Gardena AL 1810 CV P4A User manual

AL 1830 CV P4A Art. 14901
EN Operator’s Manual
Battery Quick Charger
EN

O1
X
≈
å
Y
å
≈
O2
2

GARDENA Battery Quick Charger AL 1830 CV P4A
1. SAFETY.......................3
2. OPERATION ...................5
3. MAINTENANCE.................6
4. STORAGE .....................6
5. TROUBLESHOOTING ............6
6. TECHNICAL DATA ..............7
7. ACCESSORIES .................8
8. SERVICE/WARRANTY ...........8
Original instructions.
This charger is not
intended for use by
children or persons with
physical, sensory or mental
limitations or a lack of experi-
ence or knowledge. This
charger can be used by chil-
dren aged 8 or older and by
persons who have physical,
sensory or mental limitations
or a lack of experience
or knowledge if a person
responsible for their safety
supervises them or has
instructed them in the safe
operation of the charger and
they understand the associ-
ated dangers. Otherwise,
there is a risk of operating
errors and injuries.
Intended use:
The POWER FOR ALL Battery Quick
Charger 18V is intended to charge
relevant POWER FOR ALL System
Batteries and is intended for use in
private house and hobby gardens.
The product is not intended for long
term use.
1. SAFETY
Read all the safety and
general instructions.
Failure to observe the safety and general
instructions may result in electric shock,
fire and/or serious injury.
Store these instructions in a safe
place. Only use the charger if you can
fully evaluate all functions and carry
them out without restrictions, or if you
have received corresponding instruc-
tions.
v Supervise children during use,
cleaning and maintenance.
This will ensure that children do not
play with the charger.
v Charge only lithium-ion batteries
of the POWER FOR ALL system
type PBA 18V with a capacity of
1.5 Ah or more (5 battery cells or
more). The battery voltage must
match the battery charging volta-
ge of the charger. Do not charge
any nonrechargeable batteries.
3
EN

Otherwise there is a risk of fire and
explosion.
v
Do not expose the charger
to rain or wet conditions.
Water entering a power tool will
increase the risk of electric shock.
v Keep the charger clean.
Dirt poses a risk of electric shock.
v Always check the charger, cable
and plug before use. Stop using
the charger if you discover any
damage. Do not open the charger
yourself, and have it repaired only
by a qualified specialist using only
original replacement parts. Dam-
aged chargers, cables and plugs
increase the risk of electric shock.
v Do not operate the charger on an
easily ignited surface (e.g. paper,
textiles, etc.) or in a flammable
environment. There is a risk of fire
due to the charger heating up during
operation.
v Recharge only with the charger
specified by the manufacturer.
A charger that is suitable for one
type of battery pack may create a
risk of fire when used with another
battery pack.
v In case of damage and improper
use of the battery, vapours may
also be emitted.
Ensure the area is well ventilated and
seek medical attention should you
experience any adverse effects. The
vapours may irritate the respiratory
system.
v Under abusive conditions, liquid
may be ejected from the battery.
Contact with this liquid should be
avoided. If contact accidentally
occurs, rinse off with water. If the
liquid comes into contact with
your eyes, seek additional medi-
cal attention. Liquid ejected from
the battery may cause irritation or
burns.
v Do not cover the ventilation slots
of the charger. Otherwise, the
charger may overheat and no longer
function properly.
vIn order to avoid safety hazards, if
the power supply cord needs to be
replaced, this must be done by
GARDENA or by a customer service
centre that is authorised to repair
GARDENA power tools.
Products sold in GB only:
Your product is fitted with an BS 1363/A
approved electric plug with internal fuse
(ASTA approved to BS 1362). If the plug
is not suitable for your socket outlets, it
should be cut off and an appropriate
plug fitted in its place by an authorised
customer service agent. The replace-
ment plug should have the same fuse
rating as the original plug. The severed
plug must be disposed of to avoid a
possible shock hazard and should never
be inserted into a mains socket else-
where.
DANGER! Cardiac arrest! This pro-
duct makes an electromagnetic field
while it operates. This field may under
some conditions interfere with active or
passive medical implants. To decrease
the risk of conditions that can possibly
injure or kill, we recommend persons
with medical implants to speak with their
physician and the medical implant
manufacturer before you operate the
product.
DANGER! Risk of suffocation!
Small parts can be easily swallowed.
There is also a risk that the polybag can
suffocate toddlers. Keep toddlers away
when you assemble the product.
4
EN

