Instruction manual
Instrucciones de uso
Instruções de serviço
Οδηγíες χρήσεω
AC 402/462/472/
482
Ceiling ventilation
Ventilación del techo
Ventilação de teto
Εξαερισμός οροφής

2
Table of contents Instructionmanual
Important safety information 3
Environmental protection 6
Saving energy 6
Environmentally-friendly disposal 6
Operating modes 6
Exhaust air mode 6
Air recirculation 6
Operating the appliance 7
Control panel 7
Remote control 7
Setting the fan 7
Intensive setting 7
Run-on function 8
Interval ventilation 8
Saturation display 8
Lighting 8
Safety shut-off 8
Cleaning and maintenance 9
Trouble shooting 12
Replacing the batteries in the remote control 13
Aftersales service 14
Accessory 14
: Additional information on products,
accessories, replacement parts and services can be
found at www.gaggenau.com and in the online shop
www.gaggenau.com/zz/store

3
m Important safety information
Read these instructions carefully. Only then will
you be able to operate your appliance safely and
correctly. Retain the instruction manual and
installation instructions for future use or for
subsequent owners.
The appliance can only be used safely if it is
correctly installed according to the safety
instructions. The installer is responsible for
ensuring that the appliance works perfectly at its
installation location.
This appliance is intended for domestic use and
the household environment only. The appliance
is not intended for use outside. Do not leave the
appliance unattended during operation. The
manufacturer is not liable for damage which is
caused by improper use or incorrect operation.
This appliance is intended for use up to a
maximum height of 2000 metres above sea level.
This appliance may be used by children over the
age of 8 years old and by persons with reduced
physical, sensory or mental capabilities or by
persons with a lack of experience or knowledge
if they are supervised or are instructed by a
person responsible for their safety how to use
the appliance safely and have understood the
associated hazards.
Children must not play with, on, or around the
appliance. Children must not clean the
appliance or carry out general maintenance
unless they are at least 15 years old and are
being supervised.
Keep children below the age of 8 years old at a
safe distance from the appliance and power
cable.
Check the appliance for damage after
unpacking it. Do not connect the appliance if it
has been damaged in transport.
This appliance is not intended for operation with
an external clock timer or a remote control.
Danger of suffocation!
Packaging material is dangerous to children.
Never allow children to play with packaging
material.
Danger of death!
Risk of poisoning from flue gases that are drawn
back in.
Always ensure an adequate air supply in the
room if the appliance is being operated in air
extraction mode at the same time as a non-room-
sealed heat-producing appliance.
Non-room-sealed heat-producing appliances
(e.g. gas-, oil-, wood- or coal-powered heaters,
continuous flow heaters or water heaters) draw
in combustion air from the room in which they
are installed and discharge the exhaust gases
into the open through an exhaust gas system
(e.g. a chimney).
While the ceiling ventilation is switched on, air is
extracted from the kitchen and adjacent rooms –
without sufficient supply air, this causes a
vacuum. Poisonous gases from the chimney or
the extraction shaft are drawn back into the
living space.
▯Therefore, there must always be an
adequate air supply.
▯A supply-/exhaust-air wall box alone will not
ensure compliance with the limit.
It is therefore only possible to safely operate the
appliance if the vacuum in the installation room
of the heat-producing appliance does not
exceed 4 Pa (0.04 mbar). This can be achieved
when the air needed for combustion is able to
enter through openings that cannot be sealed,
for example through doors, windows, supply-/
exhaust-air wall boxes or by other technical
means.
In any case, consult a chimney sweep. They are
able to assess the house's entire ventilation
setup and will suggest the ventilation measures
suitable for you.

