Gasmate EH325 User manual

03840 10/19
ELECTRIC
HEATER
The ideal solution for extending the outdoor
entertaining season
Can be used indoors or outdoors
 Elegantblacknish
Quartz heating element
2000W Maximum output
Adjustable pole 1.6m - 1.8m
Pull cord operation
3 Heat settings
Overall dimensions: 50cm W x 20cm D x 200cm H
Model No. EH325
Important: Retain these instructions for future use

32
Safety
Before attempting to operate this heater, the following
basic safety precautions should be taken to reduce
theriskofre,electricshockandpersonalinjury.It
is important to read the instruction manual and to
understand its’ applications, limitations and potential
hazards associated with this heater. This heater is not
intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have been
given supervision or instruction concerning the use of
the appliance by a person responsible for their safety.
This heater is not designed for use within 1m or above a
watersource.Itisimportantthatyouread,understand
and follow these instructions very carefully. They are
designed for the safety of yourself and others ensuring
a long and trouble free service life from your heater. This
electricheatercomplieswithAustralianandInternational
standards and safety requirements. Repairs should only
becarriedoutbyqualiedpersonsusingoriginalspare
parts. Failure to do so may result in considerable danger
to the operator.
SAFE OPERATION
Beware of Children and Pets
Children should not be allowed to touch or operate
heaters or touch extension cords, if used. All heaters
should be kept out of reach of children, preferably
stored or locked in a secure cabinet or room when not
in use.
Do not abuse or damage the power cord
Never yank or pull on the power cord to disconnect it
from the mains supply socket. Never carry your heater
by its’ power cord. Keep the power cord away from
heat, oil, solvents and sharp edges. Check the power
cord regularly for any damage and if the power cord
becomes damaged have it replaced by an authorised
service facility.
Extension Cords and Reels
ThisheaterisNOTdesignedtorunoanextension
cord.Ifyourequireanadditionalpowerpointplease
haveoneinstalledbyaqualiedelectrician.
The use of extension cords may cause power voltage
loss which will result in damage to the motor this will
NOT be covered under warranty.
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
Installation
Alwaysensureyouselectthecorrectxingaccessories
which suit the particular material you are attaching to, if
in doubt please discuss with your local retailer or local
hardware store. This heater is not designed for use
within 1m or above a water source. All installations must
meet the requirements of Australia Standard AS/NZS
3000:2007.
Ensure that the heater is not positioned directly above or
below a power point or switch.
This heater is not designed to be used with 3rd party
timer or programmable system.
WARNING:Fireriskexistsifthisheateriscoveredby
or positioned close to curtains or other combustible
materials.
NOTE: When using this heater outside ensure that it is
connected directly to an outdoor power point.
The electrical system of this heater must be connected
with an automatic 30mA circuit breaker and/or residual
currentdevice(RCD).Ifuncertainhaveaqualied
electrician check your electrical system before
installation and/or use.
All electrical connections are made in a dry area.
Outdoor power points must be weatherproof and
installedbyaqualiedelectrician.
SitroGroupAustraliaPtyLtdisnotresponsiblefor
incorrectlychosenxingaccessoriesoranydamage
whichmaybecausedbyanincorrectlyttedheater.

