Ganz Digimaster Series DR8HRD User manual

1

2
Specification & Organization --------------------------------------------------
Specifications ---------------------------------------------------------12
Product Contents List ---------------------------------------------------14
System Organization ----------------------------------------------------15
Product Description --------------------------------------------------------
Front Panel Description (8 & 16ch) ------------------------------------------16
Rear Panel Description (8 & 16ch) ------------------------------------------17
Remote Controller Description ---------------------------------------------19
Connect & Power On -------------------------------------------------------20
Live Display -------------------------------------------------------------------21
Menu Control --------------------------------------------------------------------21
Screen Division --------------------------------------------------------21
Sequence ------------------------------------------------------------21
PTZ Camera Control ----------------------------------------------------22
Digital Zoom ----------------------------------------------------------22
Event Log Search -------------------------------------------------------23
Panic Recording --------------------------------------------------------------23
Quick Menu ---------------------------------------------------------------------24
SYSTEM SETUP -----------------------------------------------------------25
Camera --------------------------------------------------------------
Camera Setup ------------------------------------------------------26
Color Setup ------------------------------------------------------26
PTZ Setup -------------------------------------------------------27
Motion Sensor ----------------------------------------------------29
Display --------------------------------------------------------------
OSD -----------------------------------------------------------30
Monitor ---------------------------------------------------------31
Sequence -------------------------------------------------------32
Spot Out --------------------------------------------------------34
Sound --------------------------------------------------------------
Audio -----------------------------------------------------------35
Buzzer ----------------------------------------------------------35
System --------------------------------------------------------------
Date / Time -------------------------------------------------------36
System Management ------------------------------------------------37
Control Device -----------------------------------------------------38
POS Setup -----------------------------------------------------39

3
User --------------------------------------------------------------
User Management -----------------------------------------------40
User Authority ------------------------------------------------41
Log Out ------------------------------------------------------------------41
Network -----------------------------------------------------------------
IP Setup ------------------------------------------------------------------42
DDNS -------------------------------------------------------------------43
E-mail ---------------------------------------------------------------------------43
Event / Sensor -------------------------------------------------------------
HDD Event -------------------------------------------------------44
Alarm Input -------------------------------------------------------44
Alarm Out --------------------------------------------------------45
Buzzer Out -------------------------------------------------------46
E-mail Notification --------------------------------------------------47
Disk Manage ----------------------------------------------------------48
RECORD SETUP ------------------------------------------------------------
Recording Operations ---------------------------------------------------49
Continuous / Motion Recording Setup --------------------------------------------50
Alarm Recording Setup ----------------------------------------------------------54
Panic Recording Setup -----------------------------------------------------------54
Network Streaming Setup -----------------------------------------------------------55
SEARCH -----------------------------------------------------------------55
Search By Time -----------------------------------------------------------56
Search By Event ---------------------------------------------------------60
Search By POS Event ---------------------------------------------------------62
ARCHIVING ----------------------------------------------------------------
Create a New Archive ------------------------------------------------------64
Reserved Data Management ------------------------------------------------------65
FTP Setup ---------------------------------------------------------66
WEB CONNECTION SETUP --------------------------------------------------------
Preliminary Before Connection ------------------------------------------------------67
How to Connect -----------------------------------------------------------------67
Live Mode --------------------------------------------------------------69
Search By Time -----------------------------------------------------------------------71
Search By Event ----------------------------------------------------------------72
Remote Setup ----------------------------------------------------------73
Camera ---------------------------------------------------------------------74
Display ---------------------------------------------------------------------74
Sound ---------------------------------------------------------------------75
System ---------------------------------------------------------------------75

4
Recording -------------------------------------------------------------------------75
User ---------------------------------------------------------------------76
Network ---------------------------------------------------------------------76
Sensor ---------------------------------------------------------------------77
Information --------------------------------------------------------------77
WATERMARK PROCESS ------------------------------------------------------------------78
SMARTPHONE CONNECTION ----------------------------------------------------------80