4
Unrestricted operation is possible if the ceiling
ventilation is operated exclusively in recirculation
mode.
Risk of fire!
▯Grease deposits in the grease filter may
catch fire.
Clean the grease filter at least every
2 months.
Never operate the appliance without the
grease filter.
Risk of fire!
▯Grease deposits in the grease filter may
catch fire. Never work with naked flames
close to the appliance (e.g. flambéing). Do
not install the appliance near a heat-
producing appliance for solid fuel (e.g. wood
or coal) unless a closed, non-removable
cover is available. There must be no flying
sparks.
Risk of fire!
▯Hot oil and fat can ignite very quickly. Never
leave hot fat or oil unattended. Never use
water to put out burning oil or fat. Switch off
the hotplate. Extinguish flames carefully
using a lid, fire blanket or something similar.
Risk of fire!
▯When gas burners are in operation without
any cookware placed on them, they can
build up a lot of heat. A ventilation appliance
installed above the cooker may become
damaged or catch fire. Only operate the gas
burners with cookware on them.
Risk of fire!
▯Operating several gas burners at the same
time gives rise to a great deal of heat. The
ventilation appliance may become damaged
or catch fire. The ventilation appliance must
only be combined with gas burners that do
not exceed the maximum total output of 18
kW. If the total output exceeds 12 kW, the
local regulations regarding room ventilation,
room size and the combination of ventilation
appliances with recirculation or circulated
air mode must be observed.
Risk of burns!
The accessible parts become very hot when in
operation. Never touch hot parts. Keep children
at a safe distance.
Risk of injury!
▯Components inside the appliance may have
sharp edges. Wear protective gloves.
Risk of injury!
▯Risk of falling when working on the
appliance. Use a stable stepladder. Choose
a suitable stepladder for the working height.
Only use the stepladder when it is fully
opened and on level ground. Ensure that the
spreading lock is locked in place. Always
stand on the stepladder with two feet, do not
climb too high and do not lean over the
sides.
Risk of electric shock!
▯A defective appliance may cause electric
shock. Never switch on a defective
appliance. Unplug the appliance from the
mains or switch off the circuit breaker in the
fuse box. Contact the after-sales service.
Risk of electric shock!
▯Incorrect repairs are dangerous. Repairs
may only be carried out and damaged power
cables replaced by one of our trained after-
sales technicians. If the appliance is
defective, unplug the appliance from the
mains or switch off the circuit breaker in the
fuse box. Contact the after-sales service.
Risk of electric shock!
▯Do not use any high-pressure cleaners or
steam cleaners, which can result in an
electric shock.

5
Causes of damage
Caution!
Risk of damage due to corrosion. Always switch on the
appliance while cooking to avoid condensation.
Condensate can produce corrosion damage.
Always replace faulty bulbs to prevent the remaining
bulbs from overloading.
Risk of damage due to ingress of humidity into the
electronic circuitry. Never clean operator controls with a
wet cloth.
Surface damage due to incorrect cleaning. Clean
stainless steel surfaces in the direction of the grain
only. Do not use any stainless steel cleaners for
operator controls.
Surface damage due to strong or abrasive cleaning
agents. Never use strong and abrasive cleaning agents.
Risk of damage from returning condensate. Install the
exhaust duct in such a way that it falls away from the
appliance slightly (1° slope).

6
Environmental protection
Your new appliance is particularly energy-efficient. Here
you can find tips on how to save even more energy when
using the appliance, and how to dispose of your
appliance properly.
Saving energy
▯Only switch the ventilation on when necessary. You
do not need to switch the ventilation on when
cooking something for a short time that does not
have a strong smell.
▯Select a fan setting according to what you are
cooking.
▯Switch the ventilation off again after cooking.
▯Cleaning the grease filter regularly will increase the
efficiency of the ventilation.
▯Switch the lighting on the appliance off if you are
not using it.
Environmentally-friendly disposal
Dispose of packaging in an environmentally-friendly
manner.
Operating modes
This appliance can be used in exhaust-air mode or
circulating-air mode.
Exhaust air mode
Note: The exhaust air must not be conveyed into a
functioning smoke or exhaust gas flue or into a shaft
which is used to ventilate installation rooms which
contain heating appliances.
▯Before conveying the exhaust air into a non-
functioning smoke or exhaust gas flue, obtain the
consent of the heating engineer responsible.
▯If the exhaust air is conveyed through the outer wall,
a telescopic wall box should be used.
Air recirculation
Note: To bind odours in air recirculation mode, you
must install an activated carbon filter. The different
options for operating the appliance in air recirculation
mode can be found in the brochure. Alternatively, ask
your dealer. The required accessories are available from
specialist retailers, from customer service or from the
Online Shop.
This appliance is labelled in accordance with
European Directive 2012/19/EU concerning
used electrical and electronic appliances
(waste electrical and electronic equipment -
WEEE). The guideline determines the
framework for the return and recycling of used
appliances as applicable throughout the EU.
The air which is drawn in is cleaned by the
grease filters and conveyed to the exterior
by a pipe system.
The air which is drawn in is cleaned by
the grease filters and an activated carbon
filter, and is conveyed back into the
kitchen.