2. OPERATION
To charge the battery [Fig. O1/O2]:
CAUTION!
vNote the mains voltage! The volt-
age of the power source must
match the voltage specified on the
rating plate of the charger.
1. Connect the battery charger Xinto
amains socket.
2. Slide the battery Yinto the charging
slot of the battery charger X.
The battery is not included with the
product as standard. You can find the
complete selection of accessories in
our accessories range.
Thanks to the intelligent charging pro-
cess, the charge condition of the battery
is automatically detected and then
charged up with the optimal charge
current depending on battery tempera-
ture and voltage.
In this way, the battery is treated with
care and remains permanently fully
charged when it is stored in the charger.
Meaning of the indication elements:
Indication on the charger:
(Fast) Flashing of the
Green Battery Charge
Indicator å
The rapid-charging procedure is indicated by fast flashing of the
green battery charge indicator å.
Note: The rapid-charging procedure is only possible when the battery
temperature is within the allowable charging temperature range,
see 6. TECHNICAL DATA.
(Slow) Flashing of the
Green Battery Charge
Indicator å
When the charging condition of the battery is 80%, the green battery
charge indicator åflashes slowly.
The battery can be removed for immediate use.
Continuous Lighting
ofthe Green Battery
Charge Indicator å
Full
Continuous lighting of the green battery charge indicator åindicates
that the battery is fully charged.
When the battery is not inserted, continuous lighting of the battery
charge indicator åindicates that the mains plug is inserted in the
socket outlet and that the battery charger is ready for operation.
Continuous Lighting
of the Red Battery
Error Indicator ≈
Continuous lighting of the red battery error indicator ≈indicates
that the temperature of the battery is not within the allowable charging
temperature range, see 6. TECHNICAL DATA.
As soon as the allowable charging temperature range is reached, the bat-
tery charger automatically switches to rapid charging.
Flashing Red Battery
Charge Indicator ≈
A flashing red battery error indicator ≈indicates a different
malfunction of the charging procedure, see 5. TROUBLESHOOTING.
5
EN

Practical advice:
When the charger is used continuously,
or for several consecutive charge cycles
without interruption, the charger may
heat up. This is, however, harmless and
does not indicate that the charger has
atechnical defect.
A significantly reduced operating time
after charging indicates that the battery
has deteriorated and must be replaced.
3. MAINTENANCE
To clean the battery charger:
Make sure that the surface and the con-
tacts of the battery and the battery
charger always are clean and dry before
you connect the battery charger.
Do not use running water.
v Clean the contacts and the plastic
parts with a soft and dry cloth.
4. STORAGE
To put into storage:
The product must be stored away
from children.
1. Clean the battery charger
(see 3. MAINTENANCE).
2. Store the battery charger in a dry,
enclosed and frost-free place.
Disposal:
(in accordance with RL2012/19/EC)
The product must not be dis-
posed of to normal household
waste. It must be disposed of in
line with local environmental regulations.
IMPORTANT!
v Dispose of the product through or
via your municipal recycling collection
centre.
5. TROUBLESHOOTING
Problem Possible Cause Remedy
Charging is not possible.
Green battery charge
indicator åis
continuously lit.
Red battery error
indicator ≈is flashing.
[Fig. O2]
The battery is not connected
(correctly).
v Connect the battery to
charger correctly.
Battery contacts are dirty. v Clean the battery contacts
(e.g. by connecting and
disconnecting the battery
several times. Replace the
battery if necessary.
6
EN

6. TECHNICAL DATA
Battery Quick Charger
AL 1830 CV P4A
Unit Value (Art. 14901-28 UK)
(Art. 14901-52 AU/NZ)
Mains voltage V (AC) 220 – 240
Mains frequency Hz 50 – 60
Rated power W 70
Battery charging voltage V (DC) 18
Max. battery charging
current A 3.0
Battery charging time 80%/
97 – 100% (approx.)
PBA 18V 2,0Ah W-B
PBA 18V 2,5Ah W-B
PBA 18V 4,0Ah W-C
min.
min.
min.
32 / 45
40 / 60
64 / 95
Permitted charging
temperature range °C 0 – 45
Weight according to EPTA-
Procedure 01:2014 kg 0.40
Protection class / II
Appropriate POWER FOR ALL system Batteries: PBA 18V.
Problem Possible Cause Remedy
Charging is not possible.
Green battery charge
indicator åis
continuously lit.
Red battery error
indicator ≈is flashing.
[Fig. O2]
Battery temperature is
outside the permissible
charging temperature range.
v Wait until the battery
temperature is between
0 °C – +45 °C again.
Battery is defective. v Replace the battery.
Green battery charge
indicator å/the red battery
error indicator ≈is not
illuminated [Fig. O2]
Mains plug of the charger is
not (correctly) plugged in.
v Insert the mains plug into the
mains socket (completely).
Socket outlet, mains cable or
charger is defective.
v Check the mains voltage.
Let the charger be checked
if necessary by an authorised
specialist dealer or the
GARDENA Service.
7
EN

