FWE MOISTURE-TEMP MTU Series User manual

MOISTURE-TEMP CABINETS
OPERATING
INSTRUCTIONS
Thermometer
Air Temperature
“HEAT” Control Dial
Air Moisture Control
Main Power Switch
Heat Cycling Light

12" x 20" Water Pan
and Heat Basin
Heat System
Tunnel
Control
Panel
Moisture
Drip Trough
With
Removable
Drain Plug
MOISTURE-TEMP CABINETS
1FWE MOISTURE-TEMP HEAT SYSTEM
Serial Tag
and
Parts List

FWE MOISTURE-TEMP CABINETS
COMPLETE AND RETURN YOUR WARRANTY CARD
2
...and thank you for purchasing an FWE MOISTURE-TEMP cabinet.
Your unit has been designed and manufactured under
rigid controls to assure you the most efficient service.
Please take a moment to read through this booklet of important
information pertaining to your cabinet. By following a routine
of proper use and care described on the following pages, your
cabinet will last for many years.
IMPORTANT: Your Manufacturer Registration Card must be
returned within 30 days after initial delivery to put warranty
into effect.
CONGRATULATIONS
ELECTRICAL REQUIREMENTS AND GROUNDING
UNPACKING
The amperage of your cabinet is stamped on the name plate
serial tag attached to the unit. FWE models are equipped with
a three prong grounding cord plug for your protection against
possible shock hazards. Be sure to plug only into a properly
grounded three prong wall receptacle. If you have any questions
with regard to adequate wiring or grounding in your building, a
qualified electrician should be contacted before using your cabinet.
DO NOT, UNDER ANY CIRCUMSTANCES, CUT OR REMOVE
THE GROUNDING PRONG FROM THE CORD PLUG.
WARNING: ONLY A QUALIFIED ELECTRICIAN SHOULD ATTEMPT
TO REPAIR OR REPLACE ELECTRICAL COMPONENTS OR WIRING.
BE SURE THAT MODEL IS UNPLUGGED FROM ELECTRICAL
SOURCE BEFORE REMOVING CONTROL PANEL.
After uncrating your cabinet, remove all tape and padding which
held all doors, shelves, racks, cord, etc., in place during shipment.
These numbers are found on the nameplate (serial tag) affixed
near the rear of the unit. Please record them in this booklet,
in the space provided When ordering parts and/or service, you
will need to provide this information. The voltage and amperage
of the unit are also stamped on the serial tag.
SERIAL AND MODEL NUMBER

FWE MOISTURE-TEMP CABINETS
CONTROL PANEL
3FWE MOISTURE-TEMP HEAT SYSTEM
EASY-TO-USE CONTROLS
Thermometer
Air Temperature
“HEAT” Control Dial
Air Moisture Control Dial
“P” to Indicates Proof Position
Proof Cycling Light
Main Power Switch
Heat Cycling Light
Press tactile key
to alternate
between
ACTUAL temp
(with ACTUAL LED
illuminated)
and SETPOINT
temperature

4
FWE MOISTURE-TEMP CABINETS
HEAT SYSTEM AND CABINET COMPONENTS
ADDING WATER TO 12" x 20" PAN
Heat
Tunnel
Heat Tunnel
Stand
12" x 20"
Pan
Positioned
Into
Heat Basin
Add
HOT WATER
to
12" x 20"
Pan
Add HOT water to 12" x 20" pan with heat tunnel in position.
Water Pan is positioned into heat basin.
Amount of water required in pan is determined by start-up
time, length of holding time, and level of humidity desired.
ADJUSTABLE TRAY SLIDES
Standard cabinet models are equipped
with adjustable tray slides.
Adjust tray slide positions by inserting
“J” end of slide into upright key hole.
Release tray slide from upright
with upward “J” motion.
Tray slides and uprights
are removable for cleaning.
TRAY SLIDE
“J” END OF TRAY SLIDE
UPRIGHT
UPRIGHT KEY HOLE

GENERAL OPERATING INSTRUCTIONS
1) PLUG CABINET INTO OUTLET making sure it is a properly
grounded power receptacle. Press ON-OFF rocker switch to "ON"
position. The indicating light on the switch will come on and remain
"ON" until the rocker switch is turned to "OFF" position.
2) ADD HOT WATER TO THE
12" x 20" PAN. The 12" x 20"
WATER PAN is positioned in the
HEAT BASIN. Do NOT allow
any water into the HEAT BASIN.
Add HOT water into the 12" x 20"
pan prior to heating the cabinet.
This will allow the heating system
to condition cabinet and add
humidity.
It is not necessary to remove the
pan to add water. Amount of water
required depends on start-up time,
length of proofing, and level of
humidity desired.
3) PRE-HEAT THE CABINET by turning the rocker switch to
the "ON" position. Allow approximately 15-25 minutes of pre-heat time.
The door should be kept tightly closed during this procedure to obtain
the optimum environment.
For proofing, set the air temperature to 100°F or 38°C
4) SET AIR MOISTURE CONTROL to desired setting.
The "MOISTURE" indicator light will illuminate,
and remain on for the duration of the cycle.
NOTE: As with all proofing cabinets, your results may vary, depending
on room temperature and conditions, pre-heat time, temperature of
product going into cabinet, etc.
5) LOAD THE CABINET with your product as quickly as possible.
To maintain the best conditions, the door should be tightly closed
when not loading the cabinet, and remain closed until serving.
5FWE MOISTURE-TEMP HEAT SYSTEM
PREPARING THE CABINET BEFORE LOADING FOOD
Add HOT WATER to 12" x 20" Pan
positioned in the HEAT BASIN

