Fxlion BP-HP600 User manual

14.4V 38.8Ah 559Wh
BP-HP600
14.4V/10.0A(Max)
14.4V/30A/400W(Max)
-20~55℃
0~45℃
161.7mm(L)×104.7mm(W)×105.5mm(H)
2784g
IP54
Capacity
D-tap*2 Output
Battery Output
Discharge Temperature
Weight
Waterproof Grade
Charge Temperature
Dimension
BP-HP600
User Manual
High Power Waterproof Battery
Thanks for choosing Fxlion products!
Please read this user manual before use to enable you could properly use, storage and
maintenance of the products.
Packing List: 1.Battery BP-HP600*1 2.User Manual *1
•Do not put battery into water or fire.
•Must accordance with instructions to use and store.
•Please charge by Fxlion charger or Fxlion recommended charger.
•Waterproof grade IP54, able to work just in small rain.
•Waterproof grade is tested in laboratory.
•Avoid strong impact.
•Do not heated or disassemble.
I Product Appearance
Ⅱ Battery Basic Features
Ⅲ Specification Ⅳ Cautions !
•Avoid short-circuit.
•Keep away from children.
•Battery should be charged to 50% power status when need long time
storage, charge and discharge once every three months.
•Use high rate Li-ion battery cells, it can discharge at
a high rate up to 30A, and compatible with 400W
high-power equipment.
•High power intelligent protection chip is applied, and
t h e b a t t e r y h a s o v e r c h a r g e , o v e r d i s c h a r g e ,
te mper a tur e an d ove r-cu rren t pr ote c tio n. Wi th
overload self recovery design.
•Compact structural design, integrated shell and
output terminal design, ultra-high volume energy
density ratio, truly achieving the ultimate high
capacity of Li-ion battery within a small volume.
•Ip54 waterproof grade, perfectly compatible with the
demand of LED lights, cameras, and other film and
television equipment with waterproof requirements.
•T h e w a t e r p r o o f d e s i g n a n d 3 0 A h i g h - p o w e r
discharge meet the demand for high-power LED lights
in the market, especially for LED lights above 300W
which can use portable V-mount battery directly.
•2*D-Tap design, each with an output power of up to
10A,High Power output can synchronous power
external equipment or High power external equipment
while outputting battery.
•The shell is made of special materials, which is
shockproof can meet requirements of daily outdoor
Li-ion battery use.
•5-Level LED indicators.
•Optional charger: suitable for 16.8V chargers, it is
recommended to use a FXLION charger with a
charging power of 16.8V/4A or above.

Model Production Date
Serial Number
at [phone] for assistance.
Strict quality control procedures were done to every Fxlion product before it leaves the factory.
Please contact local Fxlion distributor or call our service center
Product Production Information
Fxlion Electronic Co., Ltd.
WEB：www.fxlion.net
Email：[email protected]
ⅤStorage and Transportation ⅥMaintenance and After-sales Service
Ⅶ The warranty will not cover the following cases.
•Force majeure: Do not work or parts damage caused
by earthquake, fires and other natural disasters or
accidents.
•Disassemble or repair by non-professionals, or
failure by dropping.
•Damage caused by man-made improper use.
•Battery capacity decrease because not accordance
with instruction to use and store, make sure to charge
and discharge once every three months, and keep
battery capacity 50% for store.
•Non Fxlion products, or out of warranty period.
•Non Fxlion tieline and power supply connection
caused failure.
•Damage to device because of incorrect battery
voltage selection.
•Battery unable to charge or full charged because of
long term use of non Fxlion charger or charger Fxlion
doesn’t recommend.
•The phenomenon of a natural decrease in battery
capacity caused by multiple charging and discharging
cycles after a period of use.
Battery should be charged to 50% power status when need longterm
storage, charge and discharge once every three months.
Place in a dry and cool places, avoid touching corrosive substances
and keep away from fire.
Storage temperature: -20℃~+25℃ (12 months)、-20℃~+45℃
(3months)、-20℃~+60℃ (1 month). Storage humidity：≤75%RH .
Batteries should be packed into boxes for transport which should
prevent severe vibration, shock or extrusion, sun exposed and rain.
transportation could be use cars, trains ,boats and airplane.
Battery warranty period is one year. Battery shell, rubber
cap and V-lock part are easily-worn parts which warranty
period is 3 months.
Warranty period: start from the date of purchase with the
record on warranty card and purchase/sales invoice.