8. SERVICE/ WARRANTY
Service:
Please contact the address on the back
page.
Warranty statement:
In the event of a warranty claim, no
charge is levied to you for the services
provided.
GARDENA Manufacturing GmbH grants
a warranty for all original GARDENA new
products for two years from the date of
original purchase from the retailer, pro-
vided that the devices have been for
private use only. This manufacturer’s
warranty does not apply to products
acquired second hand. This warranty
includes all significant defects of the
product that can be proved to be materi-
al or manufacturing faults. This warranty
is fulfilled by supplying afully functional
replacement product or by repairing the
faulty product sent to us free of charge;
we reserve the right to choose between
these options. This service is subject to
the following provisions:
• The product has been used for its
intended purpose as per the recom-
mendations in the operating instruc-
tions.
• Neither the purchaser nor a third party
has attempted to open or repair the
product.
• Only Original GARDENA replacement
parts and wear parts have been used
for operation.
• Presentation of the receipt.
Normal wear and tear of parts and com-
ponents (such as blades, blade fixing
parts, turbines, light bulbs, V-belts/
toothed belts, impellers, air filters, spark
plugs), visual changes, wear parts and
consumables are excluded from the
warranty.
This manufacturer’s warranty is limited
to replacement and repair of products in
accordance with the abovementioned
conditions. The manufacturer’s warranty
does not constitute an entitlement to
lodge other claims against us as a manu-
facturer, such as for damages. This man-
ufacturer’s warranty does not, of course,
affect statutory and contractual warranty
claims against the dealer/
retailer.
The manufacturer’s warranty is governed
by the law of the Federal Republic of
Germany.
In case of a warranty claim, please return
the faulty product, together with a copy
of the receipt and a description of the
fault, with postage paid to the service
address.
7. ACCESSORIES
GARDENA System Battery
PBA 18V/36 P4A
PBA 18V/45 P4A
PBA 18V/72 P4A
Battery for additional duration or for replacement.
Art. 14902
Art. 14903
Art. 14905
8
EN