7
Operating the appliance
Note: Switch on the ceiling ventilation when you start
cooking and switch it off again a few minutes after you
have finished cooking. This is the most effective way of
removing the kitchen fumes.
Control panel
Remote control
Except for resetting the saturation indicator, you can
operate all appliance functions using the control panel
or remote control.
Point the remote control at the control panel.
Notes
‒Ensure that the ceiling ventilation is not obstructed.
‒If the appliance does not respond even when the
remote control is very close, replace the remote
control batteries.
Setting the fan
Note: Always adjust the fan strength to meet current
conditions. If there is a large build-up of steam or fumes,
select a high fan setting.
Switching on
1Press the #button.
The fan starts at setting 2.
2Press the 1, 2, 3 or Žbutton to set the
corresponding fan setting.
Note: When using the remote control, you can only
switch the fan on by pressing button 1, 2, 3 or Ž. Press
the #button to switch the fan off.
Switching off
Press the #button.
Intensive setting
You can use the intensive setting if there is a large build-
up of odours and fumes/vapours.
Switching on
1Press the #button.
The fan starts at setting 2.
2Press the Žbutton.
Intensive mode is activated.
Note: Intensive mode runs for six minutes. Once
this time has elapsed, the appliance switches back
to the previously selected fan setting.
Note: Using the remote control, you can switch on the
intensive setting directly by pressing the Ž button.
#Switches the fan on/off
1 Switches on fan setting 1
2 Switches on fan setting 2
3 Switches on fan setting 3
ŽSwitches on intensive mode
žSwitches on the fan run-on
œResets the saturation indicator
žSwitches on the lighting
#Switches off the fan
1 Switches on fan setting 1
2 Switches on fan setting 2
3 Switches on fan setting 3
ŽSwitches on intensive mode
žSwitches on the fan run-on
žSwitches on the lighting

8
Switching off
Press the #button or the button for another fan
setting.
Intensive mode is deactivated.
Run-on function
Switching on
The run-on function can be activated for any fan setting.
1Select fan setting 1, 2, 3 or Ž.
2Press the žbutton.
The run-on time for all fan settings is six minutes.
Once this time has elapsed, ventilation switches off
automatically. If the lighting is switched on, it
remains on once the run-on time has elapsed.
Switching off
Press the žbutton or the button for another fan
setting.
The run-on function stops before the remaining run-on
time elapses.
Interval ventilation
Switching on
With interval ventilation, the ventilation switches on
automatically for six minutes every hour.
1Press fan setting 1, 2 or 3.
2Press the žbutton twice.
The žbutton and the button for the fan setting
selected flash alternately. The interval ventilation is
switched on.
Switching off
Press the #button.
The interval ventilation is switched off.
Saturation display
If the metal grease filters are saturated, the œbutton
flashes.
If you have not yet done so, the metal grease filters
should be cleaned now.
For instructions on how to clean the metal grease filters,
please refer to the Cleaning and maintenance section.
Resetting the saturation indicator
Press the œbutton.
Lighting
The lighting can be switched on and off independently
of the ventilation system.
Switching on or off
Press the žbutton.
Safety shut-off
For your safety, the appliance has a safety switch-off
function. The lighting switches off after 12 hours and
the fan after 4 hours if the appliance is not operated
during this time. Exception: The fan is not switched off
during the interval ventilation.

