MACHINE FEATURES
Drop Weight Tensioner with 8 to 90 lbs Tension Range and
Permanently Engraved Weight Scale
 Professional Six Point “Quick Mount” Racquet Mounting
System- Accommodates All Racquets
 Professional “Quick Action” Dual Action, Rotating, Composite
Fixed String Clamps with Diamond Dust Coating
 Parallel Jaw Rotating Ratchet Gripper with Diamond Dust
Coated Gripping Surfaces
 High Strength Extruded Aluminum Base with Durable
Anodized Finish and Convenient Padded Tool Tray
 Unique Internal Drawer System for Storing Tools and Adaptors
FEATURES

5
ASSEMBLY INSTRUCTIONS
Engaging the Drop Weight Bar Stop
The stringing machine is shipped with the
dropweightbarinthehorizontalposition. To
limit the rotation of the drop weight bar and
prevent racquet damage during stringing,
the bar stop must be engaged.
Hold the drop weight bar in the vertical posi-
tion as shown while turning the 5mm stop
screwlocatedonthebacksideof the winder
stand clockwise.
Winder Support Stand Installation
Remove the M5 bolts from the 2 brackets
locatedintherear slots of themachinebase
using the 5MM hex key. Slide the brackets
to the right end of the base and position the
winder stand over the brackets aligning the
holesinthebaseofthewinderstandwiththe
holesinthebrackets.Attachthewindersup-
portstandusingtheM5bolts.Installall4bolts
loosely at first and then tighten all securely.
Installing the Drop Weight
Removetheendcapfromthetensionbarand
slidethedropweightontothebar. Theweight
shouldbeorientedwiththeknobendclosest
to the string winder. Replace the end cap.

6
ASSEMBLY INSTRUCTIONS
Installing the Frame Support Posts
Place the support post onto the central slot
of the turntable. While holding the mounting
plate against the inside top surface of the
turntable with your fingers, align the hole in
thesupportpostwiththeholeinthemounting
plate. Install the mounting bolt through the
support post and into the plate by hand and
tightenwiththe6mmhexwrench. Re-install
the turntable end caps.
Repeat procedure on the opposite side of
the turntable
Remove Mounting Bolts
While holding the mounting plate on the
inside of the turntable remove the support
post mounting bolts.
Note: There are two Nylon washers that are
includedforshippingpurposesonly. Remove
and discard the nylon washers.
Repeat procedure on the opposite side of
the turntable
Support Post Installation
To install the support posts you must first
remove the turntable end cap by grasping
the sides of the end cap and removing it, to
gain access to the inside of the turntable.
Repeat procedure on the opposite side of
the turntable.
Ifendcapsaretight,aflatbladescrewdriver
may be used to pry the end caps off.
Nylon
Washers

7
Adjusting the Frame Support Posts
Loosen the lock bolts of the frame support
posts and space them apart with the frame
supportslidesseparatedbytheapproximate
lengthof the racquethead.Although it isnot
required,itisgoodpracticetocenterthesup-
port posts on the turntable. Lock one of the
postsinpositionbytighteningthelockboltand
positiontheotherpostuntiltheframesupport
slide is positioned near the inside surface of
the racquet frame. Securely tighten the lock
bolt of the second support post.
Caution: To avoid racquet damage, the
center posts should not contact the racquet prior to locking down the support posts.
MOUNTING THE FRAME
Tightening the Frame Supports
Tighten the Frame Support Slides by turn-
ing the adjustment knob clockwise until
snug against the racquet frame and slight
resistance is felt.
Caution: Overtightening the Center Sup-
portswillstretchthehead of the racquet and
could cause racquet damage.
ASSEMBLY INSTRUCTIONS
String Clamp Installation
The post of the string clamp and tube of
the string clamp base are treated with
grease to provide protection against corro-
sion during shipping. Remove any exces-
sive grease with a clean cloth prior to use.
The post and tube may also be cleaned
with isopropyl alcohol. After this type of
thorough cleaning, the post and tube
should be treated with a light coating of
machine oil to protect the surfaces against
corrosion and to ensure smooth operation.