5
Thank you for purchasing the GANZ DIGIMASTER Digital Video Recorder (DVR).
This DVR is produced using the most advanced GANZ digital recording technology and its quality is
guaranteed by strict reliability and compatibility testing.
This manual provides necessary information for the correct use of this product and also contains some
useful tips and step-by-step procedures for common DVR operations.
Please read this manual thoroughly before using your DVR in order to prevent possible malfunction
due to operator error.
This manual applies to the following DIGIMASTER Series DVR models: DR8HRD / DR16HRD.
This manual describes the external features of GANZ DIGIMASTER, part names, correct connection
methods for supported domes or pan/tilt receivers, control devices, peripheral devices and the system
setup instructions. It is important to note here that some features, figures, pictures and references can
only be applied to just one model.
• GANZ cannot be held responsible if the DVR is damaged due to the use of non-compatible devices
with this product. If you have any doubts, please check.
• GANZ cannot be held responsible if the DVR is damaged due to the product being disassembled or
modified by the user.
• This product is qualified for both domestic and industrial use.
• This product has acquired international certifications, including CE (Europe) and FCC (USA).

6
All copyrights of this manual are reserved by CBC (America) Corp., CBC Group, and CBC Co., Ltd.
Copyright ©2010
Any reproduction or republishing of this manual for commercial purposes is prohibited.
It is prohibited to transfer this manual via online media such as, but not limited to, the Internet.
It is also prohibited to post, distribute or translate this manual without permission from CBC.
CBC will not be held responsible if the DVR has been damaged as a result of improper handling by any user who is
unaware of how to operate this product and did not consult this manual before attempting to operate the product.
CBC reserves the right to change the contents of this manual without notice.
CBC reserves all copyrights of registered trademarks contained within this manual.
Please be aware of the following precautions before installing the DVR:
• Avoid positioning the DVR in any place where the unit may come into contact with moisture, dust, or soot.
•Avoid placing in direct sunlight, or near heating appliances.
•Keep the product away from electric shock or magnetic substances.
•Avoid temperature extremes (recommended operation temperature is between 0°C and ~40°C).
•Do not place any conductive material through the ventilation grills.
•Keep the system turned off before installation.
•Ensure that enough space is left for cable connections.
•Place the system on a solid surface with sufficient air ventilation. Avoid any surface that vibrates.
•Placing the system near electronic devices such as radio or TV may cause the product to malfunction.
•Do not disassemble the product without seeking assistance from the supplier.
•Do not place any heavy object on the system.
•Please keep cleaning the fan filter of front panel.

7
The following are warnings and precautions to ensure user safety and prevention of property damage.
Please read the information below thoroughly.

8

9

10

11
Important Safety Instructions
1) Read all instructions contained in this manual.
2) Keep a copy of these instructions for future reference.
3) Read all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with a dry cloth.
7) Do not block any of the ventilation openings. Install in accordance with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators, space heaters, stoves, or other devices that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding type plug.
- a polarized plug has two blades with one wider than the other.
- a grounding type plug has two blades and a third grounding prong.
- the wide blade and third prong are safety features provided for your safety.
[NOTE: If the provided plug does not fit into the outlet, consult an electrician for replacement of the obsolete outlet.]
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11) Only use attachments or accessories that are specified by the manufacturer.
12) Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus (if outlet is unprotected) during a lightning storm, or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged
in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
15) This equipment is intended for indoor use and all input/output wiring is limited to the inside of a building.
16) The power socket or outlet shall be installed near the equipment and should be easily accessible.
17) CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BYAN INCORRECT TYPE.
ONLY DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
NOTE: Maximum Operating Temperature: 40℃
USB Power Output: 5V DC (Maximum 500mA)

