Gamber Johnson ZEBRA TC22 User manual

© Copyright 2023 Gamber-Johnson, LLC
7160-1856
ZEBRA TC22 / TC27 CRADLE
Rev A INST-1133
Printing Spec: PS-001
This instruction sheet is for the Zebra TC22/TC27 cradle only. The cradle is designed to
hold a Zebra TC22 or TC27 handheld computer only. The 7160-1856 will not work with
older TC2x devices. For instructions on features, set-up, and operation of the Zebra
TC22/TC27 handheld computer, please refer to the manual provided by Zebra with the
computer.
If you need assistance or have questions, call Gamber-Johnson at 1-800-456-6868
Revision Form Product
INSTALLATION INSTRUCTIONS
Product Mounting Disclaimer
Gamber-Johnson is not liable under any theory of contract or tort law for any loss, damage, personal injury, special, incidental or consequential damages for personal injury or other damage
of any nature arising directly or indirectly as a result of the improper installation or use of its products in vehicle or any other application. In order to safely install and use Gamber-Johnson
products full consideration of vehicle occupants, vehicle systems (i.e., the location of fuel lines, brake lines, electrical, drive train or other systems), air-bags and other safety equipment is
required. Gamber-Johnson specifically disclaims any responsibility for the improper use or installation of its products not consistent with original vehicle manufactures specifications
and recommendations, Gamber-Johnson product instruction sheets, or workmanship standards as endorsed through the Gamber-Johnson Certified Installer Program.
cable restraint
inserts
AMP's hole pattern
with #10-32 threaded
Cradle
slots to adjust
cable restraint
to fit USB-C cable

7160-1410 shown
#10-32 hardware
the device
the USB-C cable plugged into
for reference
cable restraint bracket
adjusts up and down to hold
USB-C cable
supplied by others
Attaching the cradle to a mount:
Attach a mount like the Gamber-Johnson 7160-1410 (shown below) to the cradle 1.
with the 3/4" long #10 machine screws, split lock and flat washers from the
hardware bag supplied with the cradle. Leave the screws loose so the cable
restraint can be adjusted up and down.
Adjust the cable restraint so it is lightly touching the USB-C power cable (suplied by 2.
others) when inserted into the bottom of the TC22/TC27 handheld computer. The
cable should not bind with the cable restraint when inserting or removing the
computer from the cradle.
Tighten the screws inserted in step 1 to hold the cradle with the cable restraint in 3.
place on the end of the mount.

45
12 3
6
Inserting the device into the cradle:
If you are using a USB-C cable to charge the device, the USB-C cable needs to be 1.
inserted into the bottom of the device before inserting the device into the cradle.
Insert the bottom of the device into the bottom of the cradle. If you have a USB-C 2.
cable inserted, the cable needs to go between the cable restraint fingers on the
bottom of the cradle. (Ref. images 1 & 2)
Rotate the top of the device into the cradle. The top latch will flex upward when the 3.
device is pushed into the cradle. (Ref. images 3 & 4)
To remove the device, push upward on the top latch and pull outward on the 4.
device. (Ref. images 5 & 6)
Note: the USB-C cable will come out with the device. Remove the cable from the 5.
bottom of the device by hand. Pulling the device outward to reach the cables limit,
could damage the cable or the device.