32
SPECIFIC SAFETY INSTRUCTIONS
WARNING
Do not use the heater in areas where there is a risk of
explosionorrefromammablegases.Ensurethat
the heating area is kept clear of combustible materials.
Do not use the heater in damp areas, without suitable
ventilation. This heater is not designed for use within 1m
or above a water source. Do not place within one metre
(1m) of any water source. Do not place directly below or
above any power points or switches.
WARNING:Fireriskexistsifthisheateriscoveredby
or positioned close to curtains or other combustible
materials.
• Thisheaterisintendedfordomestic/householduse
only.
• Alwaysensurethatthisheaterisinstalledasperthe
requirements noted in Australian Standard AS/NZS
3000:2007.
• Alwayskeepheateratleastonemetre(1m)from
combustible materials.
• DONOTlocatethisheaterdirectlybeloworabovethe
power supply socket or switch.
• DONOTusethisheaterineitherabathroom
or ensuite.
• DONOTusea3rdpartytimer,orprogrammable
system with this heater.
• DONOTcleantheheaterwhiletheheaterisonor
plugged into the mains power supply.
• DONOTtouchanypartoftheheaterwhileon,hot
surfaces may burn.
• DONOTusetheheaterasadryer.
• DONOTattempttomodifytheheater,powercord,
power plug or the supplied accessories in any way.
• DONOTexposetheheatertorain,water,orusein
damp wet conditions.
• NEVERcoverthisheater.
• NEVERcarrytheheaterbyitspowersupplycord.
• NEVERusewiththepowercordcoiled,bundledupor
tied up. Always extend fully before use.
• NEVERusetheheaterifanypartofitisdamaged.
• Ensurethattheheaterisdisconnectedfromthemains
supply when installing, cleaning or moving.
• Ensurethisheaterisnotleftonwhenunattended.
• Ensuretheheaterisnotusedinareaswhere
ammablegasesarepresent,e.g.paint,petroletc.
• AlwaysturntheheaterOFFattheunitswitchand
the power point switch when not in use for extended
periods of time.
• Alwaysallowtheheatertocool,aboutone(1)hour
aftertheheaterhasbeenturnedo,beforecleaning
the heater.
• Alwaysensurethatthepowercordisfullyextended
and NOT in contact with any part of the heater.
• Alwaysensurethattheheateriskeptcleanandfree
from dust.
• Onlyusethisheaterwhensecurelymountedtothe
supplied stand.

54
Heater EH325 (EH322)
Voltage 220-240VAC50Hz
InputWattage 650-2000W
Unit Weight 10Kg (inc. base)
IPRating IP24
SGS171001-EA
Heaterspecicationscanbefoundonthedatalabel.
IMPORTANT
Thisproductisttedwithasealedelectricalconnection
plug that is compatible with the heater, the mains supply
for Australia and meets the requirements of international
standards. This heater must be connected to a supply
voltage that is equal to that stated on the rating label.
Ifthemainsconnectionplugorpowercordbecomes
damaged it must be replaced with a complete assembly
that is identical to the original, and this must be replaced
by an authorised service centre. Always follow the
Australian requirements for connection to the mains
supply.Ifindoubtalwaysconsultaqualiedelectrician.
Technical Specification
ELECTRICAL DATA

54
NOTE: Remove any transit protection material
1. Place metal cover ‘A’ over weighted base ‘C’.
2. Push bottom pole ‘D’ into completed base ‘A+C’
and secure using screw ‘B’. Screw ‘B’ goes through
completed base ‘A+C’ and into the bottom pole ‘D’,
tighten fully.
3. Loosenandremove2screws‘L’onpole‘D’andslide
pole‘E’ontopole‘D’.Re-tandtightenfullythe2
screws‘L’.
4. Repeat step 3 for pole ‘E’.
5. a)Loosenandremovecollar‘G’frompole‘F’.
b) Remove screw from pole ‘H’.
6. Push small pole ‘H’ up through the centre of pole ‘F’,
ensure pole ‘H’ is fully through the other end of pole
‘F’.
7. Re-tandtightencollar‘G’ontopole‘F’.
8. Placeheaterheadontopole‘H’andtightenscrew‘I’.
9. Clip power cord into all cord clips ‘K’.
Heater is now complete and ready for use.
To Tilt Head
Note: Always ensure that the heater is switched
off, disconnected from the mains power supply
and is cold to touch. If heater has been recently
used, please leave the heater one (1) hour to
cool before tilting head.
1.Loosentheheadtiltscrew,donotremove.
2. Head can be tilted through 10°.
3. Tighten the head tilt screw when the desired angle is
achieved.
I
H
G
F
E
D
C
B
A
K
J
L
L
K
J
J
K
Assembled heater head
Head tilt screw
Fitted
power cord
& plug
Completed height on stand
1.7m
Fitted
pull cord
for use
Head tilt screw
100
STAND ASSEMBLY

76
To Operate
1. Pluginto240VACwallsocketandturnon.
2. Pull the cord to turn heater to low.
3. Touseall3heatsettingsandtoturno,please
follow:
1stPulloncord- Low- DisplayshowsL
2nd Pull on cord - Medium - Display shows M
3rd Pull on cord - High - Display shows H
4thPulloncord- O- DisplayshowsO
4. Turnoatwallsocketandunplug.
DISPLAY, THIS SHOWS:
OFF - O
LOW - L
MEDIUM - M
HIGH - H
OFF - O
Cleaning
Always ensure that the heater has been left for one (1)
hour to cool before cleaning.
1. Turnoanddisconnectfrommainspower,
allow to cool.
2. Wipe unit over with a damp clean soft lint free
cloth.
3. For stubborn marks you can use a mild dish
washing solution on a damp clean soft lint free
cloth.
NEVERallowwateroramilddishwashingsolutionto
enter or drip onto the heater.
NEVERusesolvents,e.g.Petrol,Toluene,Methylated
Spirits etc to clean the heater, as these will damage the
surfacenishandmaycausearewhenunitisnext
used.