9
Cleaning and maintenance
mRisk of burns!
The appliance becomes hot during operation. Allow the
appliance to cool down before cleaning.
mRisk of electric shock!
Penetrating moisture may result in an electric shock.
Clean the appliance using a damp cloth only. Before
cleaning, pull out the mains plug or switch off the circuit
breaker in the fuse box.
mRisk of electric shock!
Do not use any high-pressure cleaners or steam
cleaners, which can result in an electric shock.
mRisk of injury!
Risk of falling when working on the appliance. Use a
stable stepladder.
mRisk of injury!
Components inside the appliance may have sharp
edges. Wear protective gloves.
Cleaning agents
To ensure that the different surfaces are not damaged
by using the wrong cleaning agent, observe the
information in the table. Do not use any of the following:
▯Harsh or abrasive cleaning agents,
▯Cleaning agents with a high alcohol content,
▯Hard scouring pads or cleaning sponges,
▯High-pressure cleaners or steam cleaners.
Wash new sponge cloths thoroughly before use.
Follow all instructions and warnings included with the
cleaning agents.
Removing metal grease filter
mRisk of injury!
Risk of falling when working on the appliance. Use a
stable stepladder.
mRisk of injury!
Components inside the appliance may have sharp
edges. Wear protective gloves.
1Press the marking on the metal grease filter and
remove the metal grease filter from the holder.
While doing this, place your other hand under the
metal grease filter
Note: Grease may accumulate in the bottom of the
metal grease filter. Hold the metal grease filter
level, otherwise grease will drip out.
2Clean the metal grease filter.
3Clean the appliance from the inside.
Area Cleaning agent
Stainless steel Hot soapy water:
Clean with a dish cloth and then dry
with a soft cloth.
Clean stainless steel surfaces in the
grind direction only.
Special stainless steel cleaning prod-
ucts are available from our after-sales
service or from specialist retailers.
Apply a very thin layer of the cleaning
product with a soft cloth.
Painted surfaces Hot soapy water:
Clean using a damp dish cloth and dry
with a soft cloth/towel.
Do not use any stainless steel cleaners.
Aluminium and
plastic
Glass cleaner:
Clean with a soft cloth.
Glass Glass cleaner:
Clean with a soft cloth. Do not use a
glass scraper.
Controls Hot soapy water:
Clean using a damp dish cloth and dry
with a soft cloth/towel.
Risk of electric shock caused by pene-
trating moisture.
Risk of damage to the electronics from
penetrating moisture. Never clean
operating controls with a wet cloth.
Do not use any stainless steel cleaners.
Area Cleaning agent

10
Cleaning the metal mesh grease
filters
mRisk of fire!
Grease deposits in the grease filter may catch fire.
Clean the grease filter at least every 2 months.
Never operate the appliance without the grease filter.
Notes
‒Do not use any aggressive, acidic or alkaline
cleaning agents.
‒When cleaning the metal mesh grease filters, also
clean the holder for the metal mesh grease filters in
the appliance using a damp cloth.
‒The metal mesh grease filters can be cleaned in the
dishwasher or by hand.
In the dishwasher:
Note: Slight discolouration may occur if the metal
grease filters are cleaned in the dishwasher. This has no
effect on the function of the metal grease filters.
▯Do not clean heavily soiled metal grease filters
together with utensils.
▯Remove any heavy soiling first by hand.
▯Place the metal grease filters in the dishwasher
leaving plenty of space around them. The metal
grease filters must not be wedged in.
By hand:
▯Soak the metal grease filters in hot soapy water.
▯Clean the filters with a brush and then rinse them
thoroughly.
▯Leave the metal grease filters to drain.
Note: You can use a special degreaser to remove
stubborn dirt. This can be ordered via the online shop
(product no. 00311297). Spray the dirty metal grease
filters with the degreaser and leave it to work for up to
five minutes. Then rinse thoroughly. Observe the
instructions for use supplied with the cleaning product.
Installing the metal mesh grease filter
1Install the metal grease filter and lock in place.
Note: When installing the metal grease filter,
ensure that it is inserted correctly into the guide on
both sides. Otherwise, the metal grease filter can
fall and damage the cooktop.
2Press the œbutton.
The saturation indicator is reset.
Changing the activated charcoal filter
(only in circulating-air mode)
mRisk of injury!
Risk of falling while changing filter. Use a stable
stepladder.
In order to ensure adequate odour removal, you must
replace the activated charcoal filter regularly.
With normal levels of use (1 to 2 hours a day), the
activated charcoal filter must be replaced at least every
12 months.
Notes
‒Activated charcoal filters can be obtained through
specialist retailers, from our after-sales service, or
from the online shop with the order number
AA200110. You need one activated charcoal filter
(AA200110) per filter module.
‒The activated charcoal filters cannot be cleaned or
reactivated.
‒Activated charcoal filters do not contain any harmful
substances and can be disposed of with your
normal household waste.

11
Follow the instructions below:
1Open the flap.
2Push the sides of the activated charcoal filter
together and remove it.
3Push the sides of the new activated charcoal filter
together and insert it.
4Close the flap.