6
TROUBLE-SHOOTING CHART
Check this list first before you call for service...
PROBLEM POSSIBLE CAUSE REMEDY
TEMP
TOO
HOT
TEMP
NOT
HOT
ENOUGH
NO HEAT
AT ALL
1 A] Adjustable thermostat
set too high
1B] Thermostat needs
re-calibrating**
2A] Opening door unnecessarily
2B] Thermostat set too low
2C] Cord plug pulled out from outlet
2D] Fuse blown - no power to outlet
2E] Thermostat out of calibration**
3A] Cabinet not plugged into outlet
3B] Thermostat knob at “ OFF ”
3C] Rocker switch at “ OFF ” position
3D] Fuse Blown - no power to outlet
3E] Thermostat needs replacing
3F] Heating element burned out*
1A] Set thermostat at a lower temperature
(no lower than 140°F).
1B] Loosen screw in thermostat knob and remove knob.
Adjust set screw in hollow stem with small blade
screwdriver by turning CLOCK-WISE.
1/4 turn lowers temperature approximately 10°F.
DO NOT REMOVE SET SCREW.
2A] Keep door closed and latched shut
as much as possible.
2B] Set thermostat at a higher temperature.
2C] Replug cord into proper outlet.
2D] Have a qualified electrician check power
and fuse box.
2E] Loosen set screw in thermostat knob
and remove knob. Adjust set screw in hollow stem
with small blade screwdriver by turning
COUNTER-CLOCKWISE.
1/4 turn raises temperature approximately
10°F. DO NOT REMOVE SET SCREW.
3A] Plug cabinet into properly grounded electrical outlet.
3B] Adjust thermostat knob to temperature
setting required.
3C] Turn switch to “ ON ” position.
3D] Have a qualified electrician check power
to fuse box.
3E] Unplug cabinet from electrical source.
Loosen set screw in thermostat knob and remove
knob. Remove control panel, disconnect wires from
terminals on thermostat, and remove 2 screws
holding thermostat to control panel. Replace
thermostat with new one, and re-install control
panel and thermostat knob.
3F] Unplug cart from electrical source. Remove screws
holding heating element in place. Gently pull
element away from back wall a few inches to
expose wire connections. Disconnect wires, and
replace element with new one. Reconnect wires,
secure element with screws.
* * NOTE: CALIBRATION IS EXCLUDED FROM FWE WARRANTY. Thermostats on all units are calibrated at the factory
* * prior to shipping. Due to conditions in transit, beyond our control, occasionally units will need to be re-calibrated prior
* * to use. This is a simple procedure for which instructions are given above. (1B, 2E)
* Heating element will either function or not function. Only a slight warmth indicates a problem with the thermostat,
* not the element.

WARNING: THE WATER PAN, AIR TUNNEL AND HEATING
ELEMENT(S) ARE HOT WHEN IN USE AND COULD CAUSE INJURY.
7FWE MOISTURE-TEMP HEAT SYSTEM
CABINET CLEANING
FWE MOISTURE-TEMP CABINETS
12" x 20" pan is removable and
replaceable for easy cleaning.
12" x 20" pan correctly
positioned in HEAT BASIN.
HEAT BASIN shown
WITHOUT 12" x 20" pan.
ALLOW A HOT CABINET TO COOL BEFORE CLEANING.
Keep your cabinet clean by simply wiping the interior and exterior,
as needed, with a damp cloth or sponge and a mild soapy solution.
NEVER USE ABRASIVES, ACIDS, OR STRONG CLEANERS.
Do not flood or allow electrical parts to become wet. A stainless
steel cleaner/polish is recommended for the exterior to maintain
a "like-new" appearance. DO NOT USE WAX OR STRONG
CLEANERS ON DOOR GASKETS OR VINYL TRIM.
CLEANING
Heat
Tunnel
positions
into
tabs.
Heat
Tunnel
WATER PAN IS REMOVABLE AND REPLACEABLE
KEEP HEAT
BASIN DRY
WATER PAN
POSITIONS INTO
HEAT BASIN.
ADD WATER INTO
12" x 20" PAN
ONLY.
NO WATER IN
HEAT BASIN