12
Specifications & Organization
1. Device Specifications
DR8HRD/DR16HRD
Video Standard NTSC/PAL
Audio Bi-Directional Audio
Monitor Display Real Time: 30ips (NTSC) or 25ips (PAL), per camera
Covert Camera Operation Programmable
Event/Log Search Up to 1,000,000 event log entries for user login/out, configuration changes,
remote access, connects/disconnects.
Record Scheduling Daily or Weekly; adjustable by specific hour of the day, per channel
Remote Access Live View, Search, Playback, Configuration; via web browser or client software
Playback Up to 16-channel simultaneous playback
Pre/Post Alarm Buffers Up to 5 seconds (Pre), 3 minutes (Post), programmable per camera
Video HD: 1920X1080P
VGA: 1280x1024 (60Hz) (monitors with Multi Sync function only)
Activity Detection 22x15 grid; Sensitivity Levels: 10 (1 lowest, 10 highest)
Multitasking Triplex
Video Inputs 8, 16 x 1Vp-p, CVBS, 75 ohms, BNC
Monitor Outputs 1 x CVBS, VGA, HD Display
Spot Output 1 x 1Vp-p, CVBS, 75 ohms, BNC
Audio Inputs 4 x line-in, mono, line level, unbalanced, RCAjack
Audio Output 1 x line-out, mono, line level, unbalanced, RCAjack
Resolution 352x240, 704x240, 704x480 (NTSC), 352x288, 704x288, 704x576 (PAL)
Compression Standard H.264
Recording Speed DR16HRD: 480/400fps@D1, DR8HRD: 240/200fps@D1
Image Size 3-5 Kbyte (352x240, 352x288), 5-10 Kbyte (704x240, 704x288)
6-16 Kbyte (704x480, 704x576)
Hard Disk Drive Capacity 4 x HDD; no limit on HDD capacity
Secondary Storage USB default (USB memory stick, USB HDD)
Alarm Inputs DR16HRD: 16+2, DR8HRD: 8+2
Alarm Outputs DR16HRD: 16 Digital + 4 Relay, DR8HRD: 8 Digital + 4 Relay
Archive/Snapshot File Formats AVI, JPG, BMP
Network Speed Control 8 levels (adjustable from 56Kbyte/s ~ 8192Kbyte/s)

13
Specifications & Organization
1. Device Specifications
Pre-Alarm Recording Up to 5 seconds, programmable per camera
OSD Languages English, Spanish, Portuguese, French, Russian, Polish, German, Italian
Ethernet/LAN Network Interface Gigabit Ethernet, RJ-45
Remote Function Live View, Search, Playback, Configuration, Archiving
Support for CMS Software, Web R/Aand Smart Phone
Digital Watermark Watermarked Video & Audio (for verification of data integrity & continuity)
PTZ Control RS-485 Serial interface (full duplex) (two wires, +/-)
Supply Voltage 12VDC, 5A, 100VAC-240VAC, 60/50Hz
Operating Temperature Range 5℃to 50℃
Housing Materials Case Cover: Steel metal; Front Panel: Molded Plastic
Dimensions (WxDxH) 43cm x 46cm x 9cm
Weight 7.3kgs

14
Specifications & Organization
2. Product Contents List
Please check to make sure that all of the product contents are present after opening the product packaging.
①Basic Contents

15
Remote ControllerInstruction Manual Installation CD
AC Power Cable
②Optional Contents
Internal Hard Disk Drive
DR8HRD / 16HRD Unit 12V DC Adapter
AAA Battery x 2

