Revision
INSTALLATION INSTRUCTIONS
Product
Printing Spec:
Form
If you need assistance or have questions, call Gamber-Johnson at 1-800-456-6868
7160-0542-XX
PS-001
F110 DOCKING STATION
features, set-up, and operation of the F110 computer, please refer to the manual
provided by Getac with the computer.
This docking station is designed to be used with a variety of Gamber- ohnson
mounting systems. Installation instructions for other Gamber- ohnson products
are provided with each individual product.
This instruction sheet is for the F110 docking station only. For instructions on
This instruction sheet is for the following products:
Item No. 7160-0542-00 No RF
Item No. 7160-0542-03 Tri-RF
© Copyright 2014 Gamber-Johnson, LLC

IMPORTANT SAFETY INFORMATION FOR INSTALLERS
Safety is dependent on the proper installation and servicing of this docking station. It is
important to read and follow all instructions before installing this product.
To properly install a Gamber- ohnson docking station you must have a good understanding of
automotive electrical procedures and systems, along with proficiency in the installation and
service of aftermarket vehicle equipment.
There are no adjustments required at any time of the electrical components within the
docking station. Opening the docking station will void the p oduct wa anty.
During Installation:
DO NOT connect this docking station to the vehicle battery until:
All other electrical connections are made1.
Mounting of all components is complete2.
Verification that no shorts exist in the entire system3.
DO NOT install equipment or route wiring or cords in the deployment path of any air bag.
When drilling into the vehicle, DO make sure that both sides of the surface are clear of
anything that could be damaged.
CAUTION: If wiring is shorted to the frame, high current conductors can cause hazardous
sparks resulting in electrical fires or flying molten metal.
After installation:
Test the docking station to ensure that it is working properly.
File these instructions in a safe place and refer to them when performing maintenance or re-
installing.
WARNING: Failure to follow all safety precautions and instructions may result in property
damage, serious injury, or death.
PRE-INSTALLATION RECOMMENDATOINS
Conduct a "Bench Test"
Gamber- ohnson strongly advises a "bench test" be conducted to verify all
electronic and software issues are resolved prior to installation:
Make sure the computer is operational by itself.1.
Insert computer into the docking station and verify that the computer is 2.
operating in the dock.
Interconnect entire assembly and verify start-up of all components, 3.
including other equipment (printers, modems, scanners, etc.)
Gamber- ohnson recommends positioning of all mounts and equipment in the
vehicle prior to the actual install to verify that mounting locations are safe and
practical.

Top Hooks
Key lockable
Wing Turn Latch
Slide Plate
Base
F110 DOCKING STATION FEATURE IDENTIFICATON
Tri-RF Connector
Docking Connector
Guide Pins
1/4-20unc Threaded Inserts
(G Hole Pattern and
Vesa 75mm Hole Pattern)
CABLE
RESTRAINT
BRACKET
Serial
Serial GPS
WWAN
WLAN
Microphone
Audio
Video
HDMI
(3) USB 2.0
(1) USB 3.0
Ethernet
19 Vdc Input

DOCKING AND UNDOCKING THE COMPUTER
1. With the slide plate in the open
position, insert the bottom of the
computer into the docking station.
The guide pins on the dock will help to
align the computer.
Then rotate the top of the comptuter
under the top hooks until the
computer is resting on the two supports
sticking out from the slide plate.
(see Figues 1, 2 & 3)
3. Push downward on the wing turn
latch until the slide plate is holding the
computer in place, then turn the latch
to hold the slide plate in the
downward possition. (See Figure 4)
4. (Optional) The key lock can now
be used for security purposes.
TO UNDOCK THE COMPUTER
1. Undock the computer by double
clicking on the Getac Utilities icon on
the desktop (OSDC). Click the Docking
button to undock the computer.
2. Unlock if locked.
3. Rotate the wing turn latch 90 deg.
The slide plate is spring loaded and
should raise with your hand when you
release the pressure on the slide plate.
4. Rotate the top of the computer out
of the dock to remove.
Figu e 2
Figu e 3
Figu e 4
Figu e 1
Supports

Gamber- ohnson LLC, 3001 Borham Ave.,
Stevens Point, WI, 54481, USA, 715-344-3482
Regulatory Certification Information
Regulatory Model #: 7160-0542
G Model #'s: 7160-0542-00, & 7160-0542-03,
Descriptions: Dock-Getac-F110
Certifications:
EN 55022:2010 CISPR 22:2008 Class A•
EN 50498:2010•
EN 50581:2012•
ECE-R10: 2012 Addendum 9, Revision 4•
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions. (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
10R-04 7632