The ON-OFF rocker switch activates power to the cabinet.
Moisture-Temp cabinets are equipped with two (2) heating
elements and two (2) separate controls which regulate these
elements. This allows you to adjust the temperature
and humidity separately.
The air moisture knob adjusts the amount of
humidity in the cabinet from 1-7.
A CYCLING light indicates
that this function is activated.
The air temperature control goes from 90°F to 190°F
(30°C to 90°C), and adjusts the amount of heat in the cabinet.
An operational range thermometer shows
the actual internal temperature of the cabinet.
Add HOT water to 12" x 20" pan with heat tunnel in position.
Water Pan is positioned into heat basin.
8
FWE MOISTURE-TEMP CABINETS
EASY TO OPERATE
Heat Basin
Water Pan

9FWE MOISTURE-TEMP HEAT SYSTEM
FWE MOISTURE-TEMP CABINETS
SERVICE RECORD
Model Number ______________________
Serial Number ______________________
Date of Purchase ____________________
Notes:
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
CAUTION: HOLDING FOOD AT TEMPERATURES
OF LESS THAN 140°F MAY BE DANGEROUS.
TEMPERATURES UNDER 140°F PROMOTE THE GROWTH
OF HARMFUL BACTERIA AND TOXINS IN SOME FOODS.

FWE / Food Warming Equipment Company, Inc. (Seller) warrants to the original purchaser,
subject to the exceptions and conditions below, that FWE manufactured equipment shall be
free from defects in material or factory workmanship, under ordinary use for the purpose for
which it is designed. The effective warranty period is as follows:
PARTS: Seller will furnish without charge to the original purchaser, FOB Sellers’ factory,
replacement parts for repairs to all new standard catalog products and factory custom /
modified units, which in Seller’s sole judgement, prove defective in materials or workmanship
under normal and proper use with the reserved right to request the return of any part claimed
to be defective, prior to issuing replacement part or authorizing warranty service, for a period
of two (2) years from date of original shipment from Seller’s plant, except for equipment used
in a Correctional Environment / Facilities, which is warranted for a period of one (1) year
from date of original shipment from Seller’s plant.
LABOR: Seller’s labor warranty shall be performed by a Seller-approved Service Agency who
must contact Seller to obtain a Warranty Service Authorization (WSA) number prior to
performing any repairs. If service is required during overtime periods, the difference between
overtime and standard labor rates shall be paid by the purchaser. Seller does not assume any
responsibility for any charges not expressly authorized, incidental to the repair or replacement
of equipment covered by this warranty, nor charges exceeding, in Sellers sole judgement,
normal and customary amounts. Only approved travel charges will be allowed. Seller’s labor
warranty shall be from the date of original shipment date from Seller’s plant for a period of one
(1) year, except for equipment used in a Correctional Environment / Facilities which is
warranted for a period of six (6) months.
This warranty is for normal usage and does not apply to any product or parts thereof that have
been misused, altered, or where Seller’s operating instructions or specific voltage is not
observed; nor shall this warranty apply to defective products or parts resulting from accident
following date of original shipment, nor extend to or cover removal, installation, reinstallation
or calibration, or service calls or cost of repairs undertaken by a customer. This warranty is also
subject to the following:
1.] Customer returning the warranty registration card, accompanying Sellers original
shipment, to Seller within thirty (30) days of receipt;
2.] Giving immediate notice of any allegedly defective part or product to Seller; and
3.] Customer, at Sellers request, returning said defective parts or product to Seller.
This is the sole warranty applicable to the merchandise. It is expressly understood that Seller’s
liability hereunder is limited to the repair or replacement, at Seller’s option, of products or parts,
defective materials or workmanship as provided above. Seller’s judgement as to the cause and
nature of any defect will be final.Seller shall in no case be responsible for special or con-
sequential damages or any other obligation or liability with respect to products sold by Seller.
This warranty, as stated above, applies to equipment installed in the Continental United States.
FWE equipment installed outside the Continental United States shall carry parts coverage only.
All labor costs are approved on a discretionary basis, based on like repairs in the Continental
U.S. This warranty shall stand in whole or in part as allowed by law. Any exclusion of a part of
this warranty, as may be allowed by law, shall not void balance of warranty.
This is a limited warranty pursuant to the Consumer Product Warranties Act, 15 U.S. Code. section 2303.
© 2003 Food Warming Equipment Co., Inc.
FWE MOISTURE-TEMP CABINETS
LIMITED TWO YEAR WARRANTY
10

© 2014 Food Warming Equipment Co., Inc. Errors subject to correction. All specifications subject to change without notice. Printed in USA.
Ops-Manual-Moisture-Temp Basin-Style
P. O. Box 1001
Crystal Lake, IL 60039-1001 USA
815-459-7500 • Fax: [phone]
FWE Parts Department:
www.FWEparts.com
Order Hotline: [phone]
MANUFACTURING FACILITIES:
5599 Hwy. 31 West • Portland TN 37148
615-325-2774 • Fax: [phone]
800-222-4393
www.FWE.com
[email protected]
FOOD WARMING EQUIPMENT COMPANY, INC.