8
Frame Shoulder Support Arm
Adjustment
Being sure the shoulder supports are free
to swivel in their mountings, simultaneously
rotatetheshouldersupportadjustmentknobs
clockwiseuntilbothshouldersupportsgently
and squarely contact the frame.
Securing the Frame
Lock the shoulder supports in position by
turning the knob at the base clockwise.
Repeat the adjustment procedure for the
remaining support post.
Re-tighten all of the frame supports in the
same order as before.
Do not overtighten any of the supports as
racquet damage may occur.
Thesupportsshouldbetightenedtothepoint
wheretheracquetframewillnotmoveinthe
mounting system when the handle is grasped and attempts are made to move it. Should any
supports lose contact with the frame while stringing they should be re-tightened.
MOUNTING THE FRAME
FrameShoulderSupportAdjustment
Theshouldersupportsaredesignedtorotate
and can be adjusted to provide maximum
support to the racquet frame. Rotate the
support so that the pads contact the frame
squarely when the arms are closed against
the racquet.

9
BadmintonShoulderSupportProtec-
tion Pad Installation
Slide the badminton shoulder support cover
overtheshouldersupports. Thereisnoneed
to remove the tennis shoulder supports.
Note: An optional badminton frame support
for the head of the racquet is available.
STRINGING THE FRAME
The drop weight is of a two piece design.
When assembled, it will accommodate ten-
sions from 20 to 90 lbs For tensions from 8
to20lbs,removethe5mmboltonthefaceof
the drop weight, and use the smaller portion
of the weight as described above.
Note: Tensions above 77lbs require the
removal of the drop weight bar end cap.
Setting Tension
To set the stringing tension, loosen the
locking knob on the side of the drop weight.
Slide the weight in the appropriate direction
until the face closest to the string gripper
is indexed with the desired tension mark on
the tension bar.

10
STRINGING THE FRAME
Base Clamp Operation
Rotate the lever lock clockwise to secure
the clamp base to the turntable.
Reverse the clamping procedure to unlock
the string clamp.
The lever should be tightened enough to
prevent clamp base slippage on the turn-
table, when the desired tension is placed
on the string. To go from the loose position
to the clamped position and back, gener-
ally requires about 1/2 to 3/4 quarters of a
turn. Although when stringing at extremely
high tensions, additional tightness may be required.
Clamping the First Main String
To begin stringing the main strings, thread
the two ends of the string through the two
center holes at the appropriate end of the
frame and continue through the opposite
center holes. Thread one end of the string
through the adjacent grommet hole and
pull excess by hand.
Secure one of the strings using a string
clamp.
String Clamp Operation
The fixed clamps are of a dual action de-
sign. The string clamp and the clamp base
operate independently of one another.
To clamp a string, lift the clamp head
and place the string between the jaws.
Depress the clamp head lever to secure
the string. The clamping pressure applied
to the string should be adjusted to provide
sufficient pressure to secure the string
when subjected to the desired pulling ten-
sion. The diamond coated gripper plates provide for increased friction between the clamps
and the string to allow for reduced clamping pressure while securing and holding the string
under tension.
Note: If the string slips in the string clamp while tensioning, adjust the gap between the
clamp jaws as per the instructions on page 15.

11
Gripping the String
While holding the tension bar slightly above
horizontal, wrap the free string clockwise
around the gripper drum once and position
between the gripper jaw.
Gently turn the gripper clockwise while
squeezing the jaws together until all slack
in the string is removed.
Note: For proper operation, the string grip-
per jaw must be in the position shown. The
tension in the string provides the clamping
force to the jaws.
Pulling Tension
Whilesecurelyholdingthestringgripperdrum
with your hand, lift the tension bar above
horizontal and gently lower the bar under its
own weight. If the tension bar drops below
horizontal, repeat the above action until the
bar comes to rest parallel to the racquet.
Whenthecorrecttensionisattained,thedrop
weightbarwillresthorizontallyasshown. For
accurate tensioning, it must be lowered and
cometorestathorizontalwithoutassistance.
Manually forcing the tension bar to the hori-
zontalpositionwillgreatlyincreasethe string
tension and may result in racquet damage.
If the tension bar comes to rest above hori-
zontal, release the string by lifting the bar
and re-pull the string.
STRINGING THE FRAME
WARNING: TO AVOID INJURY, KEEP FINGERS AWAY
FROM GRIPPER JAWS WHILE TENSIONING STRING.