50
Deutschland / Germany
GARDENA Manufacturing GmbH
Central Service
Hans-Lorenser-Straße 40
D-89079 Ulm
Produktfragen:
([phone]
Reparaturen:
([phone]
[email protected]
http: //www.gardena.com
Albania
KRAFT SHPK
Autostrada Tirane-Durres
Km 7
1051 Tirane
Argentina
ROBERTO C. RUMBO S.R.L.
Predio Norlog
Lote 7
Benavidez. ZC: 1621
Buenos Aires
[email protected]
Australia
Husqvarna Australia Pty. Ltd.
Locked Bag 5
Central Coast BC
NSW 2252
Phone: (+ 61) (0) 2 4352 7400
customer.service@
husqvarna.com.au
Austria / Österreich
Husqvarna Austria GmbH
Industriezeile 36
4010 Linz
Tel. : [phone]
service.gardena@
husqvarnagroup.com
Azerbaijan
Firm Progress
a. Aliyev Str. 26A
1052 Baku
Belarus
Private Enterprise
“Master Garden”
Minsk
Sharangovich str., 7a
Phone: [phone]
Mob.: [phone]
[email protected]
Belgium
Husqvarna Belgium nv
Gardena Division
Leuvensesteenweg 542
Planet II E
1930 Zaventem
België
Bosnia / Herzegovina
SILK TRADE d.o.o.
Industrijska zona Bukva bb
74260 Tešanj
Brazil
Husqvarna do Brasil Ltda
Av. Francisco Matarazzo,
1400 – 19oandar
São Paulo – SP
CEP: 05001-903
Tel: [phone]
marketing.br.husqvarna@
husqvarna.com.br
Bulgaria
AGROLAND България АД
бул. 8 Декември, № 13
Офис 5
1700 Студентски град
София
Тел.: [phone]
[email protected]
Canada / USA
GARDENA Canada Ltd.
100 Summerlea Road
Brampton, Ontario L6T 4X3
Phone: [phone]
[email protected]
Chile
REPRESENTACIONES
JCE S.A.
Av. Del Valle Norte 857,
Piso 4
Santiago RM
Phone: (+ 56) 2 24142560
[email protected]
China
Husqvarna (Shanghai)
Management Co., Ltd.
富世华（上海）管理有限公司
3F, Benq Square B,
No207, Song Hong Rd.,
Chang Ning District,
Shanghai, PRC. 200335
上海市长宁区淞虹路207号明
基广场B座3楼, 邮编: 200335
Colombia
Husqvarna Colombia S.A.
Calle 18 No. 68 D-31, zona
Industrial de Montevideo
Bogotá, Cundinamarca
Tel. [phone] ext. 105
[email protected]
Costa Rica
Compania Exim
Euroiberoamericana S.A.
Los Colegios, Moravia,
200 metros al Sur del Colegio
Saint Francis – San José
Phone: [phone]
[email protected]
Croatia
Husqvarna Austria GmbH
Industriezeile 36
4010 Linz
Tel. : [phone]
service.gardena@
husqvarnagroup.com
Cyprus
Med Marketing
17 Digeni Akrita Ave
P.O. Box 27017
1641 Nicosia
Czech Republic
Husqvarna Česko s.r.o.
Türkova 2319/5b
149 00 Praha 4 – Chodov
Bezplatná infolinka :
800 100 425
[email protected]
Denmark
GARDENA DANMARK
Lejrvej 19, st.
3500 Værløse
Tlf.: ([phone]
[email protected]
www.gardena.com / dk
Dominican Republic
BOSQUESA, S.R.L
Carretera Santiago Licey
Km. 5 ½
Esquina Copal II.
Santiago
Dominican Republic
Phone: [phone]
[email protected]

51
Ecuador
Husqvarna Ecuador S.A.
Arupos E1-181 y 10 de
Agosto Quito, Pichincha
Tel. [phone]
[email protected]
Estonia
Husqvarna Eesti OÜ
Valdeku 132
EE-11216 Tallinn
[email protected]
Finland
Oy Husqvarna Ab
Gardena Division
Lautatarhankatu 8 B / PL 3
00581 HELSINKI
www.gardena.fi
France
Husqvarna France
9/11 Allée des pierres mayettes
92635 Gennevilliers Cedex
France
http : //www.gardena.com/ fr
N° AZUR: 0 810 00 78 23
(Prix d’un appel local)
Georgia
Transporter LLC
113b Beliashvili street
0159 Tbilisi, Georgia
Great Britain
Husqvarna UK Ltd
Preston Road
Aycliffe Industrial Park
Newton Aycliffe
County Durham
DL5 6UP
[email protected]
Greece
Π.ΠΑΠΑΔΟΠΟΥΛΟΣ ΑΕΒΕ
Λεωφ. Αθηνών 92
Αθήνα
Τ.Κ.104 42
Ελλάδα
Τηλ. ([phone]
[email protected]
Hungary
Husqvarna Magyarország Kft.
Ezred u. 1- 3
1044 Budapest
Telefon: [phone]
[email protected]
Iceland
BYKO ehf.
Bildshöfoa 20
110 Reykjavik
Ireland
Husqvarna UK Ltd
Preston Road
Aycliffe Industrial Park
Newton Aycliffe
County Durham
DL5 6UP
[email protected]
Italy
Husqvarna Italia Spa
Centro Direzionale Planum
Via del Lavoro 2, Scala B
22036 ERBA (CO)
Tel. [phone]
[email protected]
Japan
Husqvarna Zenoah Co. Ltd. Japan
1-9 Minamidai, Kawagoe
350-1165 Saitama
Japan
gardena[email protected]
Kazakhstan
LAMED Ltd.
155/1, Tazhibayevoi Str.
050060 Almaty
IP Schmidt
Abayavenue 3B
110 005 Kostanay
Korea
Kyung Jin Trading CO.,LTD.
107-4, SunDuk Bld.,
YangJae-dong,
Seocho-gu,
Seoul, (zipcode: 137-891)
Phone: (+82) (0)2 574-6300
Latvia
Husqvarna Latvija SIA
Ulbrokas 19A
LV-1021 Rīga
[email protected]
Lithuania
UAB Husqvarna Lietuva
Ateities pl. 77C
LT-52104 Kaunas
[email protected]
Luxembourg
Magasins Jules Neuberg
39, rue Jacques Stas
Luxembourg-Gasperich 2549
Case Postale No. 12
Luxembourg 2010
Phone: [phone]
[email protected]
Mexico
AFOSA
Av. Lopez Mateos Sur # 5019
Col. La Calma 45070
Zapopan, Jalisco, Mexico
Phone: [phone]
[email protected]
Moldova
Convel S.R.L.
290A Muncesti Str.
2002 Chisinau
Netherlands
Husqvarna Nederland B.V.
GARDENA Division
Postbus 50131
1305 AC ALMERE
Phone: [phone]
[email protected]
Neth. Antilles
Jonka Enterprises N.V.
Sta. Rosa Weg 196
P.O. Box 8200
Curaçao
Phone: [phone]
[email protected]
New Zealand
Husqvarna New Zealand Ltd.
PO Box 76-437
Manukau City 2241
Phone: (+64) (0) 9 9202410
[email protected]
Norway
Husqvarna Norge AS
Gardena Division
Trøskenveien 36
1708 Sarpsborg
[email protected]

