Gate Bure XL User manual

A DIRECT HEALTHCARE GROUP COMPANY
GATERD.SE
Bure XL
Technical Manual

BURE XL
GATERD.SE2

TECHNICAL MANUAL
3
GATERD.SE
Contents
1. Parts list 04
2. Spare parts 06
3. Accessories 06
4. Other instructions 07
5. General maintenance advice 07
6. Safety instructions 08
7. ID label 08
8. Recycling/Scrapping 08
9. Warranty 08
10. Technical specications 09
Bure XL
Bure XL was designed for the bigger, heavier patient and therefore provides extra space and strength.
Because extra powerful aids are required in the care and nursing of heavier patients, Bure XL is always
supplied with electric drives.

BURE XL
GATERD.SE4
1. Parts list
1A
B
C
Armrest
Knob
Plastic washer
6M
N
O
P
Q
R
End bushing/plastic
Wheel
Bolt
Washer
Nut
Washer
2D
E
F
Handle and grip
Clamp
Knob
7Protective plate (left/right)
3Upper frame 8S
T
U
V
Remote control
Holder/remote control
Battery
Control box
4G
H
I
J
Chromium-plated tube
Attachment bolt
Washer
End bushing
9X
Y
Actuator (raise/lower)
Bolt, washer (2 pcs),
nut (attachment at bottom and
top)
5K
L
Frame with battery shelf
Guide sleeve

TECHNICAL MANUAL
5
GATERD.SE

BURE XL
GATERD.SE6
2. Spare parts
No. Part no. Description
- 56-305 Touch-up paint Bure, Silver 8
- 56-306 Touch-up paint Bure, Dark grey RAL 7021
1A 57-327 Armrest right
1A 57-328 Armrest left
T 56-328 Holder, hand controller
L 56-340 Guide sleeve
J 56-343 End piece, guide tube
U 56-346-1 Battery/LA31
U 56-346 Battery incl. circuit board/LA28
X 57-004-02 Actuator (raise/lower)/LA31
X 57-004-01 Actuator (raise/lower)/LA28
2 56-353 Handle kit, Bure Std (2 pairs incl. lock knob/clamps)
- 56-357 Wheel without brake 100 mm
- 56-358 Wheel with brake 100 mm
N 56-360 Wheel without brake 125 mm
- 56-361 Wheel with brake 125 mm
- 56-387 Wheel with brake 75 mm
E 56-356 Locking clamp, handle
F 56-363 Knob for adjusting handle
B 56-364 Knob for adj. width of armrest plates
S 56-370-1 Hand control 2channel (raise/lower)/LA31
S 56-370 Hand control 2channel (raise/lower)/LA28
- 56-374-1 Power cable/LA31
56-374 Charger/LA28
V 56-345-1 Control box 220 V
3. Accessories
Part no. Description
56-334 Drip holder
56-335 Attachment for drip holder
56-336 Oxygen holder
56-337 Side support, adjustable
56-338 Drip rod complete with attachment
56-386 Footplate, Bure XL (plate)
56-389 Soft basket with attachment

TECHNICAL MANUAL
7
GATERD.SE
4. Other instructions
Control box wiring
1. Battery terminal socket.
2. Plug socket.
(NOTE: Plugs must ALWAYS be connected to the control box for IP classication to be valid.)
3. Remote control socket.
4. Socket for the raise/lower actuator.
NOTE: Make sure that plugs are connected to the correct sockets otherwise the actuators may be damaged.
Battery charging
Battery charging must take place when the walker is not in use (the battery can never be overcharged).
Charging is carried out by inserting the plug in a wall socket.
The battery should be charged at least 24 hours before rst use.
5. General maintenance advice
• Wipe the walker and its armrests clean as necessary; use soap solution.
• The product must ALWAYS feel stable. If the walker is lopsided, squeaks or makes suspicious noises alert
personnel.
• Replace damaged parts immediately; must be done by experienced personnel.
• Walkers with electric actuators – NEVER use the walker while charging.
• Make sure the guide tube (4G) is securely tightened in the upper frame (3).
1
2
3
4

BURE XL
GATERD.SE8
6. Safety instructions
The Bure Walker may only be used:
• As a WALKING AID, indoors
• On HARD, LEVEL surfaces
MAX USER WEIGHT: 240 KG
7. ID label
1. Part number
2. Product name
3. Date of manufacture
4. Max user weight
5. Serial number
6. EAN code
8. Recycling/Scrapping
When the product is no longer usable it should be recycled in accordance with legislation and regulations in
the country concerned. All electrical parts including batteries must be removed and recycled as electrical
components. (Ask your local recycling station for further information about how the different
materials in the product (metals, plastics, electronics) should be recycled).
9. Warranty
We provide two years warranty against manufacturing faults (does not apply to wear parts). For further
information or enquiries please contact:
Gate Rehab Development AB
Industrigatan 2, S-330 21 Reftele
tel [phone]
[email protected]
1
2
3
4
6
5
A DIRECT HEALTHCARE GROUP COMPANY

TECHNICAL MANUAL
9
GATERD.SE
10. Technical specications
“LIFT” denotes suitable handhold for lifting the walker
NOTE: At least two people are required for lifting.
Product weight: 29 kg
Max user weight: 240 kg

BURE XL
GATERD.SE10

TECHNICAL MANUAL
11
GATERD.SE

GATERD.SE
Gate Rehab Development AB
Industrigatan 2
Reftele, Sverige
S-330 21
T: 0371-318 00
F: 0371-318 01
E: [email protected]
LIT-00110 Issue 1
Date: January 2020