12
STRINGING THE FRAME
Weaving the Cross Strings
Follow the manufacturer's recommended
stringingpatternforoneortwopiecestringing.
This will determine the starting point for the
cross strings. If applicable, tie the first cross
string using an appropriate starting knot.
Weave the cross strings over and under
the main strings being careful to alternate
the weave direction of each consecutive
cross string so as to be opposite of the
previously installed cross string.
Completing the String Job
Once the final cross string is tensioned and
clamped,tieoffattheappropriateholespeci-
fied by the racquet manufacturer.
Removetheframefromthemountingsystem
by loosening the shoulder supports and
frame supports.
Clamping the String
Secure the tensioned main string using
the remaining fixed clamp. Release the
string from the gripper by raising the ten-
sion arm.
Repeat the procedure for all of the remain-
ing main strings and tie off following the
racquet manufacturers recommendations.

13
Storage Drawers
There is one storage drawer located in the
baseofthemachine.Thedraweropensfrom
the right side of the base and lock into the
end cap with a spring loaded latch.
To open the drawer depress the latch in the
face of the drawer and slide it to the right.
To close the drawer simply slide the drawer
back inside the base and the latch with au-
tomatically lock into place.
ADDITIONAL FEATURES

14
PATHFINDER AWL
Once the awl is inserted, pull the handle of
the awl outward while holding the tip section
in place. This leaves the outer sheath in the
grommet hole. Insert the end of the string
into the outer sheath.
Whileholdingthestring,slowlypullthesheath
outofthegrommetholetoleavethefreeend
of the string exposed.
The machine includes the pathfinder string-
ing awl which creates a pathway between
or around strings to make inserting a string
through blocked grommets easier and
quicker.
Insert the awl through the grommet hole in
thesamemannerasfortraditionalawls.The
Pathfinderawlmustbeintheclosedposition
before insertion.

15
Adjusting the Clamps
The clamps provided with your stringing
machinewillneedminoradjustmentsaccord-
ing to string type, construction, and gauge.
Toadjust,routethestringthroughtheracquet
as if you were beginning the main strings.
Clamp the strings and pull tension. If the
string slips through the jaws of the clamp,
tighten the clamp by turning the adjustment
knoboppositeofthehandle,intheclockwise
direction.Iftheclamp leaves impressions or
damages the string, it is too tight and must
be adjusted by turning the adjustment knob
counterclockwise.
The clamp jaws must be clean and free from dirt, oil, and any string coating for them to grip
properly. Clean the clamp jaws with alcohol.
Note: The string clamps supplied with your stringing machine can accommodate tight string
patternssuchasbadminton.Depending on the string pattern,theclampwillspreadthestrings
slightly which will not compromise the quality of the string job.
MAINTENANCE & ADJUSTMENTS
Turntable Bushing Adjustment
The turntable bushing is adjusted at the fac-
toryforoptimumperformance.Aftertimeand
use, the turntable bushings may need minor
adjustment.Anadjustmentisindicatedwhen
noticeable turntable looseness or wobble
occurs while stringing.
To adjust the fit between the turntable pin
andthebushings,tightenthesetscrewatthe
topof the bushingusing a 3mm hexwrench.
Tighten until the turntable rotates smoothly
without excessive free play.
Adjustment
Knob
ClampBaseLockingNutAdjustment
In the event the Locking Lever rotation is
insufficienttoensuresmoothoperationofthe
clamp base, very minor adjustments to the
Clamp Base Locking Nut can be made with
thesupplied17mmsocket. Tightenorloosen
the locking nut in very small increments to
provide more clamping pressure or running
clearance as needed.