12
Trouble shooting
Malfunctions often have simple explanations. Please
read the following notes before calling the after-sales
service.
mRisk of electric shock!
Incorrect repairs are dangerous. Repairs may only be
carried out and damaged power cables replaced by one
of our trained after-sales technicians. If the appliance is
defective, unplug the appliance from the mains or switch
off the circuit breaker in the fuse box. Contact the after-
sales service.
mRisk of injury!
The light emitted by LED lights is very dazzling, and can
damage the eyes (risk group 1). Do not look directly into
the switched on LED lights for longer than 100 seconds.
LED lights
Defective LED lights must only be replaced by the
manufacturer, their customer service department or a
licensed technician (electrician).
Fault table
--------
Disruption Possible cause Solution
The appliance does not work The plug is not plugged into the mains Connect the appliance to the electricity
supply
Power failure Check whether other kitchen appliances
are working
Faulty fuse Check in the fuse box to make sure that
the fuse for the appliance is OK
The appliance is not working, all the but-
tons are flashing
The network-cable plug is not plugged
into the mains
Check that the network cables of all the
appliances are connected
The circuit breaker is faulty Look in the fuse box and check that the
circuit breakers for all the appliances are
in working order
One of the components in the appliance
has broken
Call the after-sales service
The appliance is not working If the appliance is in operation for more
than four hours, the safety switch-off
function is activated
Switch the appliance on again
The button illumination does not work The control unit is faulty Call the after-sales service
The lighting is not working The lighting is defective Call the after-sales service
The œbutton flashes The metal filter is saturated Clean the filter, see the Cleaning and
maintenance section
The remote control is not working The batteries are flat Replace the batteries; see section
Replacing the remote control batteries

13
Replacing the batteries in the remote
control
1Press in the catch tappet and remove the cover.
2Remove the batteries.
3Correctly insert the new batteries (AAA/LR03/
1.5 V).
4Dispose of flat or faulty batteries according to local
regulations.
Note: Do not dispose of batteries in general household
waste.

14
Aftersales service
Our after-sales service is there for you if your appliance
needs to be repaired. We will always find an appropriate
solution in order to avoid unnecessary visits by
engineers.
When calling us, please give the product number (E no.)
and the production number (FD no.) so that we can
provide you with the correct advice. The rating plate
bearing these numbers can be found on the appliance.
To save time, you can make a note of the number of your
appliance and the telephone number of the after-sales
service in the space below, should it be required.
Please note that a visit from an after-sales service
engineer is not free of charge, even during the warranty
period.
Please find the contact data of all countries in the
enclosed customer service list.
To book an engineer visit and product advice
Trust the expertise of the manufacturer, and rest
assured that the repair will be carried out by trained
service technicians using original spare parts for your
domestic appliance.
Accessory
Special accessories
--------
E no. FD no.
After-sales service O
GB 0344 892 8988
Calls charged at local or mobile rate.
IE 01450 2655
0.03 € per minute at peak.
Off peak 0.0088 € per minute.
AU 1300 368 339
NZ 09 477 0492
Accessories Order number
Air recirculation module for
AC402/462/472/482
AA010810
Accessories Order number
Activated charcoal filter for
AC402/462/472/482
AA200110

15
Índice Instruccionesdeuso
Indicaciones de seguridad importantes 16
Protección del medio ambiente 19
Ahorro de energía 19
Eliminación de residuos respetuosa con el medio
ambiente 19
Modos de funcionamiento 19
Funcionamiento en salida de aire al exterior 19
Funcionamiento con recirculación de aire 19
Manejar el aparato 20
Panel de mando 20
Mando a distancia 20
Ajustar el ventilador 20
Nivel intensivo 20
Función de marcha en inercia 21
Ventilación a intervalos 21
Indicador de saturación 21
Iluminación 21
Desconexión de seguridad 21
Limpieza y mantenimiento 22
¿Qué hacer en caso de avería? 25
Cambiar las pilas del mando a distancia 26
Servicio de atención al cliente 27
Accesorios 27
: Encontrará más información sobre productos,
accesorios, piezas de repuesto y servicios en internet:
www.gaggenau.com y también en la tienda online:
www.gaggenau.com/zz/store

