the machine. If the carrier collides with the idler pulley it's not installed correctly

11.On the LCD, go to Menu > Utilities >
Maintenance > and reset the filter
timer.
WHERE TO PURCHASE
REPLACEMENTS
Replacement filter kits can be purchased
through our replacement parts store:
https://store.fusion3design.com/