16
CARE & CLEANING
With time and use, the clamping surfaces of your machine may become oily or dirty and result
in string or clamp slippage while stringing. Periodic cleaning of the String Clamps and String
Gripper is recommended. Knife sharpening stones work well for cleaning the diamond coated
stringclampingsurfaces.Cleaningwithasolventsuchasisopropylalcoholandamildabrasive
tool such as a toothbrush also works well to remove oily or greasy build up.
TROUBLESHOOTING TIPS
PROBLEM SOLUTION
String slips in clamps - Adjust gap between clamp jaws
- Clean clamp jaws
String slips in gripper - Clean gripper jaws
- Make sure string is wrapped over top gripper
prior to inserting between gripper jaws
String clamp base slips on turntable - Clean bottom of clamp & top of turntable with
alcohol
- Adjust clamp base locking nut

17
NOTES

18
PARTS LIST
4A TURNTABLE BUSHING
6A CAP SCREW
8A SET SCREW- M5x6
9 WASHER
14 WASHER
21A FRAME SUPPORT SLIDE
25 TENSION BAR
26 TENSION BAR CAP
27 DROP WEIGHT KNOB
28 FRONT WEIGHT- BADM
29 BACK WEIGHT- TENNIS
30 TENSION BAR DRUM
30A SET SCREW
31 STRING GRIPPER DRUM
34 RATCHET TEETH
35 RATCHET TEETH SPRING
83X TENSION BAR STOP SCREW
88 CAP SCREW
133 FRAME SUPP SLIDE SCREW
140 MTNG STAND TOP PLATE
141 MTNG STAND TOP PAD
144 SHLDER SUPP LOCK KNOB
146A SUPP ARM ADJUST KNOB
161 WINDER BEARING
162 GRIPPER PIVOT PIN
163 PIVOT PIN RETAINER COLLAR
255 BASE
256 TRAY PAD
257 LOWER WINDER STAND
258 UPPER WINDER STAND
259 SLIDE BRACKET
261 TURNTABLE END CAP
262 SUPP POST MT PLATE
265 DRAWER END CAP
266 BASE CORNER CAP
267 TT RIGHT END CAP
268 TT LEFT END CAP
69 3MM HEX WRENCH*
71 6MM T-HANDLE HEX WRENCH*
98 10MM WRENCH*
108 UTILITY KNIFE*
109 NEEDLE NOSE PLIERS*
229 5MM HEX WRENCH*
MA STRINGER’S AWL*
MBMSP11 BADM SHOULDER SUPP COVER
MFSPP11 FRAME SUPPORT PADS
SHORT BADMINTON (SB)
SQUASH (SQ)
TENNIS (T)
TAPERED BADMINTON (B)
MMSPP13 V-MOUNT SUPP PADS
MPSA PATHFINDER AWL*
* (NOT SHOWN)
PART # DESCRIPTION
TOOLS & ACCESSORIES
MBFC BADM FLOATING CLAMP
MBFS11 BADM FRAME SUPPORT
MBMSS11 BADM MOUNTING SYS UPG
MDCSC BADM FIXED CLAMP
MPMC MACHINE COVER
MPG STARTING CLAMP
MPS CLEANING STONE
MPXFS FLOOR STAND
SGSM STRINGER’S MAT
OPTIONAL TOOLS & ACCESS
271 SUPPORT POST
278 BASE CORNER CAP
284 TURNTABLE
288 BASE END CAP
301 RUBBER FOOT
319 TT RISER RING
323 SMALL DRAWER
356 QM ARM (LONG) RIGHT
357 QM ARM (LONG) LEFT
381 SHOULDER V-MOUNT
MCFCT COMP FIXED CLAMP
MRSG ROTATIONAL GRIPPER
MQAC11 TALL QA BASE CLAMP
PART # DESCRIPTION

19
PARTS DRAWING
256
MRSG
255
4A
29
28
27
25
MCFCT
31
26
30A
83X
30
8A
162
163 161
258
257
319
259
323
259
278
265
266
288
SQSB TB
MMSPP
284
21A
96A
356
144
140
141
146A
133
14 381
357
301
261
262
271
88
35
34
MFSPP11
MBMSP11
MQAC11
267
268

GAMMA SPORTS
200 Waterfront Drive
Pittsburgh, Pennsylvania 15222
Phone: [phone] Fax: [phone]
Visit our website at www.gammasports.com
Copyright 2012 GAMMA Sports - All Rights Reserved
MMAN-36
(MGX6F-12)