16
m Indicaciones de seguridad importantes
Leer con atención las siguientes instrucciones.
Solo así se puede manejar el aparato de forma
correcta y segura. Conservar las instrucciones
de uso y montaje para utilizarlas más adelante o
para posibles futuros compradores.
Solamente un montaje profesional conforme a
las instrucciones de montaje puede garantizar
un uso seguro del aparato. El instalador es
responsable del funcionamiento perfecto en el
lugar de instalación.
Este aparato ha sido diseñado para uso
doméstico. Este aparato no puede usarse en
exteriores. Vigilarlo mientras está funcionando.
El fabricante no asume ninguna responsabilidad
en caso de daños derivados de un uso indebido
o un manejo incorrecto.
Este aparato está previsto para ser utilizado a
una altura máxima de 2.000 metros sobre el
nivel del mar.
Este aparato puede ser utilizado por niños a
partir de 8 años y por personas con limitaciones
físicas, sensoriales o psíquicas, o que carezcan
de experiencia y conocimientos, siempre y
cuando sea bajo la supervisión de una persona
responsable de su seguridad o que le haya
instruido en el uso correcto del aparato siendo
consciente de los daños que se pudieran
ocasionar.
No dejar que los niños jueguen con el aparato.
La limpieza y el mantenimiento rutinario no
deben encomendarse a los niños a menos que
sean mayores de 15 años y lo hagan bajo
supervisión.
Mantener a los niños menores de 8 años
alejados del aparato y del cable de conexión.
Comprobar el aparato al sacarlo de su
embalaje. El aparato no debe conectarse en
caso de haber sufrido daños durante el
transporte.
Este aparato no está previsto para el
funcionamiento con un reloj temporizador
externo o un mando a distancia.
¡Peligro de asfixia!
El material de embalaje es peligroso para los
niños. No dejar que los niños jueguen con el
material de embalaje.
¡Peligro de muerte!
Los gases de combustión que se vuelven a
aspirar pueden ocasionar intoxicaciones.
Garantizar una entrada de aire suficiente si el
aparato se emplea en el modo de evacuación
del aire al exterior junto con un equipo
calefactor dependiente del aire del recinto de
instalación.
Los equipos calefactores que dependen del aire
del recinto de instalación (p. ej., calefactores de
gas, aceite, madera o carbón, calentadores de
salida libre, calentadores de agua) adquieren
aire de combustión del recinto de instalación y
evacuan los gases de escape al exterior a través
de un sistema extractor (p. ej., una chimenea).
En combinación con una ventilación de techo
conectada se extrae aire de la cocina y de las
habitaciones próximas; sin una entrada de aire
suficiente se genera una depresión. Los gases
tóxicos procedentes de la chimenea o del hueco
de ventilación se vuelven a aspirar en las
habitaciones.
▯Por tanto, asegurarse de que siempre haya
una entrada de aire suficiente.
▯Un pasamuros de entrada/salida de aire no
es garantía por sí solo del cumplimiento del
valor límite.
A fin de garantizar un funcionamiento seguro, la
depresión en el recinto de instalación de los
equipos calefactores no debe superar 4 Pa
(0,04 mbar). Esto se consigue si, mediante
aberturas que no se pueden cerrar, p. ej., en
puertas, ventanas, en combinación con un
pasamuros de entrada/salida de aire o
mediante otras medidas técnicas, se puede
hacer recircular el aire necesario para la
combustión.