16
Specifications & Organization
3. System Organization
VGA Monitor

17
Product Description
1. Front Panel
①POWER : System Power On / Shutdown
②DISPLAY : Switch Screen Division Modes (and Screen Rotation Mode)
③SEQUENCE : Toggle Sequence Mode
④PANIC : Trigger Panic Recording Mode and Panic Relay Output
⑤ZOOM : Digital Zoom on Live View or Playback
⑥LOCK : Toggle Front Panel Lock
⑦ARCHIVE : Go to Archiving Menu
⑧PTZ : Go to Camera PTZ Control Menu
⑨SETUP : Go to Main Setup Menu
⑩SEARCH : Go to Search Menu
⑪USB PORT: USB Port(s) for either USB Mouse, USB Memory Stick, or USB HDD archiving devices.
⑫RETURN : Cancel / Deselect / Return to Previous Screen
⑬ENTER : Confirm / Select / Next Screen
⑭LED Indicator : Indicates Present System Status. (POWER, REC, NETWORK)
⑮Channel Selection Buttons (1 ~ 8 / 16) : Select Channel or Input Password Digits
- Directional / Navigation Buttons (UP, DOWN, LEFT, RIGHT, ENTER)
- Remote Controller Input Sensor (IR)
- EJECT : Eject CD-ROM (Optional)
- ◀◀/ ◀: Focus Adjust (Near / Far) or Reverse Play / Fast Rewind
- Ⅱ: Pause Playback
- ▶/ ▶▶: Iris Adjust (Open / Close) or Forward Play / Fast Forward
- JOG / SHUTTLE : Outer wheel – variable REW or FF; Inner wheel – scroll frame-by frame while PAUSED.
- HOLD : Hold Current JOG / SHUTTLE Position
• If the Remote Control IR Sensor is blocked, the Remote Controller will NOT function properly.
• When a button is pressed on the Front Panel or on the Remote Controller, the DVR will beep,
unless this feature is disabled from the main menu: System Setup ÆAudio ÆBuzzer.
Tip

18
Product Description
2. Rear panel description.
A. CAMERA INPUTS and LOOP OUTPUTS:
Connect up to 16 camera inputs. Loop outputs can be used for connection to other equipment.
B. COMPOSITE AND S-VIDEO MAIN:
MONITOR CONNECTIONS Both outputs can be used at the same time if more than one main monitor
connection is required.
C. SPOT MONITOR OUTPUTS: Up to 4 spot monitors can be connected as necessary.
D. ALARM INPUTS: Up to 16 alarm inputs can be connected and configured as high or low Inputs with
common ground.
E. ALARM OUTPUTS: Up to 16 alarm outputs can be connected and configured as high or low outputs
with common ground..
F. RELAY OUTPUTS: Up to 4 Relay outputs can be connected and configured as high or low outputs
with common ground.
G. RS485: Can connect PTZ camera and controller by two RS485 connectors.
Left side : for PTZ. Right side : for keyboard controller..
H. E-SATA: Can connect ESTG by E-SATA cable.
I. AUDIO INPUTS & OUTPUTS: Up to 4 audio inputs and one audio output can be connected as
necessary.
J. VIDEO SIGNAL SWITCH: Can change Video input signal type.
Can select Video output.

19
S
SY YS ST TE EM M C CO ON NF FI IG GU UR RA AT TI IO ON N
Selectable Video outputs are HD, VGA, SD.
Video output selection to choose only one.
If user selects the video output to two or more duplicate, the video may not be output normally.
If monitor spec doesn’t support DDC, the monitor can’t be recognized.
1) If you select HD output,
2) If you select VGA output,
3) If you select SD output,
K. USB PORT: Can connect USB mouse or USB device for backup.
L. HD MONITOR OUPUT: Can connect HD monitor output.
M. VGA: Can connect VGA monitor output.
N. RS232: Serial port.
O. LAN: Can connect to a router or internal network.
P. POWER: Can connect Power cable.

20
S
SY YS ST TE EM M C CO ON NF FI IG GU UR RE E – – R Re em mo ot te e C Co on nt tr ro ol ll le er r
3. Remote Controller description.
POWER
ON/OFF SETUP : Go to Main Setup Menu
RETURN
Cancel / Deselect
Previous Screen
Channel Selection Buttons
(also used for Password Digit Entry)
Navigation Buttons
Used for Playback Control,
Menu Navigation, and PTZ Control
ID Button
Select DVR Unit ID
ENTER : Confirm / Select / Next Screen
※If there are multiple DVRs stacked or mounted in a rack, each DVR must be assigned a unique ID number,
so that each DVR can be controlled with a single remote controller, referencing each DVR by its own ID.
How to choose which ID to use on the remote controller:
- Press the ID button. The system will display ‘INPUT ID’.
- Enter the digits of the unit ID, and then press the ENTER button. (The default unit ID is ‘01’).
- To return back to normal control of the DVR, now press the RETURN button.
- Factory Default Setting: Input unit ID ‘255’ and then press ENTER and RETURN.