76
WARRANTY STATEMENT
GASMATE ELECTRIC HEATER
PRODUCT RANGE
SITROGROUPAUSTRALIA(S.G.A.)warrantsthe
purchaser of this product against defects in workmanship
and materials for a period of 12 months from the date of
purchase.
This warranty is not transferable to a subsequent
purchaser if the product is sold by the original purchaser
during the warranty period.
Ifawarrantyfaultappearswithinthewarrantyperiod,
S.G.A.reservestherighttoreplaceorrepairtheproduct.
IntheeventthatS.G.A.choosestoreplacetheproduct,
this original warranty will expire at the original date.
Iftheproductincludesvariousaccessoriesor
components, only the defective accessory or component
will be replaced or repaired.
S.G.A.reservestherighttoreplacedefectiveparts
of the product with parts and components of similar
quality, grade and composition where an identical part or
component is not available.
Products presented for repair may be replaced by
refurbished products of the same type rather than being
repaired. Refurbished parts may be used to repair the
products.
Tomakeawarrantyclaim,rstcontactS.G.A’sCustomer
ServiceLineonthecontactnumberbelow.
The purchase receipt for this product is to be retained
and must be presented if making claim under the terms
ofthisS.G.A.warranty.
Warranty repairs are free of charge, provided the product
isdeliveredtoourServiceDepartmentat33-35Lionel
Road,MtWaverley,Victoria,3149ortooneofour
Authorised Service Agents.
Ifawarrantyfaultisfoundthefreightcostwillbecredited
to the owner.
Ifnofaultisfoundtheproductwillbereturnedandany
costs associated with the service will be charged to
the owner.
Productssentfreightforwardwillnotbeaccepted.In
most cases the defective accessory or component only
will need to be returned. The product or part of the
product being returned must be adequately protected in
a box.
S.G.A.willnotberesponsibleforanyin-transitlossor
damage.
This warranty does not apply to any defect, deterioration,
loss, injury or damage occasioned by or as a result of
misuse or abuse, negligent handling or storage, normal
wear and tear or if the product has not been installed
andusedinaccordancewithS.G.A.’sinstructions,
recommendationsandspecicationsoriftheproduct
has been subjected to abnormal conditions. The warranty
does not apply to blockages caused by insects or living
organisms.
This warranty does not cover use in a commercial
premises or for hire.
The warranty is void if there is evidence of the product
being tampered with by unauthorised persons.
The warranty does not extend to installation or
disconnection costs.
Our goods come with guarantees that cannot be
excludedundertheAustralianConsumerLaw.Youare
entitled to a replacement or refund for a major failure and
for compensation for any other reasonably foreseeable
lossordamage.Youarealsoentitledtohavethegoods
repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major failure.
Thebenetsofthiswarrantyareinadditiontoanyrights
and remedies imposed by Australian State and Federal
legislation that cannot be excluded.
For warranty claims, service, spare parts or products
informationinAustralia,pleasecallSITROGROUP
AUSTRALIAPtyLtdontheCustomerServiceLine
1300 174 876.
Register your Warranty online at
www.gasmate.com.au
A receipt or proof of purchase is required and must be
keptforyourrecords.Note:Ifyoudonothaveinternet
access call our customer service team on 1300 174 876
CONTACT DETAILS
Sitro Group Australia Pty Ltd
33-35LionelRoad,Mt.Waverley
Victoria3149,Australia.
Tel [phone]
Fax [phone]
[email protected]

For any queries or assistance call
Customer Service
(Australia Only)
1300 174 876
Hours of operation:
Monday to Friday 8am - 5pm EST
Do not return to place of purchase.
Keep your purchase receipt, this will be required to
make any claims under the 12 month warranty.