17
Pedir siempre asesoramiento al técnico
competente de su región, que estará en
condiciones de evaluar todo el sistema de
ventilación de su hogar y recomendarle las
medidas adecuadas en materia de ventilación.
Si la ventilación de techo se utiliza
exclusivamente en el modo con recirculación de
aire, no hay limitaciones para el funcionamiento.
¡Peligro de incendio!
▯Los depósitos de grasa del filtro de grasas
pueden prenderse.
Los filtros de grasa deben limpiarse por lo
menos cada 2 meses.
No usar nunca el aparato sin filtro de grasa.
¡Peligro de incendio!
▯Los depósitos de grasa del filtro de grasas
pueden prenderse. Nunca trabaje con una
llama directa cerca del aparato (p. ej.,
flambear). Instalar el aparato cerca de un
equipo calefactor para combustibles sólidos
(p. ej., madera o carbón) solo si se dispone
de una cubierta cerrada no desmontable.
No deben saltar chispas.
¡Peligro de incendio!
▯El aceite caliente y la grasa se inflaman con
facilidad. Estar siempre pendiente del aceite
caliente y de la grasa. No apagar nunca con
agua un fuego. Apagar la zona de cocción.
Sofocar con cuidado las llamas con una
tapa, una tapa extintora u otro medio similar.
¡Peligro de incendio!
▯Los fogones de gas en los que no se haya
colocado ningún recipiente para cocinar
encima, generan gran cantidad de calor
durante su funcionamiento. Eso puede
dañar o incendiar el aparato de ventilación
situado encima. Utilizar los fogones de gas
únicamente colocando encima recipientes
para cocinar.
¡Peligro de incendio!
▯Cuando se usan simultáneamente varios
fogones de gas se genera mucho calor. El
aparato de ventilación puede dañarse o
incendiarse. El aparato de ventilación solo
puede combinarse con fogones de gas que
no superen una potencia total máxima
de18 kW. Al exceder la potencia total de 12
kW se deben tener en cuenta los
reglamentos locales respecto a la
ventilación del área, tamaño del área y
combinación con aparatos de ventilación en
el modo de aire de extracción o aire de
circulación.
¡Peligro de quemaduras!
Las partes accesibles se calientan durante el
funcionamiento. No tocar nunca las partes
calientes. No dejar que los niños se acerquen.
¡Peligro de lesiones!
▯Las piezas internas del aparato pueden
tener bordes afilados. Usar guantes
protectores.
¡Peligro de lesiones!
▯Peligro de caída al trabajar en el aparato.
Utilizar una escalera plegable que sea
segura. Escoger una escalera plegable
adecuada a la altura de trabajo. Utilizar
siempre la escalera plegable
completamente abierta sobre una superficie
plana. Comprobar que la barra separadora
esté encajada. Apoyar siempre ambos pies
en la escalera plegable, no subir demasiado
alto ni estirar el cuerpo.
¡Peligro de descarga eléctrica!
▯Un aparato defectuoso puede ocasionar una
descarga eléctrica. No conectar nunca un
aparato defectuoso. Desenchufar el aparato
de la red o desconectar el interruptor
automático del cuadro eléctrico. Avisar al
Servicio de Asistencia Técnica.
¡Peligro de descarga eléctrica!
▯Las reparaciones inadecuadas son
peligrosas. Las reparaciones y la sustitución
de cables de conexión defectuosos solo
pueden ser efectuadas por personal del
Servicio de Asistencia Técnica debidamente
instruido. Si el aparato está averiado,
desenchufarlo de la red o desconectar el
interruptor automático del cuadro eléctrico.
Avisar al Servicio de Asistencia Técnica.
¡Peligro de descarga eléctrica!
▯No utilizar ni limpiadores de alta presión ni
por chorro de vapor. La humedad interior
puede provocar una descarga eléctrica.

18
Causas de daños
¡Atención!
Peligro de daños por corrosión Encender siempre el
aparato cuando se vaya a cocinar con el fin de evitar la
formación de agua condensada. El agua condensada
puede conllevar daños por corrosión.
Limpiar de inmediato las bombillas defectuosas para
evitar una sobrecarga en el resto.
Peligro de daños por humedad en el interior del sistema
electrónico. No limpiar nunca los elementos de mando
con un paño húmedo.
Daños en la superficie en caso de limpieza indebida.
Limpiar las superficies de acero inoxidable siempre en
la dirección del pulido. No utilizar limpiadores
específicos para acero inoxidable para la limpieza de
los elementos de mando.
Daños en la superficie en caso de utilizar productos de
limpieza abrasivos o corrosivos. No utilizar nunca
productos de limpieza abrasivos o corrosivos.
Peligro de daños por recirculación del vapor
condensado. Instalar el canal de salida de aire del
aparato ligeramente inclinado hacia abajo (1° de
desnivel).