52
Peru
Husqvarna Perú S.A.
Jr. Ramón Cárcamo 710
Lima 1
Tel: [phone] ext. 416
[email protected]
Poland
Husqvarna
Poland Spółka z o.o.
ul. Wysockiego 15 b
03-371 Warszawa
Phone: [phone]
[email protected]
Portugal
Husqvarna Portugal, SA
Lagoa - Albarraque
2635 - 595 Rio de Mouro
Tel.: [phone]
Fax : [phone]
[email protected]
Romania
Madex International Srl
Soseaua Odaii 117- 123,
RO 013603 Bucureşti, S1
Phone: [phone]
[email protected]
Russia / Россия
ООО „Хускварна“
141400, Московская обл.,
г. Химки,
улица Ленинградская,
владение 39, стр.6
Бизнес Центр
„Химки Бизнес Парк“,
помещение ОВ02_04
http://www.gardena.ru
Serbia
Domel d.o.o.
Autoput za Novi Sad bb
11273 Belgrade
Phone: [phone]
[email protected]
Singapore
Hy-Ray PRIVATE LIMITED
40 Jalan Pemimpin
#02-08 Tat Ann Building
Singapore 577185
Phone: [phone]
[email protected]
Slovak Republic
Husqvarna Česko s.r.o.
Türkova 2319/5b
149 00 Praha 4 – Chodov
Bezplatná infolinka:
800 154 044
[email protected]
Slovenia
Husqvarna Austria GmbH
Industriezeile 36
4010 Linz
Tel. : [phone]
service.gardena@
husqvarnagroup.com
South Africa
Husqvarna
South Africa (Pty) Ltd
Postnet Suite 250
Private Bag X6,
Cascades, 3202
South Africa
Phone: [phone]
[email protected]
Spain
Husqvarna España S.A.
Calle de Rivas nº 10
28052 Madrid
Phone: [phone]
[email protected]
Suriname
Deto Handelmaatschappij N.V.
Kernkampweg 72-74
P.O.Box: 12782
Paramaribo – Suriname
South America
Phone: [phone]
www.deto.sr
Sweden
Husqvarna AB/ GARDENA Sverige
Drottninggatan 2
561 82 Huskvarna
Sverige
Switzerland / Schweiz
Husqvarna Schweiz AG
Consumer Products
Industriestrasse 10
5506 Mägenwil
Phone: (+ 41) (0) 62 887 37 90
[email protected]
Turkey
Dost Bahçe Dış Ticaret
Mümessillik A.Ş
Yunus Mah. Adil Sok. No: 3
Ic Kapi No: 1 Kartal
34873 Istanbul
Phone: [phone]
[email protected]
Ukraine / Україна
ТОВ «Хускварна Україна»
вул. Васильківська, 34,
офіс 204-г
03022, м. Київ
Тел. [phone]
[email protected]
Uruguay
FELI SA
Entre Ríos 1083 CP 11800
Montevideo – Uruguay
Tel : [phone]
[email protected]
Venezuela
Corporación Casa y Jardín C.A.
Av. Caroní, Edif. Trezmen, PB.
Colinas de Bello Monte.
1050 Caracas.
Tlf : ([phone]
[email protected]
14901-56.960.01/0521
© GARDENA Manufacturing GmbH
D-89079 Ulm
http://www.gardena.com