19
Protección del medio ambiente
Su nuevo aparato presenta una gran eficiencia
energética. Aquí se ofrecen consejos sobre cómo
manejar el aparato ahorrando más energía y cómo
desecharlo correctamente.
Ahorro de energía
▯Conectar la ventilación solo cuando sea necesario.
Si se desea calentar brevemente un plato que no
desprende un olor fuerte, también se puede dejar
apagada la ventilación.
▯Seleccionar un nivel de ventilación adecuado a
cada circunstancia.
▯Volver a apagar la ventilación tras la cocción.
▯Limpiar regularmente el filtro antigrasa, el cual
incrementa la eficacia de la ventilación.
▯Apagar la iluminación del aparato si no se utiliza.
Eliminación de residuos respetuosa
con el medio ambiente
Modos de funcionamiento
Este aparato puede utilizarse en funcionamiento con
salida de aire o en recirculación.
Funcionamiento en salida de aire al
exterior
Nota: La salida de aire no debe transmitirse ni a una
chimenea de humos o gases de escape en servicio ni a
un hueco que sirva como ventilación de los recintos de
instalación de equipos calefactores.
▯Si la salida de aire se va a evacuar en una chimenea
de humos o gases de escape que no está en
servicio, será necesario contar previamente con la
aprobación correspondiente del técnico
competente de la zona.
▯Si la salida de aire se evacua mediante la pared
exterior, se deberá utilizar un pasamuros
telescópico.
Funcionamiento con recirculación de
aire
Nota: Para neutralizar los olores durante el
funcionamiento con recirculación de aire debe
montarse un filtro de carbono activo. Para conocer
todas las posibilidades que ofrece el funcionamiento
con recirculación de aire del aparato, remitirse a la
documentación correspondiente o consultar en un
comercio especializado. Los accesorios necesarios
para tal fin pueden adquirirse en comercios
especializados, en el servicio de asistencia técnica o en
la tienda en línea.
Eliminar el embalaje de forma ecológica.
Este aparato está marcado con el símbolo de
cumplimiento con la Directiva Europea 2012/
19/UE relativa a los aparatos eléctricos y
electrónicos usados (Residuos de aparatos
eléctricos y electrónicos RAEE).
La directiva proporciona el marco general
válido en todo el ámbito de la Unión Europea
para la retirada y la reutilización de los
residuos de los aparatos eléctricos y
electrónicos.
El aire aspirado se depura a través de
filtros antigrasa y se evacua al exterior
mediante un sistema de conductos.
El aire aspirado se depura a través de
filtros antigrasa y un filtro de carbono
activo y se vuelve a suministrar a la
cocina.

20
Manejar el aparato
Nota: Encender la ventilación de techo al empezar a
cocinar y apagarla unos minutos después de haber
finalizado con las tareas de cocción. De esta manera se
neutralizarán con gran efectividad los vapores que se
desprenden al cocinar.
Panel de mando
Mando a distancia
Se podrán utilizar todas las funciones del aparato
mediante el panel de mando y el mando a distancia
excepto el restablecimiento del indicador de saturación.
Apuntar con el mando a distancia al panel de mando.
Notas
‒Asegurarse de que pueda verse la ventilación de
techo.
‒En caso de que el aparato no responda al mando a
una distancia corta, cambiar la pila del mando.
Ajustar el ventilador
Nota: Ajustar siempre la potencia del ventilador a la
circunstancia actual. Si se forma mucho vapor,
seleccionar también una potencia de ventilación alta.
Activación
1Pulsar la tecla #.
El ventilador se pone en marcha en el nivel 2.
2Pulsar las teclas 1, 2, 3 o Žpara ajustar el nivel de
ventilador correspondiente.
Nota: Con el mando a distancia, el ventilador se puede
conectar solo con la tecla 1, 2, 3 o Ž. Con la tecla #
se apaga el ventilador.
Desactivación
Pulsar la tecla #.
Nivel intensivo
En caso de fuertes olores y vapores, utilizar el nivel
intensivo.
Activación
1Pulsar la tecla #.
El ventilador se pone en marcha en el nivel 2.
2Pulsar la tecla Ž.
El nivel intensivo está activado.
Nota: La duración del nivel intensivo es de
6 minutos. Una vez transcurrido este tiempo, el
aparato vuelve al nivel de ventilador seleccionado
anteriormente.
Nota: El nivel intensivo puede activarse directamente
pulsando la tecla Ž del mando a distancia.
#Encender/apagar el ventilador
1 Activar el nivel de ventilación 1
2 Activar el nivel de ventilación 2
3 Activar el nivel de ventilación 3
ŽConectar el nivel intensivo
žActivar la marcha en inercia
œRestablecer el indicador de saturación
žConectar la iluminación
#Apagar el ventilador
1 Activar el nivel de ventilación 1
2 Activar el nivel de ventilación 2
3 Activar el nivel de ventilación 3
ŽConectar el nivel intensivo
žActivar la marcha en inercia
žConectar la iluminación
